Naväge SDG-2 User manual

Read carefully for
a great first experience.
Airbornegermsinvadethroughthe
nose,yourbody’sfirstlineofdefense
againstgermsand allergens.Navägeuses
poweredsuction tohelp flushout your
sinusessoyoucanbreathe better, sleep
deeper, snore less, and stay healthier!
Use Naväge Twice-A-Day for two weeks
andexperience whatgoodnasalhygieneand
improvednose-breathingcan doforyou!
Find out for yourself!
Owner’s
Manual

2
Nasal
Dock
Mechanical
Module Fig. 1Fig. 1
1. Fill the Upper Tank to the Fill Line with warm water (Fig. 2).
See page 6 for important information about water.
2. Placeanew SaltPodcapsuleintheCrushingChamber, foil-side
down (Fig. 3). The device will only work with a new, unused
SaltPod capsule in the crushing chamber.
3. Close the Lid firmly until you hear it click shut, and do not
reopen it (Fig.4).No peeking!
4. GentlyshakethedeviceforasecondortwotomixtheSaltPod’s
saline concentratewith thewaterin theUpperTank.
Setting Up Your Nose Cleaner Is Super Easy!
Instructions for Use
All you have to do is attach the Nasal Dock by pressing
it into the Mechanical Module (Fig. 1).
The Nose Cleaner comes completely assembled except for the
Nasal Dock, and thetwo AAbatteries are pre-installed.
Upper Tank
Fill Line
Fig. 2Fig. 2
Press together
1. Powered
suction pulls
salinein one
nostril...
2. around
thebackofthe
nose,and...
3. out the
othernostril...
3
2
1
...toflush out allergens,mucus,
bacteria, andviruses.
Twice-A-Day is the Key!

3
Fig. 3Fig. 3
Fig. 4Fig. 4
5. Run a little water over the Nose Pillows to make them easier
toslip intoyour nostrils.
6. Arrows on the Nasal Dock indicate the direction of flow
(Fig.5).TherinsegoesintoyournosethroughoneNosePillow
andnostril,andcomesoutof yournose throughthe other.
7. Locate the Power Button (see Exploded View on page 8) , and
firmly push the button all the way in. The pump will start
and the DrainValve will open, causingsaline to flowfrom the
UpperTankintoonenostril,aroundthebackofthenose,and
out the other nostril into the LowerTank. The first few times,
do this in front of a mirror and over a sink. Don’t worry, you’ll
beaproinnotime!
8. The 3 P’s guarantee your success with Naväge:
Positioning: Insert the Nose Pillows into your nostrils and
center them.Do not block the pillow tips against the nasal
walls. The pillows should be in snug, but not too snug. The
flexible pillow stems can be bent to obtain a centered,
comfortable fit (Fig. 6). It’s essential to keep the Nose Pillow
tips centeredandunblocked.
Pressure: Press the pillows into your nose firmly enough to
create a seal. Once the cycle starts, back off a little. This will
increase the flow. If you are pressing too hard and one of
the pillow tips gets blocked against the nasal wall, then the
suction will decrease or stop, and you may get water down
your throat, slow flow, or no flow at all. That’swhyyoushould
try backing off a little. Wiggling the nose pillows around in
yournostrils canalsohelp improvethe seal.
No
gaps!
No
gaps!
Fig. 6
Correct Fit
Posture: Relax…Keepyourheadlevel,look forward,standupstraight,and do not bend over
(Fig. 7). Breathenormally throughyour mouth.
Continued Next Page
Fig. 5Fig. 5
Insert new SaltPod,Insert new SaltPod,
foil-side downfoil-side down
Close lid firmly,
do not reopen
Arrow indicating
direction of ow
Correct
Posture
Fig. 7

4
1. Yikes, I’m getting water down my throat!
Thekey to success with Navägeis to make your nasal cavity intoa closed system thatis separatefrom the
oralcavity.That’swhatmakesitpossible fortherinsetogoin onenostril,out theother,andnot down your
throat.It'stheresultofclosing the soft palate. Formostnewusersthishappens naturallywithoutthinking
about it.But notforeveryone. If you runinto trouble,some tipsfollow. Or justgiveour awesome customer
serviceteamacall.TheyaredailyNavägeusersthemselvesandcanbe reachedat(800)203-6400.
