NEC Express Server
Express5800 Series
Express5800/B120d
Express5800/B110d
User’s Guide
Chapter 1 General Description
Chapter 2 Preparations
Chapter 3 Setup
Chapter 4 Appendix
40.005.02-101.02
June 2012, Second Edition
© NEC Corporation 2012
Model Number (B120d): N8400-131F/134F/135F
Model Number (B110d): N8400-137F

Documents Provided with This Product
Express5800/B120d, B110d User's Guide
2
Documents Provided with This Product
Documents for this product are provided as accompanying booklets and as electronic manuals stored within
the EXPRESSBUILDER DVD.
Precautions for Use Describes points of caution to ensure the safe use of this server. Read
these cautions before using this server.
Getting Started Describes how to use this server, from unpacking to operations. Refer to
this guide as you begin for an overview of this server.
User’s Guide
Chapter 1: General Description Overviews, names, and functions of the server’s parts
Chapter 2: Preparations Installation of additional options, connection of peripheral devices,
and ideal location for this server
Chapter 3: Setting Up Your Server System BIOS configurations and summary of EXPRESSBUILDER
PDF
Chapter 4: Appendix Specifications and other information
Installation Guide (Windows)
Chapter 1: Installing Windows Installation of Windows and drivers, and important information for
installation
PDF
Chapter 2: Installing the Bundled
Software
Installation of bundled software, such as ESMPRO and Universal
RAID Utility
Maintenance Guide
Chapter 1: Maintenance Server maintenance and troubleshooting
Chapter 2: Convenient Features Useful features and the detail of system BIOS settings, RAID
Configuration Utility, and EXPRESSBUILDER
PDF
Chapter 3: Appendix Error messages and Windows Event Logs
Other documents
PDF
Provides the detail of ESMPRO, Universal RAID Utility, and the other features.

Contents
Express5800/B120d, B110d User's Guide 3
Contents
Documents Provided with This Product.................................................................................................................2
Contents................................................................................................................................................................3
Notations Used in This Document.........................................................................................................................6
Notations used in the text....................................................................................................................6
Optical disk drives...............................................................................................................................6
Hard Disk Drives.................................................................................................................................6
Removable media...............................................................................................................................6
Abbreviations of Operating Systems (Windows).................................................................................7
Trademarks...........................................................................................................................................................8
Regulatory Notices................................................................................................................................................9
Warnings and Additions to This Document..........................................................................................................10
Latest editions...................................................................................................................................10
Precautions for Use (Be Sure to Read) ...................................................................................................11
Safety precautions ............................................................................................................................11
Symbols used in this document and on warning labels.....................................................................12
Safety notes......................................................................................................................................13
Handling precautions (for proper operations)....................................................................................15
General Description ............................................................................................................................................18
1. Introduction.....................................................................................................................................................19
2. Accessories ....................................................................................................................................................20
3. Standard Features..........................................................................................................................................21
3.1 Overview of Blade Server..........................................................................................................23
3.2 Management Features...............................................................................................................24
3.3 About the Monitoring of Chassis Sensors..................................................................................25
3.4 Firmware and Software Version Management...........................................................................25
4. Names and Features of Component...............................................................................................................26
4.1 CPU Blade.................................................................................................................................26
4.2 Hard Disk Drive (HDD)............................................................................................................31
4.3 Lamp Indications........................................................................................................................32
4.3.1 POWER Lamp........................................................................................................32
4.3.2 STATUS Lamp........................................................................................................33
4.3.3 LAN (1 - 2) Link/Access Lamps..............................................................................34
4.3.4 ID Lamp..................................................................................................................34
4.3.5 Hard Disk Access Lamp .........................................................................................34
Preparations........................................................................................................................................................35
1. Installing Internal Optional Devices ................................................................................................................36
1.1 Safety Precautions.....................................................................................................................36
1.2 Anti-static Measures...................................................................................................................37
1.3 Overview of Installation and Removal........................................................................................38
1.4 Installation and Removal Procedure (Common section)............................................................39
1.4.1 Removal of top cover..............................................................................................39
1.4.2 Removal of air duct.................................................................................................40
1.4.3 Removal of HSBP bracket......................................................................................41

