NEC AccuSync
™
CRT Series
CRT monitors ideal for home users, small-to-medium businesses and educational settings
GENERAL

For small-to-medium-sized businesses, home
offices and government and education environ-
ments, AccuSync Series monitors deliver excel-
lent image quality and easy-to-use features at
an exceptional value. This flexible series offers a
variety of sizes and options to accommodate
virtually every user’s needs.
The full line includes 15", 17", 19" and 21" models
and a multimedia version available in a 17"
screen size, delivering excellent sound quality
for public or private listening. The 17" AccuSync
750F features flat-screen technology for an
enhanced visual experience.
Excellent image quality optimizes today’s
sophisticated applications. All members of the
AccuSync family deliver outstanding screen per-
formance with crisp, sharp, accurate images
that enable comfortable viewing of text and
graphics-intensive applications. AccuSync Series
monitors feature fine dot pitches for clear, easy-
to-read text and graphics and high-resolution
support for more on-screen information.
They offer super-high refresh rates up to 160 Hz
for stable, flicker-free images that can ease eye-
strain and make viewing more comfortable.
Their FullScan™ capability also offers edge-to-
edge images without a functionless black border,
providing users with a maximum area to work
or play.
The added advantage of flat. The advanced
design of the AccuSync 750F flat-screen model
doesn’t simply improve image quality, it ensures
significantly less glare, reflection and distortion
than traditional curved screens. The innovative
design ofthe ClearFlat™ shadow mask CRT
deflects glare from overhead lighting away
from users so that what they see on-screen is
as realistic and lifelike as what they see on their
printed output. This results in reduced eye-
strain, less fatigue and improved comfort and
productivity. The AccuSync 750F—an additional
alternative in this full line of value-minded mon-
itors, with sizes, features and options to meet a
wide variety of needs at a range of outstanding
price points.
Dual Dynamic Beam Focus. This technology pro-
vides precise, continuous focus adjustments for
optimum picture quality(feature not available
on the 15" model).
Plug and Play compatibility enables easier
setup and improves performance. To minimize
setup and installation time with Windows®
95/98/2000/Me/XP, AccuSync Series monitors
feature Plug and Play compatibility. Plug and
Play allows the monitor to identify its capabili-
ties—such as screen size and resolutions sup-
ported by your computer. Display performance is
automatically optimized by providing the best
match between the capabilities of your monitor
and your computer.
ENERGY STAR®and NUTEK compliance saves
energy costs. AccuSync Series monitors include
the NEC Intelligent Power Manager™(IPM) sys-
tem, which allows the monitor to shift to a lower
power consumption level when not in use. This
can save up to two-thirds of your monitor
energy costs while your monitor is idling.
Monitors with flexible options, value and
innovation
to enhance your digital world.
Quick Specs
AccuSync Series 500
15"(14" VIS)
0.27/0.23mm horizontal
1280 x 1024 @ 66 Hz
30–71 kHz
700
17"(16" VIS)
0.27/0.23mm horizontal
1280 x 1024 @ 66 Hz
30–71 kHz
700M
17"(16" VIS)
0.27/0.23mm horizontal
1280 x 1024 @ 66 Hz
30–71 kHz
750F
17"(16" VIS)
0.24/0.21mm horizontal
1280 x 1024 @ 66 Hz
30–71 kHz
900
19" (18" VIS)
0.25/0.21mm horizontal
1600 x 1200 @ 76 Hz
30–98 kHz
Screen Size
Dot Pitch
Max.Resolution
Horizontal Frequency
NEC-Mitsubishi Accusync Revise Liska + Associates 459-085 3.2.04 Revision 0

(To realize the benefits of the IPM system, your
monitor must be used with a computer display
card or software utility that is VESA DPMS
compliant.)
