Nauticam EMWL User manual

Extended Macro Wide Lens
E M W L
Introduction 3
3
4
5
6
Package Contents
Important Instructions
Part Names
Functions
User Manual
Underwater Optics
10
11
EMWL Lens to Lens Mount
EMWL System to Lens Port
12
13
14
15
Specications
Compatibility
Care/Storage
Warranty

3
INTRODUCTION
Thank you for purchasing this Nauticam product.
Before using the product, please read this manual thoroughly to familiarize yourself with full scope of functions on the
product as well as ensuring that you will use the product correctly.
* EMWL Focusing Unit #4 (for Fujilm GF 120mm) and all
individual lenses can be sold seperately
PACKAGE CONTENTS
There are 3 different EMWL set packages :
EMWL Set #1
EMWL Set #3
EMWL Set #2
1 x Focusing Unit #1
(for Nikon FF 105mm & Olympus M4/3 60mm)
1 x Focusing Unit #3
(for Sony FF 90mm & Panasonic LEICA M4/3 60mm & Nikon APS-C 60mm)
1 x Focusing Unit #2
(for Canon FF 100mm & Canon APS-C 60mm)
1 x Relay Lens 150mm
1 x Relay Lens 150mm
1 x Relay Lens 150mm
1 x Objective Lens 60°
1 x Objective Lens 60°
1 x Objective Lens 60°
1 x Objective Lens 100°
1 x Objective Lens 100°
1 x Objective Lens 100°
1 x Objective Lens 130°
1 x Objective Lens 130°
1 x Objective Lens 130°
1 x Nauticam Package Case (with strap)
1 x Nauticam Package Case (with strap)
1 x Nauticam Package Case (with strap)
5 x Lens Protective Case
5 x Lens Protective Case
5 x Lens Protective Case
1 x Filter Sleeve
1 x Filter Sleeve
1 x Filter Sleeve
3 x Cleaning Cloth
3 x Cleaning Cloth
3 x Cleaning Cloth
1 x Nauticam T-shirt
1 x Manual Card
1 x Nauticam T-shirt
1 x Manual Card
1 x Nauticam T-shirt
1 x Manual Card
Make sure that you have all the included items listed below before using this product.
If some items are missing or damaged, contact your local Nauticam dealer.
3 x Cleaning Cloths,
Manual Card
Relay Lens
Focusing Unit
Objective Lenses
Filter Sleeve Case Strap
T-Shirt

4
IMPORTANT INSTRUCTIONS
Water-tight test of the housing (without
camera inside) along with EMWL before
usage is recommended.
Do not point of the lens directly towards
the sun.
Defective products should be shipped to
our distributors for service. Do not attempt
to disassemble and /or modify any part of
the lens.
The housing setup should be positioned
on the a stable and safe surface on land.
This product is not intened for use by children,
or persons with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they are supervised and/
or given instruction by a responsible person
concerning use of the product to ensure that
they can use it safely.
Do not use any kind of abrasive solution to
clean the glass surfaces.
Do not expose the housing in direct
sunlight for a prolonged period.
Do not sealed the housing system when
travelling by air.
1
3
5
7
9
11
4
6
8
10
2
Do not open the housing system in wet or
sandy environment. Protect the housing
and lenses from moisture and debris in
order to prevent malfunction or leakage.
Prevent any sand or dust or water
penetration inside the housing and in
between lenses. Be extra careful when
changing lens and inserting or removing
the camera.
Do not jump in water carrying the housing
setup. Always have the setup handed to
you when you are in water.

5
PART NAMES
The Complete EMWL System
Lens mount release button
Air release ring close
Air release ring
Lens sealing component
* Please do not attempt to disassemble
this part of the lens.
Air release ring open
Lens mount index mark
Objective Lens 60°
Focusing Range
Lens Hood Index Mark
Lens Hood Index Mark
Focusing Unit #1
Objective Lens 100°
Focusing Unit #2
Relay Lens 150mm
Objective Lens 130°
Focusing Unit #3
Focusing Unit #4

6
FUNCTIONS
Objective Lens 60°
∞-55mm
55mm-25mm
We recommand to set the desire focusing range before approaching the subject underwater.
There are 3 focusing ranges that can be set and adjust in water :
25-0mm
* drawings as illustrations only

