NEC pmn User manual

MultiSync LCD400
MultiSync LCD2000
User’s Manual

Declaration of the Importer
We hereby certify that the color monitors
MultiSync LCD400 (LA-1421JMW)
MultiSync LCD2000 (LA-2031JMW)
are in compliance with
Council Directive 73/23/EEC:
- EN 60950
Council Directive 89/336/EEC:
- EN 55022
- EN 61000-3-2
- EN 61000-3-3
- EN 50082-1
(IEC 801-2)
(IEC 801-3)
(IEC 801-4)
and marked with
NEC Europe Ltd. Ismaning Office
Steinheilstraße 4-6
D-85737 Ismaning, Germany

Safety Instruction
Caution:
When operating the LA-1421JMW/LA-2031JMW with a 220-240V AC
power source in Europe except UK, use the power cord provided with
the monitor.
In UK, a BS approved power cord with moulded plug has a Black (five
Amps) fuse installed for use with this equipment. If a power cord is not
supplied with this equipment please contact your supplier.
When operating the LA-1421JMW/LA-2031JMW with a 220-240V AC
Power source in Australia, use the power cord provided with the
monitor.
For all other cases, use a power cord that matches the AC voltage of the
power outlet and has been approved by and complies with the safety
standard of your particular country.
IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of
International Business Machines Corporation.
Apple and Macintosh are registered trademarks of Apple Computer Inc.
Microsoft and Windows are registered trademarks of the Microsoft Corporation.
NEC is a registered trademark of NEC Corporation. ErgoDesign, IPM, OSM, ColorControl,
OptiClear, CROMACLEAR and Advanced Digital Control System are trademarks of NEC Home
Electronics, Ltd.
MultiSync is a registered trademark of NEC Technologies, Inc in U.S., and of NEC Home
Electronics, Ltd in Canada, U.K., Germany, France, Spain, Italy, Austria, Benelux,
Switzerland, Denmark, Finland, Norway and Saudi Arabia.
All other trademarks or registered trademarks are property of their respective owners.

For the Customer to use in U.S.A or Canada.
Canadian Department of Communications Compliance
Statement
DOC: This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du
Règlement sur le matériel brouiller du Canada.
C-UL: Bears the C-UL Mark and is in compliance with Canadian
Safety Regulations according to C.S.A. C22.2 #950.
Ce produit porte la marque ‘C-UL’ et se conforme aux règlements de
sûrele Canadiens selon CAN/CSA C22.2 No. 950.
FCC Information
1. Use the attached specified cables with the LA-1421JMW and
LA-2031JMW color monitors so as not to interfere with radio and
television reception.
(1) Please use the Shielded power cable or equivalent to ensure
FCC compliance.
(2) MultiSync LCD400: Shielded video signal cable.
(3) MultiSync LCD2000: Shielded 15-pin VGA to BNC cable.
Use of other cables and adapters may cause interference with
radio and television reception.
2. This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy, and, if not installed and used in accordance with the
instruction, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and
receiver.
-Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-Consult your dealer or an experienced radio/TV
technician for help.
If necessary, the user should contact the dealer or an
experienced radio/television technician for additional
suggestion. The user may find the following booklet, prepared
by the Federal Communications Commission, helpful: “How
to Identify and Resolve Radio-TV Interference Problems.”
This booklet is available from the U.S. Government Printing
Office, Washington, D.C., 20402, Stock No.
004-000-00345-4.

English

Introduction to the NEC MultiSync LCD400/LCD2000
Congratulations on your purchase of the NEC MultiSync LCD400/
LCD2000 true colour monitor!
Analog Advantage
Capable of displaying unlimited colours in a continuous spectrum,
providing a truer representation of colour. The monitor’s high contrast
LCD enhances colour vibrancy and improves focus with no geometric
distortion.
Wider Compatibility
Because the MultiSync LCD monitor is analog through and through, it
does not require special analog to digital display or interface cards but
can accept RGB input directly.
Reduced Footprint
Provides the ideal solution for environments requiring superior image
quality but with size and weight limitations. The monitor’s small
footprint and low weight allow it to be moved or transported easily from
one location to another.
Colour Control system
Allows you to adjust the colours on your screen and customize the
colour accuracy of your monitor to a variety of standards.
OSM (On-Screen Manager) Controls
Allows you to quickly and easily adjust all elements of your screen
image via simple to use on-sreen menus.
Introduction to the NEC MultiSync LCD400/LCD2000 E - 1

