NEC EXPRESS5800/R320c-E4
Configuration Guide
For Linux
Introduction
This document contains product and configuration information that will enable you to configure your system. The
guide will ensure fast and proper configuration of your NEC EXPRESS5800 server.
April 2015
Revision 2.0
NEC Corporation

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 2
Contents
TECHNICAL SPECIFICATION........................................................................................3
Key Features..........................................................................................................................................3
Specification..........................................................................................................................................3
EXTERNAL VIEWS .........................................................................................................5
Front and Rear Views ...........................................................................................................................5
Dimensions (mm)..................................................................................................................................7
CONFIGURATION DIAGRAM.........................................................................................8
SERVER CONFIGURATION ...........................................................................................9
1Base Models...................................................................................................................................9
22nd Processor................................................................................................................................9
3Memory ...........................................................................................................................................9
4Internal Hard Disk Drives............................................................................................................11
5Optical Drive.................................................................................................................................12
6PCI Card........................................................................................................................................12
6.1 LAN Controller.....................................................................................................................12
6.2 Fibre Channel / SAS Controller...........................................................................................12
7Other Add-in Components..........................................................................................................12
7.1Input Devices.......................................................................................................................12
8Add-on Components ...................................................................................................................13
8.1 17-inch LCD Console Drawer..............................................................................................13
8.2 KVM Switch .........................................................................................................................14
8.3 Flash FDD............................................................................................................................14
8.4 Operating System................................................................................................................14
8.5 ft Server Control Software ...................................................................................................14
8.6 Tower Conversion Kit...........................................................................................................14
8.7 External Tape Drives ...........................................................................................................15
REFERENCES...............................................................................................................17
Server Management............................................................................................................................17
Supported PCI Cards and Installable Slots......................................................................................18
Copyright Notice and Liability Disclaimer........................................................................................19
REVISION HISTORY .....................................................................................................20

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 3
Technical Specification
Key Features
Fault tolerant technology based on GeminiArchitectureTM
Full manageability by integrated EXPRESSSCOPE Engine 3
High performance with the latest Intel® Xeon® processor E5-2600 product family
Up to 256GB of high speed DDR3L-1600 memory
Specification
Model
R320c-E4
Part Number
N8800-173F
Processor
Type
Intel® Xeon® processor E5-2603
Clock speed
1.80 GHz
Logical Number of
Processors
1 or 2
Cache
10 MB
Cores and Threads
4C / 4T
Chipset
Intel® C602 Chipset with GeminiEngineTM
Memory
Type
DDR3L-1600 Registered DIMM with ECC
Memory Clock
1066MHz
Logical Standard
Capacity
0GB
Logical Maximum
Capacity
256GB (16 x 16 GB)
Memory protection
ECC, x4 SDDC
Internal Storage
Standard Capacity
0GB
Maximum Logical
Capacity
9.6 TB (8 x 1.2TB)
Disk Controller
SAS: 6Gb/s (Standard)
RAID
SAS : RAID 1 (Standard)
Hot Plug
Supported
Optical Disk Drive
DVD Super Multi drive 1
Optical Drive Bays
[free]
1 [0]
Logical Disk Drive Bays
[free]
8 [8]
Expansion Slots
[free]
Standard
Total: 2 slots available
2 Low-profile PCIe x4 Gen 2 (x8 connector)
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
Supported
800 x 600 / 16.7M, 1024 x 768 / 16.7M, 1280 x 1024 / 65K
Interfaces
1 VGA (15-pin mini D-sub, 1 rear per system)
4 USB2.0 (1 front, 3 rear per system)
4 1000BASE-T LAN connector (RJ-45, 2 rear per module)
2 Management LAN connector (RJ-45, 1 rear per module)
Server Management
EXPRESSSCOPE Engine 3
Power Supply
2 x 800 Watt (1 per module, 80 PLUS® Platinum certified)
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 4
Model
R320c-E4
Power
Consumption
(Max. Config,
Operating)
1,300 VA / 1,290 Watt
Dimensions (W x D x H )
483.0 x 736.0 x 178 mm / 19.0 x 29.0 x 7.0 in (4U)
Weight (Minimum / Maximum)
45 kg / 51 kg, 99.21 lbs. / 112.44 lbs.
Temperature, Relative Humidity
(non-condensing)
Operating: 10° to 35° C / 50° to 95° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 8%
Regulatory and Safety
FCC, CE, BSMI, CCC, UL, CB, RoHS
Operating Systems
Red Hat® Enterprise Linux® 6.5(x86_64) 2
1Writing software is not provided for this DVD drive.
2Xen/KVM (Kernel-based Virtual Machine) is not supported.

