NEC POWERMATE ENTERPRISE NETPC - SERVICE User manual

First Printing — November 1997
Copyright 1997
NEC Computer Systems Division
Packard Bell NEC, Inc.
1414 Massachusetts Avenue
Boxborough, MA 01719-2298
All Rights Reserved
PROPRIETARY NOTICE AND LIABILITY DISCLAIMER
The information disclosed in this document, including all designs and related materials, is
the valuable property of NEC Computer Systems Division, Packard Bell NEC, Inc.
(hereinafter “NECCSD, PB NEC”) and/or its licensors. NECCSD and/or its licensors, as
appropriate, reserve all patent, copyright and other proprietary rights to this document, in-
cluding all design, manufacturing, reproduction, use, and sales rights thereto, except to the
extent said rights are expressly granted to others.
The NECCSD product(s) discussed in this document are warranted in accordance with the
terms of the Warranty Statement accompanying each product. However, actual
performance of each such product is dependent upon factors such as system configuration,
customer data, and operator control. Since implementation by customers of each product
may vary, the suitability of specific product configurations and applications must be
determined by the customer and is not warranted by NECCSD.
To allow for design and specification improvements, the information in this document is
subject to change at any time, without notice. Reproduction of this document or portions
thereof without prior written approval of NECCSD is prohibited.
FaxFlash is a service mark of NEC Computer Systems Division (NECCSD), Packard Bell NEC, Inc.
NEC, MultiSync, and PowerMate are registered trademarks of NEC Corporation, used under license.
MagicEye is a trademark of Packard Bell NEC, Inc.
All other product, brand, or trade names used in this publication are the trademarks or registered trademarks of their
respective trademark owners.

xiii
Preface
This manual contains technical information necessary for servicing and repairing the
NEC PowerMateEnterprise NetPC computer from NEC Computer Systems Division,
Packard Bell NEC, Inc. It contains hardware and interface information for users who need
an overview of system design. The manual also includes system setup information,
procedures for installing options, and illustrated parts lists. The manual is written for
NECCSD-trained customer engineers, system analysts, service center personnel, and
dealers.
The manual is organized as follows:
Section 1 — Technical Information provides an overview of computer features and
options, hardware design, interface ports, and internal devices. System specifications are
listed including dimensions, weight, environment, safety compliance, power consumption,
and memory.
Section 2 — Setup and Operation includes unpacking, setup, and operation information.
Procedures are also included for configuring the system with the BIOS Setup utility, setting
passwords, using power management and security features, reinstalling the operating system
or software, and using the BIOS Update utility.
Section 3 — Option Installation provides installation procedures for adding optional
expansion boards, upgrading the hard disk, adding system memory, or upgrading the
processor.
NOTE: Access to the inside of the system is
restricted. The PowerMate NetPC is designed to
be upgraded by qualified, NECCSD-trained
personnnel, such as system administrators,
authorized dealers, NECCSD customer
engineers, and service center technicians.
Section 4 — Maintenance and Troubleshooting includes recommended maintenance
information, along with possible computer problems and their solutions, and the procedures
for battery replacement. NECCSD telephone numbers are provided for obtaining service,
accessing the NECCSD Bulletin Board System, and accessing the NEC FaxFlashSM service.
Section 5 — Repair includes computer disassembly and reassembly procedures. Also
included are an exploded view diagram (Illustrated Parts Breakdown) and a parts lists for
depot-level replaceable parts.

xiv Preface
NOTE: The PowerMate NetPC system is
designed to be repaired by qualified, NECCSD-
trained technicians at the depot level of service.
Appendix A — Connector Pin Assignments provides a list of system, riser, and option
board internal connector pin assignments and a list of external pin assignments for the
keyboard, mouse, serial ports, parallel port, network ports, and video port.
Appendix B —Jumper Settings provides jumper settings for the system board, and for
options that may ship with the computer, including the CD-ROM reader and the fax/modem
board.

