NEC EXPRESS5800/R110d-1E
Configuration Guide
Introduction
This document contains product and configuration information that will enable you to configure your system. The
guide will ensure fast and proper configuration of your NEC Express5800 server.
May 2012
Revision 2.3
NEC Corporation

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 2
Contents
TECHNICAL SPECIFICATION........................................................................................3
Key Features..........................................................................................................................................3
Specification..........................................................................................................................................3
EXTERNAL VIEWS .........................................................................................................7
Front and Rear Views ...........................................................................................................................7
Dimensions (mm)..................................................................................................................................8
CONFIGURATION DIAGRAM.........................................................................................9
SERVER CONFIGURATION .........................................................................................10
1Base Models.................................................................................................................................10
2Processor .....................................................................................................................................10
3Memory .........................................................................................................................................10
4Internal Hard Disk Drives............................................................................................................11
4.1 RAID Configuration..............................................................................................................11
4.2 Internal Drive Configuration.................................................................................................13
5Optical Drive.................................................................................................................................25
6Internal Flash Memory.................................................................................................................25
7PCI Card........................................................................................................................................26
7.1 LAN Controller.....................................................................................................................26
7.2 External RAID Controller.....................................................................................................26
7.3 Fibre Channel/SAS/SCSI Controller....................................................................................27
7.4 Serial Port Adapter ..............................................................................................................27
8Add-on Components ...................................................................................................................27
8.1 17-inch LCD Console Drawer..............................................................................................27
8.2 KVM Switch .........................................................................................................................28
8.3 Server Management License...............................................................................................28
8.4 Flash FDD............................................................................................................................28
8.5 Front Bezel ..........................................................................................................................28
REFERENCES...............................................................................................................29
Note for Ordering ................................................................................................................................29
Server Management............................................................................................................................29
OS Support Matrix for PCI Cards ......................................................................................................30
Supporting PCI cards and Installable Slots .....................................................................................31
Copyright Notice and Liability Disclaimer........................................................................................32
REVISION HISTORY .....................................................................................................33

