PRODUCT OVERVIEW
NEC Express5800/120Rf-2
is a system designed to deliver scaleab
le
p
erformance to data centres, workgroup environments or remote site
s,
for which space limitation is a prime consideration
.
It is especial
ly
intended to ASPs/ISPs for
h
osting Internet and Web applications, and t
o
g
eneral corporations willing to consolidate their applications o
r
i
nfrastructure services. All these customers want to be able to grow an
d
deploy additional servers in the same amount of space.
NEC Express5800/120Rf-2 is housed in a compact 2U rack-
optimized
chassis, which allows up to 21 servers in an industry-
s
tandard 19” 42
U
rack. Based on the E7501 chipset from Intel supporting 533
MHz Front
Side Bus and 3-peer PCI, the Express5800/120Rf-2 takes full benefi
ts
of the latest Xeon processors with FC-mPGA2 packaging and high-
performance DDR266 SDRAM memories.
NEC Express5800/120Rf-2 is a bi-processor design supporting Xeon
processors from 2.8BGHz with 512KB L2 cache up to 3.20GHz
with
1MB L3 cache. The Express5800/120Rf-2 offers up to 12
GB SDRAM
memory (6 DIMM sockets) with ECC protection and 6 free PCI slots
for optimal expandability. Embedded Ultra 320 SCSI controller
an
d
integrated auto-sensing 10/100/1000
M
bps Ethernet also guarante
e
outstanding power and performance.
NEC Express5800/120Rf-
2
provides high availability features such a
s
hot-swap power supplies
a
nd hard disk drives to meet the demand o
f
b
usiness critical applications. Despite its small 2U form factor, th
e
Express5800/120Rf-2 can support up to 7 hot-swap drives (1,025.5
GB
max) with Ultra 320 technology for transfer rates up to 320MB/s.
Designed with simplicity for easy installation and manageability, NEC
Express5800/120Rf-2 comes standard with NEC EXPRESSBUILDER
set-up and configuration software and NEC ESMPRO
m
anagemen
t
software. In addition, it incorporates unique integrated
remote
management capabilities
providing remote emergency access an
d
c
ontrol of server resources (via LAN or modem connection) in an
y
situation.
Designed to run demanding and business critical applications in space-
conscious environments, the Express5800/120Rf-2 is
the high density
e-business rack server your growing business can depend on.
The
HIGH DENSITY
E-business Rack Server
NEC Express5800/

Product Guide – NEC Express5800/120Rf-2
October, 2003
4
TARGET AUDIENCES
End User Base Configuration Price
Peer to Peer, Low-end File, Print
File, Low-end database
High
-
end File, Database,
Multi-user host, Low-End Computing
Intensive Computing,
Transaction processing
Key Customer Needs
•
Reliability & Security
•
High Availability
•
Manageability
•
System Performance
•
Serviceability
•
Availability
•
Scaleability
•
Manageability
•
I/O Throughput
•
Price/Performance
•
Price
•
Scaleability
•
Manageability
•
Basic performance
•
Lowest Cost
110Eg
120Lg
NEC Express5800 Servers
120Mf
180Rd-4
120Rd-1
120Ef
120Rf-2
140Rc-4
3 layer Architecture
Mobile
Internet
Internet
PC
Firewall
Web
Mail
Cache
Security
Application
File
Backup
Database
Front-end server layer
Application server layer Back-end server layer
Product Family 1Way model
Blade Server
Appliance Server
2/4Way model
4/8Way model
Ft server
Storage
120Rf-2

Product Guide – NEC Express5800/120Rf-2
October, 2003
5
HIGHLIGHTS
* Standard HDD bays are six. When standard FDD/CD-ROM is removed, 7 HDD can be
mounted.
Up to two Xeon processors
(2.80BGHz/3.06GHz
/3.20GHz
)
533MHz Front Side Bus (FSB)
Up to 1,025.5GB (7x 146.5GB*) hot-swap
Embedded dual-channel Ethernet
(1000BASE
-
Tx 2)
6x Expansion Slots
(64-bit/100MHz PCI-X)
Slim rack mount chassis (2U)/
Full lockable front bezel
2 CPU
533 266
LAN
Connectors
2U design Key lock
Model 120Rf-2 CPU Memory
N-code

