National Instruments NI 9467 User manual

NI-9467 Getting
Started
2022-07-11

Contents
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Guidelines for Hazardous Locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Electromagnetic Compatibility Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Special Conditions for Marine Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
NI 9467 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Start-Up Behavior. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Status LED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting the NI 9467. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing the Antenna. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Maximum Cable Length. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Sleep Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
NI-9467 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
General Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
GPS Antenna Connector Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Physical Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Environmental. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Shock and Vibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Safety and Hazardous Locations Standards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Electromagnetic Compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
CE Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Product Certifications and Declarations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Environmental Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
电子信息产品污染控制管理办法（中国 RoHS）. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
NI Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
ni.com
2
NI-9467 Getting Started

Before You Begin
Read the NI-9467 Safety, Environmental, and Regulatory Information and
complete the soware and hardware installation procedures in your chassis
documentation.
Safety Guidelines
Caution Observe all instructions and cautions in the user documentation.
Using the product in a manner not specified can damage the product and
compromise the built-in safety protection.
Attention Suivez toutes les instructions et respectez toutes les mises
en garde de la documentation d'utilisation. L'utilisation du produit de
toute autre façon que celle spécifiée risque de l'endommager et de
compromettre la protection de sécurité intégrée.
Safety Guidelines for Hazardous Locations
The NI-9467 is suitable for use in hazardous locations; , and hazardous locations;
and nonhazardous locations only. Follow these guidelines if you are installing the
NI-9467 in a potentially explosive environment. Not following these guidelines may
result in serious injury or death.
Caution Do not disconnect I/O-side wires or connectors unless power has
been switched o or the area is known to be nonhazardous.
Caution Do not remove modules unless power has been switched o or
the area is known to be nonhazardous.
© National Instruments 3
NI-9467 Getting Started

Caution Substitution of components may impair suitability for Class I,
Division 2, or Zone 2.
Caution The system must be installed in an enclosure certified for the
intended hazardous (classified) location, having a tool secured cover/door,
where a minimum protection of at least IP54 is provided.
Special Conditions for Hazardous Locations Use in Europe and
Internationally
The NI-9467 has been evaluated as equipment under DEMKO ATEX and is IECEx
certified. Each NI-9467 is marked and is suitable for use in Zone 2 hazardous
locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI-9467
in Gas Group IIC hazardous locations, you must use the device in an NI chassis that
has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.
Caution Transient protection shall be provided that is set at a level not
exceeding 140% of the peak rated voltage value of 85 V at the supply
terminals to the equipment.
Caution The system shall only be used in an area of not more than
Pollution Degree 2, as defined in IEC/EN 60664-1.
Caution The system shall be mounted in an ATEX/IECEx-certified
enclosure with a minimum ingress protection rating of at least IP54 as
defined in IEC/EN 60079-15.
Caution The enclosure must have a door or cover accessible only by the
use of a tool.
ni.com
4
NI-9467 Getting Started

Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory requirements and limits
for electromagnetic compatibility (EMC) stated in the product specifications. These
requirements and limits provide reasonable protection against harmful interference
when the product is operated in the intended operational electromagnetic
environment.
This product is intended for use in industrial locations. However, harmful
interference may occur in some installations, when the product is connected to a
peripheral device or test object, or if the product is used in residential or
commercial areas. To minimize interference with radio and television reception and
prevent unacceptable performance degradation, install and use this product in strict
accordance with the instructions in the product documentation.
Furthermore, any changes or modifications to the product not expressly approved
by National Instruments could void your authority to operate it under your local
regulatory rules.
Caution To ensure the specified EMC performance, operate this product
only with shielded cables and accessories.
Special Conditions for Marine Applications
Some products are approved for marine (shipboard) applications. To verify marine
approval certification for a product, visit ni.com/product-certifications, search by
model number, and click the appropriate link.
Notice In order to meet the EMC requirements for marine applications,
install the product in a shielded enclosure with shielded and/or filtered
power and input/output ports. In addition, take precautions when
designing, selecting, and installing measurement probes and cables to
ensure that the desired EMC performance is attained.
© National Instruments 5
NI-9467 Getting Started