xv
Abbreviations
A ampere
AC alternating current
AT advanced technology (IBM PC)
ATA AT attachment
ATAPI AT attachment packet interface
BBS Bulletin Board Service
BCD binary-coded decimal
BCU BIOS Customized Utility
BIOS basic input/output system
bit binary digit
BUU BIOS Upgrade Utility
bpi bits per inch
bps bits per second
C capacitance
C centigrade
Cache high-speed buffer storage
CAM constantly addressable memory
CAS column address strobe
CD/ROM compact disk-ROM
CG character generator
CGA Color Graphics Adapter
CGB Color Graphics Board
CH channel
clk clock
cm centimeter
CMOS complementary metal oxide
semiconductor
COM communication
CONT contrast
CPGA ceramic pin grid array
CPU central processing unit
DAC digital-to-analog converter
DACK DMA acknowledge
DC direct current
DIMM Dual In-Line Memory Module
DIP dual in-line package
DLAB Divisor Latch Address bit
DMA direct memory access
DMAC DMA controller
DOS disk operating system
DRAM dynamic RAM
ECC error checking and correction
EDO extended data output
EGA Enhanced Graphics Adapter
EPROM erasable and programmable ROM
EVGA Enhanced Video Graphics Array
F Fahrenheit
FAX facsimile transmission
FCC Federal Communications
Commission
FG frame ground
FM frequency modulation
FP fast page
FRU field-replaceable unit
GB gigabyte
GND ground
HEX hexadecimal
HGA Hercules Graphics Adapter
Hz hertz
IC integrated circuit
ID identification
IDE intelligent device electronics
IDTR interrupt descriptor table register
in. inch
INTA interrupt acknowledge
IPB illustrated parts breakdown
IR infrared
IRR Interrupt Request register
ISA Industry Standard Architecture
ISR In Service register
I/O input/output
IPC integrated peripheral controller
ips inches per second
IRQ interrupt request

xvi Abbreviations
K kilo (1024)
k kilo (1000)
KB kilobyte
kg kilogram
kHz kilohertz
lb pound
LED light-emitting diode
LSB least-significant bit
LSI large-scale integration
M mega
mA milliamps
max maximum
MB megabyte
MDA Monochrome Display Adapter
MFM modified frequency modulation
MHz megahertz
MPEG Motion Picture Experts Group
mm millimeter
ms millisecond
MSB most-significant bit
NASC National Authorized Service
Center
NC not connected
NMI Non-maskable Interrupt
ns nanosecond
NSRC National Service Response Center
PAL programmable array logic
PC personal computer
PCB printed circuit board
PCI Peripheral Component
Interconnect
PDA personal digital assistant
PFP plastic flat package
PIO parallel input/output
pixel picture element
PLCC plastic leaded chip carrier
PLL phase lock loop
p-p peak-to-peak
PPI programmable peripheral
interface
PROM programmable ROM
QFP quad flat pack
RAM random-access memory
RAMDAC RAM digital-to-analog converter
RAS row address strobe
RGB red green blue
RGBI red green blue intensity
ROM read-only memory
rpm revolutions per minute
R read
RTC real-time clock
R/W read/write
S slave
SCSI Small Computer System Interface
SDRAM Synchronous Dynamic Random
Access memory
SG signal ground
SDRAM Synchronous Graphics Random
Access Memory.
SIMM single inline memory module
SPM standard page mode
SRS Sound Retrieval System
SVGA Super Video Graphics Array
SW switch
TAC Technical Assistance Center
TSC Technical Support Center
TTL transistor/transistor logic
tpi tracks per inch
USB universal serial bus
V volt
Vac volts, alternating current
Vdc volts, direct current
VESA video electronics standards
association
VFC VESA-compliant feature
connector
VGA Video Graphics Array
VRAM video RAM
W watt
W write