ErgoDesign Features
Enhance human ergonomics to improve the working environment,
protect the health of the user and save money. Examples include OSM
controls for quick and easy image adjustments, tilt/swivel base for
preferred angle of vision small footprint and compliance with MPRII
guidelines for lower emissions.
Plug and Play (MultiSync LCD400 only)
The Microsoft solution with the Windows 95 operating system
facilitates setup and installation by allowing the monitor to send its
capabilities (such as screen size and resolutions supported) directly to
your computer, automatically optimizing display performance.
IPM (Intelligent PowerManager) System
Provides innovative power-saving methodes that allow the monitor to
shift to a lower power consumption level when on but not in use, saving
two-thirds of your monitor energy cost, reducing emissions and
lowering the air conditioning cost of the workplace.
Multiple frequency Technology
Automatically adjusts monitor to the display card’s scanning frequency,
thus displaying the resolution required.
FullScan Capability
Allows you to use the entire screen area in most resolutions,
significantly expanding image size.
E - 2 Introduction to the NEC MultiSync LCD400/LCD2000

Contents of Package
Your new MultiSync LCD monitor box should contain the following:
–NEC MultiSync LCD400 (Model LA-142lJMW)/
NEC MultiSync LCD2000 (Model LA-203lJMW).
–AC power cable.
–Video signal cable – 15 pin mini D-SUB to 15 pin mini D-SUB
(LCD400)/
Video signal cable – 15 pin mini D-SUB to BNC (LCD2000).
–User’s manual.
Remember to save the original box and packing materials to transport or
ship this monitor.
Contents of Package E - 3

Recommended Use
For optimum performance, please note the following when setting up
and using the MultiSync LCD400/LCD2000 colour monitor:
•The optimum monitor position is facing away from direct
sunlight.
•Allow adequate ventilation around the monitor so that heat
can properly dissipate.
•Do not place any heavy objects on the power cord. Damage
to the cord may cause shock or fire.
•Use the monitor in a clean and dry area.
•Handle with care when transporting. Save packaging for
transporting.
•The power cable connector is the primary means of detaching
the system from the power supply. The monitor should be
installed close to a power outlet which is easily accessible.
•Clean the LCD monitor surface with a lint-free, non-abrasive
cloth. Avoid using any cleaning solution, glass cleaner or
tissue paper.
•For optimum performance, allow 20 minutes for warm-up.
•Avoid displaying fixed patterns on the monitor for extremely
long periods of the time to avoid after-image effects.
•Avoid applying pressure to the LCD monitor surface.
E - 4 Recommended Use

CORRECT PLACMENT AND ADJUSTMENT OF THE MONITOR
CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK
THE FOLLOWING WHEN YOU POSITION THE MONITOR:
•Adjust the monitor height so that thr top of the screen is at or
slightly below eye level. Your eyes should look slightly
downward when viewing the middle of the screen.
•Position your monitor no closer than 40 cm and no further
away than 70 cm from your eyes. The optimal distance of
MultiSync LCD400 is 53 cm, MultiSync LCD2000 is 61 cm.
•Rest your eyes periodically by focusing on an object at least
6 m away.
•Position the monitor at a 90° angle to windows and other light
sources to minimize glare and reflections. Adjust the monitor
tilt so that ceiling lights do not reflect on your screen.
•If reflected light makes it hard for you to see your screen, use
an anti-glare filter.
•Adjust the monitor’s brightness and contrast control to
enhance readability.
•Use a document holder placed close to the screen.
•Position whatever you are looking at most of the time (the
screen or reference material) directly in front of you to
minimize turning your head while you are typing.
•Get regular eye checkups.
Recommended Use E - 5

Installation
Connection to your Personal Computer
The MultiSync LCD400/LCD2000 true colour monitor complements PC
compatible computers. Your system has one of two configurations:
–the video controller is built into the computer.
–the video controller is in the form of a display card (sometimes
referred to as graphics card, video adapter or graphics board).
Both configurations have a video connector (or a CRT PORT on laptop
computers). If you are not sure which connector is the video connector,
refer to your computer or display card manual.
To attach the monitor to your system, follow these instructions:
1. Turn off the power to the monitor and computer.
2. If necessary, install the display card. For more information
about installing your card, refer to the display card manual.
3. Connect the 15-pin mini D-SUB of the appropriate signal
cable to the connector of the display card in your computer.
Tighten all srews.
4. For the LCD400:Connect the 15-pin mini D-SUB of the
video signal cable to the appropriate connector on the back of
the monitor.
For the LCD2000:Connect the BNC cable to the appropriate
connectors on the back of the monitor. Connect the red BNC
cable to the BNC connector on the monitor labelled R, the green
BNC cable to the BNC connector on the monitor labelled
G/Sync, the blue BNC cable to the BNC connector on the
monitor labelled B. If you have a fourth BNC connector
(Composite Sync), connect it to the BNC connector on the
monitor labelled H/CS. If you have a fifth BNC connector
(Vertical Sync), connect it to the BNC connector on the monitor
labelled VS.
E - 6 Installation

