NEC IE-77016-CM-LC User manual

User’s Manual
IE-77016-CM-LC
Level Converter for In-Circuit Emulator
Target devices
µ
µµ
µ
PD77015
µ
µµ
µ
PD77017
µ
µµ
µ
PD77018
µ
µµ
µ
PD77018A
µ
µµ
µ
PD77019
µ
µµ
µ
PD77110
µ
µµ
µ
PD77111
µ
µµ
µ
PD77112
Document No. U14139EJ1V0UMJ1 (1st edition)
Date Published August 2000 N CP(K)
Printed in Japan
1999©

User’s Manual U14139EJ1V0UM00
2
[MEMO]

User’s Manual U14139EJ1V0UM00 3
This product is designed to be used in a commercial or industrial district. If it is used in a residential district or in an area
in the vicinity of a residential district, radio and TV receivers in the district may be affected.
Use this product correctly by carefully reading its User’s Manual.
Windows is either a registered trademark or a trademark of Microsoft Corporation in the United States and/or
other countries.
PC/AT is a trademark of International Business Machines Corporation.
M8E 00.4
The information in this document is current as of July, 2000. The information is subject to change
without notice. For actual design-in, refer to the latest publications of NEC's data sheets or data
books, etc., for the most up-to-date specifications of NEC semiconductor products. Not all products
and/or types are available in every country. Please check with an NEC sales representative for
availability and additional information.
No part of this document may be copied or reproduced in any form or by any means without prior
written consent of NEC. NEC assumes no responsibility for any errors that may appear in this document.
NEC does not assume any liability for infringement of patents, copyrights or other intellectual property rights of
third parties by or arising from the use of NEC semiconductor products listed in this document or any other
liability arising from the use of such products. No license, express, implied or otherwise, is granted under any
patents, copyrights or other intellectual property rights of NEC or others.
Descriptions of circuits, software and other related information in this document are provided for illustrative
purposes in semiconductor product operation and application examples. The incorporation of these
circuits, software and information in the design of customer's equipment shall be done under the full
responsibility of customer. NEC assumes no responsibility for any losses incurred by customers or third
parties arising from the use of these circuits, software and information.
While NEC endeavours to enhance the quality, reliability and safety of NEC semiconductor products, customers
agree and acknowledge that the possibility of defects thereof cannot be eliminated entirely. To minimize
risks of damage to property or injury (including death) to persons arising from defects in NEC
semiconductor products, customers must incorporate sufficient safety measures in their design, such as
redundancy, fire-containment, and anti-failure features.
NEC semiconductor products are classified into the following three quality grades:
"Standard", "Special" and "Specific". The "Specific" quality grade applies only to semiconductor products
developed based on a customer-designated "quality assurance program" for a specific application. The
recommended applications of a semiconductor product depend on its quality grade, as indicated below.
Customers must check the quality grade of each semiconductor product before using it in a particular
application.
"Standard": Computers, office equipment, communications equipment, test and measurement equipment, audio
and visual equipment, home electronic appliances, machine tools, personal electronic equipment
and industrial robots
"Special": Transportation equipment (automobiles, trains, ships, etc.), traffic control systems, anti-disaster
systems, anti-crime systems, safety equipment and medical equipment (not specifically designed
for life support)
"Specific": Aircraft, aerospace equipment, submersible repeaters, nuclear reactor control systems, life
support systems and medical equipment for life support, etc.
The quality grade of NEC semiconductor products is "Standard" unless otherwise expressly specified in NEC's
data sheets or data books, etc. If customers wish to use NEC semiconductor products in applications not
intended by NEC, they must contact an NEC sales representative in advance to determine NEC's willingness
to support a given application.
(Note)
(1) "NEC" as used in this statement means NEC Corporation and also includes its majority-owned subsidiaries.
(2) "NEC semiconductor products" means any semiconductor product developed or manufactured by or for
NEC (as defined above).
•
•
•
•
•
•