NI 9467 Overview
The NI-9467 is a stationary GPS timing module for C Series platforms. It provides
accurate timing and geographic location information to the C Series host, which
enables synchronization of C Series systems.
Start-Up Behavior
At start-up, the NI-9467 automatically begins determining its location through a
process known as self-survey. During the self-survey, the module computes a
location fix every second and averages the locations at the end to obtain a more
accurate location. Aer the self-survey, the NI 9467 no longer computes new
location fixes; it uses its known location and satellite signals to generate accurate
timing signals.
Like all GPS receivers, the NI-9467 requires GPS satellite ephemeris and almanac
data to compute accurate time and location. The ephemeris is detailed orbital
information about each satellite (where each satellite is expected to be at a given
time). The almanac data describes the general health of each satellite (for example,
the receiver must not use signals from satellites marked as unhealthy) and contains
coarse orbit information. The GPS satellites broadcast the ephemeris and almanac
data every 30 seconds. Therefore, it usually takes approximately 30 seconds for it to
receive the ephemeris and almanac data and start computing location and timing
fixes.
Status LED
The NI-9467 has a front panel LED to indicate status. The following table describes
the meaning of each LED pattern.
Conditions LED State
Normal operation Solid green
Performing survey Blinking green
Not enough or no satellites Blinking yellow
Antenna error (no antenna or over-current) Solid yellow
Unconfigured O
ni.com
6
NI-9467 Getting Started

Note Although the module may not detect the presence of very low-
power GPS antennas, it can still function correctly. Note that the LED and
soware may report antenna error under these conditions, and if the
current consumed is close to the detection threshold the LED may flicker.
Refer to the Specifications section for more details.
Connecting the NI 9467
The NI-9467 has one SMA female connector on its front panel for a GPS active
antenna. The connector provides a DC voltage to power the antenna and also serves
as input for the GPS RF signal.
Installing the Antenna
Caution National Instruments recommends using a lightning arrester in
line with the GPS antenna installation to protect the NI-9467 and the C
Series system from possible damage and operators from injury in the
event of lightning.
The embedded GPS receiver in the NI-9467 requires signals from several satellites to
compute accurate timing and location. The more satellites available to the receiver,
the more accurately it can determine time and location. Therefore, the antenna
location should be such that it receives signals from the greatest number of
satellites possible. As the number of satellites visible to the antenna decreases, the
synchronization performance may also decrease. Choose the antenna location so
that the antenna has a clear view of the sky. There is no strict definition for a clear
view of the sky, but a suitable guideline is that the GPS antenna should have a
straight line of sight to the sky in all directions (360°) down to an imaginary line
making a 30° angle with the ground. Locations far from trees and tall buildings that
could block or reflect GPS satellite signals are best.
Maximum Cable Length
Maximum cable length depends on the GPS antenna gain and the cable’s loss per
unit of distance. National Instruments recommends a GPS signal strength of
© National Instruments 7
NI-9467 Getting Started

between -135 dBm and -120 dBm at the NI-9467 SMA input. GPS signal strength on
the Earth’s surface is typically -130 dBm. Targeting a signal strength of -125 dBm at
the SMA input, you can compute the maximum cable length as:
■Max_cable_loss = -130 dBm + antenna_gain - (-125 dBm)
■Max_cable_length = Max_cable_loss / (loss_per_unit_of_distance)
For example, if you use an active antenna with gain of 28 dB and RG-58 cable, which
has a rated loss at 1.5 GHz of about 0.8 dB/m (24.5 dB/100 ), the maximum cable
length you could use is:
■Max_cable_loss = -130 dBm + 28 dB - (-125 dBm) = 23 dB
■Max_cable_length = 23 dB / (0.8 dB/m) ≈ 29 m
Sleep Mode
This module supports a low-power sleep mode. Support for sleep mode at the
system level depends on the chassis the module is plugged into. Refer to the chassis
manual for information about support for sleep mode. If the chassis supports sleep
mode, refer to the soware help for information about enabling sleep mode. Visit
ni.com/info and enter cseriesdoc for information about C Series documentation.
Typically, when a system is in sleep mode, you cannot communicate with the
modules. In sleep mode, the system consumes minimal power and may dissipate
less heat than it does in normal mode. Refer to the Specifications section for more
information about power consumption and thermal dissipation.
Notice that when the NI-9467 is in sleep mode, the GPS receiver is not powered and
stops tracking satellites. When the module exits sleep mode and power to the GPS
receiver is restored, the module goes through the normal power-up process, which
includes the ephemeris/almanac data acquisition and self-survey process.
Therefore, it can take approximately 30 seconds before usable timing and location
signaling can be generated. Refer to Start-Up Behavior for more information.
NI-9467 Specifications
The following specifications are typical for the range -40 °C to 70 °C unless otherwise
noted.
ni.com
8
NI-9467 Getting Started