Note: Incorrect cable connections may result in irregular operation,
damage display quality/components of LCD module and/or shorten the
module’s life.
5. Connect one end of the power cable to the MultiSync LCD
monitor and the other end to the power outlet.
6. Turn on the monitor and the computer.
7. This completes the installation.
If you have any problems, please refer to the Troubleshooting section of
this manual.
Connection to your Personal Computer (Macintosh)
With the Macintosh cable adapter, the MultiSync LCD400/LCD2000
colour monitor is compatible with the Macintosh family of computers.
You will connect your MultiSync colour monitor one of two ways to
your Macintosh computer:
–On-board video port
–NuBus/PCI/PDS display card
Both configurations should have the same style video connector. If you
are not sure which port is the monitor connector, please reference your
computer or display card manual.
To attach the monitor to your system, follow these instructions:
1. Turn off the power to your MultiSync LCD monitor and
Macintosh.
2. If necessary, install the display card. For more information on
this installation, reference the display card manual.
3. Connect the MultiSync LCD400 or MultiSync LCD2000
Macintosh cable adapter to the computer. Attach the 15-pin
mini D-SUB end of the appropriate signal cable to the
Macintosh cable adapter. Tighten all srews.
Installation E - 7

4. For the LCD400:Connect the 15-pin mini D-SUB of the
video signal cable to the appropriate connector on the back of
the monitor.
For the LCD2000:Connect the BNC cable to the appropriate
connectors on the back of the monitor. Connect the red BNC
cable to the BNC connector on the monitor labelled R, the
green BNC cable to the BNC connector on the monitor
labelled G/Sync, the blue BNC cable to the BNC connector
on the monitor labelled B. If you have a fourth BNC
connector (Composite Sync), connect it to the BNC connector
on the monitor labelled H/CS. If you have a fifth BNC
connector (Vertical Sync), connect it to the BNC connector
on the monitor labelled VS.
Note: Incorrect cable connections may result in irregular operation,
damage display quality/components of LCD module and/or shorten the
module’s life.
5. Connect one end of the power cable to the MultiSync LCD
monitor and the other end to the power outlet.
6. Turn on the monitor and the computer.
7. This completes the installation.
If you have any problems, please refer to the Troubleshooting section of
this manual.
Please contact your local dealer for information about the Mac Adapter.
Power Macintosh 6100/60 and 66 users need to use the Apple HDI-45
cable adapter and Powerbook users need to use the Apple VID-14 cable
adapter in conjunction with the appropriate MultiSync Macintosh cable
adapter when connecting a MultiSync LCD monitor.
E - 8 Installation

Controls
OSM Controls
The OSM controls on the front of the monitor provide the following
functions:
Control Main Menu Sub-Menu
EXIT Exits the OSM controls. Exits to the OSM controls
main menu.
CONTROL ▲/▼Moves the highlighted
area up/down to select one
of the controls.
Moves the highlighted
area up/down to select
one of the controls
CONTROL -/+Has no function. Moves the bar in the +or
-direction to increase or
decrease the adjustment.
PROCEED Proceeds to selected menu
choice (indicated by the
highlighted area).
Activates Auto Adjust
feature. In Display Mode,
opens additional window
RESET: The
currently highlighted
control to the factory
setting.
Resets all the controls
within the highlighted
menu.
Resets the highlighted
control.
NOTE: When RESET is pressed, a warning window will appear
allowing you to cancel the reset function.
Controls E - 9