User’s Manual U14139EJ1V0UM00
4
Regional Information
Some information contained in this document may vary from country to country. Before using any NEC
product in your application, pIease contact the NEC office in your country to obtain a list of authorized
representatives and distributors. They will verify:
• Device availability
• Ordering information
• Product release schedule
• Availability of related technical literature
• Development environment specifications (for example, specifications for third-party tools and
components, host computers, power plugs, AC supply voltages, and so forth)
• Network requirements
In addition, trademarks, registered trademarks, export restrictions, and other legal issues may also vary
from country to country.
NEC Electronics Inc. (U.S.)
Santa Clara, California
Tel: [phone]
800-366-9782
Fax: [phone]
800-729-9288
NEC Electronics (Germany) GmbH
Duesseldorf, Germany
Tel: [phone]
Fax: [phone]
NEC Electronics (UK) Ltd.
Milton Keynes, UK
Tel: [phone]
Fax: [phone]
NEC Electronics Italiana s.r.l.
Milano, Italy
Tel: [phone]
Fax: [phone]
NEC Electronics (Germany) GmbH
Benelux Office
Eindhoven, The Netherlands
Tel: [phone]
Fax: [phone]
NEC Electronics (France) S.A.
Velizy-Villacoublay, France
Tel: [phone]
Fax: [phone]
NEC Electronics (France) S.A.
Madrid Office
Madrid, Spain
Tel: [phone]
Fax: [phone]
NEC Electronics (Germany) GmbH
Scandinavia Office
Taeby, Sweden
Tel: [phone]
Fax: [phone]
NEC Electronics Hong Kong Ltd.
Hong Kong
Tel: [phone]
Fax: [phone]
NEC Electronics Hong Kong Ltd.
Seoul Branch
Seoul, Korea
Tel: [phone]
Fax: [phone]
NEC Electronics Singapore Pte. Ltd.
United Square, Singapore
Tel: [phone]
Fax: [phone]
NEC Electronics Taiwan Ltd.
Taipei, Taiwan
Tel: [phone]
Fax: [phone]
NEC do Brasil S.A.
Electron Devices Division
Guarulhos-SP Brasil
Tel: [phone]
Fax: [phone]
J00.7

User’s Manual U14139EJ1V0UM00 5
INTRODUCTION
Target Readers This manual is intended for engineers who understand the functions of the
µ
PD77016
Family and
µ
PD77111 Family and wish to design application programs using these
products.
The
µ
µµ
µ
PD77016 Family is used to refer collectively to the
µ
µµ
µ
PD77015, 77016, 77017,
77018, 77018, 77018A, 77019, and 77019-013. However, the
µ
µµ
µ
PD77016 is not one of
the target devices in this manual.
The
µ
µµ
µ
PD77111 Family is used to refer collectively to the
µ
µµ
µ
PD77110, 77111, and
77112.
Purpose This manual is designed to give you an understanding of the basic specifications of the
IE-77016-CM-LC and its correct use.
Organization This manual consists of the following chapters.
CHAPTER 1 GENERAL
CHAPTER 2 PART NAMES AND FUNCTIONS OF COMPONENTS
CHAPTER 3 INSTALLATION
How to Read This Manual It is assumed that the readers of this manual have general knowledge of logic circuits
and microcontrollers. The IE-77016-CM-LC is used connected to the IE-77016-98/PC in-
circuit emulator. This manual describes the basic setup procedure and how to connect
the IE-77016-CM-LC to the IE-77016-98/PC.
For additional information on the IE-77016-98/PC, refer to the IE-77016-98/PC User’s
Manual.
To understand the basic specifications and use method
→Read this manual in the order of the CONTENTS.
To learn about the operation method of the ID77016, the function of commands, and
software settings
→Read the ID77016 User’s Manual (separately available)
Conventions Data significance: Higher digits on the left and lower digits on the right
Active low representation: ××× (overscore over pin or signal name)
Note: Footnote for item marked with Note in the text
Caution: Information requiring particular attention
Remark: Supplementary information
Numerical representation: Binary ... ×××× or 0b××××
Decimal ... ××××
Hexadecimal ... 0×××××

User’s Manual U14139EJ1V0UM00
6
Related Documents The documents listed below may include preliminary versions. However, preliminary versions
are not marked as such.
Documents Related to the
µ
µµ
µ
PD77016
Document Name User’s Manual Application Note
Part Number Pamphlet Data Sheet Architecture Instructions Basic Software
µ
PD77016 U10891E
µ
PD77015
µ
PD77017
µ
PD77018
U10902E
µ
PD77018A
µ
PD77019
U11849E
µ
PD77019-013
U12395E
U13053E
U10503E U13116E U11958E
Documents Related to the
µ
µµ
µ
PD77111
Document Name User’s Manual Application Note
Part Number Pamphlet Data Sheet Architecture Instructions Basic Software
µ
PD77110 U13858E
µ
PD77111 U12801E
µ
PD77112
U12395E
U13858E
Under
preparation U13116E U11958E
Documents Related to Development Tools
Document Name Document Number
IE-77016-98/PC User’s Manual Hardware EEU-1541
IE-77016-CM-LC User’s Manual This manual
Caution The related documents listed above are subject to change without notice. Be sure to use the
latest version of each document for designing.