Contents
Express5800/B120d, B110d User's Guide
4
1.4.4 Installation of top cover, air duct, HSBP cover........................................................42
1.5 Processor (CPU)........................................................................................................................43
1.5.1 Installation ..............................................................................................................44
1.5.2 Removal.................................................................................................................48
1.6 DIMM.........................................................................................................................................49
1.6.1 Adding Order and Precautions................................................................................51
1.6.2 Installation ..............................................................................................................51
1.6.3 Removal.................................................................................................................54
1.7 Mezzanine Card.........................................................................................................................55
1.7.1 Notes......................................................................................................................57
1.7.2 Installation ..............................................................................................................57
1.7.3 Removal.................................................................................................................58
1.8 Hard Disk Drive (HDD) / Solid State Drive (SSD) ......................................................................59
1.8.1 Installation ..............................................................................................................60
1.8.2 Removal.................................................................................................................62
1.8.3 Replacement ..........................................................................................................63
1.8.4 Resetting Management Information........................................................................66
1.9 Use of Internal Hard Disk Drives in the RAID System ...............................................................67
1.9.1 Enabling a RAID System........................................................................................67
1.9.2 Notes on setting up a RAID System.......................................................................68
1.10 TPM (Trusted Platform Module) Kit .........................................................................................69
1.10.1 Installation.............................................................................................................70
1.10.2 Removal................................................................................................................71
1.11 EXPRESSBUILDER Assembly Kit ..........................................................................................72
1.11.1 Installation.............................................................................................................73
1.11.2 Removal................................................................................................................74
2. Installation and Connection ............................................................................................................................75
2.1 Installation..................................................................................................................................75
2.1.1 Checking MAC Address..........................................................................................76
2.2 Connecting Peripheral Devices..................................................................................................78
2.2.1 USB Connection by K410-150(00) SUV Cable.......................................................80
2.2.2 Connecting with Network........................................................................................80
2.2.3 Connecting with UPS..............................................................................................81
Setup...................................................................................................................................................................82
1. Power-on of Blade Server ..............................................................................................................................83
1.1 Power ON from CPU Blade .......................................................................................................84
1.2 Power ON from Network Serial Port ..........................................................................................85
1.3 Power ON from Remote Console ..............................................................................................85
1.4 Operation after Power ON .........................................................................................................85
1.5 POST.........................................................................................................................................86
1.5.1 POST Execution Flow ............................................................................................86
1.5.2 POST Error Messages ...........................................................................................88
2. Details of System BIOS..................................................................................................................................89
2.1 Starting SETUP..........................................................................................................................89
2.2 Parameter Descriptions .............................................................................................................89
2.2.1 Main........................................................................................................................90
2.2.2 Advanced................................................................................................................92
2.2.3 Security ................................................................................................................ 111
2.2.4 Server...................................................................................................................115
2.2.5 Boot...................................................................................................................... 119
2.2.6 Save & Exit...........................................................................................................121
2.3 Cases that Require Configuration............................................................................................122
3. EXPRESSSCOPE ENGINE 3 ......................................................................................................................124
3.1 Overview..................................................................................................................................124
3.2 EXPRESSSCOPE ENGINE 3 Network Configuration .............................................................124
4. EXPRESSBUILDER.....................................................................................................................................126
4.1 Features of EXPRESSBUILDER.............................................................................................126
4.2 Starting EXPRESSBUILDER...................................................................................................126

Contents
Express5800/B120d, B110d User's Guide 5
5. Installing Software Components...................................................................................................................127
6. Device Identification .....................................................................................................................................128
7. Power-off of Blade Server.............................................................................................................................129
Appendix...........................................................................................................................................................130
1. Specifications ...............................................................................................................................................131
2. Interrupt Lines...............................................................................................................................................133

