NEC NEC C User manual

First Printing — November 1997
Copyright 1997
NEC Computer Systems Division
Packard Bell NEC, Inc.
339 North Bernardo Avenue
Mountain View, CA 94043-5223
All Rights Reserved
Proprietary Notice and Liability Disclaimer
The information disclosed in this document, including all designs and related materials, is the
valuable property of NEC Computer Systems Division, Packard Bell NEC (NECCSD, PBNEC)
and/or its licensors. NECCSD and/or its licensors, as appropriate, reserve all patent, copyright
and other proprietary rights to this document, including all design, manufacturing,
reproduction, use, and sales rights thereto, except to the extent said rights are expressly granted
to others.
The NECCSD product(s) discussed in this document are warranted in accordance with the
terms of the Warranty Statement accompanying each product. However, actual performance of
each such product is dependent upon factors such as system configuration, customer data, and
operator control. Since implementation by customers of each product may vary, the suitability
of specific product configurations and applications must be determined by the customer and is
not warranted by NECCSD.
To allow for design and specification improvements, the information in this document is
subject to change at any time, without notice. Reproduction of this document or portions
thereof without prior written approval of NECCSD is prohibited.
NEC and PowerMate are registered trademarks of NEC Corporation, used under license; C400 and C500 are trademarks of
NEC Technologies, Inc.
All other product, brand, or trade names used in this publication are the trademarks or registered trademarks of their
respective trademark owners.

Contents iii
Contents
About this guide.......................................................................... v
Who should use this guide?...............................................................v
How should I use this guide? ............................................................v
What about text conventions?..........................................................vi
Setting up your monitor.............................................................. 1
Check the carton contents.................................................................2
Attach the stand................................................................................2
Get acquainted..................................................................................4
Connect the monitor.........................................................................6
Looking at features ..................................................................... 9
Plug and Play..................................................................................10
Ergonomic design...........................................................................10
Optimized power management........................................................11
Reduced emissions..........................................................................11
Multiple frequency technology........................................................12
Adjusting the monitor............................................................... 13
Access the On-Screen Display.........................................................14
Control panel buttons................................................................15
On-Screen Display....................................................................16
Use the On-Screen Display .............................................................17
The status display......................................................................17
The control menu......................................................................18

iv Contents
How to adjust your monitor........................................................... 19
Contrast control....................................................................... 19
Brightness control.................................................................... 19
Horizontal size control ............................................................. 20
Vertical size control ................................................................. 21
Horizontal position control....................................................... 22
Vertical position control........................................................... 23
Pincushion control.................................................................... 24
Trapezoid control..................................................................... 25
Red gain control....................................................................... 26
Green gain control.................................................................... 27
Color switch control................................................................. 28
Degauss ................................................................................... 29
Reset........................................................................................ 30
Solving problems.......................................................................31
Solving common problems............................................................. 32
Getting help................................................................................... 34
Working safely............................................................................35
Safety precautions.......................................................................... 36
Setting up a healthy work environment........................................... 38
Monitor specifications...............................................................39
Index

About this guide v
About this guide
This guide describes how to set up and use your new NEC C Series
monitor.
Who should use this guide?
We’ve written this guide for anyone who wants to learn about using
the NEC C Series monitor.
How should I use this guide?
We suggest that you read:

“Setting up your monitor” for a list of what comes in the
carton with your monitor and for directions on connecting the
monitor.

“Looking at features” for descriptions of the special features
that are built into your monitor.

“Adjusting the monitor” for directions on using the monitor’s
control buttons and the On-Screen Display.

“Solving problems” to find the likely solution if you encounter
a problem.

“Working safely” for the precautions you should take when
using any equipment, and for tips on setting up a healthy and
comfortable environment.

“Monitor specifications” for details about the characteristics
and capabilities of your monitor.

vi About this guide
What about text conventions?
This guide uses the following text conventions.

Warnings, cautions, and notes have the following meanings:
!
WARNING
Warnings alert you to situations that could result in serious
personal injury or loss of life.
!
CAUTION
Cautions indicate situations that can damage the hardware
or software.
Note:
Notes give important information about the
material being described.

Names of keyboard keys are printed as they appear on the
keyboard, for example, Ctrl, Alt, or Enter.
 Text or keystrokes that you enter appear in boldface type. For
example, type return and press Enter.
 Mouse input is a single click of the left mouse button unless
indicated otherwise.