PC and Macintosh®compatibility adds flexibility
for the future. AccuSync Series monitors are
fully compatible with PC and Macintosh comput-
ers, giving you the flexibility to change platforms
or use both without having to purchase a second
monitor. In addition, AccuSync monitors are com-
patible with a variety of resolutions, ensuring
that your monitor will grow with you as your
needs change.
ErgoDesign®enhancements increase comfort,
productivity and ease of use. AccuSync Series
monitors are designed according to NEC
ErgoDesign philosophy. ErgoDesign enhancements
adapt technology to the way you work, resulting
in increased comfort and ease of use.
Asset management capability assists managers.
AccuSync Series monitors support asset manage-
ment capability by adhering to VESA DDC and
EDID standards. Based on these standards, infor-
mation from the monitor—such as serial number,
model name, timing data and color settings—can
be communicated to a central system using asset
management software.
NEC designs all AccuSync monitors with total
cost of ownership(TCO) in mind. From superior
product support to excellent compatibility, from
energy-efficient technologies to a comprehensive
3-year limited warranty, all facets of NEC
AccuSync monitors have been engineered to
maximize performance while minimizing TCO.
Featured on the AccuSync
700M, integrated speakers
deliver outstanding
sound quality and free up
desk space. Multimedia
performance–just one of
the value-minded options
in the full AccuSync line.
Series Features and Benefits
ClearFlat shadow mask CRT (AccuSync 750F)
delivers an outstanding screen performance
with a virtually flat image, eliminating distor-
tion and reducing glare so that what you see
on-screen is as realistic and lifelike as what
you see on your printed output
Outstanding screen performance provides
you with a more comfortable visual experi-
ence with crisp, sharp and accurate images
Flexible options in screen sizes and types,
advanced technologies, cabinet colors and
multimedia capabilities allow you to match
your display needs
FullScan capabilities let you view images at
their best, with true-to-life representation to
the very edge of the screen and no distract-
ing black border
On Screen Manager (OSM®) puts you in
complete control of your screen setting
adjustments
PC and Macintosh compatibility allows
for flexible system support with multiple
resolutions
Exclusive OptiClear®screen surface virtu-
ally eliminates glare while enhancing focus
and contrast and preventing dust buildup
Fine dot pitches create crisp, easy-to-read
text and graphics
NEC quality and reliability provide peace
of mind with a 3-year limited parts and labor
warranty and 24/7 customer service and
technical support
NEC-Mitsubishi Accusync Revise Liska + Associates 459-085 3.2.04 Revision 0
120
21"
(20" VIS)
0.25/0.22mm horizontal
1600 x 1200 @ 76 Hz
30–98 kHz

