GETTING STARTED GUIDE
NI 9344
4 Switch Input/4 LED Output

This document explains how to connect to the NI 9344.
Note Before you begin, complete the software and
hardware installation procedures in your chassis
documentation.
Note The guidelines in this document are specific to
the NI 9344. The other components in the system might
not meet the same safety ratings. Refer to the
documentation for each component in the system to
determine the safety and EMC ratings for the entire
system.
Safety Guidelines
Operate the NI 9344 only as described in this document.
Caution Do not operate the NI 9344 in a manner not
specified in this document. Product misuse can result in
a hazard. You can compromise the safety protection
built into the product if the product is damaged in any
way. If the product is damaged, return it to NI for
repair.
2| ni.com | NI 9344 Getting Started Guide

Safety Guidelines for Hazardous Locations
The NI 9344 is suitable for use in Class I, Division 2, Groups A,
B, C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4
and Ex nA IIC T4 hazardous locations; and nonhazardous
locations only. Follow these guidelines if you are installing the
NI 9344 in a potentially explosive environment. Not following
these guidelines may result in serious injury or death.
Caution Do not toggle switches unless power has
been switched off or the area is known to be
nonhazardous.
Caution Do not remove modules unless power has
been switched off or the area is known to be
nonhazardous.
Caution Substitution of components may impair
suitability for Class I, Division 2.
Caution For Division 2 and Zone 2 applications,
install the system in an enclosure rated to at least IP54
as defined by IEC/EN 60079-15.
NI 9344 Getting Started Guide | © National Instruments | 3

Special Conditions for Hazardous Locations Use in
Europe and Internationally
The NI 9344 has been evaluated as Ex nA IIC T4 Gc equipment
under DEMKO Certificate No. 12 ATEX 1202658X and is
IECEx UL 14.0089X certified. Each NI 9344 is marked II 3G
and is suitable for use in Zone 2 hazardous locations, in ambient
temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI 9344
in Gas Group IIC hazardous locations, you must use the device in
an NI chassis that has been evaluated as Ex nC IIC T4, Ex IIC
T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.
Caution The system shall only be used in an area of
not more than Pollution Degree 2, as defined in
IEC 60664-1.
Caution The system shall be mounted in an
ATEX/IECEx-certified enclosure with a minimum
ingress protection rating of at least IP54 as defined in
IEC/EN 60079-15.
Caution The enclosure must have a door or cover
accessible only by the use of a tool.
4| ni.com | NI 9344 Getting Started Guide

Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory
requirements and limits for electromagnetic compatibility (EMC)
stated in the product specifications. These requirements and
limits provide reasonable protection against harmful interference
when the product is operated in the intended operational
electromagnetic environment.
This product is intended for use in industrial locations. However,
harmful interference may occur in some installations, when the
product is connected to a peripheral device or test object, or if the
product is used in residential or commercial areas. To minimize
interference with radio and television reception and prevent
unacceptable performance degradation, install and use this
product in strict accordance with the instructions in the product
documentation.
Furthermore, any changes or modifications to the product not
expressly approved by National Instruments could void your
authority to operate it under your local regulatory rules.
NI 9344 Getting Started Guide | © National Instruments | 5

Special Conditions for Marine Applications
Some products are Lloyd’s Register (LR) Type Approved for
marine (shipboard) applications. To verify Lloyd’s Register
certification for a product, visit ni.com/certification and search
for the LR certificate, or look for the Lloyd’s Register mark on
the product.
Caution In order to meet the EMC requirements for
marine applications, install the product in a shielded
enclosure with shielded and/or filtered power and
input/output ports. In addition, take precautions when
designing, selecting, and installing measurement probes
and cables to ensure that the desired EMC performance
is attained.
6| ni.com | NI 9344 Getting Started Guide