Abbreviations xvii

iii
Contents
Page
Preface......................................................................................................................... xiii
Abbreviations............................................................................................................... xv
Section 1 Technical Information
System Overview......................................................................................................... 1-1
System Board .............................................................................................................. 1-5
Processor and Secondary Cache............................................................................ 1-7
System BIOS........................................................................................................ 1-8
I/O Addressing...................................................................................................... 1-10
System Memory.................................................................................................... 1-11
Hardware Monitor................................................................................................ 1-12
Interrupt Controller............................................................................................... 1-12
Plug and Play........................................................................................................ 1-15
Chassis.................................................................................................................. 1-15
PCI Local Bus ...................................................................................................... 1-15
PCI/IDE Ports ...................................................................................................... 1-16
Parallel Interface................................................................................................... 1-16
Serial Interface...................................................................................................... 1-17
USB Interface....................................................................................................... 1-19
Video Interface..................................................................................................... 1-19
Integrated Audio................................................................................................... 1-20
Diskette Drive Support................................................................................................ 1-21
Hard Disk Drive........................................................................................................... 1-21
Power Supply .............................................................................................................. 1-21
Riser Card.................................................................................................................... 1-22
Mouse ......................................................................................................................... 1-22
Keyboard..................................................................................................................... 1-22
Specifications............................................................................................................... 1-23
Section 2 Setup and Operation
Site Selection............................................................................................................... 2-1
Installation................................................................................................................... 2-2

iv Contents
Checking the Voltage Switch................................................................................ 2-3
Selecting System Orientation................................................................................. 2-4
Connecting Cables ................................................................................................ 2-5
Preventing Internal Access.................................................................................... 2-6
Operation..................................................................................................................... 2-7
Starting Up........................................................................................................... 2-7
Shutting Down...................................................................................................... 2-9
Setup Utility ................................................................................................................ 2-10
When to Use Setup............................................................................................... 2-11
How to Start Setup............................................................................................... 2-11
How to Use Setup................................................................................................. 2-12
Main Menu ........................................................................................................... 2-13
Displayed Information.................................................................................... 2-13
Language....................................................................................................... 2-13
System Time/Date.......................................................................................... 2-13
Floppy Options .............................................................................................. 2-14
Primary IDE................................................................................................... 2-14
Advanced Menu.................................................................................................... 2-16
PnP O/S......................................................................................................... 2-16
Reset Configuration Data............................................................................... 2-16
Memory Cache............................................................................................... 2-16
Memory Banks 0 and 1 .................................................................................. 2-16
Resource Configuration.................................................................................. 2-16
Peripheral Configuration ................................................................................ 2-17
Keyboard Configuration................................................................................. 2-19
DMI Event Logging....................................................................................... 2-19
Security Menu....................................................................................................... 2-20
User Password Is ........................................................................................... 2-20
Supervisor Password Is.................................................................................. 2-20
Set User or Supervisor Password................................................................... 2-20
Clear User Password...................................................................................... 2-21
User Setup Access ......................................................................................... 2-21
Using a Password........................................................................................... 2-21
Unattended Start............................................................................................ 2-21
Power Menu......................................................................................................... 2-22
Boot Menu ........................................................................................................... 2-22
Exit Menu............................................................................................................. 2-24

Contents v
Flash Utility ................................................................................................................. 2-24
LANDesk Client Manager............................................................................................ 2-25
PC Health Indicator .............................................................................................. 2-26
Workstation Management .............................................................................. 2-26
PC Health Meter............................................................................................ 2-26
PC Health Description.................................................................................... 2-26
Inventory.............................................................................................................. 2-27
DMI...................................................................................................................... 2-28
Monitoring Capabilities......................................................................................... 2-28
NEC Auto Backup Utility............................................................................................ 2-29
NEC Select Install CD ................................................................................................. 2-29
Operating System Restore..................................................................................... 2-30
Selective Application Restore Program ................................................................. 2-36
Section 3 Option Installation
General Rules........................................................................................................ 3-1
Safety Precautions................................................................................................. 3-2
Required Tools ..................................................................................................... 3-3
Internal Access...................................................................................................... 3-4
Removing the System Unit Top Cover ........................................................... 3-4
Opening the System Chassis........................................................................... 3-5
Closing the System Chassis ............................................................................ 3-7
Replacing the System Unit Top Cover............................................................ 3-8
Expansion Board................................................................................................... 3-8
Installing an Expansion Board........................................................................ 3-9
Removing an Expansion Board....................................................................... 3-11
DIMM Upgrade.................................................................................................... 3-12
Checking System Memory.............................................................................. 3-12
Removing a DIMM........................................................................................ 3-12
Installing a DIMM.......................................................................................... 3-13
Processor Upgrade................................................................................................ 3-14
Removing the Processor................................................................................. 3-14
Installing an Upgrade Processor..................................................................... 3-15
Hard Disk Upgrade............................................................................................... 3-16