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 3
Technical Specification
Key Features
High performance with the latest Intel® Xeon® processor E3-1200 series
Up to 32 GB of high speed DDR3-1333 memory
High energy efficiency with intelligent fan control, power capping feature and 80 PLUS® Gold power
supply
Full manageability by integrated EXPRESSSCOPE Engine 3
Specification
3.5-inch Drive Model
Model
R110d-1E
Part Number
N8100-1744F
Processor
Type
Intel® Pentium®
processor G630
Intel® Xeon®
processor E3-1220
Intel® Xeon®
processor E3-1270
Clock speed
2.70 GHz
3.10 GHz
3.40 GHz
Number of Processor
1
Cache
3 MB
8 MB
8 MB
Cores and Threads
2C / 2T
4C / 4T
4C / 8T
Chipset
Intel® C204 Chipset
Memory
Type
DDR3-1333 ECC Unbuffered DIMM
Standard Capacity
0 GB
Maximum Capacity
32 GB (4 x 8 GB)
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SATA : 12 TB (4 x 3 TB)
Disk Controller
SATA : 3 Gb/s (Integrated)
RAID
SATA : 1 2 RAID 0/1/10 (Standard), RAID 5/6 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
[free]
1 [1]
Disk Drive Bays [free]
4 [4]
Expansion Slots [free]
Total: 2 slots available
1 [1] x PCIe 2.0 x8 (x16 connector)
1 [1] x PCIe 2.0 x8 (x8 connector)
Video Controller (VRAM)
Integrated in Server Management Controller (32MB)
Interfaces
1 x VGA (15-pin mini D-sub,1x rear)
1 x Serial (9-pin mini D-sub, RS232-C, Serial A, 1 x rear)
8x USB2.0 (2 x front, 4 x rear, 2 x internal)
2x 1000BASE-T LAN connector (1000BASE-T / 100BASE-TX /
10BASE-T, RJ-45, 2 x rear)
1 x Management LAN connector (100BASE-TX / 10BASE-T,
RJ-45, 1 x rear)
Server Management
EXPRESSSCOPE Engine 3
System Fan
Standard
Power Supply
1 x 400 Watt 80 PLUS® Gold certified non-Hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 4
Model
R110d-1E
Power
Consumption
(Max. Config, Idling)
108 VA / 102 Watt
109 VA / 105 Watt
109 VA / 106 Watt
(Max. Config,
Operating)
161 VA / 159 Watt
223 VA / 222 Watt
281 VA / 270 Watt
Acoustical Noise
(Sound Pressure
Level) 3
Minimum Config.
42.3 dB
39.3 dB
39.3 dB
Maximum Config.
43.1 dB
48.8 dB
48.8 dB
Dimensions (W x D x H )
444.0 x 615.2 x 43.6 mm / 17.5 x 24.2 x 1.7 in (1U)
Weight (Minimum / Maximum)
10 kg / 18 kg, 22.05 lbs. / 39.68 lbs.
Temperature, Relative Humidity
(non-condensing)
Operating: 10° to 35° C / 50° to 95° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, CE, BSMI, CCC, UL, CB, RoHS, WEEE
Pre-installed Operating System
-
Operating Systems
Microsoft® Windows Server® 2003 R2, Standard Edition SP2 or later
Microsoft® Windows Server® 2003 R2, Enterprise Edition SP2 or later
Microsoft® Windows Server® 2003 R2, Standard x64 Edition SP2 or later
Microsoft® Windows Server® 2003 R2, Enterprise x64 Edition SP2 or later
Microsoft® Windows Server® 2008 Standard
Microsoft® Windows Server® 2008 Standard (x64)
Microsoft® Windows Server® 2008 Enterprise
Microsoft® Windows Server® 2008 Enterprise (x64)
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Enterprise
Red Hat Enterprise Linux 5.6 or later 4
Red Hat Enterprise Linux 5.6 or later (EM64T) 4
Red Hat Enterprise Linux 6.0 or later (x86) 4
Red Hat Enterprise Linux 6.0 or later (x86_64) 4
1On-board SATA Controller does not support RAID 10 configured with 2TB and 3TB HDDs.
2The on-board SATA RAID controller is not supported on Linux operating systems.
3Noise emission was measured in accordance with ISO 7779. The actual value may vary by the operating
environment.
4For Linux support, contact our sales representative or go to the NEC website at:
http://www.nec.com/global/prod/express/linux/index.html