Notations Used in This Document
Express5800/B120d, B110d User's Guide
6
Notations Used in This Document
Notations used in the text
In addition to safety-related symbols urging caution, 3 other types of notations are used in this document.
These notations have the following meanings.
Important Indicates critical items that must be followed when handling the server or operating software.
If the procedures described are not followed, server failure, data loss, and other serious
malfunctions could occur.
Note Indicates items that must be confirmed when handling the server or operating software.
Tips Indicates information that is helpful to keep in mind when using this server.
Optical disk drives
This server is equipped with one of the following drives, depending on the order at the time of purchase. These
drives are referred to as optical disk drives in this document.
●DVD-ROM drive
●DVD Super MULTI drive
Hard Disk Drives
Unless otherwise stated, Hard Disk Drives (HDD) described in this document refer to both of the following.
●Hard disk drives (HDD)
●Solid state drive (SSD)
Removable media
Unless otherwise stated, Hard Disk Drives (HDD) described in this document refer to both of the following.
●USB memory
●Flash FDD

Notations Used in This Document
Express5800/B120d, B110d User's Guide 7
Abbreviations of Operating Systems (Windows)
Windows Operating Systems are referred to as follows.
Refer to Chapter 1 (1.2 Supported Windows OS) in Installation Guide (Windows) for detailed information.
Notations in this document Official names of Windows
Windows Server 2008 R2 Standard
Windows Server 2008 R2 Windows Server 2008 R2 Enterprise
Windows Server 2008 Standard
Windows Server 2008 *1 Windows Server 2008 Enterprise
Windows Server 2003 R2 Standard x64 Edition
Windows Server 2003 R2 x64 Edition Windows Server 2003 R2 Enterprise x64 Edition
Windows Server 2003 R2 Standard
Windows Server 2003 R2 *2 Windows Server 2003 R2 Enterprise
Windows Server 2003 Standard
Windows Server 2003 *2 Windows Server 2003 Enterprise
Windows 7 Professional 64-bit(x64) Edition
Windows 7 Windows 7 Professional 32-bit(x86) Edition
Windows Vista Business 64-bit(x64) Edition
Windows Vista Windows Vista Business 32-bit(x86) Edition
Windows XP Professional x64 Edition
Windows XP Windows XP Professional
Windows PE *3 Windows Preinstallation Environment
*1 Includes 64-bit and 32-bit Editions unless otherwise stated.
The following appears on EXPRESSBUILDER.
●Windows Server 2008 64-bit Edition: Windows Server 2008 x64
●Windows Server 2008 32-bit Edition: Windows Server 2008 x86
*2 Unless otherwise stated, Windows Server 2003 R2 and Windows Server 2003 are collectively referred to as
Windows Server 2003.
*3 Used as an installation platform only.

Trademarks
Express5800/B120d, B110d User's Guide
8
Trademarks
ESMPRO and EXPRESSSCOPE are registered trademarks of NEC Corporation.
Microsoft, Windows, Windows Server, and MS-DOS are registered trademarks or trademarks of Microsoft Corporation in the United
States and other countries. Intel, Pentium, and Xeon are registered trademarks of Intel Corporation of the United States.
AT is a registered trademark of International Business Machines Corporation of the United States and other countries.
Adaptec, its logo, and SCSISelect are registered trademarks or trademarks of Adaptec, Inc. of the United States.
LSI and the LSI logo design are trademarks or registered trademarks of LSI Corporation.
Adobe, the Adobe logo, and Acrobat are trademarks of Adobe Systems Incorporated.
DLT and DLTtape are trademarks of Quantum Corporation of the United States.
PCI Express is a trademark of Peripheral Component Interconnect Special Interest Group.
All other product, brand, or trade names used in this publication are the trademarks or registered trademarks of their respective
trademark owners.

