Navig8r NAVSPORT-WF2 User manual

1
WIFI 60FPS 1080P FHD
NAVSPORT-WF2 USER GUIDE
*
Includes themed stickers only. Extra cameras notincluded.

2
WIFI 60FPS 1080P FHD
IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS
Read all instructions carefully before use
Retain this product manual for future reference.
Use this product only in the manner described.
Only use a water-dampened soft-cloth to clean the surface of the camera including the lens. Remove particulate
such as dirt orgrease before you do so otherwise you may risk scratching the case. The camera is not
waterproof when itis outside itswaterproof case
Be aware of environmental conditions such extreme heat and cold, humidity, dusty, salty or sandy
environments.In extremely cold weatherand afterprolonged usage,condensation may forminsidethe case
which may cause thelens to fog up. We would recommend to stopusing thecamera and let the condensation
evaporate (i.e.: don’t try to wipe it off)
For first time use, it is recommended to charge overnight to ensure a full battery charge. Subsequent charges
can be as required. During charging, or extended use, the product may become warm.
There are no user serviceable parts in this product.
Un-authorized attempts to dismantle or repair this product will void your
product warranty
Do notpoint the camera directly at the sun as this may damage the video sensor
Do notwipe the lens surface with yourfingers. Instead use an appropriate lens cleaning cloth or lens cleaning
solution.

3
WIFI 60FPS 1080P FHD
ACCESSORIES IN THE BOX 4
PRODUCT CONNECTION AND BUTTONS 5
MODES 6
VIDEO MODE – SCREEN ICONS 6
CARE MODE - SCREEN ICONS 7
CAMERA MODE - SCREEN ICONS 8
PLAYBACK MODE – CAR, VIDEO AND JPG 8
PLAYBACK MODE OPTIONS 8
CHARGINGTHE BATTERY 10
WATERPROOF CASE 10
HANDLEBAR / SEATPOST MOUNT 11
HELMET MOUNTING KIT 11
INSERTING THE MICROSD CARD 12
START UP / SHUTDOWN 10
START RECORDING / TAKE PHOTO 11
CONNECTING TO A COMPUTER 12
CONNECTING TO A HD TV 13
REMOTE CONTROL 13
USING THESMARTPHONE APP 14
FAQ 17

4
WIFI 60FPS 1080P FHD
ACCESSORIES IN THE BOX
1x Waterproof Housing, 1x Handle Bar Mount,1x Helmet Mount and Strap, 1x Car Charger, 1x Remote Control, 4
x Vinyl Camera Stickers, 1 x Suction Cup Mount,1x User manual
CLIP
-
ON COVER

5
WIFI 60FPS 1080P FHD
PRODUCT CONNECTION AND BUTTONS:
Infrared Lightreceiver
Camera Lens
HDMIInterface
Micro USB (Charge & file transfer)
Mode /
Power On/Off Button
-
Shutter button
-
Select/OK button
LCD Screen
Microphone
Wifi On/Off Button
Scrollbutton
Busy/Charging Light
Battery Compartment
Micro SD
Card Slot
-
Display (On/Off)
- Menu button
-
“Back” Button
PowerLED
(Status and
charging)

6
WIFI 60FPS 1080P FHD
MODES
First, press the MODE button to changebetween modes, as shown below. (Video, Car, Photo and
Playback). Once you have arrived atthe selected MODE, simply press the shutter button to being
recording or to review previously recorded file (only when playback mode is selected)
Note: To review and change MENU OPTIONS for selected MODES, press the
MENU button once you have arrived at the selected MODE
VIDEO MODE - SCREEN ICONS
Video recording icon
Frame rate
Video
resolution
Battery
capacity indicator
Recordable time
remaining

7
WIFI 60FPS 1080P FHD
CAR MODE - SCREEN ICONS
CAMERA MODE - SCREEN ICONS
Camera
recording icon
Camera
quality
Camera “shots” left
Car
recording icon
Frame rate
Video
resolution s
elected
Battery
capacity indicator
Recordable time
remaining
Battery time left icon