• Relax – no one has ever drowned doing nasal irrigation! Seriously,themorerelaxedyouare,theeasieritis.
Nasallavageissafeandeffective,anditispracticedeverydaybytensofmillionsallovertheworldincluding
over3,000,000Navägeusers.Forsomenewusersthere’salearningcurveanditmaytake3or4oreven5tries,but
beassuredthatyou’llmasterit,too.Bestofall,justlikeridingabicycle,onceyou’vegotit,you’vegotitforever!
• The Nose Pillows should be in snug, but not too snug. Press thepillows infirmly tocreate aseal. Oncethe
cyclestarts,back off a little toincreasetheflow.Don’t block the tips against the inside walls of your nose.
Less pressure usuallyresultsinmore flow.
• Reverse the direction of flow. Rotate the Nasal Dock 180 degrees and
the saline will then flow in the opposite direction. This can make a huge
difference, soyoushouldtryirrigatingbothways(Fig.8).
• Breathe normally through your mouth.
• Press your tongue firmly against the roof of your mouth and sing or say
“sung”, holding the“ng”sound.This will help close the soft palate, block off
thethroat,and separatethe nasal cavity fromthe oral cavity!
• Again,ifyou’reinthatsmall groupforwhomthereisa learningcurve,don’t give up! Therearecountless
online reviews like this one:“Absolutely love this. Once you get the hang of it, it works better than
anything I have ever bought! So hang in there, it’s worth it!” Persistencepays.
2. The Power Button won’t push in – Tips for New Users.
For the Power Button to work, a new Naväge SaltPod capsule must be placed in the Crushing Chamber
foil-side down and the Lid clicked shut. The device only works when loaded with a genuine, unused
SaltPod. This is an important safety feature to avoid the stinging and discomfort that can be caused by
running unsalted water through your nose. It is also convenient and eliminates the mess of measuring
and mixing. This is critical: If you reopen the Lid, the Power Button will no longer work with that
particular SaltPod, even if you re-close the Lid. The Power Button will be locked out and it won’t be
possible to push it in. No peeking!
9. Nasal irrigation is safe and effective, and because it is all-natural and drug-free, you can do it as often
asyou wish. To get the hang of it quickly, we recommend using your Naväge several times in a row
when you’re first learning.
10. Standard Nose Pillows fit thevast majorityof Navägeusers.However,if youareamong those for whom
theStandardPillowsaren’tquiteright,Small andExtra-Large Nose Pillows areavailableatnavage.com.
11. ANavägecyclecanlastfrom10to60secondsdependingonhowcongestedyouare,andonyourpersonal
anatomy.Mostcycleslastfrom15to30 seconds.WhentheUpperTankisempty,the cycleiscomplete.
12. 100% sinus blockage is rare, and nasal irrigation can help relieve even the most stuffed up sinus
condition. If you are completely congested and can’t breathe through your nose at all, see
TroubleshootingTip#5 on page5.
13. When you’re finished, release the Power Button and remove the Nose Pillows from your nostrils. Most
userswill have a littlesaline left in theirnose.Tilt yourhead forward andgently blowyour nose.
14. Twist off the LowerTankand empty it. Clean yourdevice accordingtothe instructions on page 5.
Troubleshooting – Problems and Solutions
Fig. 8Fig. 8

5
3. The Power Button won’t push in –Tips for Experienced Users.
This is especially important if you haven’t used your Nose Cleaner for a while.
Rinse the device with hot water for at least 30 seconds in the three places
marked A, B, and C (Fig. 9). This will melt salt crystal buildup that can interfere
with device operation.Time it – 30 seconds is the magic number and it's longer
than you think!After rinsing, liftthe DrainPull(C)to verify thatit isnotstuck.
4. The button pushes in all the way but the pump doesn’t start.
Visuallyreconfirmthat thebatteries areinstalled in the rightdirection.