Regulatory Notices
Express5800/B120d, B110d User's Guide 9
Regulatory Notices
FCC Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
Industry Canada Class A Emission Compliance Statement
This ClassA digital apparatus complies with Canadian ICES-003.
Avis de conformité à la réglementation d'Industrie Canada
Cet appareil numérique de la classeA est conforme à la norme NMB-003 du Canada.
CE Statement
This is a Class A product. In domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures (EN55022).
BSMI Statement
WEEE
Disposing of your used product
In the European Union
EU-wide legislation as implemented in each Member State requires that
used electrical and electronic products carrying the mark (left) must be
disposed of separately from normal household waste. This includes
Information and Communication Technology (ICT) equipment or electrical
accessories, such as cables or DVDs.
When disposing of used products, you should comply with applicable
legislation or agreements you may have. The mark on the electrical and
electronic products only applies to the current European Union Member
States.
Outside the European Union
If you wish to dispose of used electrical and electronic products outside
the European Union, please contact your local authority and ask for the
correct method of disposal.

Warnings and Additions to This Document
Express5800/B120d, B110d User's Guide
10
Warnings and Additions to This Document
●Unauthorized reproduction of the contents of this document, in part or in its entirety, is prohibited.
●The contents of this document may change without prior notice.
●Do not make copies or alter the document content without permission from NEC Corporation.
●Every effort has been made to ensure the completeness of this document. However, if you have any
concerns, or discover errors or omissions, please contact your retailer.
●Regardless of these Item 4, NEC Corporation does not take responsibility for effects resulting from
operations.
●The sample values used in this document are not the actual values.
Keep this document nearby so that you may refer to it as necessary.
Latest editions
This document was created based on the information available at the time of its creation. The screen images,
messages and procedures may differ from the actual screens, messages and procedures. Substitute as
appropriate when content has been modified.
The most recent version of User’s Guide, as well as other related documents, is also available for download
from the following website.
http://www.nec.co.jp/

Precautions for Use (Be Sure to Read)
Express5800/B120d, B110d User's Guide 11
Precautions for Use (Be Sure to Read)
The following provides information required to use your server safely and properly. For details of names in this
section, refer to Names and Functions of Parts in this document.
Safety precautions
Follow the instructions in this document for the safe use of the NEC Express server.
This User’s Guide describes hazardous parts of the server, possible hazards, and how to avoid them. Server
components with possible danger are indicated with a warning label placed on or around them (or, in some
cases, by printing the warnings on the server).
In User’s Guide or on warning labels, WARNING or CAUTION is used to indicate a degree of danger. These
terms are defined as follows:
WARNING Indicates there is a risk of death or serious personal injury
CAUTION Indicates there is a risk of burns, other personal injury, or property damage
Precautions and notices against hazards are presented with one of the following three symbols. The individual
symbols are defined as follows:
Attention This symbol indicates the presence of a hazard if
the instruction is ignored.
An image in the symbol illustrates the hazard type.
Prohibited
Action This symbol indicates prohibited actions. An image
in the symbol illustrates a particular prohibited
action.
Mandatory
Action This symbol indicates mandatory actions. An
image in the symbol illustrates a mandatory action
to avoid a particular hazard.
(Electric shock risk)
(Example)
(Do not disassemble)
(Example)
(Example)
(Disconnect a plug)

Precautions for Use (Be Sure to Read)
Express5800/B120d, B110d User's Guide
12
(A label example used in this User’s Guide)
Symbols used in this document and on warning labels
Attentions
Indicates the presence of electric shock
hazards. Indicates the presence of mechanical parts that can result in bodily injury.
Indicates the presence of a hot surface
or component. Touching this surface
could result in bodily injury.
Indicates the presence of mechanical
parts that can result in pinching or other
bodily injury.
Indicates there is a risk of explosion. Indicates the presence of laser beam
that cause blindness.
Indicates there is a risk of fire or fumes. Indicates a general notice or warning
that cannot be specifically identified.
Prohibited Actions
Do not disassemble, repair, or modify
the server. Otherwise, an electric shock
or fire may be caused.
Do not touch the server with wet hand.
Otherwise, an electric shock may be
caused.
Do not touch the component specified
by this symbol. Otherwise, an electric
shock or burn may be caused.
Do not use the server in the place
where water or liquid may pour.
Otherwise, an electric shock or fire may
be caused.
Do not place the server near the fire.
Otherwise, a fire may be caused. Indicates a general prohibited action that cannot be specifically identified.
Mandatory Actions
Unplug the power cord of the server.
Otherwise, an electric shock or fire may
be caused.
Indicates a mandatory action that
cannot be specifically identified. Make
sure to follow the instruction.
Make sure equipment is properly grounded.
Otherwise, an electric shock or fire may
be caused.
WARNING
Use only the specified outlet
Use a grounded outlet with the specified voltage. Use of an improper power source
may cause a fire or a power leak.
Symbol to draw
attention Description of a warning Term indicating a degree of danger