General Characteristics
Signal type L1 frequency; GPS C/A code
Datum WGS-84
RF GPS signal frequency 1575.42 MHz
Recommended signal strength at SMA[1] -135 dBm to -120 dBm
Max RF power at input 3 dBm
Input impedance 50 Ω, nominal
MTBF 2,234,702 h at 25 °C; Bellcore Issue 2, Method 1, Case 3,
Limited Part Stress Method
PPS accuracy[2] ±100 ns, > 99% typical
1 Higher signal strength might saturate the receiver and degrade performance.
2 For the best timing accuracy performance, ensure that the GPS antenna has a clear
view of the sky. Refer to the Antenna Installation section for more details.
GPS Antenna Connector Characteristics
GPS antenna connector type SMA female
DC voltage output for active antenna +5 V ± 10%
Max. current output 30 mA
Minimum current for antenna presence detection 6 mA typical, 9.5 mA max
Over-voltage protection ± 30 VDC
Power Requirements
Power consumption from chassis
Active mode 150 mA maximum
© National Instruments 9
NI-9467 Getting Started

Sleep mode 1 mA
Thermal dissipation (at 70 °C)
Active mode 550 mW maximum
Sleep mode 5 mW
Physical Characteristics
Dimensions Visit ni.com/dimensions and search by module number.
Weight 141 g (4.5 oz)
Environmental
Refer to the manual for the chassis you are using for more information about
meeting these specifications.
Operating temperature (IEC 60068-2-1, IEC 60068-2-2) -40 °C to 70 °C
Storage temperature (IEC 60068-2-1, IEC 60068-2-2) -40 °C to 85 °C
Ingress protection IP40
Operating humidity (IEC 60068-2-30) 10% RH to 90% RH, noncondensing
Storage humidity (IEC 60068-2-30) 5% RH to 95% RH, noncondensing
Pollution Degree 2
Maximum altitude 5,000 m
Indoor use only.
Shock and Vibration
To meet these specifications, you must panel mount the system.
Operating vibration
Random 5 g RMS, 10 Hz to 500 Hz
ni.com
10
NI-9467 Getting Started

Sinusoidal 5 g, 10 Hz to 500 Hz
Operating shock 30 g, 11 ms half sine; 50 g, 3 ms half sine; 18 shocks at 6 orientations
Safety and Hazardous Locations Standards
Note The NI-9467 module does not provide electrical isolation.
This product is designed to meet the requirements of the following electrical
equipment safety standards for measurement, control, and laboratory use:
■IEC 61010-1, EN 61010-1
■UL 61010-1, CSA C22.2 No. 61010-1
■EN 60079-0:2012, EN 60079-15:2010
■IEC 60079-0: Ed 6, IEC 60079-15; Ed 4
■UL 60079-0; Ed 5, UL 60079-15; Ed 3
■CSA 60079-0:2011, CSA 60079-15:2012
Note For safety certifications, refer to the product label or the Product
Certifications and Declarations section.
Hazardous Locations
U.S. (UL) ; ,
Canada (C-UL) ; ,
Europe (DEMKO)
Electromagnetic Compatibility
CE Compliance
© National Instruments 11
NI-9467 Getting Started

■2014/34/EU; Potentially Explosive Atmospheres (ATEX)
Product Certifications and Declarations
Refer to the product Declaration of Conformity (DoC) for additional regulatory
compliance information. To obtain product certifications and the DoC for NI
products, visit ni.com/product-certifications, search by model number, and click the
appropriate link.
Environmental Management
NI is committed to designing and manufacturing products in an environmentally
responsible manner. NI recognizes that eliminating certain hazardous substances
from our products is beneficial to the environment and to NI customers.
For additional environmental information, refer to the Engineering a Healthy
Planet web page at ni.com/environment. This page contains the environmental
regulations and directives with which NI complies, as well as other environmental
information not included in this document.
EU and UK Customers
• Waste Electrical and Electronic Equipment (WEEE)—At the end of the product life
cycle, all NI products must be disposed of according to local laws and regulations.
For more information about how to recycle NI products in your region, visit ni.com/
environment/weee.
电子信息产品污染控制管理办法（中国 RoHS）
•
540
e
中国 RoHS— NI 符合中国电子信息产品中限制使用某些有害物质指令
(RoHS)。关于 NI 中国 RoHS 合规性信息，请登录 ni.com/environment/
rohs_china。(For information about China RoHS compliance, go to ni.com/
environment/rohs_china.)
ni.com
12
NI-9467 Getting Started

NI Services
Visit ni.com/support to find support resources including documentation,
downloads, and troubleshooting and application development self-help such as
tutorials and examples.
Visit ni.com/services to learn about NI service oerings such as calibration options,
repair, and replacement.
Visit ni.com/register to register your NI product. Product registration facilitates
technical support and ensures that you receive important information updates from
NI.
NI corporate headquarters is located at 11500 N Mopac Expwy, Austin, TX,
78759-3504, USA.
© National Instruments 13
NI-9467 Getting Started
© 2022 National Instruments Corporation.