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 5
External Views
Front and Rear Views
Front View
AC D EF
G
H
J
N O
K L M
P Q R S T U
A
I
B
B
Legend
A.
Drive Bays
L.
CPU Fault LED
B.
UID Button
M.
Memory Fault LED
C.
DVD Super Multi Drive
N.
Module Power LED
D.
System Power LED
O.
SAFE TO PULL LED
E.
System Status LED
P.
PRIMARY LED
F.
System FT LED
Q.
IO Module Fault LED
G.
UID LED
R.
Fan Fault LED
H.
USB Connector
S.
PSU Fault LED
I.
Pull-out Tab
T.
DC Power Fault LED
J.
Power Button
U.
Temperature Fault LED
K.
Module ID LED

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 6
Rear View
A
B C D D
E
G
HF
F
Legend
A.
USB Connectors
E.
AC Inlet
B.
Management LAN Connector
F.
PCI Slots (Low-Profile)
C.
Module ID LED
G.
Serial Port Connector 1
D.
Data LAN Connectors
H.
VGA Connector
1For service personnel only.

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 7
Dimensions (mm)
Rack mount
450
689
736
483
178
Tower Conversion (Optional)
220 804
592
327

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 8
Configuration Diagram
Server
Optical Drive Bay
HDD Bay HDD BayHDD Bay HDD Bay
HDD Bay HDD BayHDD Bay HDD Bay
HDD Bay HDD BayHDD Bay HDD Bay
HDD Bay HDD BayHDD Bay HDD Bay
CPU/IO Module
Backplane
CHASSIS
FRONT
CHASSIS
REAR
CPU/IO Module
CPU/IO module #0 :
CPU/IO module #1 :
CHASSIS
FRONT
CHASSIS
REAR
PCIe 2.0 x4 (x8 socket) LP
PCIe 2.0 x4 (x8 socket) LP
Drive Cage
Power Supply
Processor
DIMM #1
DIMM #2
DIMM #3
DIMM #4
DIMM #8
DIMM #7
DIMM #6
DIMM #5
DIMM #9
DIMM #10
DIMM #11
DIMM #12
DIMM #16
DIMM #15
DIMM #14
DIMM #13
Cooling Fan #1 - #4
Processor
HDD Bay HDD BayHDD Bay HDD Bay
HDD Bay HDD BayHDD Bay HDD Bay
PCIe 2.0 x4 (x8 socket) LP
PCIe 2.0 x4 (x8 socket) LP
Drive Cage
Power Supply
Processor
DIMM #1
DIMM #2
DIMM #3
DIMM #4
DIMM #8
DIMM #7
DIMM #6
DIMM #5
DIMM #9
DIMM #10
DIMM #11
DIMM #12
DIMM #16
DIMM #15
DIMM #14
DIMM #13
Cooling Fan #1 - #4
Processor
HDD Bay HDD BayHDD Bay HDD Bay
HDD Bay HDD BayHDD Bay HDD Bay
Legend: Minimum required components Standard components

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 9
Server Configuration
1 Base Models
Product Name / Description
Part Number
EXPRESS5800/R320c-E4
no RAM, no 2.5-inch HDD
Including:
Intel Xeon Processor E5-2603, 1 x DVD Super Multi, EXPRESSBUILDER DVD
NOTE:
- The base model is common forWindows and Linux. Active Upgrade DVD is included but
not supported on Linux
N8800-173F
2 2nd Processor
Available logical sockets: 1
Product Name / Description
Part Number
Intel® Xeon® Processor E5-2603 2nd Processor Kit : 1.8 GHz / 4C-4T / 10 MB, 2
processors included
N8801-044
3 Memory
Available logical slots: 8 per processor
Product Name / Description
Part Number
4GB DDR3-1600 REG Memory Kit : 2 x 1 x 4GB DIMM included
N8802-057
32GB DDR3-1600 REG Memory Kit : 2 x 4 x 8GB DIMM included
N8802-058
64GB DDR3-1600 REG Memory Kit : 2 x 4 x 16GB DIMM included
N8802-059
NOTE:
Minimum one memory kit must be installed.

