User
Guide
nbn™ Fixed
Wireless connection
For installations after July 1st 2013
Includes information about your
nbn™equipment
Please refer to this guide, and to the important safety
warnings on the back cover before attempting to
perform maintenance on your nbn™ equipment.

2
© 2015 nbn co limited | ABN 86 136 533 741
Contents
Your new nbn™ equipment 4
Connecting the nbn™ connection box to your own equipment 5
Maintaining your nbn™ equipment 6
Troubleshooting checklist 8
nbn™ connection box indicator lights 9
Frequently asked questions 10
Important safety warnings Back cover

3
© 2015 nbn co limited | ABN 86 136 533 741
Congratulations on connecting to the nbn™ network through
your chosen service provider. Services delivered over the nbn™
network have the potential to transform many aspects of our
lives including healthcare, education, business and government
services. Your new nbn™ Fixed Wireless connection gives you
access to this vital communications infrastructure.
This guide provides information on how to help ensure your
nbn™connection equipment stays in good working order. It also
outlines what to do should your system not work properly.
Your nbn™user guide

4
© 2015 nbn co limited | ABN 86 136 533 741
The nbn™ equipment installed is comprised of three components:
The nbn™ outdoor antenna and cable that connects the nbn™
outdoor antenna into your property, the wall outlet and the
nbn™ connection box – which is the hand o point between the
nbn™network and your internal wiring and connected equipment.
Once your nbn™ equipment has been installed and checked by the
installer, you can connect your equipment to your nbn™ connection
box following the guide on the next page and begin enjoying your
new nbn™ service straight away.
Your new nbn™equipment
This Wireless Outdoor Unit (ODU)
is the property of the nbn™
DO NOT REMOVE
WNTD
Property
of nbn™
DO NOT REMOVE
SIGNAL STRENGTH
ODUSTATUS
nbn™ connection box
(220 x 127mm)
Wall
outlet
nbn™ outdoor antenna
(450mm tall)
Inside your premises
Outside your premises

5
© 2015 nbn co limited | ABN 86 136 533 741
Your broadband services will be delivered through the data
(UNI-D) ports on the nbn™ connection box. Your service provider(s)
should advise you which data (UNI-D) ports have been designated
for your services, and how to connect any necessary equipment to
the correct port for each service.
All the cables required for the nbn™ connection box to operate will
be supplied and connected by your installer. Any extra cables
required to connect your own equipment to the nbn™ connection
box will need to be supplied by you or your service provider.
The cable that connects the nbn™ connection box to the nbn™
outdoor antenna is supplied by nbn and will be fitted to the nbn™
connection box by the installer. The cable connection is protected
by a tamper-evident cover. Do not attempt to remove this connection
or connect to it.
Connecting the nbn™connection
box to your own equipment
If you have followed the instructions from your service
provider and your internet or other broadband connections
are NOT working, or there are any red or flashing lights on the
nbn™ connection box, go straight to the TROUBLESHOOTING
guide on page 8.
The back of the nbn™ connection box has a row of ports like this;
The four data (UNI-D) ports are to
connect data and in-band video services,
using Ethernet RJ-45 cables.
Port for
the power
cable.
PowerData (UNI-D) Ports
This Wireless Outdoor Unit (ODU)
is the property of the nbn™
DO NOT REMOVE
WNTD
Property
of nbn™
DO NOT REMOVE
SIGNAL STRENGTH
ODUSTATUS

6
© 2015 nbn co limited | ABN 86 136 533 741
Maintaining your nbn™ equipment
The nbn™ equipment in your premises should require very
little maintenance if properly cared for.
Here are some important do’s and don’ts to ensure the
nbn™ connection box and nbn™ outdoor antenna stay in
good working order.
WNTD
Property
of nbn™
DO NOT REMOVE
SIGNAL STRENGTH
ODUSTATUS
Keep the nbn™ connection box
plugged directly in to the mains
power at all times and turned on.
Do not use water to clean
the equipment.
WNTD
Property
of nbn™
DO NOT REMOVE
SIGNAL STRENGTH
ODUSTATU S
Regularly check the LED light indicators
on the nbn™ connection box. If they are
not showing a green light, refer to the
guide on page 9.
Inside your property
STATU S
WNTD
Property
of nbn™
DO NOT REMOVE
SIGNAL STRENGTH
ODU
Do not cover or paint any
part of the equipment.

7
© 2015 nbn co limited | ABN 86 136 533 741
Outside your property
This Wireless Outdoor Unit (ODU)
is the property of the nbn™
DO NOT REMOVE
The nbn™ outdoor antenna is a professionally
installed nbn™ Fixed Wireless modem with an
antenna specifically pointed in the direction
of the nbn™ Fixed Wireless facility. The height
and direction of the antenna is specially
tuned to your premises. It is important that
the equipment is not moved and nothing is
placed in front of the nbn™ outdoor antenna,
as this will likely aect the signal quality and
therefore the performance of the system.
Keep branches and shrubs away
from the nbn™ outdoor antenna.
This Wireless Outdoor Unit (ODU)
is the property of the nbn™
DO NOT REMOVE
If any external construction work is carried out at your property, nbnrecommends
you contact your service provider after the work is completed to get a system
check carried out to ensure the installation is still operating at peak performance
for your premises.
Do not cover or paint any part of the equipment.