User’s Manual U14139EJ1V0UM00 7
CONTENTS
CHAPTER 1 GENERAL ...................................................................................................................... 9
1.1 Checking Packing Box.......................................................................................................... 10
1.2 Operating Environment......................................................................................................... 10
1.2.1 IE-77016-98/PC (sold separately).............................................................................................. 10
1.2.2 ID77016 (sold separately).......................................................................................................... 10
CHAPTER 2 PART NAMES AND FUNCTIONS OF COMPONENTS ........................................... 11
2.1 Part Names of IE-77016-CM-LC Component....................................................................... 11
2.2 Functions of IE-77016-CM-LC Component.......................................................................... 12
2.2.1 IE-77016-CM-LC Component Functions.................................................................................... 12
2.2.2 Functions of Accessories........................................................................................................... 12
CHAPTER 3 INSTALLATION ............................................................................................................. 13
3.1 IE-77016-CM-LC Settings ......................................................................................................13
3.1.1 DIPSW1: Selecting the JTAG interface signal level................................................................... 13
3.1.2 DIPSW2: Forced TRST signal output enable/disable selection................................................. 13
3.2 IE-77016-98/PC Settings........................................................................................................ 13
3.2.1 Connecting the IE-77016-CM-LC and IE-77016-98/PC............................................................. 13
3.3 Connecting the Target System and IE-77016-CM-LC......................................................... 14
3.3.1 In the case of the
µ
PD77016 Family (except
µ
PD77016).......................................................... 14
3.3.2 In the case of the
µ
PD77111 Family.......................................................................................... 14
3.4 Switching Power ON.............................................................................................................. 15
3.5 Starting Up ID77016............................................................................................................... 15
APPENDIX TARGET SYSTEM PINS................................................................................................... 17

User’s Manual U14139EJ1V0UM00
8
LIST OF FIGURES
Figure No. Title Page
1-1. System Configuration ............................................................................................................................. 9
2-1. External View of IE-77016-CM-LC.......................................................................................................... 11
2-2. External View of Flat Cable .................................................................................................................... 11
3-1. Connecting Target System and IE-77016-CM-LC.................................................................................. 14

User’s Manual U14139EJ1V0UM00 9
CHAPTER 1 GENERAL
The IE-77016-CM-LC is a JTAG signal level converter that converts +5 V JTAG interface signals input/output from
an IE-77016-98/PC, which is an in-circuit emulator for the
µ
PD77016 FamilyNote and the
µ
PD77111 Family, to +3 V or
+2.5 V JTAG interface signals.
By combining the IE-77016-CM-LC with the IE-77016-98/PC and ID77016 (debugger control software), it is
possible to use the in-circuit emulation function built in the
µ
PD77016 Family and the
µ
PD77111 Family.
Figure 1-1 shows the system configuration.
Note The
µ
PD77016 is excluded. In the case of the
µ
PD77016, the +5 V JTAG interface signals input/output
from the IE-77016-98/PC can be input/output as is to the device debug pin. At this time, use the cable
provided with the IE-77016-98/PC.
Figure 1-1. System Configuration
Host machine
IBM PC/AT
TM
or compatibles
or PC-9800 Series IE-77016-98/PC (sold separately)
IE connection cable
(supplied with IE-77016-CM-LC)
IE-77016-CM-LC
Flat cable
(supplied with IE-77016-CM-LC)
ID77016
(sold separately)
Target system on which device
of the PD77016 Family or
PD77111 Family is mounted
µµ
Remark The term ID77016 is a debugger control software product name in Japan.
Outside of Japan, please regard ID77016 as general debugger control software.

CHAPTER 1 GENERAL
User’s Manual U14139EJ1V0UM00
10
1.1 Checking Packing Box
The IE-77016-CM-LC packing box contains an IE-77016-CM-LC main unit, a guarantee card, a packing list, and a
bag (accessory bag) containing the accessories.
The accessory bag contains this manual and the cables. Please verify the contents of this bag. If there are
missing or damaged items, contact an NEC sales representative or an NEC distributor.
(1) Main unit
IE-77016-CM-LC
(2) Accessories
IE-77016-CM-LC connection cable ×1
10-pin flat cable ×1
12-pin flat cable ×1
14-pin flat cable ×1
User’s Manual (This manual) ×1
Guarantee card ×1
Packing List ×1
1.2 Operating Environment
The IE-77016-CM-LC’s operating environment conforms to the operating environment of the IE-77016-98/PC and
ID77016.
1.2.1 IE-77016-98/PC (sold separately)
This is the board for the interface between the in-circuit emulation function built in the device and the host
machine. There are two types of board available depending on the host machine. The IE-77016-PC is inserted in the
ISA bus slot of IBM PC/AT or compatibles, and the IE-77016-98 is inserted in the C bus slot of PC-9800 Series
computers. For details, refer to the IE-77016 98/PC User’s Manual.
1.2.2 ID77016 (sold separately)
This is the debugger control software for controlling the on-chip emulation function in the device from the host
machine. It operates on WindowsTM 95/NT. For details, refer to the ID77016 User’s Manual.

