Installation Manual
Navico WM-2
Sirius Satellite Weather &
Radio Module
English
www.simrad-yachting.com
www.northstarnav.com.
Brands by Navico - Leader in Marine Electronics

Contact SIRIUS at 1-800-869-5480
WM-2 – WEATHER/RADIO MODULE
P/N: 000-10036-001
S/N: 010036MMDDYYNNNN
ESN: 012345678912
Please place the ESN sticker in the box below
This ESN number is
important. You will
need it to activate
SIRIUS services see
page 20

Preface | 3
Preface
FCC Statement
This equipment has been tested and complies with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a normal installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. This
device must accept any interference received, including
interference that may cause undesired operation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and•
receive r.
Connect the equipment into an output on a circuit different•
from that to which the receiver is connected.
Consult the dealer or an experienced technician for help.•
A shielded cable must be used when connecting a peripheral•
to the serial ports.
Changes or modications not expressly approved by the
manufacturer could void the user’s authority to operate
the equipment.
Warranty
The warranty card is supplied as a separate document and
includes worldwide sales and service information.
In case of any queries, refer to the brand web site of your
display or system.
www.simrad-yachting.com

4 | Preface
Contents
Preface .......................................................... 3
FCC Statement .............................................3
Warranty .....................................................3
Disclaimer....................................................6
Introduction .................................................. 7
Parts List .....................................................7
Required tools ..............................................8
Required materials ........................................8
Installing the antenna ................................... 9
Select the mounting location ..........................9
Pedestal mount........................................... 10
Surface mount............................................ 11
Installing the weather module .................... 12
Mounting Location....................................... 12
Wiring the WM-2 Weather Module ............... 13
Wiring guidelines ........................................ 13
Connectors overview ................................... 13
Connect Power ........................................... 14
Audio connection ........................................ 16
Connecting to your display .......................... 17
Simrad NSE8, NSE12 ................................... 17
Enable weather on NSE display ............. 18
Enable audio if subscribed to service ..... 18

Preface | 5
Check status of the SIRIUS service........ 18
Simrad GB40.............................................. 19
SIRIUS activation ........................................ 20
Spare parts.................................................. 21
Troubleshooting .......................................... 22
LED Information ......................................... 22
Module Data Retention................................. 23
Specications .............................................. 24
Dimensions.................................................. 25

6 | Preface
Disclaimer
As Navico is continuously improving this product, we retain the
right to make changes to the product at any time which may
not be reflected in this version of the manual. Please contact
your nearest distributor if you require any further assistance.
It is the owner’s sole responsibility to install and use the
instrument and transducers in a manner that will not cause
accidents, personal injury or property damage. The user of
this product is solely responsible for observing safe boating
practices.
NAVICO HOLDING AS. AND ITS SUBSIDIARIES, BRANCHES
AND AFFILIATES DISCLAIM ALL LIABILITY FOR ANY USE
OF THIS PRODUCT IN A WAY THAT MAY CAUSE ACCIDENTS,
DAMAGE OR THAT MAY VIOLATE THE LAW.
Governing Language: This statement, any instruction manuals,
user guides and other information relating to the product
(Documentation) may be translated to, or has been translated
from, another language (Translation). In the event of any
conflict between any Translation of the Documentation, the
English language version of the Documentation will be the
official version of the Documentation.
This manual represents the product as at the time of printing.
Navico Holding AS. and its subsidiaries, branches and affiliates
reserve the right to make changes to specifications without
notice.
Copyright © 2010 Navico Holding AS.

Introduction | 7
Introduction
The Navico Satellite Weather Module (000-10036-001) is
compatible with the following Navico displays:
NSE
GB40
Functionality cross reference
Display system Weather Satellite radio
Simrad NSE Y Y
GB40 Y* N
*Some feature functionality could be limited depend on
region.
Parts List
Part Number Description
151-10006-01
WM-2
Navico WM-2
weather module
000-0127-54 Power cable
000-10032-001 Audio Interface
cable 3m (9 ft)
000-0127-51 Ethernet cable 2m
(6 ft)
Mounting screws (4)
for WM-2 module