Brightness and Contrast
Brightness: Adjust the overall image and background screen brightness.
Contrast: Adjust the image brightness in relation to the background.
Auto Adjust Contrast: Corrects the image displayed for non-standard
video inputs.
Auto Adjust
Allows automatic adjustment of the position and image adjust control.
Position
Control horizontal and vertical image position within the display area of
the LCD.
Auto Adjust Position: Automatically sets the horizontal and vertical
image position within the display area of the LCD.
Image Adjust
Coarse: Adjust the horizontal size by increasing or decreasing the
Coarse total.
Fine: Improves focus, clarity and image stability by increasing or
decreasing the Fine total.
NOTE: The Image Adjust Fine control must be used to complete the
setup of your MultiSync LCD2000 monitor.
Auto Adjust Coarse/Fine: (MultiSync LCD400 monitor only) Auto-
matically adjusts the Coarse or Fine settings.
Auto Adjust Coarse: (MultiSync LCD2000 monitor only) Auto-
matically adjusts the Coarse setting.
Color Control System
Colour presets 1 through 5 selects the desired colour setting. Each
colour setting is adjusted at the factory to the stated degree Kelvin. If a
setting is adjusted, the name of the setting will change from degree
Kelvin to Custom. Color Gain (Red, Green, Blue): Increases or
decreases red, green or blue colour portion depending upon which is
selected. The change in colour will appear on screen and the direction
(increase or decrease) will be shown by the colour bars.
E - 10 Controls

OSM Location
You can choose where you would like the OSM control image to appear
on your screen. Selecting OSM Location allows you to manually adjust
the position of the OSM control menu left, right, up or down.
OSM Turn Off Time
The OSM control menu will stay on as long as it is in use. In the OSM
Turn Off Time submenu, you can select how long the monitor waits
after the last touch of a button to shut off the OSM control menu. The
preset choices are 10, 20, 30, 60 and 120 seconds.
OSM Lock Out
This control completely locks out access to all OSM control functions.
When attempting to activate OSM controls while in the lock out mode, a
screen will appear indicating the OSM controls are locked out. To
activate the OSM Lock Out function, press PROCEED, then ▲and
hold down simultaneously. To de-activate the OSM Lock Out, press
PROCEED,then ▲and hold down simultaneously.
Display Mode
Display Mode provides information about the current resolution display
and technical data including the preset timing being used and the
horizontal and vertical frequencies.
NOTE: Display Mode should only be used if a resolution is not recognized
by the monitor. The user can change to the appropriate resolution by entering
the Display Mode sub-menu and selecting the corresponding option.
Language Select
OSM control menus are available in six languages.
Factory Preset
Selecting Factory Preset allows you to reset all OSM control settings
back to the factory settings. The RESET button will need to be held
down for several seconds to take effect, individual settings can be reset
by highlighting the control to be reset and pressing the RESET button.
Controls E - 11

Specifications
MultiSync LCD400
Display 35.8 cm (14.1 inch) viewable image size; 1024 x 768
native resolution (Pixel Count); active matrix;
thin film transistor (TFT); liquid crystal display (LCD);
0.28 mm dot pitch; XtraView™ technology; 180 cd/m²
white luminance, typical; 150:1 contrast ratio, typical
Input Signal Video Analog 0.7 Vp-p 75 Ω
Sync Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative)
(TTL Level)
Sync on Green video (Positive) 0.7
Vp-p and sync. Negative 0.3 Vp-p
Display Colours Analog Input: Unlimited number of colours
(Depends on the graphics board)
Synchronisation
Range Horizontal 24.8 kHz to 60.0 kHz (Automatically)
Vertical 56.2 Hz to 85.1 Hz (Automatically)
Resolutions
Supported 720 x 400: VGA text* 640 x 480 at 60 Hz to 85 Hz*
800 x 600 at 56 Hz to 85 Hz*
832 x 624 at 75 Hz*
1024 x 768 at 60 Hz to 75 Hz**
Active Display
Area*** Horizontal 286 mm
Vertical 214 mm
Power supply AC 100-120 V / 220-240 V 50/60 Hz
Current Rating 0.9 A @ 100-120 V /
0.5 A @ 220-240 V
Dimensions W x H x D 357 x 362 x 168 mm
Weight 5.2 kg
E - 12 Specifications

Operating
Environmental
Considerations
Temperature 5° C to + 35° C
Humidity 30% to 80%
Storage
Environmental
Considerations
Temperature -10° C to + 60° C
Humidity 10% to 85%
* Interpolated Resolutions: when resolutions are shown that are lower than the pixel
count of the LCD module, text my appear chappy or lines may appear to be bold. This is
normal and necessary for all current flat panel technologies, each dot on the screen is
actually one pixel, so to expand resolutions to full screen, an interpolation of the
resolution must be done. When the interpolated resolutions is not an exact multiple of
the native resolution, the mathematical interpolation necessary may cause some lines to
appear thicker than others.
** NEC cites recommend resolutions at 60 Hz for optimal display performance.
*** Active display area is dependent upon the signal timing.
Technical specifications are subject to change without notice.
Specifications E - 13