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 5
2.5-inch Drive Model
Model
R110d-1E
Part Number
N8100-1745F
Processor
Type
Intel® Pentium®
processor G630
Intel® Xeon®
processor E3-1220
Intel® Xeon®
processor E3-1270
Clock Speed
2.70 GHz
3.10 GHz
3.40 GHz
Number of Processor
1/1
Cache
3 MB
8 MB
8 MB
Cores and Threads
2C / 2T
4C / 4T
4C / 8T
Chipset
Intel® C204 Chipset
Memory
Type
DDR3-1333 ECC Unbuffered DIMM
Standard Capacity
0 GB
Maximum Capacity
32 GB (4 x 8 GB)
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SAS : 5.4 TB (6 x 900 GB)
SATA : 6 TB (6 x 1 TB)
SSD : 600 GB (6 x 100 GB)
Disk Controller
SATA : 3 Gb/s (Integrated)
SAS : 6 Gb/s (Optional)
RAID
SATA : 1RAID 0/1/10 (Standard), RAID 5/6 (Optional)
SAS : RAID 0/1/10/5/6 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
[free]
1 [1]
Disk Drive Bays [free]
6 [6]
Expansion Slots [free]
Total: 2 slots available
1 [1] x PCIe 2.0 x8 (x16 connector)
1 [1] x PCIe 2.0 x8 (x8 connector)
Video Controller (VRAM)
Integrated in Server Management Controller (32MB)
Interfaces
1 x VGA (15-pin mini D-sub,1x rear)
1 x Serial (9-pin mini D-sub, RS232-C, Serial A, 1 x rear)
8x USB2.0 (2 x front, 4 x rear, 2 x internal)
2x 1000BASE-T LAN connector (1000BASE-T / 100BASE-TX /
10BASE-T, RJ-45, 2 x rear)
1 x Management LAN connector (100BASE-TX / 10BASE-T,
RJ-45, 1 x rear)
Server Management
EXPRESSSCOPE Engine 3
System Fan
Standard
Power Supply
1 x 400 Watt 80 PLUS® Gold certified non-Hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power
Consumption
(Max. Config, Idling)
107 VA / 102 Watt
123 VA / 119 Watt
125 VA / 120 Watt
(Max. Config,
Operating)
149 VA / 146 Watt
236 VA / 233 Watt
261 VA / 260 Watt
Acoustical Noise
(Sound Pressure
Level) 2
Minimum Config.
42.3 dB
39.3 dB
39.3 dB
Maximum Config.
43.1 dB
48.8 dB
48.8 dB
Dimensions (W x D x H )
444.0 x 615.2 x 43.6 mm / 17.5 x 24.2 x 1.7 in (1U)
Weight (Minimum / Maximum)
10 kg / 18 kg, 22.05 lbs. / 39.68 lbs.

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 6
Model
R110d-1E
Temperature, Relative Humidity
(non-condensing)
Operating: 10° to 35° C / 50° to 95° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, CE, BSMI, CCC, UL, CB, RoHS, WEEE
Pre-installed Operating System
-
Operating Systems
Microsoft® Windows Server® 2003 R2, Standard Edition SP2 or later
Microsoft® Windows Server® 2003 R2, Enterprise Edition SP2 or later
Microsoft® Windows Server® 2003 R2, Standard x64 Edition SP2 or later
Microsoft® Windows Server® 2003 R2, Enterprise x64 Edition SP2 or later
Microsoft® Windows Server® 2008 Standard
Microsoft® Windows Server® 2008 Standard (x64)
Microsoft® Windows Server® 2008 Enterprise
Microsoft® Windows Server® 2008 Enterprise (x64)
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Enterprise
Red Hat Enterprise Linux 5.6 or later 3
Red Hat Enterprise Linux 5.6 or later (EM64T) 3
Red Hat Enterprise Linux 6.0 or later (x86) 3
Red Hat Enterprise Linux 6.0 or later (x86_64) 3
1The on-board SATA RAID controller is not supported on Linux operating systems.
2Noise emission was measured in accordance with ISO 7779. The actual value may vary by the operating
environment.
3For Linux support, contact our sales representative or go to the NEC website at:
http://www.nec.com/global/prod/express/linux/index.html

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 7
External Views
Front and Rear Views
Front View for 2.5-inch Drive Model
Front View for 3.5-inch Drive Model
Legend
A.
USB Connectors
H.
Pull-out Tab
B.
Power LED
I.
Drive Bays
C.
Data LAN 1 Activity LED
J.
Hard Drive Activity LED
D.
UID LED
K.
Data LAN 2 Activity LED
E.
BMC Reset Switch
L.
System Status LED
F.
UID LED Button
M.
Dump (NMI) Switch
G.
Power Button
A B D GHC
I
JKLM
F
E
I
A B D GHC
J K L M
F
E

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 8
Rear View
Legend
A.
AC Inlet
F.
VGA Connector
B.
Serial Port Connector
G.
Power LED
C.
Data LAN 1 Connector
H.
USB Connectors
D.
Data LAN 2 Connector
I.
Management LAN Connector
E.
PCI Slots
J.
UID LED / Button
Dimensions (mm)
ABCDE
F G H I J
740.9 mm
615.2 mm 44.3 mm
43.6 mm
485.0 mm
444.0 mm 482.0 mm