Precautions for Use (Be Sure to Read)
Express5800/B120d, B110d User's Guide 13
Safety notes
This section provides notes on using the server safely. Read this section carefully to ensure proper and safe
use of the server. For symbols, refer to Safety precautions.
WARNING
Do not use the server for services where human life may be at stake or high reliability is required.
This server is not intended for use in medical, nuclear, aerospace, mass transit or other applications
where human life may be at stake or high reliability is required, nor is it intended for use in controlling
such applications. We disclaim liability for any personal injury and property damages caused by such use
of this server.
Do not disassemble, repair, or alter the server.
Never attempt to disassemble, repair, or alter the server on any occasion other than described in this
User's Guide. Failure to follow this instruction may cause an electric shock or fire as well as malfunctions
of the server.
Do not attempt to remove lithium, NiMH, or Li-ion batteries.
The server contains the lithium, NiMH, or Li-ion battery (some optional devices have a lithium, NiMH, or
Li-ion battery installed). Do not remove the battery. Placing a battery close to a fire or in the water may
cause an explosion.
When the server does not operate appropriately due to the dead battery, contact the store you purchased
the product or your maintenance service company. Do not attempt to disassemble the server to replace or
recharge the battery by yourself.
Do not use the server if any smoke, odor, or noise is present.
If smoke, odor, or noise is present, immediately turn off the power of all of the CPU blades, turn off the
power of Blade Enclosure, then contact your sales representative. Using the server in such conditions
may cause a fire.
Do not insert needles or metal objects.
Do not insert needles or metal objects into ventilation holes in the server or openings in the optical disk
drive. Doing so may cause an electric shock.
Do not install devices in any other chassis than the specified Blade Enclosure.
Devices including CPU blades should be installed in the dedicated Blade Enclosure for their uses. Do not
install the CPU blades and other devices in a chassis other than the Blade Enclosure. Failure to follow it
may result in fire and/or electric shock to occur.
Do not use the server in an environment where corrosive gas is present
Do not install the server in a place subject to corrosive gases including sodium chloride, sulfur dioxide,
hydrogen sulfide, nitrogen dioxide, chlorine, ammonia, or ozone. Do not install the server in an
environment that contains dust, chemicals that accelerate corrosion such as NaCl or sulfur, or conductive
materials. Failure to follow this warning may cause the wiring on the printed wiring board to short-circuit,
leading to fire. If you have any questions, contact the store where you purchased the product or a
maintenance service company.