NEC AccuSync 500, 700, 700M, 750F, 900, 120 Specifications
AS900
18"/45.7 cm
19" CRT
FST(Shadow Mask) CRT
30-98 kHz
50-160 Hz
203 MHz
640 x 480 @ 50-160 Hz
800 x 600 @ 50-153 Hz
832 x 624 @ 50-144 Hz
1024 x 768 @ 50-105 Hz
1152 x 870 @ 50-105 Hz
1280 x 1024 @ 50-89 Hz
1600 x 1200 @ 50-76 Hz
1600 x 1200 @ 76 Hz
1280 x 1024 @ 85 Hz
On Screen Manager(OSM),
Plug and Play protocol
(DDC2B), 2 color presets,
parallelogram, pincushion,
trapezoid, tilt, brightness,
contrast, Intelligent Power
Manager(IPM), Reduced
Magnetic Field Technology,
AccuColor controls, FullScan
Capability
More than 16 million
100-240 VAC, 50-60 Hz,
2.0 A
83 W
None
15 pin d-Sub
17.6 x 17.9 x 18.5"
448 x 454 x 470mm
(w/stand)
40.8 lbs/18.5 kg(w/stand)
47.4 lbs/21.5 kg(w/carton)
Yes(1.5m)
UL, C-UL, TUV-GS, CE, FCC,
DOC, DHHS, PTB, MPR-II,
Energy Star, TUV-Ergo
3 years parts and labor
24hours/7 days
AS750F
16"/40.6 cm
17" CRT
FCDT(Flat Mask) CRT
30-71 kHz
50-120 Hz
110 MHz
640 x 480 @ 50-120 Hz
800 x 600 @ 50-110 Hz
832 x 624 @ 50-106 Hz
1024 x 768 @ 50-87 Hz
1152 x 870 @ 50-77 Hz
1280 x 1024 @ 50-66 Hz
1280 x 1024 @ 66 Hz
1024 x 768 @ 85 Hz
On Screen Manager(OSM),
Plug and Play protocol
(DDC2B), 2 color presets,
parallelogram, pincushion,
trapezoid, tilt, brightness,
contrast, Intelligent Power
Manager(IPM), Reduced
Magnetic Field Technology,
AccuColor controls, FullScan
Capability
More than 16 million
100-240 VAC, 50-60 Hz,
2.0 A
83 W
None
15 pin d-Sub
15.7 x 15.9 x 16.9"
400 x 404 x 429mm
(w/stand)
34.2 lbs/15.5 kg(w/stand)
40.8 lbs/18.5 kg(w/carton)
Yes(1.5m)
UL, C-UL, TUV-GS, CE, FCC,
DOC, DHHS, PTB, MPR-II,
Energy Star, TUV-Ergo
3 years parts and labor
24hours/7 days
AS500
14"/35.5 cm
15" CRT
FST(Shadow Mask) CRT
30-71 kHz
50-120 Hz
110 MHz
640 x 480 @ 50-120 Hz
800 x 600 @ 50-110 Hz
832 x 624 @ 50-106 Hz
1024 x 768 @ 50-87 Hz
1152 x 870 @ 50-77 Hz
1280 x 1024 @ 50-66 Hz
1280 x 1024 @ 66 Hz
1024 x 768 @ 85 Hz
On Screen Manager(OSM),
Plug and Play protocol
(DDC2B), 2 color presets,
parallelogram, pincushion,
trapezoid, tilt, brightness,
contrast, Intelligent Power
Manager(IPM), Reduced
Magnetic Field Technology,
AccuColor controls, FullScan
Capability
More than 16 million
100-240 VAC, 50-60 Hz,
1.5 A
63 W
None
15 pin d-Sub
14.2 x 15.3 x 15.4"
360 x 389 x 392mm
(w/stand)
27.3 lbs/12.4 kg(w/stand)
32.2 lbs/14.6 kg(w/carton)
Yes(1.5m)
UL, C-UL, TUV-GS, CE, FCC,
DOC, DHHS, PTB, MPR-II,
Energy Star, TUV-Ergo
3 years parts and labor
24hours/7 days
AS700
16"/40.7 cm
17" CRT
FST(Shadow Mask) CRT
30-71 kHz
50-120 Hz
110 MHz
640 x 480 @ 50-120 Hz
800 x 600 @ 50-110 Hz
832 x 624 @ 50-106 Hz
1024 x 768 @ 50-87 Hz
1152 x 870 @ 50-77 Hz
1280 x 1024 @ 50-66 Hz
1280 x 1024 @ 66 Hz
1024 x 768 @ 85 Hz
On Screen Manager(OSM),
Plug and Play protocol
(DDC2B), 2 color presets,
parallelogram, pincushion,
trapezoid, tilt, brightness,
contrast, Intelligent Power
Manager(IPM), Reduced
Magnetic Field Technology,
AccuColor controls, FullScan