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 9
Configuration Diagram
2.5-inch Drive Model
Legend: Minimum requirement components Standard components
3.5-inch Drive Model
Legend: Minimum requirement components Standard components
2.5-inch
HDD Cage
Fixed
Power
Supply
Media Bay #1
CHASSIS
FRONT
CHASSIS
REAR
Media Bay #1 HDD Bay
HDD Bay
HDD Bay HDD Bay
HDD Bay HDD Bay
BBU slot #1
BBU slot #2
DIMM #1
DIMM #2
DIMM #3
DIMM #4
Processor
PCIe 2.0 x8 (x16 socket)
LP/MD2
PCIe 2.0 x8 (x8 socket)
LP/MD2
3.5-inch
HDD Cage
Fixed
Power
Supply
DIMM #1
DIMM #2
DIMM #3
DIMM #4
Processor
Media Bay #1
CHASSIS
FRONT
CHASSIS
REAR
Media Bay #1
HDD Bay
BBU slot #1
BBU slot #2
HDD BayHDD BayHDD Bay
PCIe 2.0 x8 (x16 socket)
LP/MD2
PCIe 2.0 x8 (x8 socket)
LP/MD2

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 10
Server Configuration
1 Base Models
Product Name / Description
Part Number
NEC EXPRESS5800/R110d-1E Server
no processor, no RAM, no 3.5-inch HDD
Including:
3.5-inch HDD Cage, EXPRESSBUILDER DVD
N8100-1744F
NEC EXPRESS5800/R110d-1E Server
no processor, no RAM, no 2.5-inch HDD
Including:
2.5-inch HDD Cage, EXPRESSBUILDER DVD
N8100-1745F
NOTE:
The base model must be ordered with a processor kit.
2 Processor
Available sockets: 1
Product Name / Description
Part Number
Processor Kit (2C/G630)
Intel® Pentium® Processor G630 (2.70GHz / 2C-2T / 3MB)
N8101-529F
Processor Kit (4C/E3-1220)
Intel® Xeon® Processor E3-1220 (3.10 GHz / 4C-4T / 8 MB)
N8101-506F
Processor Kit (4C/E3-1270)
Intel® Xeon® Processor E3-1270 (3.40 GHz / 4C-8T / 8 MB)
N8101-507F
NOTE:
One processor kit from above must be installed.
The processor kit must be ordered with the base model.
3 Memory
Available slots: 4
Product Name / Description
Part Number
2GB Memory Kit
2GB (1x 2 GB) DDR3-1333 ECC Unbuffered DIMM
N8102-416F
4GB Memory Kit
4GB (1x 4 GB) DDR3-1333 ECC Unbuffered DIMM
N8102-417F
8GB Memory Kit
8GB (1x 8 GB) DDR3-1333 ECC Unbuffered DIMM
N8102-418F
NOTE:
Minimum one memory kit must be installed.
It is recommended to install two identical memory kits for dual-channel symmetric configuration to
increase memory transfer speed.
Actual DIMM speed is set to 1066 MHz when you choose Pentium Processor.