Fresh AA batteries should last at least 3 to 4 months of twice daily use.
5. My nose is completely blocked and I can’t breathe through
either nostril.
For nasal irrigation to work, there must be room in the nose for the rinse to
go in one nostril and come out the other. 100% blockage is rare, and nasal
irrigationcanhelprelieveeventhemoststuffedupsinuscondition.If you are
extremely congested, space is limited in the nasal cavity and irrigating will be slow at first. Youmay
needto startandstopa fewtimesto loosen the mucus andbreakup the congestion.We suggest the
following tips when you're really stuffed up: a. Irrigateforabout10seconds; b. Gentlyblowyournose;
c. Rotatethe NasalDock 180°toreverse theflow, andirrigate inthe oppositedirection for10 seconds;
d. Gentlyblow your nose and relax for a couple of minutes; e. Rotatethe Nasal Dock 180° again;
f. Repeatuntil the rinse begins to flow into the bottom tank. This repeated“back and forth”motion
willhelpreducecongestionand allowtherinse toflowfromonenostriltotheother. Persistencepays!
6. Still need help? I nstructionalvideosandadditionaltroubleshootingtips areavailableatnavage.com.
You can also email us at [email protected]om or call [phone] during normal business hours.
Ourcustomer supportreps aredaily Navägeusers themselves,andtheyare caring,knowledgeable,and
eagerto assistyou.If none of these tips work, please call customer support – we can help!
C
DRAIN PULL
A
B
Fig. 9Fig. 9
Rinsing
Areas
Cleaning and Drying Instructions
• The Naväge Nose Cleaner is neither dishwasher nor microwave safe. Exposing the tanks to high heat
can warpthem andpreventtheir sealingto themechanical module.Running theNose Cleanerthrough a
dishwasherormicrowavevoidsthewarranty.
• Upper and Lower Tanks: Detach and hand-wash withliquid soap.
• Mechanical Module: Wipe the underside of the white Mechanical Module with a cloth
dampened with liquid soap. The Mechanical Module is not waterproof. Do not immerse
or rinse the underside with running water, as this can force water into the battery
compartment and causecorrosion.
• Drain Pipes, Nose Pillows, and Nasal Dock: Use the included Scrubber to thoroughly
cleantheinsidesurfacesoftheseparts.TocleantheDrainPipes,putadropofliquidsoap
on the Scrubber and insert it as shown in Figures 10 and 11. To rinse, lift the Drain Pull
(CinFig.9above)andrunhotwaterthroughtheopening.TocleantheNosePillowsand
Nasal Docks,detachthem andfollow thesame cleaningsteps.
• Crushing Chamber Lid: SeeFig.9andrinseareasAandBwithhot water for 30 seconds
tomeltanysaltcrystals.
• Let your Nose Cleaner dry completely between uses: separate theTanks, Nasal Dock, and
Nose Pillows from the Mech Module, and place them in the Countertop Caddy
(available at navage.com)aftereachuse. This alsohelpspreventfilmy buildups.
• Deep cleaning: Spray parts with an anti-bacterial spray. Let sit 10 minutes and rinse
thoroughly, but do not rinse underside ofMechanicalModule.
• TheNaväge Custom Cleaning Kit withspecialcleaningtoolsisalsoavailableatnavage.com.
Fig. 10
Drain Pipe
Fig. 11
Drain
Pipe

6
• Useonlyasindicatedintheseinstructionsorasdirectedbyyourphysician.Ifyouexperiencepainduring
use,stopimmediately.
• Side effects from saline nasal irrigation are generally minor and resolve in a short period of time. These
include nasal burning, local irritation or pain, ear discomfort, ear fullness or popping, and nose bleeds.
Side effects can often be avoided or reduced by making small changes in use. Go to the FAQs on navage.com
orcall the NavägeCustomerSupportTeamat800-203-6400for help.
• About Water: The US FDA advises using filtered, distilled, or previously boiled water for nasal irrigation.