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 10
Memory Configuration Guideline
See the table below for the number of memory kits required in accordance with logical main memory size and number
of logical processors. Memory configurations which are not listed below are not supported in the system.
Number of Logical
Processors
Logical Main Memory
Size
Number of Memory Kits Required
4GB
32GB
64GB
1
4GB 1
1
-
-
8GB
2
-
-
12GB
3
-
-
16GB
4
-
-
20GB
5
-
-
24GB
6
-
-
28GB
7
-
-
32GB
8
-
-
-
1
-
48GB
4
1
-
64GB
-
2
-
64GB
-
-
1
96GB
-
1
1
128GB
-
-
2
2
4GB 1
1
-
-
8GB 1
2
-
-
12GB 1
3
-
-
16GB
4
-
-
24GB
6
-
-
32GB
8
-
-
40GB
10
-
-
48GB
12
-
-
56GB
14
-
-
64GB
16
-
-
-
2
-
96GB
8
2
-
128GB
-
4
-
-
-
2
192GB
-
2
2
256GB
-
-
4
1Interleave is not supported.

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 11
4 Internal Hard Disk Drives
Available bays: 8
Category
Product Name / Description
Part Number
SAS HDD
600GB 10K Hot Plug 2.5-inch SAS HDD : 1 x 600GB
N8850-047
900GB 10K Hot Plug 2.5-inch SAS HDD : 1 x 900GB
N8850-048
1.2TB 10K Hot Plug 2.5-inch SAS HDD : 1 x 1.2TB
N8850-051
146.5GB 15K Hot Plug 2.5-inch SAS HDD : 1 x 146.5GB
N8850-049
300GB 15K Hot Plug 2.5-inch SAS HDD : 1 x 300GB
N8850-050
SAS SSD
200GB Hot Plug 2.5-inch SSD: 1 x 200GB
N8850-052
NOTE:
Hard drives must be installed in identical pairs to configure RAID 1.
Recommended Partition layout
See the table below for the recommended partition layout.
Pattern
Setting
Partition
File system
Size
1
/boot
ext4
512MB 1
/var/crash
ext4
24GB 2,4
swap
swap
2GB - 3
/
ext4
16GB
Free area
-
Remaining
2
/boot
ext4
512MB 1
/var/crash
ext4
24GB 2,4
swap
swap
2GB - 3
/
ext4
16GB
/home
ext4
Remaining
3
/boot
ext4
512MB 1
/var/crash
ext4
24GB 2,4
swap
swap
2GB - 3
/
ext4
Remaining
１/boot partition size is recommended to be 300MB to 500MB in case of additional installation of the latest kernel
including security updates and bug fixes in the future.
224GB is required regardless of memory size. Otherwise, ft Server Control Software installation may fail.
3Required swap partition size differs depending on the installed memory size in the server. See the table below for
the memory size and swap capacity.
Memory Size
Swap Capacity
Less than 4GB
2GB
4GB to 16GB
4GB
16GB to 64GB
8GB
64GB to 256GB
16GB
4/var/crash partition for dump is required for ft Server Control Software. It is mandatory for the R320c.
NOTE:
LVM of hard drives including system partition is not supported.