vi Contents
Section 4 Maintenance and Troubleshooting
Online Services............................................................................................................ 4-2
NECCSD FaxFlash Service................................................................................... 4-2
NECCSD Bulletin Board System .......................................................................... 4-3
E-Mail/Fax Technical Support Services................................................................. 4-4
Internet................................................................................................................. 4-5
Maintenance ................................................................................................................ 4-6
System Cleaning.................................................................................................... 4-6
Keyboard Cleaning................................................................................................ 4-7
Mouse Cleaning.................................................................................................... 4-8
Troubleshooting........................................................................................................... 4-9
Diagnosing and Solving Problems ......................................................................... 4-9
Replacing the CMOS Battery................................................................................ 4-13
Section 5 Disassembly and Reassembly
Safety Procedures ........................................................................................................ 5-1
Recommended Tools ................................................................................................... 5-3
Removal and Replacement........................................................................................... 5-3
System Unit Top Cover......................................................................................... 5-4
Removal......................................................................................................... 5-4
Replacement .................................................................................................. 5-5
Front Bezel........................................................................................................... 5-6
Removal......................................................................................................... 5-6
Replacement .................................................................................................. 5-7
Battery.................................................................................................................. 5-7
EMI Shield ........................................................................................................... 5-8
Removal......................................................................................................... 5-8
Replacement .................................................................................................. 5-9
EMI Clip (Riser Card)........................................................................................... 5-10
Removal......................................................................................................... 5-10
Replacement .................................................................................................. 5-10
Fan ....................................................................................................................... 5-11
Removal......................................................................................................... 5-11
Replacement .................................................................................................. 5-12

Contents vii
Hard Disk Drive.................................................................................................... 5-13
Removal......................................................................................................... 5-13
Replacement .................................................................................................. 5-14
Memory................................................................................................................ 5-15
Removal......................................................................................................... 5-15
Replacement .................................................................................................. 5-16
System Board ....................................................................................................... 5-16
Removal......................................................................................................... 5-16
Replacement .................................................................................................. 5-19
PCI Card............................................................................................................... 5-19
Side Covers .......................................................................................................... 5-21
Removal......................................................................................................... 5-21
Replacement .................................................................................................. 5-22
Bottom Cover....................................................................................................... 5-22
Removal......................................................................................................... 5-22
Replacement .................................................................................................. 5-23
Power Supply/Fan/Top Chassis............................................................................. 5-24
Removal......................................................................................................... 5-24
Replacement .................................................................................................. 5-26
Processor.............................................................................................................. 5-27
Removal......................................................................................................... 5-27
Replacement .................................................................................................. 5-28
Riser Card............................................................................................................. 5-29
Removal......................................................................................................... 5-29
Replacement .................................................................................................. 5-30
Depot Level Parts List ................................................................................................. 5-31
Appendix A Connector Pin Assignments
System Board Connector Locations ............................................................................. A-1
Parallel Interface Connector.................................................................................. A-3
Serial Interface Connectors................................................................................... A-4
Keyboard and Mouse Connectors.......................................................................... A-5
VGA Interface Connector..................................................................................... A-6
Line In Connector................................................................................................. A-7
Line Out Connector .............................................................................................. A-7
Universal Serial Bus Connectors ........................................................................... A-7
DIMM Connectors....................................................................................................... A-8