8 | Introduction
Required tools
Screwdriver. Marking pencil, drill and drill bits 14 mm, 3 mm
(9/16”, 7/64”), or other tools appropriate to your specific
application may also be needed.
Required materials
Silicone sealer when flush mounting
A
B
C
D
E
F
SRA-40 antenna
with surface / pole
mount
AAntenna
B Pole / Flush
mount ange
C ‘O’ Ring
D Surface mount
base
EGasket
FCable
7.62 m (25 ft)
antenna cable
Mounting screws (3)
for SIRIUS antenna
Documentation
Installation manual,
warranty card

Installing the antenna | 9
Installing the antenna
Select the mounting location
X
X
Electromagnetic Interference
0.5 m (20”) Min 1.8 m (6 ft) Min
1.2 m (4 ft) Min
RADAR
Radio or AIS Transmitter
Compass
Do not cut or alter the antenna cable. Do not remove its
connector.
Antenna assembly
A SIRIUS antenna
B Thread adapter
CO-Ring
DBase
E Knife slit for passage of cable
F 6” (15cm) cable
G Mounting gasket
HMounting ange
A
B
H
G
C
D
E
F

10 | Installing the antenna
Pedestal mount
3 mm (7/64”)
14 mm (9/16”)
B
A
C
C
D
E
Use mounting gasket1
as a template for hole
locations.
Drill pilot holes for2
mounting screws. Use
3mm (7/64th) drill bit.
Drill 14 mm (9/16th3
hole for antenna cable.
Secure base (C) and1
gasket (D) to the
surface using 3 screws
(E).
Connect Antenna2
extension cable (C)
to the antennas short
cable (B).
Screw the Antenna and3
mounting ange (A) to
the base.
The antenna can also be
mounted to a standard 25
mm (1”) marine mounting
pole.

Installing the antenna | 11
Surface mount
Mounting on surfaces up to 6 mm (1/4”) in thickness.
Mounting on surfaces 6 mm (1/4”) to 25 mm (1”) in thickness.
B
C
D
A
6mm (1/4” ) - 25 mm (1”)
AntennaA
Lock washer and nutB
Antenna extension cableC
AntennaA
Extension shaftB
Lock washer and nutC
Antenna extension cableD
A
B
C
6mm (1/4” )max

12 | Installing the weather module
Installing the weather module
Mounting Location
A
B
C
D
BWM-2
Key Description
A Navico WM-2 Weather module. Preferably mount on
to a vertical surface with connectors facing down.
B Secure the module to the surface using the screws
provided or other suitable fastener
C When mounted on a vertical surface. Create drip
loops to prevent moisture entering the connectors.
Be care full not to place strain in the connectors
D Secure cables
X
X
Electromagnetic interference
Gasoline fumes
Vibration
Heat
Sunlight
Salt spray
Physical damage
2.0 m (6.5 ft) Min 1.8 m (6 ft) Min
1.5 m (5 ft) Min
RADAR
Radio or AIS Transmitter
Compass
WM-2
WM-2
WM-2
WM-2
WM-2

Wiring the WM-2 Weather Module | 13
Wiring the WM-2 Weather Module
Wiring guidelines
Don’t do this Do this
Don’t make sharp bends in
the cables.
Do make drip and service
loops
Don’t run cables in a way
that allows water to ow
down into the connectors.
Do tie-wrap all cables to keep
them secure
Don’t route the data cables
in areas adjacent to radar,
transmitter, or large current
carrying cables.
Don’t cut or modify the
antenna cable
Connectors overview
Red Fuse
Yellow
Black
12 or 24 V DC
+_
D
BA C
Key Description
A Audio out: line level audio out. Connect to onboard
amplier and speakers using the provided cable.
B Network. Connect to the display system’s Ethernet
network.
C Sirius satellite antenna connector.
D Power: Connect to 12 or 24 v DC. The WM-2 is pro-
tected by an internal auto resetting fuse. Connect to a
breaker or fuse to protect the cable