8
WIFI 60FPS 1080P FHD
PLAYBACK MODE – CAR, VIDEO AND JPG
From the playback screen, press the SCROLL BUTTON to highlight
your option then press OK to confirm.
From any video mode,scrolldown and pressOK to begin playback
Car and from the playback screen, press the MENU SCROLLING
BUTTON to highlight your option then press OK
Video MODE playback screen icons are detailed below:
Suggested menu selections
Playback time
Date
stamp
Suggested menu selections
Icon of playback mode
File counter
(Camera screen playback icon)
File counter
(Right)
CAMERA
MODE
playback
screen
icons
Note: To protect or to delete a file, press
the MENU from inside the playback
MODE screen to access the Delete or
Save screen

9
WIFI 60FPS 1080P FHD
PLAYBACK MODE – OPTIONS
VIDEO AND CAR MODE
MODE DESCRIPTION OPERATION
1 Movie Size Adjust quality (and size) of recorded
images
720P (60fps),720op (120fps),
1080P (30fps), 1080P (600fps),
1440P (30fps)
2 Video Dist. Automatically turn off screen after
periods ofno use On / Off
3 Invert mode
Flip the screen for“up
-
side
-
down”
installation On / Off
4 Slow Motion Reduce the recording speed forslow
motion effect On / Off
5 White Balance Adjust colour effect of image Auto / Daylight / Cloudy /
Tungsten/Fluro
6 Date Stamp
Include date stamp at bottom of
recorded images Off/ Date / Date & Time
VIDEO AND CAR MODE SETTINGS
1 Power Save Turn camera offafter inactivity
period Off/ 1 / 3 / 5 Minutes
2 Date & Time
Adjust date and time stamp
information {Set Date and Time}
3 Language Select menu languages English / Chinese
4 Light Frequency [Adjust to 50Hz for Australia] 50 / 60Hz
5 Time-lapse Delay image capture for time-lapse
effect Off / 3 / 5 / 10 / 30 / 60 Seconds
6
Time
-
lapse
Duration
Allocate a pre
-
set time limit for time
-
lapse capture
Unlimited / 5/ 10 / 15 / 20/ 30 /
60 minutes
7 System Access system tools Factory Reset / System Info / Card
Info
8
WIFI Password
Display and orenterWiFi password
{Display WIFI password}
9
Format…
Format SD
Yes / No
CAMERA MODE
MODE DESCRIPTION OPERATION
1 Resolution Adjust quality (and size) of recorded
images
16MP (4640x3480), 8MP
(3264x2448) 5MP (2592x1944),
4MP (2304x1728)
2
Driverburst
Take time delayed pictures
Off/ 2 / 10 seconds orDouble
3 Photo burst Take pictures in groups Off 3 / 5 / 10 Photos
VIDEO AND CAR MODE SETTINGS
(Same as above)

10
WIFI 60FPS 1080P FHD
RED LAMP INDICATOR
CHARGING THE BATTERY
Turn the camera off and connectthe USB cable to the camera and to your power source (i.e.in-car charger, PC
USB port orUSB Mains Power Adaptor) The charging indicator light will turn BLUE. When the battery charge is
full, the BLUE light will turn OFF.A typicalfullchargetakes up to 4 hours depending on yourchargersoutput.
WATERPROOF CASE
1. Use your fingertip to gently pull the release clamp out and back, in the direction of thearrow (on the clamp)
2. Inspect the whiterubberwaterseal gasket to ensure it is in good condition, and then insert thecamera in the
correctorientation.
Note 1: You can test the gasketby closing the case without the camera inside and submersing itcompletely in a bowl of
water for a few minutes. Remove thecase from the water, dry off theexteriorwith a towel, and then open the
case carefully. If the interior is dry, the camera and case will be safe for use under water.
Note 2: Only two buttonsare required for recording video and images:the ShutterButton, and the On/Off button.
Note 3: Remember,when the unit is turned OFF and ON again, the unit will defaultto VIDEOmodes and
the default resolutions.
Release clamp / Case Hinge
OR
Wifi
On/OffButton
Button
Shutter
Button
PowerOn/Off Button