7
FUNCTIONS
Relay Lens 150mm
The EMWL objective lenses generate an inverted image, making the image appear upside down. The relay lens corrects
the inverted image and relays the image back to the focusing unit and into the camera sensor.
Objective Lens Relay Lens Focusing Unit Macro Lens Camera
Image Plane
With Relay Lens
Setup
82-116mm
82-116mm
(depending on different
objective lens)
(depending on different
objective lens)
(depending on different
focusing unit)
(depending on different
focusing unit)
(depending on different
macro port)
(depending on different
macro port)
105mm
~282-393mm
~177-288mm
54-67mm
54-67mm
41-105mm
41-105mm
Without Relay Lens
Setup
The relay lens is 150mm in
length and only 62mm at its
widest point.
This allows the front of EMWL
to be placed extremely close to
the subject while keeping the
bulk of the camera system and
the photographer at an
extended distance.
It is possible to use the EMWL
without the relay lens if you do
not need the extended working
distance, but you will want a
camera or a monitor that can
correct the inverted image in
EVF or LCD.
* drawings as illustrations only

8
FUNCTIONS
Air Release Ring
Type 1 :
Objective Lens 60°
Type 2 :
Objective Lens 100°
Objective Lens 130°
Relay Lens
The EMWL modular system is designed for exchangability underwater, each module can assemble and disassemble in
water. When entering the water or each time after interchanging lenses, air bubbles might be trapped in between lenses.
The air release ring is to allow water to pass through and therefore releasing the air bubbles.
* Interchanging lenses in sandy bottom and murky water is not recommanded.
* We recommand to open and close the air release ring only when the water is clear.
There are 2 types of air release ring :
* drawings as illustrations only
air release ring in open position
air release ring in open position
air release ring in close position
air release ring in close position

9
FUNCTIONS
Filter Sleeve
To prevent particles being trapped in between lenses in murky water, we suggest to wrap lter sleeve provided over the
air release ring before going into bad water condition. The air release ring on/off position can function as usual after
wrapping.
wrapping lter sleeve over the air release ring
lter sleeve can be peeled off easily by hand
* drawings as illustrations only

10
EMWL LENS TO LENS MOUNT
* drawings as illustrations only
The EMWL uses the Nauticam bayonet mounting system for assembling and disassembling.
To disassemble
To Assemble
1
2

11
EMWL SYSTEM TO LENS PORT
* drawings as illustrations only
To remove
To attach
1
2
Before mounting the EMWL onto the lens port, it is necessory to rst attach a M67 to bayonet converter (#83250).
macro port
M67 to bayonet converter

12
SPECIFICATIONS
Focusing Units
Objective Lenses
Accessories
Focusing Units Relay Lens
#87201 Focusing Unit #1
#87221 Objective Lens 60°
#87205 Focusing Unit #4 #87211 Relay Lens 150mm
#87202 Focusing Unit #2
#87222 Objective Lens 100°
#87203 Focusing Unit #3
#87223 Objective Lens 130°
Optical Design
Optical Design
Optical Design Optical Design
Bayonet
Focus Range
Bayonet Bayonet
Largest Diameter
Largest Diameter Largest Diameter
6 elements in 3 groups
9 elements in 6 groups
6 elements in 3 groups 14 elements in 10 groups
6 elements in 3 groups
9 elements in 6 groups
6 elements in 3 groups
9 elements in 6 groups
Nauticam bayonet mount
15 mm to ꝏ
Nauticam bayonet mount Nauticam bayonet mount
96mm
96mm 62mm
Nauticam bayonet mount
15 mm to ꝏ
96mm
Nauticam bayonet mount
10 mm to ꝏ
96mm
Length 83.4mm 71.4mm 66.9mm
Weight
Depth Rating
In air 740g / In water 480g
150m
In air 627g / In water 400g
150m
In air 616g / In water 410g
150m
Lens Body
Lens Coating
Hard anodized aluminium alloy
Anti-reection
Hard anodized aluminium alloy
Anti-reection
Hard anodized aluminium alloy
Anti-reection
Length Length75.4mm 164.5mm
Weight Weight
Depth Rating Depth Rating
In air 645g / In water 420g In air 592g / In water 320g
150m 150m
Lens Body Lens Body
Lens Coating Lens Coating
Hard anodized aluminium alloy Hard anodized aluminium alloy
Anti-reection Anti-reection
Bayonet
Largest Diameter
Nauticam bayonet mount
62mm
Nauticam bayonet mount
62mm
Nauticam bayonet mount
62mm
Length 97.0mm 88.5mm 123.2mm
Weight
Depth Rating
In air 378g / In water 260g
150m
In air 218g / In water 130g
150m
In air 510g / In water 290g
150m
Lens Body
Lens Coating
Hard anodized aluminium alloy
Anti-reection
Hard anodized aluminium alloy
Anti-reection
Hard anodized aluminium alloy
Anti-reection
# 87501
# 83250
# 87512
# 87513
# 87516
# 87517
EMWL Flip Holder
M67 to Bayonet Converter II
Lens Hood for Objective Lens 130°
Lens Hood for Objective Lens 100°
EMWL Bayonet Holder for Ø70 Float Arm
EMWL Bayonet Holder for Ø90 Float Arm