Product Guide – NEC Express5800/120Rf-2
October, 2003
6
KEY PRODUCT FEATURES & USER BENEFITS
Next-generation Xeon Processing and Enhanced System Architecture
NEC Express5800/120Rf-2 is built to take full advantage of the latest Xeon processors from
2.80BGHz up to 3.20GHz. These processors are packaged in the new FC-mPGA2 form factor, a
603-pin socket version of the Xeon.
The design of NEC Express5800/120Rf-2 is built upon a 533MHz Front Side Bus (FSB), the
E7501 chipset from Intel and DDR266 SDRAM memory. The Intel Xeon processor for dual-
processing servers offers users several new system performance boosts, with the Intel Netburst
microarchitecture on Intel’s 0.13-micron manufacturing process, Hyper-Threading technology, a
larger cache size and the E7501 server chipset.
The Intel E7501 chipset supports DDR memory technology and is optimized for the Intel Xeon
processor. The new chipset will accelerate memory access to increase platform performance and
deliver new levels of performance for I/O intensive server applications.
This chipset also allows increased throughput and enhanced overall system performance through
the high-performance 533MHz FSB and full-speed 266MHz memory access.
The I/O subsystem of NEC Express5800/120Rf-2 is built on a dual peer PCI bus architecture
that provides concurrency of data transfers between the different high speed I/O channels and
CPU or memory. I/O traffic is balanced as follows:
- First PCI bus (32-bit): IDE, graphics and I/O ports
- Second PCI bus (64-bit): Dual-port LAN and 3x 64-bit full-height PCI slots
- Third PCI bus (64-bit): Ultra 320 SCSI channels and 3x 64-bit low-profile PCI slots
Improved Memory Architecture
NEC Express5800/120Rf-2 offers 6 DIMM sockets for industry-standard 128MB, 256MB,
512MB, 1GB or 2GB SDRAM DDR266 DIMM. The Express5800/120Rf-2 allows easy
expansion of system’s capabilities to memory-intensive environments (scalability up to 12GB)
and comes standard with 9-bit parity/ECC 266MHz SDRAM for maximum data integrity.
High-performance Ultra 320 Disk Drives and Flexible Storage Configurations
NEC Express5800/120Rf-2 supports the latest disk drives with Ultra 320 SCSI technology
(10Krpm or 15Krpm), giving data rates of up to 320MB/s for maximum throughput.
Disk bay Device bay (-> Disk bay)
The Express5800/120Rf-2 includes a 3.5-
inch diskette drive, a CD-ROM drive, six
hot-swap SCSI hard disk drive bays, and
removable media device bay.
The hot-swap SCSI hard disk drive bays
support up to seven 1-inch SCSI hard disk
drives that can be swapped in or out of the
system without powering it down, if RAID
functionality is configured in the system.
Xeon TM processor

