NavAtlas NA1BT Operating instructions

NA1BT
INSTALLATION/OWNER'S MANUAL
Digital Bluetooth Controller
®

2 3
NA1BT NA1BT
CONTROLLER MOUNTING
TOOLS NEEDED:
- Crimp Tool
- Wrench or Pliers
- 4mm Allen Wrench
OPTIONAL TOOLS NEEDED:
- Hand saw or Jigsaw
ROLLBAR / CAGE MOUNT
1.5” 1.75” 2.00”
4mm
Allen Head
YOU can rotate 90ofor the
best mounting position
FLUSH MOUNT
SURFACE MOUNT
1) Always check mounting depth before cutting
3) Cutout hole exactly
5) Use optional silicon glue to give extra hold
6) Insert CONTROLLER
1) Check mounting depth before drilling
3) Drill or cut wire hole exactly
screw in place
5) Insert CONTROLLER
UNIVERSAL INSTALLATION
RED - 12V+ACC
BLACK - CHASSIS GROUND
BLUE - OPTIONAL LED CONTROL
POWER
RED RCA - ANALOG RIGHT
WHITE RCA - ANALOG LEFT
GREY RCA- DIGITAL CO-AXIAL OUTPUT
AUDIO
AFTERMARKET SYSTEM
UNIVERSAL CABLE
L
R
Digital out
8 pin waterproof DIN connector
LED ON/OFF
10 Feet (10GA)
2 pin waterproof DIN connector
8 pin waterproof DIN connecto
r
10 Feet (18GA) for
Soundbar 8 pin waterproof
DIN connector
Ground(-)
NS14A/27A/35A
UNIVERSAL CABLE TO AFTERMARKET AMPLIFIER (BASS AMP, ECT...)
*DIGITAL OUT NOT
USED
Digita R L
l
LED ON /OFF
A2A CABLE
NA1BT/NA2BT/NA30C
NA81MDVR
WHEN USING AFTERMARKET AMPLIFIERS WITH SOUNDBARS, YOU MUST USE ANALOG
CABLES FOR DASIY CHAIN FUNCTION TO WORK, A2A CABLE(SOLD SEPARATELY) IS
REQUIRED FOR ANALOG AUDIO OUTPUT TO WORK IN THIS SETUP.
ANALOG INSTALLATION W/AFTERMARKET AMPS
12V +

4 5
NA1BT NA1BT
OUTPUT CAN CONNECT TO ANY MODEL
(NS14A/27A/35A, NT650AT, BMA500M, ECT...)
10 Feet (10GA)
2 pin waterproof DIN connector
8 pin waterproof DIN connector
8 pin waterproof
DIN connector
Ground(-)
4 pin waterproof DIN connector
4 inch(18ga)
Ground(-)
10 Feet (12GA)
NS14A/27A/35A
NT65AT
8 pin waterproof DIN connector
A2A CABLE
NT308W
BMA500M
Ground(-)
D2D CABLE
CONNECTING CABLE
CONNECTING CABLE
10 Feet (18GA) for soundbar
Y ADAPTER CABLE
D2D CABLE
D2D CABLE
*OPTIONAL ACCESSORIES ARE D2Y AND D2D CABLES (SOLD SEPARATELY)
NA1BT/NA2BT/NA30C
NA81MDVR
EXAMPLE OF DAISY CHAIN DIGITAL CONFIGURATIONS FOR
ANY VEHICLE
12V +
12V +
12V +
GETTING STARTED
1
2
3LED LIGHT ON/OFF
POWER ON
EQ MODES: FLAT - LOW - MID - HIGH
4
5
6
VOLUME UP
PLAY/PAUSE/MUTE
VOLUME DOWN
PREVIOUS TRACK
7
8
9
AUX INPUT/USB CHARGING
NEXT TRACK
8
7
4
23
9
USB 1
A
CHARGING
NOT FOR
AUDIO PLAYBACK
OPEN
NOTE: TO AVOID WATER
DAMAGE, PLEASE KEEP
AUX/USB COVER CLOSED
WHEN NOT IN USE
.
1
5
6
*
*NOTE: WHEN USING EQ MODES, SOME MUSIC CAN DISTORT AT MAX VOLUME
ON CERTAIN PHONES/DEVICES