Setting up your monitor 1
Setting up your monitor
Your NEC C Series color monitor is easy to set up. See the following
sections to:

check out the items that come in the carton

attach the monitor stand to the monitor

get acquainted with the features on the front and rear of the
monitor

connect the monitor to your computer.

2 Setting up your monitor
Check the carton contents
In addition to this guide, the carton contains the following items:

NEC C Series color monitor

monitor stand

power cable

signal cable

registration card (please fill out and return as soon as
possible).
Make sure you have these items before you attach the monitor stand
and set up the monitor. Please save the original box and packing
materials in case you ever need to transport or ship the monitor.
Attach the stand
Your NEC C Series monitor comes with a stand that allows you to
adjust the monitor horizontally and vertically for optimum viewing.
Use the following steps to attach the stand to the monitor.
1. Make sure your monitor is powered off and all cables are
disconnected.
2. Place the monitor face down on a flat, smooth, clean, and
stable surface.

Use care to avoid scratching the monitor screen.

Position the monitor with the base facing towards you.

Setting up your monitor 3
3. Align the hooks on the stand with the hook slots in the base of
the monitor (see the following figure).
Be sure the arrow on the stand is pointing towards the front of
the monitor.
4. Insert the hooks into the slots and slide the stand towards the
front of the monitor until the stand locks in place.
If you ever need to remove the stand, press in the release latch
and slide the stand up and off the hook slots.
Attaching the monitor stand
5. Carefully set the monitor upright on your work surface.

4 Setting up your monitor
Get acquainted
You can find features on the front of the monitor for powering on and
adjusting the video image. Additional control buttons are located
behind the front panel door.
Locating front features

Setting up your monitor 5
The following figure shows the location of the power cable socket
and signal cable connector on the rear of the monitor.
Locating rear features

6 Setting up your monitor
Connect the monitor
Your NEC C Series monitor has a signal cable and a power cable that
need to be connected to your computer and a power source.
Use the following steps to connect the signal and power cables.
Note:
See the documentation that comes with your
computer to locate the monitor connector on the computer.
1. Make sure your computer is powered off.
2. Connect the signal cable (see the following figure).

Remove the protective cap from each connector on the
signal cable.

Locate the connector marked with a C(for computer).
Carefully align the connector with the VGA video port on
your computer and plug it into the port. Tighten the two
connector screws.

Carefully align and plug the other connector into the rear
of your monitor. Tighten the two connector screws.
3. Connect one end of the power cable to the monitor and the
other end to a properly grounded power outlet.

Setting up your monitor 7
Connecting the signal and power cables
4. Press the power button on your monitor.
5. Power on your computer.

Looking at features 9
Looking at features
Your NEC C Series monitor includes a host of features that enhance
performance, ensure your comfort, save power, and let you maximize
your multimedia applications.
Just plug your monitor into a Plug and Play compatible system and
it’s automatically ready to provide optimal performance.
The unlimited color palette and non-glare screen provide a crisp,
detailed image.

10 Looking at features
Your color monitor has the following features:

Plug and Play capability

contemporary ergonomic design

optimized power management system

reduced magnetic field technology

multiple frequency technology

color management with the On-Screen Display (OSD).
Plug and Play
Plug and Play is the Microsoftsolution with Windows95 that
provides automatic peripheral connections without confusing and
time-consuming setup. When used with a Plug and Play compatible
system and display board, the NEC C Series monitor automatically
tells the system its identification and capabilities. The system then
selects its highest resolution and refresh rate to take advantage of the
capabilities of your monitor.
Ergonomic design
The NEC C Series monitor has been designed to enhance human
ergonomics (human and earth conditions), which improve the
working environment, protect the health of the user, and save money.
The color monitor has a tilt/swivel stand so you can adjust it fully for
maximum comfort. It has a high-resolution, flicker-free screen that
can be adjusted using an easy-to-use screen display.
The ergonomic principles used in the monitor design parallel the strict
European standards of power management and reduced emissions and
the requirements in the TCO (Swedish Confederation of Professional
Employees) Agreement on Environmental Labeling 1992.