Precautions for Use (Be Sure to Read)
Express5800/B120d, B110d User's Guide
14
WARNING
Do not handle the CPU blade if it is installed in the Blade Enclosure.
To install or remove an option from the CPU blade, first turn off the power of the CPU blade and remove
the CPU blade from the Blade Enclosure.
If you touch any components on the CPU blade with it connected to Blade Enclosure, you may get an
electric shock.
Do not install or remove more than one CPU blade at a time.
Install or remove CPU blades one by one. If you install or remove more than one CPU blade at a time or a
CPU blade with the cover of another slot removed, you may be electrically shocked.
CAUTION
Keep water or foreign matter away from the server.
Do not let any liquid such as water or foreign materials including pins or paper clips enter the server.
Failure to follow this warning may cause an electric shock, a fire, or failure of the server. When such
things accidentally enter the server, immediately turn off the power and disconnect the power plug from
the outlet. Do not disassemble the server, and contact the store where you purchased the product or your
maintenance service company.
Make sure to complete device installation.
Always install an interface cable, CPU blade, Solid State Drive, and option board firmly. An incompletely
installed device may cause a contact failure, resulting in smoking or fire.
Use only the specified interface cable.
Use only interface cables authorized by NEC and locate a proper device and connector before connecting
a cable. Using an unauthorized cable or connecting a cable to an improper destination may cause a short
circuit, resulting in a fire.
Also, observe the following notes on using and connecting an interface cable.
Do not use any damaged cable connector.
Do not step on the cable.
Do not place any object on the cable.
Do not use the server with loose cable connections.
Do not use any damaged cable.
High temperature
Components including internal Solid State Drives in the server are extremely hot just after the server is
turned off. Allow the surface to cool before installing/removing.
Avoid contact with the server during thunderstorms.
Do not touch any part of the server including the cables when a thunderstorm is approaching. Also, do not
connect or disconnect any devices. There may be a risk of electric shock from lightning strike.
Keep animals away from the server.
Keep animals such as pets away from the server. Pet hair or other waste enters the server, which may
cause a fire or electric shock.

Precautions for Use (Be Sure to Read)
Express5800/B120d, B110d User's Guide 15
Handling precautions (for proper operations)
Be sure to observe the following precautions for the proper functioning of the server. Ignoring the precautions
may cause server malfunction or failure.
●General
– Do not block air vents of the CPU blades, Blade Enclosures, power supply units, and additional FAN
units.
– The CPU blade is extremely sensitive to static electricity. For static notes, refer to Chapter 2 (1.2
Anti-static Measures).
– The CPU blade and internal option devices contain precision component that is easily affected by
drastic temperature change. If the device is used after storage or relocation, make sure that the
device is fully adapted to the operating environment.
– Do not touch the CPU blade terminals or on-board components by a bare hand nor place the CPU
blade directly on the desk.
– It is recommended to use options provided by NEC. Some memory devices and Solid State Drives of
other vendors are designed to be available for the server. If such an option causes the server to be
defected or damaged, you will be charged for the repair within the warranty period.
– Turn off the cellular phone or pager around the server. Radio interference may cause malfunctions of
the server.
●CPU blade
– N8400-131F/134F/135F/137F CPU blade should be installed in the Blade Enclosure
(SIGMABLADE).
– Install or remove CPU blades one by one.
– Hold the portions covered with metal plates when a CPU blade is installed or removed. To carry a
CPU blade, put it into the case in which the CPU blade was contained at the purchase and pack it
into the package.
– Check and adjust the system clock before the operation if any of the following conditions is
applicable.
After transportation
After storage
After the server is used following a period of disuse, in which storage conditions did not conform to
those that guarantee server operations (temperature: 10 C to 35 C; humidity: 20% to 80%).
– Check the system clock at the rough rate of once per month. When the system clock is installed in a
system requiring high time precision, it is recommended to use a time server (NTP server).
If the system clock is remarkably delayed or advanced as the passage of time in spite of adjustment,
contact your sales representative to ask maintenance.
– Store the unit under the storage condition (temperature: –10°C to 55°C, humidity: 20% to 80%,
without condensation).
– Turn on the power of each CPU blade by pressing the POWER switch or the remote power-on
operation after the period of 60 seconds or longer has passed from the supply of power (the POWER
lamp of the CPU blade goes on amber). The power of the CPU blade may not be turned on if the

