Large-Screen LCD
NEC AccuSyncTM Multimedia Series
32", 40" and 46" digital LCD televisions
Feature-rich affordability. Bringing your home entertainment to digital life no longer re-
quires the support of a big budget. With the value-driven NEC AccuSync Multimedia Series,
just about anyone can begin realizing the many benefits of flat-panel digital televisions.
The NEC AccuSync PV32, NEC AccuSync PV40 and NEC AccuSync PV46 combine the
functionalities of a computer display and high-definition television, making them ideal for
your home theater system.
Experience high-definition brilliance. Whether you’re using AccuSync Multimedia Series
displays to broadcast the big game to a packed crowd, watch your favorite action movie
or blast evil aliens in the latest video game, their screen performance will leave no head
unturned. A remarkable 1366 x 768 resolution, 500 cd/m2brightness and 5000:1 dynamic
contrast ratio add amazing detail to video, images and text, while the integrated HD tuner
makes high-definition movies, sports and network programs jump off the screen with out-
of-this-world clarity.
Surround yourself with superior sound quality. Appeal to your senses with a detachable,
bottom-mount speaker system. This component, which reaches an industry-leading 20W
(PV40 & PV46), combines with the display’s 7-band equalizer and automatic volume lev-
eler to provide a complete surround sound solution.
Interface with the latest devices. With the advanced screen capabilities of AccuSync
Multimedia Series displays, it is only fitting that they be compatible with the most cutting-
edge peripherals. Multiple component and HDMI inputs with HDCP support allow you
to link to the most recently unveiled computers, DVD players and other high-definition
hardware for an optimal visual performance.
Series Features and Benefits
High-definition display provides optimal resolu-
tion (1366 x 768) for almost any application
Integrated tuner allows for high-definition
broadcast capabilities
Detachable, bottom-mount TruSurround®
XT speaker provides virtual surround sound
solution with 7-band equalizer and automatic
volume leveler
Progressive scan produces more detailed images
and improved image quality
Motion adaptive and enhancement de-interlace
provide superior interpolation for moving video,
resulting in a smooth image with greater detail
Comprehensive input panel, including compo-
nent, HDMI and VGA interfaces with comput-
ers, DVD players and many other devices
Multiple aspect ratio control allows flexibility
with today’s many source choices
PIP/POP allows two sources to be displayed on
the screen at one time
XtraView® technology provides for some of the
widest-angle views in the industry
5000:1 dynamic contrast ratio enhances your
view with superior images
Swivel stand expands your viewing options
RoHS compliance ensures the displays are free
of hex-chrome, cadmium, PBDE and PBB, with
reduced mercury and lead
NEC Display Solutions’ quality and reliability
provide peace of mind with a 1-year limited
parts and labor warranty (including backlight)
and industry-leading customer service and
technical support

NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
AccuSync PV32
32”
0.5108mm
500 cd/m2
5000:1 (Dynamic)
178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Rapid Response (6ms grey-to-grey)
256 RGB Level, more than 16.7 million
Manual
76 x 45 cm / 29.9 x 17.7 in.
16:9
56 - 68.7 kHz
50 - 85 Hz
ANALOG 0.7 Vp-p/75 Ohms
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative 0.7Vp-p
positive)
Analog D-Sub
HDMI w/ HDCP (2)
Composite RCA (3)
S-Video
Component BNC (2)
PC Audio
NTSC-M (Latin: NTSC-M, PAL-M, PAL-N), ATSC
RS-232C
No
Composite RCA
Headphone, RCA, SPDIF
15W + 15W
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
1024 x 768 @ 60-85 Hz
1280 x 1024 @ 60 Hz
1280 x 768 @ 60-75 Hz
1360 x 768 @ 60 Hz
NTSC, HDTV, 480p, 576p, 720p, 1080i
1366 x 768
1366 x 768
English, French, Spanish and Portugese
3-D comb filter, 5-mode picture status memory,
detachable speakers (15W + 15W), 4-mode
color status memory, sound status memory, digital
smooth, digital control, swivel, VESA mount, Om-
niColor (NCM), sharpness/softness, off-timer, 10-bit
gamma, running hours, AutoBright (signal input),
color temperature mode, auto DVI selection, swivel
stand, RGB delay compensations, PIP/POP, V-Chip,
aspect ratio converter, still image, child lock
AC 100-120 V / AC 200-240 V @ 50/60 Hz
Internal
130W
<5W
31.7 x 25.4 x 9.3 in. / 806 x 644 x 235mm
31.7 x 23.5 x 4.5 in. / 806 x 597 x 114mm
44.1 lbs / 20 kg
41.1 lbs / 18.6 kg
200 x 200mm
0-40°C / 32-104°F
0-80%
4000m / 13,123 ft.
0-60°C / -4-140°F
0-90%
10,000m / 32,808 ft.
UL/C-UL or CSA, FCC CLASS B/CANADIAN DOC
AC power cord, user manual, 15-pin RGB (VGA)
cable, warranty card
Tilting wall mount
2 years parts and labor, including backlight
M - F (7am - 7pm CST)
AccuSync PV40
40”
0.648mm
500 cd/m2
5000:1 (Dynamic)
178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Rapid Response (6ms grey-to-grey)
256 RGB Level, more than 16.7 million
Manual
95.2 x 55.10 cm / 37.5 x 21.7 in.