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 12
Notes for BTO with HDD/SSD
The smallest capacity HDD/SSD is installed in the 1st HDD bay (as system disk) at factory.
5 Optical Drive
Available bays: 1
Product Name / Description
Part Number
Internal DVD Super Multi Drive : 1 x DVD Super Multi drive, not including writing software
(Standard)
6 PCI Card
6.1 LAN Controller
Category
Product Name / Description
Part Number
LAN Controller
1000BASE-T 2ch board kit : 2 x GbE NIC
Intel® Gigabit ET Dual Port Server Adapter
N8804-009
10GBASE-T 1ch Adapter Kit : 2 x 10GbE NIC
Intel® X540-T1
NOTE:
- Up to one controller per module
- FCoE functionality is not supported
N8804-011
NOTE:
For iSCSI (data) connection, only 1000BASE-T ports (Including standard LAN ports) are supported.
6.2 Fibre Channel / SAS Controller
Category
Product Name / Description
Part Number
Fibre Channel
Controller
Fibre Channel board kit (8Gbps) : 2 x FC Controller
QLogic QLE2560 8Gbps Fibre Channel Adapters
N8803-038
SAS Controller
SAS Controller : 1 x SAS Controller
LSI SAS9212-4i4e Host Bus Adapter
NOTE: Up to one controller per module
N8803-039
NOTE:
For supported NEC Storage products to connect with N8803-038, contact your sales representative or
refer to the NEC Storage WEB site. (http://www.nec.com/global/prod/storage/)
7 Other Add-in Components
7.1 Input Devices
Category
Product Name / Description
Part Number
Keyboard
USB Keyboard
N8870-002AF
Mouse
USB Optical Wheel Mouse
N8870-012
Cable
USB cable : 1.5m USB extension cable
K410-177(1A)

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 13
8 Add-on Components
8.1 17-inch LCD Console Drawer
Category
Product Name / Description
Part Number
Drawer
w/ KVM
Switch
Drawer
17inch LCD Console Unit (1U/8port)
17-inch LCD, US 83-keys Keyboard, Optical mouse, 8 port KVM
switch, 1U height
N8143-77F
17-inch LCD Console Drawer (8port)
17-inch LCD, US 83-keys Keyboard, Optical mouse, 8 port KVM
switch, 1U height, black
N8143-106F
Cable
Switch Unit Connection Cable Set (USB, 1.8m)
1.8 m, 1 x 15-pin mini D-SUB to 1 x 15-pin mini D-SUB / 1 x
4-pin USB A
K410-118(1A)
Switch Unit Connection Cable Set (USB, 3m)
3 m, 1 x 15-pin mini D-SUB to 1 x 15-pin mini D-SUB / 1 x 4-pin
USB A
K410-118(03)
Switch Unit Connection Cable Set (USB, 5m)
5 m, 1 x 15-pin mini D-SUB to 1 x 15-pin mini D-SUB / 1 x 4-pin
USB A
K410-118(05)
Drawer
w/o KVM
Switch
Drawer
17inch LCD Console Unit 1U
17-inch LCD, US 83-keys Keyboard, Optical mouse, 1U height,
4-pin USB B to 4-pin USB Acable 2m, PS/2 Y-splitter cable 2m,
15-pin mini D-sub VGA cable 2m
N8143-76F
17inch LCD Console Unit 1U
17-inch LCD, US 83-keys Keyboard, Optical mouse, 1U height,
4-pin USB B to 4-pin USB Acable 2 m, PS/2 Y-splitter cable 2m,
15-pin mini D-sub VGAcable 2 m, black
N8143-105F
17inch LCD Console Drawer (1port)
17-inch LCD, US 103-keys Keyboard with 10-key, Touch pad
with 3-button, 1U height, 4-pin USB B to 4-pin USB A cable 1.8
m, Two PS/2 cable 1.8 m, 15-pin mini D-sub VGA cable 1.8 m
N8143-84F
17inch LCD Console Drawer (1port)
17-inch LCD, US 103-keys Keyboard with 10-key, Touch pad
with 3-button, 1U height, 4-pin USB B to 4-pin USB A cable 1.8
m, Two PS/2 cable 1.8 m, 15-pin mini D-sub VGA cable 1.8 m,
black
N8143-108F
Keypad
Keyboard Unit (JP)
JP 108-keys Keyboard with 10-key for N8143-84F 17inch LCD
Console Drawer (1port)
N8143-85
Keyboard Unit (UK)
UK 104-keys Keyboard with 10-key, for N8143-84F 17inch LCD
Console Drawer (1port)
N8143-87
Keyboard Unit (JP)
JP 108-keys Keyboard with 10-key for N8143-108F 17inch LCD
Console Drawer (1port)
N8143-109
Keyboard Unit (UK)
UK 104-keys Keyboard with 10-key, for N8143-108F 17inch LCD
Console Drawer (1port)
N8143-111