viii Contents
Riser Card Connector Locations ..................................................................................A-10
Wake On LAN Connector.....................................................................................A-11
Remote Wake Up Connector ................................................................................A-11
System Reset Connector .......................................................................................A-11
Modem Remote Wake Up Connector....................................................................A-12
Storage Device Connectors...................................................................................A-12
Diskette Drive Connector...............................................................................A-12
IDE Connector...............................................................................................A-13
PCI Connector......................................................................................................A-14
Power Supply Connectors.....................................................................................A-15
RJ-45 Connector...................................................................................................A-16
Appendix B Jumper Settings
Setting System Board Jumpers..................................................................................... B-1
Changing Processor Jumper Settings..................................................................... B-2
Clearing a Password.............................................................................................. B-4
Normal Mode................................................................................................. B-5
Configure Mode............................................................................................. B-6
Recovery Mode.............................................................................................. B-6
Riser Card.................................................................................................................... B-7
Riser Card Fan Speed Control Jumper................................................................... B-8
LAN Enable/Disable Jumper ................................................................................. B-8
Index
Figures
1-1 Powermate NetPC Features – Front View......................................................1-2
1-2 Powermate NetPC Features – Back View.......................................................1-2
1-3 Top and Bottom Chassis Assemblies..............................................................1-3
1-4 Chassis Hardware Features.............................................................................1-4
2-1 Computer Vents.............................................................................................2-2
2-2 Line Voltage Switch Selector.........................................................................2-4
2-3 Horizontal Orientation ...................................................................................2-4
2-4 Vertical Orientation........................................................................................2-5
2-5 Rear Panel Connectors...................................................................................2-6
2-6 Chassis Security.............................................................................................2-6

Contents ix
2-7 Front Panel Controls and Indicators ...............................................................2-8
2-8 Setup Main Menu...........................................................................................2-12
2-9 Welcome Screen ............................................................................................2-33
2-10 Restore Mode Screen.....................................................................................2-34
2-11 Partitioning the Hard Drive Screen.................................................................2-34
2-12 Format Mode Screen......................................................................................2-35
2-13 Installing Applications Screen.........................................................................2-35
2-14 Selective Application Restore Program Screen...............................................2-36
3-1 Antistatic Wrist Strap and Mat.......................................................................3-2
3-2 Required Tools ..............................................................................................3-3
3-3 Removing the System Unit Top Cover ...........................................................3-5
3-4 Removing the Front Bezel..............................................................................3-6
3-5 Locating System Chassis Screws....................................................................3-6
3-6 Separating the Chassis Top and Bottom.........................................................3-7
3-7 Replacing the System Unit Cover...................................................................3-8
3-8 Removing the Slot Cover and Retaining Bracket............................................3-10
3-9 Installing an Expansion Board........................................................................3-11
3-10 Removing a DIMM........................................................................................3-13
3-11 Releasing the Processor..................................................................................3-15
3-12 Removing the Hard Disk Screws and Cables ..................................................3-17
3-13 Hard Disk Cable Connections.........................................................................3-18
4-1 Removing the Keyboard Enclosure.................................................................4-7
4-2 Removing the Mouse Ball Cover....................................................................4-8
4-3 Locating the Battery.......................................................................................4-14
4-4 Removing the Battery ....................................................................................4-14
5-1 Removing the System Unit Top Cover ...........................................................5-5
5-2 Replacing the System Unit Top Cover............................................................5-6
5-3 Removing the Front Bezel..............................................................................5-7
5-4 Removing the Battery ....................................................................................5-8
5-5 Removing the EMI Shield..............................................................................5-9
5-6 Installing the EMI Clip On the Riser Card......................................................5-11
5-7 Removing the Fan..........................................................................................5-12
5-8 Removing the Hard Disk Drive ......................................................................5-13
5-9 Connecting the IDE Cable to the Hard Disk and Riser Card ...........................5-14