13
COMPATIBILITY
#87201
Focusing Unit #1
#87202
Focusing Unit #2
#87203
Focusing Unit #3
#87205
Focusing Unit #4
Camera Mount Compatible Lenses Lens PortFocusing Units Camera Sensor
Nikon AF-S VR Micro Nikkor 105mm f/2.8G IF-ED
Canon EF 100mm f/2.8L Macro IS USM
Sony SEL90M28G FE 90mm F2.8 Macro G OSS
Fujilm GF 120mm f/4 Macro R
#18702 N120
Macro Port 87
#18703 N120
Macro Port 94
#37126 N100
Macro Port 105
#21160 Extension
Ring 60 with Lock
#36163 N85
Macro Port 65
#18704 N120
Macro Port 41
#36135 N85
Macro Port 45
#18701 N120
Macro Port 60
#18701 N120
Macro Port 60
M4/3 mount
M4/3 mount M4/3
M4/3
Full Frame
Medium Format
Sony E mount
Fujilm GF mount
Olympus M.Zuiko Digital ED 60mm f2.8 Macro
Canon EF-S 60mm f2.8 Macro USM
Panasonic LEICA DG MACRO-ELMARIT 45mm F2.8
Nikon AF-S Micro NIKKOR 60mm f2.8G ED with
HOYA + 2 Close-up diopter on lens
Nikon F mount
Canon EF mount
Nikon F mount
Canon EF mount
Nikon Z mount with FTZ
APS-C
Full Frame
Full Frame
DX
Canon RF (with EF-EOS R)
Panasonic L mount
(with Sigma MC-21)

14
CARE/STORAGE
Soak the housing system along with the
EMWL in fresh water after salt water
usage
Protect the housing and lenses with
robust and shock-proof travel case
during transportation. Do not travel
with camera inside housing.
Operate all controls and buttons at
least 3 times while immersed in fresh
water
We recommand cleaning and inspecting
the main O-ring each time after diving for
any damage and every time the housing
is opened.
We recommand to ship the housing to our
servic centers for a complete overhual
after 200 dives/every 2 years.
1
3
5
4
2

15
WARRANTY
All NAUTICAM Housing Products and Viewnders are
warranted against any material and manufacturing
defects for two years from the date of purchase for
consumer use. NAUTICAM Optical Accessories are
warranted against material and manufacturing defects
for a period of one year, and HDMI cables carry a year
warranty.
This warranty only applies to products purchased from
authorized NAUTICAM dealers and does not extend be-
yond the original retail purchaser.
To return your product for service, please contact your
regional authorized service center(s). Please note that
this warranty only applies when the product is pur-
chased in the territory where the service center is lo-
cated.
NAUTICAM accepts no liability for any damage to and
defects in the housing caused by improper use and/or
poor maintenance; it is the responsibility of the own-
er to carefully follow the instructions in our manuals.
NAUTICAM does not hold responsibility for damage, of
any nature, to any equipment used with and/or placed
within our products.
NAUTICAM accepts no liability for any loss of captured
images or the inability to capture images even if it is
due to the malfunctioning of our products.
Unauthorized modications and/or repairs of our
products will automatically invalidate the warranty.

Nauticam Internationl Ltd.
Rm 2203, CCT Telecom Bldg,
11 Wo Shing St,
Fo Tan,
Hong Kong
Tel. +852 - 26902711
Fax. +852 - 26909778
URL. www.nauticam.com
Gallery. www.nauticam.smugmug.com