6 7
NA1BT NA1BT
1
PAIRING & DISCOVERING A NEW BLUETOOTH CONNECTIO
N
1) Power on the CONTROLLER by short-pressing the 1Power button
NOTE: You have 2 minutes before you must restart this procedure over again.
2) The CONTROLLER is now in pairing mode:
ANDROID users:
a. Go into the Settings Menu of your device
b. Enter the Bluetooth Menu
c. TURN ON Bluetooth and press SCAN
d.“NA1BT ” will now be displayed under AVAILABLE DEVICES
iOS users:
a. Go into the Settings Menu of your iOS device
b. Enter the Bluetooth Menu
c. TURN ON Bluetooth
d.“NA1BT” will now be displayed
3) If NA1BT is not seen, repeat the above steps to refresh the “Device List”
4) When the connection is successful a tone will be heard, and the Bluetooth LED
indicator will light solid, you are now ready to stream music from your player to the
CONTROLLER
BLUETOOTH OPERATION
RECONNECTION
1) Power on the
CONTROLLER and your last paired device Bluetooth.
2) Ensure you are within range of the
reconnect
CONTROLLER , the unit will now automatically
3) If the device is out of range from the
CONTROLLER , it will disconnect automatically:
a
. The
range
CONTROLLER will reconnect automatically to your device when in
4) If your device was previously paired with the
paired device:
CONTROLLER , but it wasn’t the last
a. Ensure no other devices are currently paired
b. Enter the Bluetooth Menu on your device being paired
c. “NA1BT”will display under AVAILABLE DEVICES
d. Choose the “NA1BT”to reconnect
4) Long press
EQ button 3~6 seconds, reset paired device list.
5) Long press
PLAY/PAUSE button 3~6 seconds, enter pairing mode .
NOTE:
Some devices may require a manual Bluetooth
reconnection once the devices
Bluetooth
is powered
OFF / ON
and/or back in range
BLUETOOTH OPERATION
2
4
2
4

8 9
NA1BT NA1BT
NOTE: Bluetooth HD Streaming available on devices/phones that support
Tips
3
2
1
5
4
BLUETOOTH OPERATION
1) Press the 1PLAY/PAUSE once to start playing music or press the PLAY
button from your devices touch screen
2) To skip songs or advance, press the 2NEXT TRACK button
3) To select the previous song, press the 3PREVIOUS TRACK button
VOLUME CONTROL
4) To raise the volume press the 4VOLUME UP button or use your devices controls
5) To lower the volume press the
controls
5VOLUME DOWN button or use your devices
NOTE: Some devices use an independent volume control, for most devices the
volume control on the controller will adjust the phone volume, in other cases you will
need to raise the phone volume to max in order hear the music clearly.
WARNING: DO NOT USE AUX AND BLUETOOTH AT THE SAME TIME.
Make sure your device Bluetooth volume is set at 100% level
before stowing your device
STREAMING MUSIC
YOU CAN PLAY AUDIO
FROM ANY DEVICE
THAT HAS A 3.5MM
HEADPHONE JACK
INSERT
(Cable not included)
YOUR
DEVICE
2
3
4
1
CONTROLLER AUX-IN OPERATION
1) Power on the
button for 3 seconds
CONTROLLER by pressing and holding down the 1POWER
2) Disconnect any paired Bluetooth Bluetooth in your
devices Settings Menu
3) Connect your 3.5mm AUX-IN cable located on front side of the CONTROLLER
to your devices headphone jack
4) Route the wire back to CONTROLLER , secure your device in a safe location
VOLUME CONTROL
5) To raise the volume press the 2VOLUME UP button
6) To lower the volume press the 3VOLUME DOWN button
AUX-INPUT
BLUETOOTH OPERATION
1) Press the 1PLAY/PAUSE once to start playing music or press the PLAY
button from your devices touch screen
2) To skip songs or advance, press the 2
NEXT TRACK button
3) To select the previous song, press the 3PREVIOUS TRACK button
VOLUME CONTROL
4) To raise the volume press the 4 VOLUME UP button or use your devices controls
5) To lower the volume press the
controls
5VOLUME DOWN button or use your devices
NOTE: Some devices use an independent volume control, for most devices the
volume control on the controller will adjust the phone volume, in other cases you will
need to raise the phone volume to max in order hear the music clearly.
WARNING: DO NOT USE AUX AND BLUETOOTH AT THE SAME TIME.
this function/codec
*NOTE:

10 11
NA1BT NA1BT
is device complies with part 15 of the FCC Rules. Operation is subject to
the condition that this device does not cause harmful interference (1) this
device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired
operation.
Changes or modications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: is equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. ese limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This equipment
should be installed and operated with minimum distance between 20cm the
radiator your body: Use only the supplied antenna.
FCC Compliance

Support Line: 1-562-946-7471
9AM-5PM PST Monday-Friday
www.navatlas.com
All rights reserved.
NSA0318-V01
Printed in China