16:9
56 - 68.7 kHz
50 - 85 Hz
ANALOG 0.7 Vp-p/75 Ohms
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative 0.7Vp-p
positive)
Analog D-Sub
HDMI w/ HDCP (3)
Composite RCA (3)
S-Video
Component BNC (2)
PC Audio
NTSC-M (Latin: NTSC-M, PAL-M, PAL-N), ATSC
RS-232C
No
Composite RCA
Headphone, RCA, SPDIF
20W + 20W
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
1024 x 768 @ 60-85 Hz
1280 x 1024 @ 60 Hz
1280 x 768 @ 60-75 Hz
1360 x 768 @ 60 Hz
NTSC, HDTV, 480p, 576p, 720p, 1080i
1366 x 768
1366 x 768
English, French, Spanish and Portugese
3-D comb filter, 5-mode picture status memory,
detachable speakers (20W + 20W), 4-mode
color status memory, sound status memory, digital
smooth, digital control, swivel, VESA mount, Om-
niColor (NCM), sharpness/softness, off-timer, 10-bit
gamma, running hours, AutoBright (signal input),
color temperature mode, auto DVI selection, swivel
stand, RGB delay compensations, PIP/POP, V-Chip,
aspect ratio converter, still image, child lock
AC 100-120 V / AC 200-240 V @ 50/60 Hz
Internal
205W
<5W
39.3 x 29.4 x 11.7 in. / 998 x 748 x 298mm
39.3 x 27.5 x 4.8 in. / 998 x 698 x 121.2mm
52.1 lbs / 23.6 kg
48.1 lbs / 21.8 kg
200 x 200mm
0-40°C / 32-104°F
0-80%
4000m / 13,123 ft.
0-60°C / -4-140°F
0-90%
10,000m / 32,808 ft.
UL/C-UL or CSA, FCC CLASS B/CANADIAN DOC
AC power cord, user manual, 15-pin RGB (VGA)
cable, warranty card
Tilting wall mount
2 years parts and labor, including backlight
M - F (7am - 7pm CST)
AccuSync PV46
46”
0.7455mm
500 cd/m2
5000:1 (Dynamic)
178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Rapid Response (6ms grey-to-grey)
256 RGB Level, more than 16.7 million
Manual
76 x 45 cm / 29.9 x 17.7 in.
16:9
56 - 68.7 kHz
50 - 85 Hz
ANALOG 0.7 Vp-p/75 Ohms
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative 0.7Vp-p
positive)
Analog D-Sub
HDMI w/ HDCP (3)
Composite RCA (3)
S-Video
Component BNC (2)
PC Audio
NTSC-M (Latin: NTSC-M, PAL-M, PAL-N), ATSC
RS-232C
No
Composite RCA
Headphone, RCA, SPDIF
20W + 20W
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
1024 x 768 @ 60-85 Hz
1280 x 1024 @ 60 Hz
1280 x 768 @ 60-75 Hz
1360 x 768 @ 60 Hz
NTSC, HDTV, 480p, 576p, 720p, 1080i
1366 x 768
1366 x 768
English, French, Spanish and Portugese
3-D comb filter, 5-mode picture status memory,
detachable speakers (20W + 20W), 4-mode
color status memory, sound status memory, digital
smooth, digital control, swivel, OmniColor (NCM),
sharpness/softness, off-timer, 10-bit gamma, running
hours, AutoBright (signal input), color temperature
mode, auto DVI selection, swivel stand, RGB delay
compensations, PIP/POP, V-Chip, aspect ratio
converter, still image, child lock
AC 100-120 V / AC 200-240 V @ 50/60 Hz
Internal
260W
<5W
45 x 33 x 14 in. / 1142 x 937 x 355mm
45 x 31.1 x 4.8 in. / 1142 x 789 x 121.4mm
85.1 lbs / 38.6 kg
80.1 lbs / 36.3 kg
688 x 216mm
0-40°C / 32-104°F
0-80%
4000 m / 13,123 ft.
0-60°C / -4-140°F
0-90%
10,000m / 32,808 ft.
UL/C-UL or CSA, FCC CLASS B/CANADIAN DOC
AC power cord, user manual, 15-pin RGB (VGA)
cable, warranty card
Tilting wall mount
1 year parts and labor, including backlight
M - F (7am - 7pm CST)
Model
Display
Viewable Size Image
Pixel Pitch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Display Colors
Color Control
Active Screen Area (W X H)
Screen Aspect Ratio
Synchronization Range
Horizontal
Vertical
Input Signal
Video
Sync
Input
RGB1
RGB2
Video 1
Video 2
Component Video 1
Audio
Tuner
External Control
Output
RGB
Video
Audio
Audio Amplifier
Resolutions Supported
Native Resolution
Recommended Resolution
Languages
Additional Features
Voltage Rating
Power Supply
Power Consumption (typical)
On
Power Savings Mode
Dimensions (WxHxD)
Net (with stand)
Net (without stand)
Net Weight
(with stand)
(without stand)
VESA Hole Configuration Specifications
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Regulatory Approvals
Included Accessories
Optional Accessories
On-Site Limited Warranty
Technical Support
XtraView is a registered trademark, and AccuSync is a trademark of NEC Display
Solutions. All other brand or product names are trademarks or registered trademarks
of their respective holders.
Product specifications subject to change. 6/08 ver. 3.
©2008 NEC Display Solutions of America, Inc. All rights reserved.