14 | Wiring the WM-2 Weather Module
Connect Power
Before starting the installation, be sure to turn electrical power
off. If power is left on or turned on during the installation, fire,
electrical shock, or other serious injury may occur. Be sure that
the voltage of the power supply is compatible with the WM-2
weather module
The WM-2 has a voltage rating of 12 V DC or 24 V DC. (9 V DC -
32 V DC max range).
The red wire should always be connected to (+) DC V using a
fuse or thermal breaker (5 Amp) to protect the cable. The WM-2
is protected by an internal auto resetting fuse.
The yellow Power control wire has to be either:
Common with the red wire ( after fuse or breaker).•
Connected in common to the power control wire of another•
display or device.•
Red
Fuse
Black
Yellow
Blue
(no connect)
WM-2
12 - 24 V DC
+_
Power cable Pin Color Function
2 m (6.5 ft)
1Black Battery (-)
2Blue N/C
3Yellow Power Ctrl
4Red Battery (+)
12-24 V DC

Wiring the WM-2 Weather Module | 15
The WM-2 weather module can be configured to turn on when
the display is turned on.
For NSE connect the Power Control wires.
12 - 24 V DC
Red
Black
NSE
WM-2
Yellow Red
Black
Yellow
Remote Power On Bus
+_
Simrad GB40 connect the Grey wire on the 12 pin utility cable
to the yellow wire on the WM-2 power cable
12 - 24 V DC
Red
Black
GB40
WM-2
Grey
Red
Black
Yellow
Remote Power On Bus +_

16 | Wiring the WM-2 Weather Module
Audio connection
SIRIUS satellite radio can be accessed and controlled from
certain Navico displays. The supplied audio cable is connected
to an on board amplifier.
B
C
D
A
WM-2
Key Description
A WM-2 Weather module
B Audio out cable (supplied) 7 pin to 2 x RCA male
connectors.
C On board audio system with analog input..
D Audio system speakers.
Audio cable
Audio cable Pin Function
+
+
-
-
Left
White
Red
Right
1 -
2 -
3 Right channel (-)
4 Right channel (+)
5 Left channel (+)
6 Left channel (-)
7Shield

Connecting to your display | 17
Connecting to your display
Simrad NSE8, NSE12
A
B
D
C
CC
Key Description
A Simrad NSE8 or NSE12
B Navico WM-2
C Ethernet cables 5 pin yellow: Connect directly to one
of the three Ethernet ports or to NEP —see below.
D NEP (Network expansion port) 5 port Ethernet switch
alternative for larger or multi-display systems.

18 | Connecting to your display
Enable weather on NSE display
Enable audio if subscribed to service
Check status of the SIRIUS service
Activate your account see SIRIUS activation page 20.
MENU

WIN
x2

Connecting to your display | 19
Simrad GB40
In order for GB40 to function properly, a software upgrade is
needed, see your dealer for more information.
A
CD
E E
B
Key Description
A Simrad GB40 NavComputer
B Navico WM-2 Weather module
C 8 Port Ethernet Linker
D Ethernet Adapter cable 5 pin yellow - RJ45
E Ethernet cables RJ45
GB40 does not support Sirius Audio. Do not connect audio
cable.
After activation (see SIRIUS activation page 20) display
weather by selecting PAGES > WEATHER then select the
desired overlay function from the WEATHER OVERLAYS menu.

20 | SIRIUS activation
SIRIUS activation
To use the WM-2 weather module. You must have a subscription
to the SIRIUS weather / radio service. Individual weather and
audio subscriptions are available. You can also purchase a
subscription that includes both weather and audio.
For more information visit www.sirius.com/marineweather
Simrad GB40 can only display weather information
Before calling SIRIUS
Make sure you verify signal strength before calling (see page 19
for further information). In addition, make sure you have the
following information:
The ID/ESN number from your WM-2 weather module. This•
can be found on the module box, in the front cover of this
manual and on the packaging of the product. Keep in a safe
place
WM-2 – WEATHER/RADIO MODULE
P/N: 000-10036-001
S/N: 010036MMDDYYNNNN
ESN: 012345678912
Billing information to arrange payment of the subscription .•
A major credit card is required, with the card holders billing
details (US Billing address only)
Make sure your display unit and WM-2 module are turned on•
To activate a SIRIUS subscription
The SIRIUS weather service can only be activated by contacting
SIRIUS by phone.
Contact SIRIUS by calling 1-800-869-5480
ESN Number