Looking at features 11
Optimized power management
The NEC C Series monitor uses an optimized power management
system. This is an innovative power-saving feature that complies with
both the EPA’s Energy Star requirements and Europe’s
TCONUTEK’s power management requirements. Energy Star
products use less than 30 watts when in the main power-saving mode.
The NUTEK specification 803299 requires automatic power down to
less than 30 watts in the suspend mode and less than 8 watts in the off
mode.
When in the maximum power-down mode, the monitor consumes
approximately 10% of the total power drawn under normal operation.
This innovation adds up to 90% energy savings, longer monitor life,
environmental protection, reduced emissions, and reduced air
conditioning costs of the work environment.
Reduced emissions
The NEC C Series monitor incorporates reduced magnetic field
technology to reduce magnetic and alternating electric field emissions
and static electricity.
NEC monitors follow the strictest magnetic field, alternating electric
field, and electrostatic recommendations of the Swedish Board for
Technical accreditation.
SWEDAC (previously known as MPR, National Board for
Measurement and Testing) specifies maximum recommended values
of electric and magnetic fields. The NEC C Series monitor conforms
to SWEDAC’s MPR 1990:8 (MPR II) methods, which is one of the
most restrictive guidelines in the world.

12 Looking at features
Multiple frequency technology
Multiple frequency technology automatically adjusts the monitor to
the display card’s scanning frequency, displaying the resolution you
desire.
Increased refresh rates at all resolutions provide a flicker-free image
which is easier on your eyes and extends your viewing time.
Depending on the system used, a wide range of graphics standards is
supported by the monitor:

640 x 480 — 60 to 75 Hz vertical refresh

800 x 600 — 56 to 75 Hz vertical refresh

832 x 624 — 75 Hz vertical refresh

1024 x 768 — 60 to 75 Hz vertical refresh (recommended for
optimal display performance)

1280 x 1024 — 60 Hz (maximum resolution based on
horizontal and vertical frequencies only).

Adjusting the monitor 13
Adjusting the monitor
Your NEC C Series monitor features On-Screen Display (OSD)
controls for adjusting monitor settings.
On-Screen Display controls make the monitor easier to use by
providing an on-screen control menu. A touch of the front controls
turns on the OSD, allowing you to move through a menu and adjust
settings.

14 Adjusting the monitor
OSD controls let you adjust the following settings:

horizontal and vertical position

horizontal and vertical size

a convex or concave screen

trapezoid screen shape

color saturation and balance.
You can also use OSD controls to:

return to factory-state settings

degauss (demagnetize) the monitor.
In addition, two manual controls on the front of the monitor allow
you to adjust the brightness and contrast of your monitor screen.
See the following sections for information about using the OSD
controls and the brightness and contrast controls.
Access the On-Screen Display
You can adjust your monitor using a combination of the following
features:

On-Screen Display (OSD) control menu

control panel buttons.
See the following sections for information about using the control
panel buttons and the OSD control menu. The buttons are located
behind the control panel door.
To open the control panel door, press the triangle-shaped icon at the
lower right corner of the door.

Adjusting the monitor 15
Control panel buttons
To use control panel buttons, monitor and computer power must be
on. See the following figure to locate the monitor control panel
buttons.
Locating control panel buttons
Note:
The power lamp shows the operating state of
the monitor. When the lamp is red, the monitor is on, but it
is not getting a signal (either because the signal cable is
not connected or the computer is not on). When the lamp is
green, the monitor is on and is receiving a signal. When the
lamp is orange, the monitor is in power management mode.
Use control panel buttons to bring up the OSD menus and adjust
monitor settings.

16 Adjusting the monitor
On-Screen Display
The On-Screen Display consists of an OSD status display and an
OSD control menu.
The OSD status display shows the horizontal and vertical frequency
and synchronization polarities of the monitor. The status display also
shows the type of display. The OSD status display looks like the
following when you bring it up.
The OSD status display
The OSD control menu is comprised largely of icons. The icons
represent the settings you can access. The OSD control menu is
divided into two areas:

the icon bar

the adjustment bar.
Two rows of icons appear on the top of the OSD control menu in the
icon bar. The adjustment bar appears along the bottom of the menu.
The adjustment bar shows the value of the monitor settings. The OSD
control menu looks like the following menu when you bring it up.
The OSD control menu