11
WIFI 60FPS 1080P FHD
Case
s
crew
Mount
4
1
-
20 Screw
Search YOUTUBE for Navig8r
Sportscam - How to prepare
your helmet mount to view
our instructionalvideo or
click this link if you are
viewing this file online
https://www.youtube.com/
watch?v=EgLbwFummrY
HANDLEBAR / SEAT POST MOUNT
1. Connect the bar clamp to your handlebar (3, 4).
2. Connect your cameracase to the screw (1) securely.
3. Loosen the tilt knob (5)and adjust.
4. After positioning tighten allclamp nuts.
HELMET MOUNTING KIT
Note: This bracket will only work with vented Helmets such as bicycle helmets.
Use the supplied strap to loop through the holes in yourhelmetand then through
the long slotson the helmetmount.Tighten asrequired. Then observethe steps in
the previous section regarding adjustment.
MOUNTING EXAMPLES
Locking
Wheel
HelmetBelt
Helmet Mount
Tilt
Knob
HANDLE BAR
Mount
HELMET Mount
SUCTION CUP Mount
LockingWheel
BarClamp
Nuts
BarClamp
Tilt
Knob
Screw
Tilt
Knob

12
WIFI 60FPS 1080P FHD
INSERTING THE MICRO SD CARD
Carefully push the memory card into the card slot,as shown in the diagram below(using your fingernail). The
Micro SD card will “click into place”. To take the memory card out, gently press the end of the memory card
inward using your fingernail until a click is heard. An internal spring will then release the card.
Note: This camera has no built-in memory. A memory card is needed for operation.
Note 2: High Definition and High Frame Rate videocapture devices, place huge demands
on memory cards. Pending your user settings, it is recommended that a CLASS 10 SDCard
be used to avoid Read/Write complications, which will appear as an error message on the
screen during use.If you are not sure, please test any lower class cards (Read/Write speed)
in the device before use.
START-UP/SHUTDOWN
START-UP: Press and hold the power button until the Digital readout displays“ON”
Note: The remote control cannot turn the camera ON. You must use the power
button on the camera
SHUTDOWN: Press and hold the power button until the Digital readoutdisplays“OFF”.
Note 1: The camera will automatically shut down after 5 minutes of inactive use to conserve power.
Note 2: If there is not enough power the low powerbattery icon will flash.When power has been exhausted
the camera will shutdown.
Note 3: The camera can be turned off with the remote control.
START RECORDING / TAKE PHOTO
When the camera is turned on, itwill automatically enter video mode. Either select anothermode orstart
recording video by simply pressing the shutter button
Note: To stop video recording, press the shutter button again. When the memory card is fullor the battery is
too low, the camera will also automatically stop recording.
CONNECTING TO A COMPUTER
Files can be played back directly from the Camera to a Windows ® Computervia a USB cable. The camera will
appear as a common removable disk under Window Explorer. (Drivers are not required)

13
WIFI 60FPS 1080P FHD
CONNECTING TO A HD TV
Connectthe camera to a high-definition TV (or HDMIequipped monitor) with a Mini HDMI to HDMI cable (as
shown above). The HDMIsignal will carry Full HD video and 2 channel stereo.
REMOTE CONTROL
Shutter Button
(pressonce to take
one photo) Record Video
Button stop/start
Off Button
(remote does
not turn on
camera)
Infrared
transmitter
Lanyard Hole
Note: Point the remote
directly at the camera’s
Infrared receiver, during
operation as shown above