User’s Manual U14139EJ1V0UM00 11
CHAPTER 2 PART NAMES AND FUNCTIONS OF COMPONENTS
The part names of the IE-77016-CM-LC and their function are described below.
2.1 Part Names of IE-77016-CM-LC Component
Figure 2-1. External View of IE-77016-CM-LC
OUTPUT
DIPSWHOSTTRSTB
TARGET ON/OFF
Interface level converter
IE-77016-CM-LC
Flat cable Cable for IE connection
ON (Sliding switch)
ON (Push switch)
Figure 2-2. External View of Flat Cable
(a) 10-pin flat cable (for the PD77016 Family)
(b) 12-pin flat cable (for the PD77111 Family)
(c) 14-pin flat cable (for the PD77111 Family)
µ
µ
µ

CHAPTER 2 PART NAMES AND FUNCTIONS OF COMPONENTS
User’s Manual U14139EJ1V0UM00
12
2.2 Functions of IE-77016-CM-LC Component
2.2.1 IE-77016-CM-LC Component Functions
Name Function
ON/OFF (SW1) JTAG interface signal output ON/OFF
ON : Output JTAG signal from host to target system.
OFF: Do not output JTAG signal from host to target system.
TRSTB (SW2) Forced TRST signal output
When ON, an active signal is input to the TRST pin of the device. This switch
is enabled/disabled by the value of DIPSW-2.
DIPSW-1 (DIPSW-1) JTAG interface signal level selection.
ON : +2.5 V
OFF: +3.3 V (factory setting)
DIPSW-2 (DIPSW-2) Forced TRST signal output enable/disable selection.
ON : Enabled
OFF: Disabled (factory setting)
OUTPUT (LED1) JTAG signal output indicator.
Lights when the JTAG signal is output from the target system.
TARGET (J1) Connector used for connection to target device.
Use the flat cable supplied with the IE-77016-CM-LC together with the device
to be debugged.
HOST (J2) Connector used for connection to IE-77016-98/PC.
Use the IE connection cable supplied with the IE-77016-CM-LC to connect to
the host machine.
2.2.2 Functions of Accessories
Name Function
Cable for IE connection Connects the IE-77016-CM-LC with the IE-77016-98/PC.
10-pin flat cable Connects the IE-77016-CM-LC with the target device on the target system
(for the
µ
PD77016 Family).
12-pin flat cable Connects the IE-77016-CM-LC with the target device on the target system
(for the
µ
PD77111 Family).
14-pin flat cable Strengthened version of the 12-pin flat cable. When using this cable, a
corresponding measure must also be implemented on the target system side
(for the
µ
PD77111 Family).

User’s Manual U14139EJ1V0UM00 13
CHAPTER 3 INSTALLATION
3.1 IE-77016-CM-LC Settings
3.1.1 DIPSW1: Selecting the JTAG interface signal level
This DIP switch is used to select whether to convert the +5 V signal output from the IE-77016-98/PC to +2.5 V or
+3.3 V.
If a device of the
µ
PD77016 Family or
µ
PD77111 Family is used, set this DIP switch to OFF.
To select the +2.5 V input/output voltage for the JTAG interface, for example in order to support ASIC products,
set this DIP switch to ON.
Setting value Function
ON Signal is converted to +2.5 V and output from the TARGET (J1) connector.
OFF Signal is converted to +3.3 V and output from the TARGET (J1) connector (factory setting).
3.1.2 DIPSW2: Forced TRST signal output enable/disable selection
The TRSTB (SW2) switch is used to enable/disable forced TRST signal output.
Normally, set this switch to OFF.
Also, if the target device that is used belongs to the
µ
PD77016 Family, the TRSTB (SW2) switch is disabled
regardless of the setting of this switch.
Setting value Function
ON Enables TRSTB (SW2) switch.
OFF Disables TRSTB (SW2) switch (factory setting).
3.2ýIE-77016-98/PC Settings
Following the instructions given in the IE-77016-98/PC User’s Manual, set up the IE-77016-98/PC to the host
machine.
3.2.1 Connecting the IE-77016-CM-LC and IE-77016-98/PC
Connect the J2 connector of the IE-77016-CM-LC and the CN3 connector of the IE-77016-98/PC to the IE
connection cable supplied with the IE-77016-CM-LC. Do not use the JTAG cable supplied with the IE-77016-98/PC.