Product Guide – NEC Express5800/120Rf-2
October, 2003
7
Integrated Ultra 320 I/O Controller
NEC Express5800/120Rf-2 system board features an integrated dual-channel SCSI
controller providing Ultra 320 SCSI interfaces for the support of Ultra 320 hard disk
drives and SCSI media devices (DAT, AIT).
The system board also includes a single channel EIDE controller providing support for the
internally mounted CD-ROM.
Multiple RAID Options
NEC Express5800/120Rf-2 comes with a complete range of optional high-performance Ultra 320
RAID boards. These boards give top levels of performance, maximum reliability and fault
tolerance when running demanding server applications.
•The 64bit RAID controller features 2x Ultra 320 SCSI channels, Intel GC80303 processor
and 128MB of cache with battery backup unit.
•The 64bit RAID controller features 1x Ultra 320 SCSI channel, Intel GC80302 processor and
64MB of cache without battery backup unit. It is possible to add optional battery backup unit.
Embedded Auto-sensing 10/100/1000Mbps Ethernet
NEC Express5800/120Rf-2’s system board includes a dual-channel gigabit network interface
controller based on the Intel 82546EB. The 82546EB is a highly integrated PCI LAN controller
in a 21 mm2PBGA package. The controller supports 10/100/1000 operation on both the channels
and it supports alert-on-LAN functionality.
The 82546EB controller supports the following features:
-64-bit, 100MHz PCI-X interface
-Integrated IEEE 802.3 10Base-T, 100BASE-TX, and 1000Base-T compatible PHY
-IEEE 820.3u auto-negotiation support
-Chained memory structure similar to the 82559, 82558, 82557 and 82596
-Full duplex support at both 10 Mbps, 100Mbps and 1000Mbps operation
-Low power +3.3 V device
The auto-sensing PRO/100+ Server Adapter from Intel can also be supported on NEC
Express5800/120Rf-2. By installing multiple PRO/100+ boards, high-availability (load balancing,
fault tolerance) and top performance features are provided for the most demanding networking
environments.

Product Guide – NEC Express5800/120Rf-2
October, 2003
8
Integrated Video
NEC Express5800/120Rf-2 has an integrated ATI Rage XL PCI graphics accelerator with 8 MB
of video SDRAM. The embedded SVGA video subsystem supports:
- Resolution up to 1600 x 1200 under 2D and 1024 x 768 under 3D
- CRT and LCD monitors up to 100Hz vertical refresh rate
6 Expansion Slots
The server’s expansion capabilities meet the needs of workgroup and department servers for high-
performance I/O by providing 6 free 64bit PCI-X slots including 3x LowProfile.
2U Rack-Optimized Design
NEC Express5800/120Rf-2’s compact and practical 2U
packaging is ideal for space-constrained environments. Up to
22 systems can fit in an industry-standard 19-inch 44U
rackframe, occupying a limited floor space. In addition, the
chassis allows tool-free access, simplifying upgrades even more.
Finally, NEC Express5800/120Rf-2 is part of a comprehensive
portfolio of rackable NEC Express5800 servers, rack
enclosures and accessories for optimal flexibility.
External Device Connectors
The external I/O connectors of NEC Express5800/120Rf-2 provide support for a PS/2-
compatible mouse and a keyboard, connectors for VGA monitor, two serial port connectors
(RJ-45 x1, D-sub 9pin x1), three USB connections and a 68-pin Wide SCSI connector.

Product Guide – NEC Express5800/120Rf-2
October, 2003
9
Redundant Hot-Swap Power Supplies
NEC Express5800/120Rf-2 supports redundant hot-swap power supplies to ensure system
operation even if one of the power supplies fails. The system comes standard with one 500W
power supply and a second one is optional for redundancy.
Each power supply has auto-ranging input 50/60Hz, automatic voltage sensing (100-240V) and
comes with its own AC cord for better reliability.
Optional Backup Devices
NEC Express5800/120Rf-2 can accommodate optional high-performance DAT tape options for
back-up: DDS3 (12/24GB) and DDS4 (20/40GB) and AIT tape options for back-up: AIT-1A
(25GB/35GB), AIT-2 (50GB) and AIT-3 (100GB).
Operating Environments
NEC Express5800/120Rf-2 is certified for the following NOS: Windows 2000 Server / Advanced
Server; Windows Server 2003 Standard Edition/Enterprise Edition and Red Hat Linux.
Power supply slot 1 Power supply slot 2
AC inlet for
power supply slot 1
AC inlet for
power supply slot 2
AC POWER lamp