14
WIFI 60FPS 1080P FHD
USING the Smartphone app (Android or iOS)
By wirelessly connecting theNavig8r Sportscam Wifi to a smartphone, you can control, view and review video
or still images remotely.
With your smartphone,you can seewhat the camera sees in real time,allowing you to frame up a shotwithout
needing to remove the camera from it’s mount (for example if it’s on your helmet,handle bars or outside the
car).You can then stop /start recording from yoursmartphone as well as adjusta multitude of camerasettings
or check the battery level or recording space lefton the SD card.
Once a recording (video orphoto)hasbeen saved, you can review them on your smartphone.
Photos stored on the camera can be viewed directly.
Videos stored on the camera willfirstneed to bewirelessly transferred to yoursmartphone’sphotos folder for
review. This is done via the Navig8r Sports Cam app.Oncestored on your smartphone, the videos orphotoscan
be shared or uploaded.
Navig8r Sports Cam App
Search for“SYMAGIX2” in Google Play (for Android OS)or APP Store (for iOS) and install it
onto yoursmartphone (or tablet).When installation has completed,the Navig8rSportscam icon will appear on
your device.
Sportscam Wifi Setup
Turn on your Sportscam,inserta Micro SD card and turn on Wifi.
Smartphone Wifi Setup
iOS – Access Settings -> Wifi->Enable Wifi on your portable device and
search for the new camera ID.When complete, the message “Connected
successfully” will be displayed.
Note: The password “1234567890” will need to
be entered when connecting for the first time.
Android – Acess Settings -> WiFi -> Wireless &
Networks on your tabletand search for the new
camera ID NSPTWF2. When complete, the
message “Connected successfully” will be
displayed.
Note: The password “1234567890” will need to be entered when connecting for the first time.
WifiOn/OffButton
Button
WifiOn/OffButton
Button

15
WIFI 60FPS 1080P FHD
Navig8r App screen
Once the SportsCam Wifi has established a connection with
your smartphone, you can then start the app
Note; should the wifi connectiondrop off (sometimes due to
range or other competing wifi products (routers, hotspots, etc),
then you mayneed to “renew the wifilease”
OPERATING THE CAMERA APP – SMART PHONE
Battery Level forCamera (Display only)
Shutter timer delay Adjustthe delay to 2 or 10seconds (and OFF)
for selfportraits
StillShot (photo)
Resolution Increase or decrease the resolution. Select between 8M(3264x2448) or 5M(2592x1944)
Auto White Balancestatus (Display only)
Settings
Continuous Shooting: take multiple images with
one shutter button press. Select between 3
photos and OFF.
White balance: Adjust for ambientlighting
conditions. Select between Auto, Daylight,
Cloudy, Fluorescent and Incandescent.
(*Frequency: Default set to 50Hz for Australia.)
Format Camera: Erase al files from memory
your card
About: Display camera diagnostic information
Save files Select and or save files from your camera to
your smart Phone
Shutter Button Press to take a photo
Camera/Video Mode Switch between Camera and video modes

16
WIFI 60FPS 1080P FHD
OPERATING THE CAMERA APP - ANDROID DEVICE
Video Resolution Selectbetween: FHD (1080P 60fps) and HD (720P
60fps), HD (720P) 30fps)
Timer Displays the amount of recording time left on
your storage card
Settings
Continuous Shooting (Camera): Take multiple
images with oneshutter button press. Select
between 3 photos and OFF.
Car Mode: Rotate the camera screen image
180degrees for mounting up-side-down.
Slow-Motion Function: Add this special effect to
your recorded video
White Balance: Adjust for ambient lighting
conditions. Select between Auto, Daylight,
Cloudy, Fluorescent and Incandescent.
Frequency: (*Frequency: Default set to 50Hz for
Australia.)
Format Camera: (Diagnostic information only:
App Version, Product Name, FW Version, About)
Battery Level for Camera (Display only)
Auto WhiteBalancestatus (Display only)
Save files Select and or save files from your camera
wirelessly to your device (wifi connection
required)
Shutter Button Press to take start or stop recording
Camera/Video
Mode Switch between Camera orvideo mode