CHAPTER 3 INSTALLATION
User’s Manual U14139EJ1V0UM00
14
3.3 Connecting the Target System and IE-77016-CM-LC
3.3.1 In the case of the
µ
µµ
µ
PD77016 Family (except
µ
µµ
µ
PD77016)
Connect the IE-77016-CM-LC to the target system using the 10-pin flat cable supplied with the IE-77016-CM-LC.
First connect the 14-pin connector of the flat cable to the J1 connector of the IE-77016-CM-LC. Then connect the
10-pin connector to the pin provided on the target system side (Refer to APPENDIX TARGET SYSTEM PINS).
3.3.2 In the case of the
µ
µµ
µ
PD77111 Family
Connect the IE-77016-CM-LC to the target system using the 12-pin (or 14-pin) flat cable supplied with the IE-
77016-CM-LC.
First connect the 14-pin connector of the flat cable to the J1 connector of the IE-77016-CM-LC. Then connect the
12-pin (or 14-pin) connector to the pin provided on the target system side (Refer to APPENDIX TARGET SYSTEM
PINS).
Remark Connector pins with 14-pin specifications are recommended for the target system side. In the case of
the supplied flat cables, the 14-pin flat cable is recommended over the 12-pin flat cable due to its higher
strength.
If connecting a connector pin with 12-pin specifications to the target system, the 14-pin flat cable can be
used, if enough space is left when positioning components around the connector pin so that the flat
cable connector does not interfere with the components on the target device. In this case, since there
are no signals for the 2 extra pins of the 14-pin flat cable, no special handling is required for these 2
pins.
Figure 3-1. Connecting Target System and IE-77016-CM-LC
10/12/14-pin flat cable (included with IE-77016-CM-LC)
To IE-77016-CM-LC J1
Target system

CHAPTER 3 INSTALLATION
User’s Manual Guide U14139EJ1V0UM00 15
3.4 Switching Power ON
Next, switch the power ON following the sequence described below. Follow the reverse sequence when switching
the power OFF.
(1) Switch ON the host machine.
(2) Switch ON the target system.
(3) Set the SW1 of the IE-77016-CM-LC to ONNote (JTAG signal is output).
Note This switch does not control the power of the IE-77016-CM-LC.
Caution If removing or replacing devices on the target system, be sure to set SW1 of the IE-77016-CM-LC
to OFF when you switch OFF the power of the target system.
3.5ýStarting Up ID77016
Start up the ID77016 on the host machine. For details, refer to the ID77016 User’s Manual.

User’s Manual U14139EJ1V0UM00
16
[MEMO]

User’s Manual U14139EJ1V0UM00 17
APPENDIX TARGET SYSTEM PINS
Provide a dedicated debug pin on the target system.
[In the case of the
µ
µµ
µ
PD77016 Family (except
µ
µµ
µ
PD77016)]
•When using the 10-pin flat cable
GND GND
6 mm
17 mm
2.54 mm
2.54 mm ×4
TMS
TDI
TCK
TICE
TDO
PD77015,
µ
PD77017, µ
PD77018,
µ
PD77018A,
µ
PD77019 µ
= Pin ( 0.635, I = 6 mm)
= Key Removed (to prevent incorrect insertion, to not provide pin.)

APPENDIX TARGET SYSTEM PINS
User’s Manual U14139EJ1V0UM00
18
[In the case of the
µ
µµ
µ
PD77111 Family]
•When using the 12-pin flat cable
GND GND
6 mm
16 mm
2.54 mm
2.54 mm ×5
TMS
TRST
TDI
TCK
TICE
TDO
PD77110,
µ
PD77111,
µ
PD77112, µ
= Pin ( 0.635, I = 6 mm)
= Key Removed (to prevent incorrect insertion, to not provide pin.)
•When using the 14-pin flat cable (Recommended)
GND GND
6 mm
22 mm
2.54 mm
2.54 mm ×6
TMS
TRST
TDI
TCK
TICE
TDO
PD77110,
µ
PD77111,
µ
PD77112, µ
= Pin ( 0.635, I = 6 mm)
= Key Removed (to prevent incorrect insertion, to not provide pin.)