Product Guide – NEC Express5800/120Rf-2
October, 2003
10
NEC ESMPRO Server Management Software
NEC Express5800/120Rf-2 includes NEC ESMPRO Server Management Software that allows
network administrators to monitor, control and manage NEC Express5800 servers and desktops
across a network from a management console or any PC with an Internet browser.
NEC ESMPRO enables:
•Local or remote management (via your network or the Web)
•Comprehensive real-time fault management
•Performance and load monitoring
•Broad configuration and asset management
It allows system administrators to optimise server operations through an
easy-to-use Windows-based graphical user interface.
NEC ESMPRO comes with SNMP agents for Microsoft Windows environments
accommodating all NEC Express5800 servers.
“Plug-in” applications are also available to comprehensively integrate NEC Express5800
systems with leading enterprise and network managers such as HP OpenView NNM for
Windows, Tivoli Enterprise, or CA Unicenter TNG.
To lower the Total Cost of Ownership even more, NEC Express5800/120Rf-2 features
hardware integrated remote management capabilities implemented through the Baseboard
Management Controller (BMC) and RomPilot (extended BIOS). This built-in solution provides
remote emergency access and control of server resources (via LAN or standard modem
connection) from a Management Workstation Application (MWA) allowing critical actions
such as remote power control, remote Event Log access or remote console redirection,
regardless of the state of the operating system or the network. In the past, this capability was
available only through an expensive emergency management ISA/PCI add-in card.
•Remote Control
•Remote Console
•Remote Drive
CPU
Main Memory
Hard Disk
Power Supply
Fan
Monitor
Express5800/100series
Baseboard
Management
Controller
Monitoring
Resource
ESMPRO
Management Workstation Application
•HW/SW inventory management
•Alert management
•Remote power-on/off
Failure
In case of trouble
Normal Condition

Product Guide – NEC Express5800/120Rf-2
October, 2003
11
NEC EXPRESSBUILDER System Installation Software
NEC Express5800/120Rf-2 systems come with NEC EXPRESSBUIDER set-up and configuration
software that provides a logical and comprehensive process for your server installation.
Degradation Feature
The degradation feature automatically isolates a failed DIMM or processor to assure continuous
operation of the server when the POST (Power on Self-Test, self-diagnosis program after power on)
detects such a DIMM or processor.
Remote Power-On Feature (Wake On LAN)
NEC Express5800/120Rf-2’s system board supports Wake-on-LAN. The remote power-on function
turns on the server through a network. It sends a special packet from the management computer to a
remote server to turn it on if the server is off-powered.
System Security and Front Bezel Removing
To help prevent unauthorized entry or use of the system, the system includes a full lockable front
bezel and Server Management software that monitors the front bezel intrusion switch.
•Security with mechanical locks and monitoring:
The front bezel contains a mechanical lock and an intrusion switch to
prevent access to the computer chassis. When the cover is opened, the
switch transmits an alarm signal to the system board, where server
management software processes the signal.
•Software Locks via the system set up utility
The BIOS set up utility provides a number of security features to prevent
unauthorized or accidental access to the system. Once the security measures are
enabled, access to the system is allowed only after the user enters the correct
password(s). For example:
- Enable the keyboard lockout timer so that the server requires a password to reactivate
the keyboard and mouse after a specified time-out period (1 to 120 min)
- Set and enable an administrative password
- Set and enable a user password
- Set secure mode to prevent keyboard or mouse input and to prevent use of the front
panel reset and power switches
- Disable writing to the diskette drive when secure mode is set.
2
1
A

Product Guide – NEC Express5800/120Rf-2
October, 2003
12
-
NEC Express5800/120Rf-2 FRONT VIEWS

Product Guide – NEC Express5800/120Rf-2
October, 2003
13

Product Guide – NEC Express5800/120Rf-2
October, 2003
14
NEC Express5800/120Rf-2 REAR VIEW