8
© 2015 nbn co limited | ABN 86 136 533 741
Trouble shooting checklist
If any services provided through your nbn™ connection box stop
working, please check the following:
1. Power Check
2. Indoor nbn™ connection box
3. nbn™ outdoor antenna
This Wireless Outdoor Unit (ODU)
is the property of the nbn™
DO NOT REMOVE
»Have a look at the nbn™ outdoor
antenna. Can you see any
obvious damage?
For example, a fallen branch could
have knocked it out of alignment.
»Check the power indicator ( ) on the nbn™ connection box is
illuminated green and is not flashing.
»Is it plugged in to a power point and is it turned on?
»Do you have power coming into your property?
»Check the ‘ODU ’ LED indicator light on the nbn™ connection box.
It should show a steady or blinking green light.
»Check the ‘STATUS’ LED indicator light on the nbn™ connection box.
It should be blinking green.
»Watch the indicators for approximately 60 seconds to ensure
they are not changing/resetting. Note down the colour and state
(steady or blinking) of each LED indicator.

9
© 2015 nbn co limited | ABN 86 136 533 741
Power
Indicator
Indicator Meaning Action
Green Power On No action is required
No Light No Power Check the nbn™ connection box
is plugged in and switched on
Status
Indicator
Indicator Meaning Action
Green Flashing Normal Operation No action is required
Green Device is in test mode No action is required
Amber Flashing Device is starting up & installing No action is required
Red There is a system fault Contact your service
provider for assistance
Outdoor Unit
Indicator
Indicator Meaning Action
Green Online No action is required
Green Flashing Activity No action is required
Red Oine Contact your service
provider for assistance
Red Flashing There is an error Contact your service
provider for assistance
Signal
Indicator
Indicator Meaning Action
Red Low signal strength (no fault) No action is required
Amber Medium signal strength No action is required
Green High signal strength No action is required
nbn™connection box
indicator lights
WNTD
Property
of nbn™
DO NOT REMOVE
SIGNAL STRENGTH
ODUSTAT US

10
© 2015 nbn co limited | ABN 86 136 533 741
What if I damage the nbn™
equipment?
You are responsible for the nbn™
connection box and nbn™ outdoor
antenna on your property, just as
you are responsible for connection
equipment for other services such
as power, phone and gas. If you
accidentally damage any of the
equipment or cable, you will need to
contact your service provider for repair
and you may be charged for the repair.
Is the nbn™ Fixed Wireless
network safe?
Yes, it is safe. The nbn™ connection
box has been designed to be installed
and maintained by professional,
trained technicians. The fixed wireless
outdoor antenna uses radio waves and
operates within levels that comply with
Australian standards. When working in
the vicinity of the outdoor antenna the
radio waves can be disabled by turning
o the internal nbn™ connection box.
Can I connect other devices to
the unused ports on the nbn™
connection box?
Each port on the nbn™ connection
box is reserved for a dierent service
in case you choose to use services from
more than one service provider. Ports
that you aren’t purchasing services
for won’t work. If you connect one
of your devices to an unused nbn™
connection box port it will not have
access to a service.
What if I want to move the
nbn™ connection box or nbn™
outdoor antenna?
If you need to have equipment or
cables relocated, contact your service
provider who can advise you of the
cost and also arrange for a technician
to move the equipment. When
considering relocating nbn™ equipment
or cables you should bear in mind
the following:
»The nbn™ connection box must
be protected from water, steam or
excessive heat.
»The location of the nbn™ connection
box must be well ventilated, near a
dedicated power point and easy for
you to check the indicator lights.
»The nbn™ connection box must
be positioned in a location away
from busy areas and protected
from damage, where there is
sucient light to see if the device is
functioning correctly.
»The nbn™ outdoor antenna location
is determined by Radio Frequency
performance. It may not be possible
to relocate this to any other position
on site.
»You are responsible for the
relocation cost.
FAQs

11
© 2015 nbn co limited | ABN 86 136 533 741
What if I want to renovate my
premises?
If the renovation is changing the
physical shape / structure of your
premises, then this may aect the
signal performance of the nbn™
outdoor antenna. Before starting any
renovation work you may need to have
the nbn™ outdoor antenna moved
to a more suitable physical position.
Your service provider can arrange this.
If the renovation is internal to the
premises, and is aecting internal
walls – then care needs to be taken
not to re-route the cable that connects
the nbn™ connection box to your nbn™
outdoor antenna.
If in doubt, contact your service
provider for advice.
I have a monitored home or
premises security system, will it
work over the nbn™ network?
If you would like to use an existing
system, you should check with your
security system provider to ensure that
your particular equipment and service
is nbn-compatible, and check with your
service provider that they can support
this function with your connection.
Can I run everything on a
wireless network within my
premises?
Yes, it is possible to run most services
over a Wi-Fi network within premises
but should you find Wi-Fi limiting for
any reason there are other options.
For instance, powerline networking
adapters can make a home network by
using existing electricity wiring in your
house. These plug directly into home
powerpoints and use existing in-home
electrical wiring for data networking,
avoiding the need to install new
cables. For more information search
“powerline network adaptor” through
your internet browser.
Do I need to install any cables
and outlets?
It is possible to run most services over
a Wi-Fi network, but you may prefer to
have cabled connections for data and/
or phone outlets. You can arrange for
a cable installer to install points now or
you can wait until you and the installer
have agreed on the location of your
nbn™ connection box. You can arrange
to have as many internal home network
points as you like.
The cable installer you choose to
undertake this work must be registered
with an Australian Communications and
Media Authority (ACMA) accredited
industry registrar.
Who do I contact for
assistance?
Your service provider will help you if
you have any questions or need to
report a fault.

© 2015 nbn co ltd. ‘nbn’, ‘bring it on’ and the Aurora device are trademarks of nbn co ltd,
ABN 86 136 533 741. All rights reserved. Not for general distribution.
NBN764_FWUG_0615
For more information: 1800 687 626 | nbn.com.au | [e-mail]