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 14
8.2 KVM Switch
Category
Product Name / Description
Part Number
KVM Switch
Server Switch Unit (8 server)
1U USB 8 port KVM switch
N8191-12F
Server Switch Unit (8 server)
1U USB 8 port KVM switch, black
N8191-14F
Cable
KVM
Switch Unit Connection Cable Set (USB,1.8m)
1.8 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin
USB A
K410-118(1A)
Switch Unit Connection Cable Set (USB,3m)
3 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin
USB A
K410-118(03)
Switch Unit Connection Cable Set (USB,3m)
5 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin
USB A
K410-118(05)
Cascading
Switch Unit Connection Cable 1.8 m
1.8 m, 1 x 15-pin mini D-sub - 1x 15-pin mini D-Sub / 2x PS/2
K410-119(1A)
8.3 Flash FDD
Order the Flash FDD if you need to prepare an alternative for a floppy drive.
Product Name / Description
Part Number
Flash FDD
USB flash emulating USB floppy disk, Native capacity 1.44 MB
N8160-96
8.4 Operating System
Red Hat® Enterprise Linux® 6.5 (x86_64) is supported on the R320c series. Purchase the OS and support
service from a Red Hat reseller directly.
8.5 ft Server Control Software
Product Name / Description
Part Number
ft Server Control Software 9.0.5 for Red Hat Enterprise Linux 6.5
UL4349-008E
NOTE:
ft Server Control Software for Linux is not included in the base model. Be sure to order UL4349-008E
to install Red Hat Enterprise Linux 6.5 on R320c series.
8.6 Tower Conversion Kit
Product Name / Description
Part Number
Tower Conversion Kit
23 inch height pedestal with front bezel
N8843-004

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 15
8.7 External Tape Drives
8.7.1 Tape Drive Selection
Refer to the section in accordance with your type of tape drives.
LTO
LTO2
SAS
Refer to 8.7.2
LTO3
SAS
Refer to 8.7.2
LTO4
Refer to 8.7.2
SAS
LTO5
Refer to 8.7.2
SAS

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 16
8.7.2 LTO / SAS
Category
Product Name / Description
Part Number
Controller
Required
SAS Controller
LSI SAS9212-4i4e Host Bus Adapter
6Gb/s SAS, Int. 4 / Ext. 4, 7-pin SATA / SFF-8088, PCIe 2.0 x8,
LP/FH
NOTE: Up to one controller per module
N8803-039
External Cable
Required
External SAS cable
2 m, for Tape Drive Enclosure connection
K410-191(02)
Tape Enclosure
Required
2U Tape Drive Enclosure
4 x 5-inch media bays, two internal SAS cables included, black
N8141-75F
Power Module
Recommended
Power Supply
1 x non-hot plug power supply unit for redundant configuration
N8181-54F
Internal Cable
SAS Cable
For 2U Tape Drive Enclosure internal connection
NOTE: Required when three or more SAS connections
(including other general purpose servers) to the N8141-75F
K410-335(00)
Drive
2 bays available
Internal LTO (SAS)
LTO3, Half height, Native capacity 400GB, black
N8151-126
Internal LTO (SAS)
LTO4, Half height, Native capacity 800GB, black
N8151-127
Internal LTO (SAS)
LTO5, Half height, Native capacity 1500GB, black
N8151-128
Internal LTO (SAS)
LTO6, Half height, Native capacity 2.5 TB, black
N8151-129
8.7.3 Notes for Double Backup
In a single backup configuration, in case a CPU/IO module or backup device fails, backup is not possible
until the failed part is repaired or replaced. If this does not meet your system requirements, consider a
double backup configuration.
Refer to the following notes on double backup configuration.
When configuring two sets of a SAS controller, a SAS cable and a backup device, two backup devices
are recognized separately by the OS. When scheduling an automatic backup job, make a job for each
backup device so that the other backup device can backup in case one device fails.
8.7.4 Supported Backup Software
See the table below for the supported backup software on NEC EXPRESS5800/R320c.
Tape drive
Backup software
Product Name / Description
Part Number
NetVault 9.2
NetVault 10.0
RHEL6.5
RHEL6.5
Internal LTO (SAS)
LTO3, Half height, Native capacity 400 GB
N8151-102/126