17
WIFI 60FPS 1080P FHD
FAQ
Windows mediaplayer can not
play the recorded video files? Try installing the CODEC pack supplied on the installCD, otherwise we find most customers have better luck with VLC Player.
How many minutes of video can I
record to my SD card?
In full 1080P mode, each minute willrecord up to95MBofdata. So a 4GB
card willstore up to 45 minutes and a 16GB cardup to 170 minutes.
How long does a full charge take and
how long willit last?
A fullchargecan take up to4 hoursand will record
up to 90 minutes of video,
depending on your settingsand situation e.g.time of dayand detail of image.
How many metersdeep can I use the
waterproof case in water? The waterproof casecan safely go down to60 metersin depth.
How do I know that my camera is
recording?
There are 3 ways:
- Monitor the camera via the smart phone App
- Observe the red LED indicator on the front of the camera (is it flashing?)
- Observe the digital read indications that recording has begun
Does yourCamera work with the
Generic App called Symagix2,on the
App store / Google Play?
Yes it does. Symagix2 isa generic App thatwill work, atleastin part, with
mostsports cameras.
I am trying tousea high resolution
setting but I cannot select it?
In most ofthese casesthe SD card maynotbe a high enough class to write at
this speed. Please double check your card speed and upgrade to a class 10
where required.
TECHNICAL SPECIFICATIONS
Image sensor
8
million pixel (CMOS)
Functions
Camera,Video
In
-
Car
Crashcam
recorder.
Camera lens
F3.1
f=2.9mm
(170
°
combined view)
Z
oom
4
X Digital
Shutter
Electronic
Image resolution
16MP (4608 x 3456
-
Default
),
12M
P
(4000 × 3000), 10M
P
(3648x2736), 8MP (3264x2448), 5MP (2560×1920), 4MP (2289 x
1712)
Video resolution
(Higher resolution = better image quality)
(Higher frame rate = smoother playback)
HD
720
1280x720
(
120
frames/sec)
FHD 1080p 1920x1080 (30 frames/sec)
FHD 1080p 1920x1080 (60 frames/sec)
White balance
Automatic
Exposure
Automatic
File formats
JPEG
Video
AVI
H.264
Storage medium
M
icro SD
card (
U
p to 32GB)
. There is no built in memory.
Minimum Class6 (otherwise 1080P resolutioncannot be selected
in user menu settings
)
USB interface
High
-
speed
USB 2.0 interface
PowerSupply
Built
-
in 3.7V rechargeable lithium
Dimension (length × width ×height)
74 x 52 x 33mm
Weight
72
grams

18
WIFI 60FPS 1080P FHD
Warranty against Defects
Laser CorporationPty Ltd (“Laser”) warrants your new productto be freefrom defects in materials and workmanship for 12 months, from the dateof
purchase, provided that the product is used in accordance with accompanying recommendations or instructions where provided. The benefit of this
warranty is in addition to your rights underthe Australian Consumer Law and to other rightsand remediesof the consumerunder a law in relation to
thegoods or services to which the warranty relates.
Through a networkof retailers and resellers, Laser will provideyou with your choice of a refund, repair or exchange (where possible) for this product
if it becomes defective within the warranty period. This warranty will no longer apply where the defect is a result of alteration, accident, misuse,
abuse, normalwear and tear, neglect or improperstorage.
Pleaseretain yourreceipt asproof of purchase.
How tomakea productwarrantyclaim:
Step 1: Find your receipt which proves the date of purchase. Where the date of purchase cannot be verified, your place of purchase or Laser will
make an assessmentbased onthedateof manufacture,the conditionofthe Laserproduct and the type ofdefect.
Step 2a): Contact your place of purchase. They will assess the nature of the fault and refund or replace the product as per their store refund or
warrantypolicy.
Step 2b): If your place of purchase cannot be contacted, then you can contact Laser Customer Service with details of your defective Laser Product
Phone [phone]; or Email: [e-mail] or online www.laserco.net/support/warranty (click on “Consumers (End Users)”). Our
businessaddress isat 1/6-8 Byfield Street, North Ryde, NSW 2113
Step 3: Laser will issue you with aReturn Authorisation (RA) number within 48 hours.When requested, send us thedefective product and a copyof
your receipt. Laser will coverthe cost of the return delivery.
Step 4: Waitfor us to contactyou.Once we have received your defective Laser product for inspection, we will inform you ofour assessment of your
claim within 7 days. When we contact you, we will firstly let you know whether you have a valid claim under this Warranty, and if so, we will inform
you whether your defective Laser product will be replaced or repaired, together with the number of days you can expect to wait to receive your
replaced orrepaired Laserproduct.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a
major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if
thegoodsfail to beof acceptablequalityand thefailuredoesnotamountto a majorfailure.