Product Guide – NEC Express5800/120Rf-2
October, 2003
15

Product Guide – NEC Express5800/120Rf-2
October, 2003
16
NEC Express5800/120Rf-2 INTERIOR VIEW

Product Guide – NEC Express5800/120Rf-2
October, 2003
17
NEC Express5800/120Rf-2 Mother Board

Product Guide – NEC Express5800/120Rf-2
October, 2003
18
NEC Express5800/120Rf-2 SYSTEM BLOCK DIAGRAM

Product Guide – NEC Express5800/120Rf-2
October, 2003
19
NEC Express5800/120Rf-2 TECHNICAL SPECS
FORM FACTOR
Tower-Rack convertible 2U Rack
PROCESSOR
Number of processors 2
Type Xeon 2.80GHz, 3.06GHz and 3.20GHz
Socket / slot type FC-mPGA2
Integrated L1 cache 8KB
L2/L3 cache Xeon 2.80GHz and 3.06GHz: 512KB L2 cache
Xeon 3.20GHz: 1MB L3 cache
ARCHITECTURE & MOTHERBOARD
Chipset Intel E7501
Processor front side bus (FSB) speed 533MHz
I2O ready Yes
MEMORY
Memory min / max / type 512MB / Up to 12GB / ECC SDRAM DDR266
Memory sockets 6 DIMMs
STORAGE
Optional Hard disk drives 36.3/73.2/146.5GB 10Krpm Ultra 320 SCSI
18.1/36.3/73.2GB 150Krpm Ultra 320 SCSI
Hard disk drive and media interface 2x Ultra 320
1x EIDE
RAID controller Optional
Maximum internal storage capacity 1,025.5GB (7x 146.5GB)
CD ROM drive Load on tray type, x24 speed
Floppy disk drive 1.44MB
Disk expansion unit Optional
BAYS
3.5" Media bays (total / free) 1 /1
3.5" Hot swap HDD bays 7x 1" (6x 1” + 1 x 1" in removing FDD/CD-ROM)
SLOTS
Bus slots 6 PCI-X (64-bit/100MHz)
Bus slots free All
VIDEO
Video controller Embedded PCI SVGA
Video memory std / max / type 8MB VRAM
*When a front bezel is included
NETWORK
Network interface controller Embedded 10/100/1000 Ethernet
SECURITY
Limited access to front panel / bays Yes / Yes
I/O PORTS
USB ports 3
Serial port 2
Parallel port -
Mouse / keyboard port 1
System Management On-board
Ethernet Port 2 (RJ45)
POWER SUPPLY
Power supply specs 500W w/ PFC
Power supply numbers (standard/max) 1/2
Hot-swap power supply Yes, with optional 2nd power supply
Maximum consumption power 800W
VENTILATION
Fan specifications Standard , Non-Redundant
PHYSICAL SPECIFICATIONS
Size (W x D x H) 483x613(660*)x88 mm
Weigh (standard/max) 16kg / 25kg
Operating constraints 10°C to 35°C, 20% to 80% RH
OS AND SOFTWARES
Operating system Windows 2000 Server/Advanced Server;
Windows Server 2003 Standard Edition /
Enterprise Edition,
Red Hat Linux
Management software NEC ESMPRO
Installation & configuration software NEC ExpressBuilder Setup and Configuration
software
REGULATORY & SAFETY
Regulatory compliance UL/FCC, C-Tick, Taiwan EMC

Product Guide - Express5800/120Rf-2
October,
2003
20
TRADEMARK ACKNOWLEDGMENT
All companies or products listed are trademarks or registered trademarks of their respective companies.
This document is for informational purposes only. THERE ARE NO WARRANTIES, EXPRESSED OR
IMPLIED, IN THIS SUMMARY.
Specifications are subject to change without notice.
Competitive product information is based on competitors’ current published specifications.
Developed by Client And Server Division
NEC Corporation
October, 2003