Internal LTO (SAS)
LTO4, Half height, Native capacity 800 GB
N8151-90/127


Internal LTO (SAS)
LTO5, Half height, Native capacity 1.5 TB
N8151-103/128


Internal LTO (SAS)
LTO6, Half height, Native capacity 2.5 TB
N8151-106/129



CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 17
References
Server Management
The EXPRESSSCOPE Engine 3, integrated into the server, provides superior remote control and system
management features listed in the table below.
Hardware
monitoring
Temperature/voltage/power/fan

HDD
-
Degeneration (memory/hard drive)
-
Hardware configuration collection

Hardware event log collection

Boot monitoring
Booting, BIOS/POST stall, OS stall,
shutdown

Alerting
HW error, Boot error and OS panic
(by SNMP, E-Mail)

Remote KVM
POST/BIOS setup, DOS utility

(via LAN)
Panic screen, Boot screen

Text-based screen (OS console)

GUI-based screen (OS console)

Remote control
Remote reset/power on-off/ dump

(via LAN)
Power Capping
-
BIOS/BMC FW update
-
Remote BIOS setting
-
OS shutdown

Remote media (CD/DVD/FD/USB)

CLP (Command Line Protocol) (DMTF
compliant)

Remote control via Web browser (multi
user login at the same time)

Scheduling (without UPS)
-
Others
Set automatic IP address via DNS/DHCP

LDAP/Active Directory verification/user
control

Clock synchronization of main unit and
the RTC

Access log collection

Industry standard
IPMI
2.0

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 18
Supported PCI Cards and Installable Slots
Part Number
Product Name
Slots
Notes
Slot # :
#1
#2
PCI Slot:
x4
x4
Card height:
LP
LP
Slot type:
x8
x8
N8804-009
1000BASE-T 2ch board kit


N8804-011
10GBASE-T 1ch board set


Max. 1
N8803-038
Fibre Channel board kit
1
1
N8803-039
SAS board
1
1
Max. 1
1Not installable when using Tower Conversion Kit.

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 19
Copyright Notice and Liability Disclaimer
The information contained herein is subject to change without notice.
Microsoft and Windows Server are either registered trademarks or trademarks of Microsoft Corporation in
the United States and/or other countries
Intel and Xeon are registered trademarks or trademarks of Intel Corporation or its subsidiaries in the United
States and other countries.
Linux is a trademark of Linus Torvalds.
Red Hat is a registered trademark of Red Hat, Inc. in the U.S.
All other products, brands, or trade names used in this document are trademarks or registered trademarks
of their respective holders.
NEC shall not be liable for technical or editorial errors or omissions contained herein.
For hard drive capacity measurements, 1 GB = 1 billion bytes. Actual formatted capacity is less.

CONFIGURATION GUIDE –NEC EXPRESS5800/R320c-E4 for Linux
NEC Corporation Revision 2.0, April 2015 20
Revision History
Revision
Date
Description
2.0
2015.4.28
New products added:
17-inch LCD Console Drawer (8port) N8143-106F
17inch LCD Console Unit 1U N8143-105F
17inch LCD Console Drawer (1port) N8143-108F
Keyboard Unit (JP) N8143-109
Keyboard Unit (UK) N8143-111
Server Switch Unit (8 server) N8191-14F
Flash FDD N8160-96
2U Tape Drive Enclosure N8141-75F
SAS cable K410-335(00)
Internal LTO (SAS) N8151-126/ N8151-127/ N8151-128/ N8151-129
Discontinued products removed:
Flash FDD N8160-86
2U Tape Drive Enclosure N8141-59F
Internal SAS cable K410-249(00)
Internal LTO (SAS) N8151-102/ N8151-90/ N8151-103/ N8151-106
1.0
2014.10.24
Initial release