x Contents
5-10 Removing a Memory Module (DIMM) ..........................................................5-15
5-11 Removing the System Board Screws and Riser Card Cables...........................5-17
5-12 Removing the Plastic Rivets On the Riser Card ..............................................5-17
5-13 Removing the System Board and Riser Card ..................................................5-18
5-14 Separating the System Board and Riser Card..................................................5-18
5-15 Removing the Retaining Bracket and Filler Panel............................................5-20
5-16 Installing the PCI Card and Bracket ...............................................................5-21
5-17 Removing the Side Covers.............................................................................5-22
5-18 Removing the Bottom Cover..........................................................................5-23
5-19 Installing the Bottom Cover ...........................................................................5-24
5-20 Removing the Top Chassis Screws.................................................................5-25
5-21 Opening the Chassis.......................................................................................5-25
5-22 Disconnecting the Cables On the Riser Card...................................................5-26
5-23 Removing the Processor.................................................................................5-28
5-24 Separating the System Board and Riser Card..................................................5-29
5-25 Installing the EMI Clip On the Riser Card......................................................5-30
5-26 Powermate NetPC Illustrated Parts Breakdown.............................................5-33
A-1 System Board External Connector Locations..................................................A-1
A-2 System Board Internal Connector Locations...................................................A-2
A-3 Parallel Interface Connector...........................................................................A-3
A-4 Serial Interface Connectors............................................................................A-4
A-5 PS/2-Style Keyboard and Mouse Interface Connectors...................................A-5
A-6 VGA Interface Connector..............................................................................A-6
A-7 Riser Card Component and Connector Locations...........................................A-10
B-1 Locating System Configuration Jumpers.........................................................B-3
B-2 BIOS Recovery Jumper..................................................................................B-4
B-3 Riser Card Jumper Settings ............................................................................B-7
Tables
1-1 PowerMate NetPC System Configuration....................................................... 1-4
1-2 System Board Feature Components................................................................ 1-7
1-3 System Memory Map..................................................................................... 1-9
1-4 I/O Address Map ........................................................................................... 1-10
1-5 Memory Configurations ................................................................................. 1-11
1-6 Interrupt Level Assignments........................................................................... 1-13

Contents xi
1-7 DMA Settings................................................................................................ 1-14
1-8 Parallel Port Addresses and Interrupts............................................................ 1-16
1-9 Serial Port 1 Addresses and Interrupts............................................................ 1-18
1-10 Serial Port 2 Addresses and Interrupts............................................................ 1-18
1-11 Supported Resolutions, Colors, and Refresh Rates ......................................... 1-20
1-12 System Board Specifications .......................................................................... 1-23
1-13 General Specifications.................................................................................... 1-24
1-14 Mouse Specifications ..................................................................................... 1-24
1-15 Keyboard Specifications................................................................................. 1-24
1-16 System Unit Specifications............................................................................. 1-25
1-17 2.0-GB Hard Disk Drive Specifications.......................................................... 1-25
1-18 3.2-GB Hard Disk Drive Specifications.......................................................... 1-27
1-19 Environmental Standards................................................................................ 1-28
1-20 Power Supply Specifications .......................................................................... 1-29
1-21 Riser Card Specifications ............................................................................... 1-30
2-1 Power Supply Voltage Rating ........................................................................ 2-3
2-2 Power LED Functions.................................................................................... 2-7
2-3 Navigation Keys............................................................................................. 2-12
4-1 NECCSD Service and Support Telephone Numbers....................................... 4-1
4-2 Problems and Solutions.................................................................................. 4-9
5-1 Parts Removal and Replacement..................................................................... 5-3
5-2 Service and Ordering Information................................................................... 5-31
5-3 PowerMate NetPC Depot-Level Parts List..................................................... 5-32
5-4 PowerMate NetPC Documentation and Packaging ........................................ 5-34
A-1 System Board Connectors.............................................................................. A-2
A-2 Parallel Interface Pin Assignments.................................................................. A-3
A-3 Serial Interface Pin Assignments..................................................................... A-4
A-4 Keyboard and Mouse Pin Assignments........................................................... A-5
A-5 VGA Interface Connector Pin Assignments.................................................... A-6
A-6 Line In Connector Pin Assignments................................................................ A-7
A-7 Line Out Connector Pin Assignments............................................................. A-7
A-8 Universal Serial Bus Connector Pin Assignments............................................ A-7
A-9 DIMM Socket Pin Assignments ..................................................................... A-8

xii Contents
A-10 Riser Board Connectors and Components ......................................................A-10
A-11 Wake On LAN Connector Pin Assignments....................................................A-11
A-12 Remote Wake Up Connector Pin Assignments ..............................................A-11
A-13 System Reset Pin Assignments.......................................................................A-11
A-14 Modem Remote Wake-up Pin Assignments....................................................A-12
A-15 Diskette Drive Pin Assignments......................................................................A-12
A-16 IDE Interface Pin Assignments.......................................................................A-13
A-17 PCI Bus Pin Assignments...............................................................................A-14
A-18 Power Connector Pin Assignments.................................................................A-15
A-19 RJ-45 Connector Pin Assignments.................................................................A-16
B-1 Processor Bus Speed Jumper Settings............................................................ B-3
B-2 Fan Speed Control ......................................................................................... B-7
B-3 LAN Enable Jumper Pin Assignments............................................................. B-7