Preparing the Environment
Ensure that the environment in which you are using the NI 9344
meets the following specifications.
Operating temperature
(IEC 60068-2-1, IEC 60068-2-2)
-40 °C to 70 °C
Operating humidity
(IEC 60068-2-78)
10% RH to 90% RH,
noncondensing
Pollution Degree 2
Maximum altitude 5,000 m
Indoor use only.
Note Refer to the Environmental section for complete
specifications.
NI 9344 Getting Started Guide | © National Instruments | 7

NI 9344 Front Panel
User Switch 3
User Switch 2
User Switch 0
User Switch 1
User LEDs
8| ni.com | NI 9344 Getting Started Guide

Table 1. Front Panel Descriptions
Front Panel Description
User LEDs User-programmable LEDs
User Switch User-programmable switch
NI 9344 LEDs
12 3 4
1. User LED0
2. User LED1
3. User LED2
4. User LED3
NI 9344 Getting Started Guide | © National Instruments | 9

Table 2. LED Indicators
LED Pattern Indication
Solid The channel has been programmed to be in the ON state.
Off The channel has been programmed to be in the OFF
state.
10 | ni.com | NI 9344 Getting Started Guide

NI 9344 Input/Output Circuitry
NI 9344
DO
User
LED
Vint
DI
User
Switch
Vint
Out
In
User Software
• You can program the user LEDs as indicators for your
software application.
• You can program the LEDs and the switches independently.
NI 9344 Getting Started Guide | © National Instruments | 11

NI 9344 Specifications
The following specifications are typical for the range -40 °C to
70 °C unless otherwise noted.
General Characteristics
Number of channels
Digital input 4 channels, switches
Digital output 4 channels, LEDs
Switch life expectancy 50,000 operations
Power Requirements
Power consumption from chassis
Active mode 145 mW maximum
Sleep mode 25 μW maximum
Thermal dissipation (at 70 °C)
Active mode 145 mW maximum
Sleep mode 25 μW maximum
12 | ni.com | NI 9344 Getting Started Guide

Physical Characteristics
If you need to clean the module, wipe it with a dry towel.
Tip For two-dimensional drawings and three-
dimensional models of the C Series module and
connectors, visit ni.com/dimensions and search by
module number.
Weight 150 g (5.3 oz)
Safety Voltages
Isolation
Channel-to-channel None
Channel-to-earth
ground
None
NI 9344 Getting Started Guide | © National Instruments | 13

Hazardous Locations
U.S. (UL) Class I, Division 2, Groups A,
B, C, D, T4; Class I, Zone 2,
AEx nA IIC T4
Canada (C-UL) Class I, Division 2, Groups A,
B, C, D, T4; Class I, Zone 2, Ex
nA IIC T4
Europe (ATEX) and
International (IECEx)
Ex nA IIC T4 Gc
Safety and Hazardous Locations Standards
This product is designed to meet the requirements of the
following electrical equipment safety standards for measurement,
control, and laboratory use:
• IEC 61010-1, EN 61010-1
• UL 61010-1, CSA 61010-1
• EN 60079-0:2012, EN 60079-15:2010
• IEC 60079-0: Ed 6, IEC 60079-15; Ed 4
• UL 60079-0; Ed 5, UL 60079-15; Ed 3
• CSA 60079-0:2011, CSA 60079-15:2012
14 | ni.com | NI 9344 Getting Started Guide

Note For UL and other safety certifications, refer to
the product label or the Online Product Certification
section.
Electromagnetic Compatibility
This product meets the requirements of the following EMC
standards for electrical equipment for measurement, control, and
laboratory use:
• EN 61326-1 (IEC 61326-1): Class A emissions; Industrial
immunity
• EN 55011 (CISPR 11): Group 1, Class A emissions
• EN 55022 (CISPR 22): Class A emissions
• EN 55024 (CISPR 24): Immunity
• AS/NZS CISPR 11: Group 1, Class A emissions
• AS/NZS CISPR 22: Class A emissions
• FCC 47 CFR Part 15B: Class A emissions
• ICES-001: Class A emissions
Note In the United States (per FCC 47 CFR), Class A
equipment is intended for use in commercial, light-
industrial, and heavy-industrial locations. In Europe,
Canada, Australia and New Zealand (per CISPR 11)
NI 9344 Getting Started Guide | © National Instruments | 15

