National Public Seating Cluster Swivel User manual

Cluster Swivel
Booth Seat
Instructions
Accessory Tool
Hardware List
Parts List
ⒸConnecting frame x 2 ⒹConnecting plate x 2
Ⓑ-1.Seat x 4
ⒺSeat frame x 2
ⒻSwivel control-L x 2
ⒼSwivel control-R x 2
Ⓑ-2.Seat base x 4
ⒽHex key ⒾPhillips wrench
ⒿOpen end
wrench
ⒶTable frame x 1
M6 x 10 screw
Nut sheet
M8 x 55 bolt
Washer
M8 x 16 bolt
x4
x16
x16
x2
x4
❶
❷
❸
❹
❺
Nut
x26
❼
❼
2
3
Align the holes on the flat side of two connecting frames Ⓒ with the holes on the
table frame Ⓐ. Insert four M8 x 16 bolts❶ and tighten with four nuts ❼using
enclosed hex key Ⓗ and open end wrenchⒿ.
*Donʼt fully tighten the bolts until you make sure that the main structure is level
with the ground at step 4.
❶
Ⓒ Ⓒ
ⒽⒿ
1Install table frame Ⓐ to tabletop as follows: Begin by aligning the six frame holes
over pilot holes on underside of tabletop. Using the six 25mm pan-head screws
❽, tightly fasten screws to tabletop.
Ⓐ
Align the holes on two connecting plates Ⓓ with the holes on two sides of connect-
ing frames Ⓒ. Insert two M8 x 55 bolts ❹ through four washers ❺ and tighten
with two nuts ❼ using enclosed hex key Ⓗ and open end wrench Ⓙ.
*Donʼt fully tighten the bolts until you make sure that the main structure is level
with the ground at step 4.
Ⓓ Ⓓ
Ⓒ
Ⓗ Ⓙ❹ ❼❺ ❺
Ⓒ
M8 x 45 bolt
x20
❻
Fastening plate
x4
Screw x4
❾
Floor connection
optional parts
Expansion bolt
x4
❿
⓫
www.nationalpublicseating.com
25mm Pan-
head screw
x6
❽

Place seat Ⓑ-1downward on a flat
and clean surface. Put four nuts
sheet ❸ into the groove at bottom
of seat. Note that the arrow on seat
base Ⓑ-2 should point foward.
After aligning the holes, insert four
M6 x 10 screws ❷ and tighten them
using enclosed Phillips wrench Ⓘ.
6
7
4
5
Fasten seat frame Ⓔ into the mouth of connecting frame Ⓒ. After aligning holes to
holes on seat frame, insert two M8 x 45 bolts ❻ and tighten with two nuts ❼ using
enclosed hex key Ⓗ.
Ⓒ
Ⓔ
Ⓗ
Ⓙ
❻
❼
Make sure that four legs touch the ground
evenly and then tighten the bolts within Step
1 and 2.
❸
❸
FRONT
Ⓘ
❷
Ⓑ-2
Ⓑ-1
Align the holes on seat bases Ⓑ with
the holes on seat frames Ⓔ. Insert
two M8 x 45 bolts ❻ and tighten
with two nuts ❼ using enclosed hex
key Ⓗ and open end wrench Ⓙ.Ⓑ
Ⓑ
Ⓔ
Ⓔ
Ⓗ
❼
❻
Ⓙ
Turn seat Ⓑ straight ahead.
Place swivel control-L Ⓕ at the
left hand side and swivel
control-R Ⓖ at the right hand
side and align the holes to holes
on seat frame Ⓔ. Insert two M8
x 45 bolts ❻ and tighten with
two nuts ❼ using enclosed hex
key Ⓗ and open end wrench
Ⓙ. Rotate the seats to
make sure all of them turn
outward.
TIGHTEN
level on the ground
Ⓔ
Ⓗ
❼
❻
ⒿLeft Right
Ⓕ
ⒻⒼ
2022.03
Ⓘ
❽
❿
For unit with optional floor connectors- Step 1
Optional Swivel control
Ⓔ
Place seat frame Ⓔ on a flat and clean surface. Align the hole on fastening plate❽ as
the direction shown below with hole at the bottom of seat frame. Insert screw ❿ and
tighten it using enclosed Phillips wrench Ⓘ.
※For optional floor connection
, make sure that fastening plate
should be placed backward.

Recommended items for unit with optional floor connectors.
Optional floor connection-Step 5
Optional floor connection-Step 4
Optional floor connection-Step 2
Optional floor connection-Step 3 Optional floor connection-assembly completed
After placing the
cluster swivel booth
to the position
where you are going
to fix, mark four
holes of fastening
plate ❽ by pencil
Ⓝ on the floor.
Follow below steps for for unit with optional floor connectors.
Drill the marked holes using electric
drill Ⓚ with 3/8 drill bit to a depth of
75mm.。
Align the holes on fastening plate ❽
with the holes on the floor. Knock
expansion bolt ❾ into the hole using
hammer Ⓛ.
Tighten expansion bolt ❾ using wrench
Ⓞ to fix fastening plate ❽ on the floor.
After drilling, clear out the dust
from the holes using dust blowing
ball Ⓜ.
Ⓝ
❽
ⓀⓂ
Ⓛ
❽
❾
Ⓞ
❽
❾
ⓀElectric drill
3/8 drill bit ⓁHammer ⓂDust
blowing ball
ⓃPencil ⓄWrench