Section 1
Technical Information
SYSTEM OVERVIEW
NEC PowerMateEnterprise NetPC computers are designed to enable central
administration of computer resources in network environments. A highly manageable
platform, the NetPC features network boot capabilities, controlled upgrade paths for system
enhancements, and a “sealed case” that prevents end-user access for changing the system
hardware or software configuration.
NOTE: The PowerMate NetPC system is
designed to be repaired by qualified, NECCSD-
trained technicians at the depot level of service.
PowerMate NetPC systems are available in two basic models with the following features:

Windows®95 operating system, 166-MHz Intel®Pentium®MMXprocessor,
16 MB (minimum) of Synchronous Dynamic Random-Access Memory
(SDRAM), and a 2.0-GB IDE hard disk drive
 Windows NT®4.0 operating system, a 200-MHz Intel Pentium MMX processsor,
32 MB of SDRAM, and a 3.2-GB hard disk drive.
The MMX processor technology boosts audio, video, and 3D graphics performance.
Both PowerMate NetPC models come with an RJ-45 network connector and a video chip
with 2 MB of Synchronous Graphics Random-Access Memory (SGRAM).
Both models also contain audio/video components for multimedia presentations and support
optional memory expansion modules. For further hardware enhancements, both models
contain a PCI expansion slot for adding an optional, half-length, plug and play-compatible
PCI board.
The system features two USB ports, two serial ports, and one parallel port. Ultra DMA,
remote wakeup (“Wake on LAN”), 3D graphics, and power management are supported.
Build choices include hard disk drive and Pentium MMX processor upgrades. System
memory is provided in 16-MB, 32-MB, and (as available) 64-MB and 128-MB DIMM
sticks, in memory configurations ranging from 16 MB to 256 MB.
Figures 1-1 and 1-2 show the front and back features of the PowerMate NetPC system.

1-2 Technical Information
Figure 1-1 PowerMate NetPC Features – Front View
Figure 1-2 PowerMate NetPC Features – Back View

Technical Information 1-3
The NetPC chassis is divided into two sheet-metal halves. This allows the box to be
completely enclosed and “sealed” before plastics are installed on the outside. The top half of
the system contains the hard disk, fan, and power supply. The bottom half contains the
system board and riser card.
Figure 1-3 Top and Bottom Chassis Assemblies
The basic hardware features inside the PowerMate NetPC are listed below:
 Intel CN430TX system board
 Intel Pentium 166-MHz MMX processor
Intel Pentium 200-MHz MMX processor
 RJ-45 LAN connector (on riser card) for connection to an Ethernet network
 Two 168-pin DIMM sockets; system memory from 16 MB using 16-MB, 32-MB,
and (per availability) 64-MB or 128-MB sticks; upgradeable to 256 MB

S3 Trio 64 ViRGE/GX graphics chip integrated on system board
 2 MB of video SDRAM
 256-KB pipeline burst cache memory
 2.0-GB or 3.2-GB hard disk drive
 Yamaha OPL3-SA3 sound system integrated on system board
 Chicony 104 keyboard
 MicrosoftIntelliMouse.

1-4 Technical Information
Figure 1-4 Chassis Hardware Features
PowerMate NetPC computers are configured according to Table 1-1.
Table 1-1 PowerMate NetPC System Configuration
Component Description
System Unit
System Board Intel CN430TX (with sound)
CPU* Pentium 166-MHz MMX
Pentium 200-MHz MMX
System RAM* 16 MB to 256 MB of SDRAM in 2 DIMM sockets
IDE Hard Disk
Drive* Western Di
g
ital Ultra DMA/33:
2.0 GB (WDAC22000)
3.2 GB (WDAC33200)
L2 Cache 256-KB
Graphics S3 Trio 64 ViRGE/GX 3D Graphics on system board
Video DRAM 2 MB of SGRAM soldered on system board
* Varies by system
Hard Disk
DIMM
Sockets
System Board
Processor/Heatsink
Riser Card
