MultiSync®LCD2335WXM
23" wide-format LCD PC/TV display Series Features and Benefits
TV tuner allows you to watch your
favorite programs while you work in PC
applications
Picture-in picture allows for a live TV
frame and second video/PC application
frame within the screen area
Picture-on-picture surrounds the
standard live TV frame with multiple
channel preview TV frames
Picture-by-picture splits the standard
TV frame into two live TV frames
Rapid ResponseTM technology (25ms)
delivers virtually uninterrupted,
undistorted viewing of high-speed,
full-motion video
Integrated sound bar delivers high-
quality sound, while freeing up space
normally taken up by external speakers
Ambix dual-input technology allows for
digital/analog compatibility with
upgraded video cards and software as
well as connection to two systems
XtraView technology allows for wid-e-
angle views up to 170°
No Touch Auto AdjustTM reduces setup
time and provides optimal image settings
upon initial power-on
Easy-to-use On Screen Manager (OSM®)
puts you in complete control of your
screen setting adjustments
NEC's quality and reliability provide
peace of mind with a 1-year limited parts
and labor warranty (including backlight)
and 24/7 customer service and technical
support
www.necdisplay.com/35
Only from NEC.
In today’s society, the search for convenience is at an all-time high. If there’s a way to make life
easier, people jump at the chance. Imagine how convenient it would be if you could check your
email, surf the Internet or work on a presentation for work–all while watching the nightly
newscast or catching the big play in your home team’s football game. With the 23" NEC MultiSync
LCD2335WXM, a wide-format LCD PC/TV display, you need not imagine anymore. This model fuses
the most advanced technologies of both PC monitors and TVs into one sleek, stylish display.
With its massive wide screen, the LCD2335WXM provides roughly the same amount of screen area as
two displays, allowing you to work simultaneously in multiple applications. Other benefits include
Ambix®digital/analog connectivity, amazing brightness and contrast ratio, an integrated sound
bar that surrounds your ears with high-quality sound and an easy-to-use On Screen Manager, which
is accessible either through the controls on top of the display or by remote control.
The LCD2335WXM’s dynamic design allows for dramatic space savings – whether it’s placed
directly on your desktop or mounted on an arm or wall. Coupled with XtraView®wide-angle
technology, its design allows for multiple viewers to enjoy its unrivaled screen performance. The
HDTV-ready display features many technologies to enhance your TV viewing, including picture-e-
in-picture (PIP), picture-on-picture (POP) and picture-by-picture (PBP). A remote control adds
further convenience to your visual experience.
www.necdisplay.com/35
NEC Display Solutions

Model
Display
Viewable Image Size
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Display Colors
Synchronization Range
Horizontal
Vertical
Input Signal
Video
Sync
Inputs
PC
Video
Audio
Audio Outputs
Resolutions Supported
Native Resolution
Voltage Rating
Power Consumption (typical)
On
Power Savings Mode
Power Off Mode
Dimensions (W x H x D)
Net (with stand)
Gross (carton box)
Weight
Net (with stand)
Gross (carton box)
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Limited Warranty
Technical Support
LCD2335WXM
22.9"/58.2 cm
.390mm
65 @ native resolution
500 cd/m2
500:1
85U/85D/85R/85L (CR>5)
25ms
More than 16 million
31.5-60 KHz (analog/digital)
56-75 Hz (analog/digital)
Analog 0.7 Vp-p/75 Ohms
Separate sync: TTL Level
(positive/negative)
(1) VGA 15 pin D-sub, (1) DVI-D
(1) Composite, (1) S-video, (1) RF,
(2) HD component (Y/PB/PR)
(1) 3.5mm stereo minijack, (3) RCA L/R
(1) RCA L/R, (1) RCA subwoofer
ANALOG/DIGITAL
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
1024 x 768 @ 60-75 Hz
1280 x 768 @ 60-75 Hz
1152 x 864 @ 60-70 Hz
1280 x 960 @ 60-70 Hz
1280 x 1024 @ 60-70 Hz
1280 x 768 @ 60 Hz
AC 100-120V/AC 220-240V
120W
5W
5W
22.8 x 18.4 x 8.3 in.
580 x 467.5 x 210mm
26.6 x 22.9 x 10.5 in.
676 x 582 x 266mm
22 lbs./10 kg
30.9 lbs./14 kg
5-35°C/41-95°F
30-80%
3658m/12,001 ft.
-10-60°C/-14-140°F
10-85%
12,192m/40,000 ft.
1 year parts and labor,
including backlight
24 hours/7 days
Rapid Response and No Touch Auto Adjust are trademarks, and Ambix and
MultiSync are registered trademarks of NEC Display Solutions. All other brand
or product names are trademarks or registered trademarks of their respective
holders. Product specifications subject to change.
©2005 NEC Display Solutions of America, Inc. All rights reserved.
Item No. LCD2335-1. 03/05 ver. 1.
Whether it’s used as a PC or TV display, the MultiSync LCD2335WXM offers you many
enhanced features to make your visual experience as exciting as possible.
A slim footprint allows you to
position the display in even the
most cramped spaces
Adjust the display to the perfect
angle using its tilt functionality
Easy-to-use display controls are
conveniently located on the top of
the display (remote also included)
An integrated sound bar delivers
ear-pleasing sound and saves space
normally taken up by external speakers
Compatibility is not an issue given
the number of PC, video and audio
inputs available
The display’s design lends a dash of
modern style to your home, making
you the envy of even your most
tech-savvy neighbors