TheUSCentersforDiseaseControlprovidesdetailedinformationaboutboiling,filtering,anddisinfecting
water for nasal irrigation at www.cdc.gov.
• Most people prefer to use warm water. Do not overheat the water. It should be lukewarm to the touch
andnot hotterthanabout 90° F or32°C.
• Rinsing yournasal passageswithplain, unsalted waterwill causestingingand considerablediscomfort.
• Consultyourphysicianbeforeuse if yourecentlyhad ear or nosesurgery.
• Do not use if your nasal passages are 100% blocked and you cannot breathe through either nostril.
100%blockageis rare,andnasalirrigationcanhelprelieveeventhemoststuffedupsinuscondition.See
TroubleshootingTip#5on page 5 formoredetails.
• Donot use if youhavean ear infection orif your earsare blocked.
• MicrowavingtheNaväge NoseCleaneror its accessoriescan be dangerousand voidsthewarranty.
• Consult your physician if you are using the Naväge Nose Cleaner to relieve congestion due to a nasal
illness and there is no improvement after use; or if your symptoms persist or worsen; or if you have
apersistentlythick, yellow, orgreendischarge;orifskinatthebaseofthe nostrilsbecomesraworcrusted.
• Terminateuse ifno saline appears inthelowertankafter60 seconds.
• Donot use continuouslyfor longerthanthree minutes.
• To prevent cross infection between users, the Nasal Dock and Nose Pillows should not be shared. For
householdsthatwouldlike tosharethe sameNoseCleaner,individual Nose Pillow-Nasal Dock Combos
areavailableon navage.com.
• Notforuseby childrenunder 12 yearsold.
• Cleanthe Nose Pillowsanddevice after each useaccordingto the cleaninginstructions.
• Usingtheproductwithillegaldrugs,alcohol,orprescriptiondrugsexceptwhenprescribedbyaphysician,
is prohibited, maydamage the device, voidsthe warranty, and may causeserious injury.
• Everyindividualis unique and experienceswill vary. Thisproduct maynot be right foryou.
• Fresh batteries will provide enough power for at least 4
months of twice daily use. If you notice that the motor is
runningat alowerpitch,or ifthereis lesssuction thanyou’re
usedto,it’sprobablytimefornewbatteries.
• To change the batteries, unscrew the Battery Door with
a Phillips-head screwdriver (Fig. 12). Use your fingernail or
thescrewdrivertogentlypryupthedoor.Inserttwo,newAA
batteries,andscrewtheBatteryDoorontightly.
Changing the Batteries
Fig. 1 2GentlyGently
Pry HerePry Here
Cautions

7
Frequently Asked Questions
What actually happens during nasal irrigation?
Saline exits the UpperTank, enters one nostril, and flows to the back of the nose where there is a gap between
the rear edge of the nasal septum and the back wall of the nasal cavity. The rinse flows through the gap and
makes a U-turn, returning to the front of the nose where it exits through the second nostril. Along the way
it cleans and moisturizes the nasal passages, flushing out allergens, mucus, bacteria, and viruses. In short,
in one nostril, around the back of the nose, and out the other nostril.
How is the Naväge system dierent from other nasal irrigators?
Powered suction is the key, and Naväge is the world’s only nose cleaner with powered suction. Itpulls saline
throughthenosewhileotherdevicessuchasthenetipotandnasalsqueezebottlepush.It’slikethedifference
betweenavacuumcleaneranda broom.Asaresult,there’snothingasneatandconvenientasNaväge!
What’s in a Naväge SaltPod® capsule?
Naväge SaltPod capsules contain salt and water. There are no drugs. The salt is pharmaceutical grade,
containing 99.99% sodium chloride with zero additives and fillers. (For comparison, table salt is about
98% sodium chloride and 2% additives, including iodine, sodium aluminosilicate, magnesium carbonate,
and other fillers.) The water is purified with carbon filtration, deionization, ultra-violet (UV) sterilization,
and a sub-micron finishing filter. The result is super-pure H2O. Naväge aromatic SaltPod capsules such as
Eucalyptus,adda pureessentialoil toenhancethe Navägeexperience.