Class A equipment is intended for use only in heavy-
industrial locations.
Note Group 1 equipment (per CISPR 11) is any
industrial, scientific, or medical equipment that does
not intentionally generate radio frequency energy for
the treatment of material or inspection/analysis
purposes.
Note For EMC declarations and certifications, and
additional information, refer to the Online Product
Certification section.
CE Compliance
This product meets the essential requirements of applicable
European Directives, as follows:
• 2014/35/EU; Low-Voltage Directive (safety)
• 2014/30/EU; Electromagnetic Compatibility Directive
(EMC)
• 94/9/EC; Potentially Explosive Atmospheres (ATEX)
16 | ni.com | NI 9344 Getting Started Guide

Online Product Certification
Refer to the product Declaration of Conformity (DoC) for
additional regulatory compliance information. To obtain product
certifications and the DoC for this product, visit ni.com/
certification, search by model number or product line, and click
the appropriate link in the Certification column.
Shock and Vibration
To meet these specifications, you must panel mount the system.
Operating vibration
Random (IEC
60068-2-64)
5 grms, 10 Hz to 500 Hz
Sinusoidal (IEC
60068-2-6)
5 g, 10 Hz to 500 Hz
Operating shock (IEC
60068-2-27)
30 g, 11 ms half sine; 50 g, 3 ms
half sine; 18 shocks at
6 orientations
NI 9344 Getting Started Guide | © National Instruments | 17

Environmental
Refer to the manual for the chassis you are using for more
information about meeting these specifications.
Operating temperature
(IEC 60068-2-1, IEC 60068-2-2)
-40 °C to 70 °C
Storage temperature
(IEC 60068-2-1, IEC 60068-2-2)
-40 °C to 85 °C
Ingress protection IP40
Operating humidity
(IEC 60068-2-78)
10% RH to 90% RH,
noncondensing
Storage humidity
(IEC 60068-2-78)
5% RH to 95% RH,
noncondensing
Pollution Degree 2
Maximum altitude 5,000 m
Indoor use only.
18 | ni.com | NI 9344 Getting Started Guide

Environmental Management
NI is committed to designing and manufacturing products in an
environmentally responsible manner. NI recognizes that
eliminating certain hazardous substances from our products is
beneficial to the environment and to NI customers.
For additional environmental information, refer to the Minimize
Our Environmental Impact web page at ni.com/environment. This
page contains the environmental regulations and directives with
which NI complies, as well as other environmental information
not included in this document.
Waste Electrical and Electronic Equipment
(WEEE)
EU Customers At the end of the product life cycle, all
NI products must be disposed of according to local
laws and regulations. For more information about how
to recycle NI products in your region, visit ni.com/
environment/weee.
NI 9344 Getting Started Guide | © National Instruments | 19

电子信息产品污染控制管理办法（中国 RoHS）
中国客户 National Instruments 符合中国电子信息产
品中限制使用某些有害物质指令(RoHS)。关于
National Instruments 中国 RoHS 合规性信息，请登
录 ni.com/environment/rohs_china。(For
information about China RoHS compliance, go to
ni.com/environment/rohs_china.)
Worldwide Support and Services
The NI website is your complete resource for technical support.
At ni.com/support, you have access to everything from
troubleshooting and application development self-help resources
to email and phone assistance from NI Application Engineers.
Visit ni.com/services for NI Factory Installation Services, repairs,
extended warranty, and other services.
Visit ni.com/register to register your NI product. Product
registration facilitates technical support and ensures that you
receive important information updates from NI.
20 | ni.com | NI 9344 Getting Started Guide
