NATURE'S INSTRUMENTS NI-PG-303-01 User manual

1970mm [77 1/2"]
4497mm [177"]
915mm [36"]
915mm [36"]
RECOMMENDED CLEARANCE
ZONE [RCZ]
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZRCZRCZRCZRCZRCZRCZRCZRCZRCZRCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZ
RCZRCZRCZRCZRCZRCZRCZRCZRCZRCZRCZ
PRODUCT NUMBER
PAGE SCALE @ 8.5x11 DRAWN CHECKED PHONE NUMBER:
1-877-733-7456
COPYRIGHT©2018NATURE'SINSTRUMENTS.DONOTSCALEDRAWINGS.NOTFORCOMMERCIALUSEORREPRINTWITHOUTEXPRESSEDWRITTENPERMISSIONFROMNATURE'SINSTRUMENTS.
OF PR LL1:251 1
ART PANEL: POST MOUNTED
NI-PG-303-01 LAYOUT PLAN

ART PANEL: POST MOUNTED
COMPONENTS
PANEL INSTALLATION
NATURE'S INSTRUMENTS NI-PG-303-01 POST MOUNTED ART PANEL. NI PACKAGE INCLUDES:
203mm[8"]ØCONCRETESONOTUBEFOOTINGSARENOTSUPPLIED.
·89 x 89mm [4"x4"] CEDAR POST: x 2
·PRE-ASSEMBLED ART PANEL: x 1
·· PAINTED BOTH SIDES, FRAMED IN CEDAR TRIM
·PRE-ASSEMBLED CEDAR BASE-'T': x 1
·38 x 140mm [2"x6"] CEDAR CAP: x 1
·64mm [2 12"] BROWN DECK SCREWS: x 36
ART
PANEL
1. FASTEN THE POSTS TO EACH SIDE OF THE ART PANEL
USING SUPPLIED SCREWS FASTENED THROUGH PRE-DRILLED
HOLES IN THE PANEL FRAME (FRONT & BACK).
1.a. TOP OF POSTS TO BE FLUSH WITH THE TOP OF THE
FRAME.
2. FASTEN THE BASE-'T' TO THE BOTTOM OF THE PANEL USING
SUPPLIED SCREWS THROUGH PRE-DRILLED HOLES IN THE
PANEL FRAME (FRONT & BACK).
2.a. BASE-'T' TO BE FLUSH WITH FINISHED SURFACE.
3. FASTEN CAP TO THE TOP OF THE PANEL USING SUPPLIED
SCREWS THROUGH PRE-DRILLED HOLES IN THE PANEL
FRAME (FRONT & BACK).
3.a. IF INSTALLED AGAINST A WALL OR FENCE, THE CAP
MUST BE FLUSH WITH THE BACK OF THE PANEL FRAME
WITH 25mm [1"] OVERHANG ON BOTH SIDES.
3.a. IF INSTALLED FOR CIRCULATION ON ALL SIDES, THE CAP
CAN BE CENTERED ON POSTS FRONT TO BACK.
4. FOOTING HOLES TO EXTEND BELOW THE FROST LINE FOR
YOUR REGION; 915 - 1220mm [36"-48"] BELOW FINISHED GRADE.
5. PLACE THE POSTS (ATTACHED TO THE ASSEMBLED PANEL)
INTO PRE-DUG HOLES:
5.a. ENSURE BOTTOM OF BASE-'T' IS FLUSH WITH FINISHED
GRADE OF SURROUNDING SURFACES.
5.b. LEVEL THE PANEL LEFT TO RIGHT.
6. FILL SONOTUBES WITH POST-MIX CONCRETE AS PER
CONCRETE MANUFACTURER'S INSTRUCTIONS.
7. FOOTING TO BE NON-VISIBLE; TOP OF CONCRETE TO REMAIN
AT LEAST 102mm [4"] BELOW FINISHED SURFACE.
8. FINISHED SURFACE AROUND THE PANEL MUST BE LEVEL
FOR THE ENTIRE LENGTH OF THE PANEL.
9. FOLLOW ADJACENT SURFACES DETAILS.
10. RESTORE ADJACENT SURFACING TO PRE-CONSTRUCTION
CONDITION UNLESS OTHERWISE SPECIFIED.
FOOTING SECTION
915 - 1220mm
[36"-48"]
2527mm [99 1/2"] O.C.
2667mm [105"]
1435mm [56 1/2"]
℄ ℄
FINISHED GRADE
0.00m [+0"]
TOP OF FOOTING
-0.102m [-4"]
CAP
FRAME
POST
BOTTOM OF FOOTING:
-1.220m [-48"]
BASE-'T' FLUSH WITH
FINISHED SURFACE
FRONT ELEVATION
PRODUCT NUMBER
PAGE SCALE @ 8.5x11 DRAWN CHECKED PHONE NUMBER:
1-877-733-7456
COPYRIGHT©2018NATURE'SINSTRUMENTS.DONOTSCALEDRAWINGS.NOTFORCOMMERCIALUSEORREPRINTWITHOUTEXPRESSEDWRITTENPERMISSIONFROMNATURE'SINSTRUMENTS.
1 OF 1 1:25 PR LL
ART PANEL: POST MOUNTED
NI-PG-303-01 INSTALL DRAWING
