Nauticam M24D3R140-M28A1R170 User manual

1
M24D3R140-M28A1R170 HDMI 2.0 Cable
1
Cable Clamp
To monitor To camera
2
unscrew the M28 accessory
port cap from monitor housing
unscrew the M24 accessory port cap
from A7C housing and screw the M24
adaptor into the housing port
place the cable clamp as shown
above
slide the camera tray into the
housing along the tray rail then
lock camera tray
plug the cable into the HDMI micro
jack on the camera with camera
tray attached before sliding into the
camera housing
plug the cable into the
accessory port, gently push
the connection head into the
accessory port until it cannot
go further then tighten the
screw
plug the cable into the accessory port,
gently push the connection head into
the accessory port until it cannot go
further then tighten the screw
connection head
M24 accessory
port cap
remove adaptor cap
M24 adaptor for
HDMI 2.0 cable
1
2
3
1
2
3
M24D3R140
M24 - HDMI Connector Type D - 140mm
User Manual
May, 2021
HDMI 2.0 Cable
PN 25098
PACKAGE CONTENTS

2
WARRANTY
All NAUTICAM Housing Products and Viewfinders are
warranted against any material and manufacturing
defects for two years from the date of purchase for
consumer use. NAUTICAM Optical Accessories are
warranted against material and manufacturing defects
for a period of one year, and HDMI & SDI cables carry a
year warranty.
This warranty only applies to products purchased from
authorized NAUTICAM dealers and does not extend
beyond the original retail purchaser.
To return your product for service, please contact your
regional authorized service center(s). Please note
that this warranty only applies when the product is
purchased in the territory where the service center is
located.
Do not place excessive stress on your HDMI
& SDI cable connector.
Do not bend or twist your HDMI & SDI cable.
NAUTICAM accepts no liability for any damage to and
defects of the products caused by improper use and/
or poor maintenance; it is the responsibility of the own-
er to carefully follow the instructions in our manuals.
NAUTICAM does not hold responsibility for damage, of
any nature, to any equipment used with and/or placed
within our products.
NAUTICAM accepts no liability for any loss of captured
images or the inability to capture images even if it is
due to the malfunctioning of our products.
Unauthorized modifications and/or repairs of our
products will automatically invalidate the warranty.
Nauticam Internationl Ltd.
Rm 2203, CCT Telecom Bldg,
11 Wo Shing St,
Fo Tan,
Hong Kong
Tel. +852 - 26902711
Fax. +852 - 26909778
URL. www.nauticam.com
Gallery. www.nauticam.smugmug.com
IMPORTANT INSTRUCTIONS
SPECIFICATIONS
Dimensions
Depth
Outer Diameter
Rating
Total Cable Length
7 mm
150 m
1000 mm