How often should I irrigate?
Naväge is completely drug-free and designed for purity, safety, and convenience so you can irrigate as often
as you wish.We suggest you use Naväge twice a day, morning and evening, but doctors advise that it’s safe to
usemorefrequently.Findout what’sbestforyou.Useit regularlyforacouple ofweeks andjudge foryourself!
I leak saline, sometimes hours after I irrigate! What’s happening?
Sometimes during an irrigation cycle a small amount of saline can flow into one of the two maxillary sinus
cavities, remain there, and flow out later. This can be annoying and even embarrassing, but it is completely
harmless.Toavoidit,trythis:Aftercompletingacycle,bendoveratthewaistandbringyourchintoyourchest.
First, turnyour headto theleft and lookup over your left shoulder.Then turn your headto theright andlook
upoveryourrightshoulder.If there’sanyresidualsaline,this usuallylets itflowout.Gentlyblowyournose.
Naväge Nose Cleaner Warranty
TheNavägeNoseCleaneriscoveredbyaone-yearpartsandlaborwarranty.Wewillreplaceanyproductthat
malfunctions due to a manufacturing defect within a year of purchase. For service, email [email protected],
or call [phone]. Please note that the Naväge Nose Cleaner is not water-proof. The warranty does not
coverdamagecausedby:
• UsingtheNoseCleanerwithouta genuine,unusedNavägeSaltPodcapsule
• Theuseofharmfuladditivessuchasteatreeoil thatcancause irreparabledamagetoplastic
• SubmergingtheMechanicalModule inwater • Notfully tighteningthescrewsonthe battery door
• PlacingtheNoseCleaner inadishwasher • Productabuse,dropping,andotheraccidents
Disposal and Recycling
Please recycle. Naväge SaltPod capsules are made from HDPE, recycling code #2.The SaltPod packaging is
madefromrecycledPET(RPET).TheNavägesystemis completelyBPA-free.
Electromagnetic Compatibility
The Naväge Nose Cleaner complies with the applicable electromagnetic compatibility requirements (EMC) according to
IEC60601-1-2forresidential,commercial,andlightindustryenvironments.Detailsareavailableatnavage.com/electromagnetic.

[phone] navage.com RhinoSystems, Brooklyn, OH, USA
©2023RhinoSystems,Inc.allrightsreserved.Patents:navage.com/patents
RhinoSystems, Inc. is the
manufacturer of the Naväge Nose
Cleaner and SaltPod® Capsules.
RhinoSystems is registered with the United
StatesFoodandDrugAdministration(USFDA),
and theNavägeNoseCleanerisapprovedbythe
USFDA for sale in the United States. Naväge
SaltPodsarelicensedbyHealthCanada’s Natural
Health Product Directorate, Natural Product
License Number 80035721. RhinoSystems
is committed to continually improving our
products through ongoing research and
development. We strive to maintain the
highest quality in everything we do.
The Naväge Nose Cleaner is designed in the
USA and made in China. SaltPod capsules are
madeinourownBrooklyn,Ohiofacility.Nose
Cleaners and SaltPods are made in facilities
certied to comply with ISO 13485:2016, the
international quality standard for medical
devicemanufacturing.
Don’t forget
the SaltPod!
Sensitive tissue lines the inside of the
nose. Exposing it to water with too
much or too little salt will cause
stinging and considerable discomfort.
To avoid this, the Power Button only
works with a new SaltPod capsule in
the Crushing Chamber. That way you
get just the right amount of salt every
singletime.
If you reopen the Lid after loading
a SaltPod capsule, the device won’t
start. That’s why Doc Rhino says...
UpperTank
Lid
Nasal
Dock
Crushing
Chamber
SaltPod
Capsule
Nose
Pillows
Arrow indicating
direction of flow
AA
Mechanical
Module Power
Button
Lower Tank
Battery Door
Exploded
View
LL 5125 RevBG0223
Use Naväge Twice-A-Day for two weeks
Andexperiencewhatgoodnasalhygieneand
improvednose-breathingcandoforyou!
Find out for yourself!