Capability
More than 16 million
100-240 VAC, 50-60 Hz,
2.0 A
73 W
None
15 pin d-Sub
15.7 x 15.6 x 16.5"
400 x 395 x 420mm
(w/stand)
31.1 lbs/14.1 kg(w/stand)
36.6 lbs/16.6 kg(w/carton)
Yes(1.5m)
UL, C-UL, TUV-GS, CE, FCC,
DOC, DHHS, PTB, MPR-II,
Energy Star, TUV-Ergo
3 years parts and labor
24hours/7 days
AS700M
16"/40.7 cm
17" CRT
FST(Shadow Mask) CRT
30-71 kHz
50-120 Hz
110 MHz
640 x 480 @ 50-120 Hz
800 x 600 @ 50-110 Hz
832 x 624 @ 50-106 Hz
1024 x 768 @ 50-87 Hz
1152 x 870 @ 50-77 Hz
1280 x 1024 @ 50-66 Hz
1280 x 1024 @ 66 Hz
1024 x 768 @ 85 Hz
On Screen Manager(OSM),
Plug and Play protocol
(DDC2B), 2 color presets,
parallelogram, pincushion,
trapezoid, tilt, brightness,
contrast, Intelligent Power
Manager(IPM), Reduced
Magnetic Field Technology,
AccuColor controls, FullScan
Capability
More than 16 million
100-240 VAC, 50-60 Hz,
2.0 A
73 W
None
15 pin d-Sub
17.7 x 15.4 x 16.3"
450 x 392 x 415mm
(w/stand)
33.5 lbs/15.2 kg(w/stand)
40.1 lbs/18.2 kg(w/carton)
Yes(1.5m)
UL, C-UL, TUV-GS, CE, CB,
FCC, DOC, DHHS, PTB, MPR-II,
Energy Star, TUV-Ergo
3 years parts and labor
24hours/7 days
AS120
20"/50.8 cm
21" CRT
FST(Shadow Mask) CRT
30-98 kHz
55-160 Hz
208 MHz
640 x 480 @ 60-188 Hz
800 x 600 @ 55-152 Hz
832 x 624 @ 55-144 Hz
1024 x 768 @ 55-119 Hz
1152 x 870 @ 55-105 Hz
1280 x 1024 @ 55-89 Hz
1600 x 1200 @ 55-76 Hz
1600 x 1200 @ 76 Hz
1280 x 1024 @ 85 Hz
On Screen Manager(OSM),
Plug and Play protocol
(DDC2B), 2 color presets,
parallelogram, pincushion,
trapezoid, tilt, brightness,
contrast, Intelligent Power
Manager(IPM), Reduced
Magnetic Field Technology,
AccuColor controls, FullScan
Capability
More than 16 million
100-240 VAC, 50-60 Hz,
2.0 A
140 W
None
15 pin d-Sub
19.6 x 20.1 x 20.2"
498 x 510 x 512mm
(w/stand)
66.1/30.0 kg(w/stand)
77.0 lbs/35.0 kg(w/carton)
Yes(1.8m)
UL, C-UL, TUV-GS, FCC, DHHS,
CRA, CSA, MPR-II,
EnergyStar
3years parts and labor
24hours/7 days
Model
Display
Viewable Image Size
Notes
CRT Type
Synchronization Range
Horizontal
Vertical
Pixel Clock
Resolutions Supported
Maximum Resolution
Recommended Resolution
Additional Features
Display Colors
Power Supply
Power Consumption
USB Capability
Input
Dimensions(W x H x D)
Weight
Net Weight
Gross Weight
SignalCable
Regulatory Approvals
LimitedWarranty
Technical Support
OSM, OptiClear and ErgoDesign are registered trademarks and ClearFlat, FullScan, AccuSync,
Reduced Magnetic Field, IPM, and IntelliBase are trade marks of NEC Display Solutions. MAC
and Macintosh a reregistered trademarks of Apple Computer, Inc. ENERGY STAR is a U.S.
registered trademark. All other brand or product names are trademarks or registered
trademarks of their respective holders. Product specifications subject to change.
©2005 NEC Display Solutions of America, Inc. All rights reserved.
Item No. ASCRT-1 3/05 ver.4.
500 Park Boulevard, Suite 1100
Itasca, Illinois 60143
866-NEC-MORE
www.necdisplay.com
NEC Display Solutions