Precautions for Use (Be Sure to Read)
Express5800/B120d, B110d User's Guide
16
power-on operation is done within the period of less than 60 seconds from the supply of power. After
making sure that the power is supplied to every CPU blade, turn on the power of each CPU blade by
pressing the POWER switch.
– After turning off the power of a CPU blade once, turn on the power again after 30 seconds have
passed from the power-off.
– Remove a CPU blade after turning off the power of the CPU blade.
– Do not perform any of the following operation during POST (including similar operations from EM
card and external applications).
Press the POWER switch of the CPU blade.
Press the RESET switch of the CPU blade.
Remove the CPU blade from the Blade Enclosure.
Disconnect the power cord from the power unit of the Blade Enclosure.
●Hard disk drive
– Confirm the slot to which the Hard Disk Drive is inserted. The slot for the Hard Disk Drive to be
connected to each CPU blade is defined previously.
Tips Maintenance service
We offer periodic diagnosis and maintenance services by staff with expert
knowledge of the maintenance of this server.
We recommend that you make a periodic maintenance service contract with your
maintenance service company to keep your server in good condition.

Precautions for Use (Be Sure to Read)
Express5800/B120d, B110d User's Guide 17
Using a computer extensively may affect different parts of your body. Here are tips you should follow while working
on a computer to minimize strain on your body.
Keep proper posture
The basic body position for using a computer is sitting straight with
your hands on the keyboard parallel with the floor, and your eyes
directed slightly downward toward the monitor. With the proper
posture described above, no unnecessary strain is applied on any
part of your body, in other words when your muscles are most
relaxed.
Working on the computer with bad posture such as hunching over
or being too close to the monitor could cause fatigue or deteriorated
eyesight.
Adjust the angle of your display
Most display units are designed for adjustment of the horizontal and
vertical angles. This adjustment is important to prevent the screen
from reflecting bright lights and to make the display contents easy
to see. Working without adjusting the display to a comfortable angle
makes it difficult for you to maintain a proper posture and you will
get tired easily. Adjust the viewing angle before use.
Adjust the brightness and contrast of the display
Display screens have functions to control brightness and contrast.
The most suitable brightness/contrast depends on age, individuals,
and environment, so adjust it to suit your preferences. A too bright
or too dark display is bad for your eyes.
Adjust the angle of keyboard
Some keyboards are ergonomically designed, which allow the
angle to be adjusted. Adjusting the angle of the keyboard is
effective to reduce tension on your shoulders, arms, and fingers.
Clean your equipment
Keeping your equipment clean is important not only for the appearance but also for functional and safety reasons. A
dusty monitor makes it difficult to see the display contents, so clean it regularly.
Take rest breaks
When you feel tired, take a break. Light exercise is also
recommended.
Tips for your health and safety

Express5800/B120d, B110d User's Guide
18
NEC Express5800 Series
Express5800/B120d-h
Express5800/B120d-h
General Description
This chapter describes the features of the server and bundled software, and precautions on installation.
1. Introduction
2. Accessories
Verify the condition of your server's accessories.
3. Standard Features
Describes standard features of the server and system management utilities.
4. Names and Functions of Parts
This section describes the name of each part contained in this server.

Chapter 1 General Description 1. Introduction
Express5800/B120d, B110d User's Guide 19
1. Introduction
Welcome to the NEC Express5800/BladeServer series server.
This high performance and high density server is powered by the latest microprocessor "Intel®Xeon®
processor.
NEC’s latest technology and architectures realize more space-saving and reduction of running cost than ever.
The server is designed with consideration of not only reliability but also expandability, which enables you to use
it as a network server.
Read this document before using the server thoroughly to fully understand handling of Express5800 Series
Server and appreciate its functions to the maximum extent.

Chapter 1 General Description 2. Accessories
Express5800/B120d, B110d User's Guide
20
2. Accessories
The carton box contains various accessories which are required for setup or maintenance. Make sure you
have them all for future use.
EXPRESSBUILDER
*1
Getting Started
*1 Documents are stored in EXPRESSBUILDER. Adobe Reader is required to read the documents so make
sure you have it installed in your PC.
Make sure you have all accessories and inspect them. If an accessory is missing or damaged, contact your
sales representative.
Important The chassis serial number plate and maintenance label is located on the
server. If the serial number does not match the number on the warranty, you
may not be guaranteed against failure even within the warranty period.
Contact your sales representative if they do not match.