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 11
Maximum Available Memory
See the table below for the maximum memory size that you can actually use on your system.
The maximum available memory is less than the maximum physical memory supported by your system
because some chipsets require PCI resource space of about 750MB. PCI resource requirements vary
depending on the type and the number of PCI cards you are using.
Maximum Memory Size Supported by OS
Maximum Available Memory
4 GB
Microsoft Windows Server 2003 R2, Standard Edition
Microsoft Windows Server 2008 Standard
4 GB (HW-DEP enabled)
App. 3.3 GB (HW-DEP disabled)
32 GB
Microsoft Windows Server 2003 R2, Standard x64 Edition
Microsoft Windows Server 2008 Standard (x64)
Microsoft Windows Server 2008 R2 Standard (x64)
32 GB
64 GB
Microsoft Windows Server 2003 R2, Enterprise Edition
Microsoft Windows Server 2008 Enterprise
32 GB
1 TB
Microsoft Windows Server 2003 R2, Enterprise x64 Edition
32 GB
2 TB
Microsoft Windows Server 2008 Enterprise (x64)
Microsoft Windows Server 2008 R2 Enterprise (x64)
32 GB
16 GB
Red Hat Enterprise Linux 5
Red Hat Enterprise Linux 6
16 GB
256 GB
Red Hat Enterprise Linux 5 (EM64T)
32 GB
2 TB
Red Hat Enterprise Linux 6.0 (x86_64)
32 GB
4 Internal Hard Disk Drives
4.1 RAID Configuration
Refer to the section in accordance with your disk form factor and RAID configuration.
4.1.1 3.5-inch Drive
NOTE:
On-board SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
On-board SATA RAID Controller does not support RAID 10 configured with 2TB and 3TB HDDs.
Hot plug insertion/removal is not supported with the on-board SATAnon-RAID controller.
All hard drives within a RAID array should be of the same capacity.
An optional RAID controller occupies one PCI slot.
Non-RAID
RAID 5/6
On-board SATA
RAID Controller
Optional RAID
Controller
128MB Cache
256MB Cache
512MB Cache
256MB Cache
Refer to 4.2.1
Refer to 4.2.2
Refer to 4.2.3
Refer to 4.2.4
Refer to 4.2.5
RAID 0/1/10
SATA
SATA
SATA
SATA
SATA
Available Disk

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 12
4.1.2 Up to four 2.5-inch Drive
NOTE:
On-board SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
Hot plug insertion/removal is not supported with the on-board SATAnon-RAID controller.
All hard drives within a RAID array should be of the same capacity and rotation speed.
Mixing SAS and SATA hard drives in the same system is not supported.
An optional RAID controller occupies one PCI slot.
4.1.3 Up to six 2.5-inch Drive
NOTE:
An optional RAID controller occupies one PCI slot.
All hard drives within a RAID array should be of the same capacity and rotation speed.
Mixing SAS and SATA hard drives in the same system is not supported.
Non-RAID
RAID 5/6
On-board SATA
RAID Controller
Optional RAID
Controller
128MB Cache
256MB Cache
512MB Cache
256MB Cache
Refer to 4.2.6
Refer to 4.2.7
Refer to 4.2.8
Refer to 4.2.9
Refer to 4.2.10
RAID 0/1
SATA, SSD
SAS, SATA, SSD
SAS, SATA, SSD
SAS, SATA, SSD
SAS, SATA, SSD
Available Disk
RAID 5/6
128MB Cache
256MB Cache
512MB Cache
256MB Cache
Refer to 4.2.11
Refer to 4.2.12
Refer to 4.2.13
Refer to 4.2.14
RAID 0/1/10
SAS, SATA, SSD
SAS, SATA, SSD
SAS, SATA, SSD
SAS, SATA, SSD
Available Disk

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 13
4.2 Internal Drive Configuration
4.2.1 3.5-inch Drive with On-board SATA Controller
Category
Product Name / Description
Part Number
Storage Controller
On-board SATA Controller
4 x SATA ports, RAID 0/1 capable
(Standard)
Cable
Internal SATA Cable
1x SATA to 1x SATA, 4 sets
(Standard)
HDD Cage
3.5-inch HDD Cage
4 x 3.5-inch hot plug hard drive bays
(Standard)
HDD
4 slots available
160GB HDD
1 x 160 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-285
250GB HDD
1 x 250 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-279
500GB HDD
1 x 500 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-280
1TB HDD
1 x 1 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-282
2TB HDD
1 x 2 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-283
3TB HDD
1 x 3 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-336
NOTE:
On-board SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
On-board SATA RAID Controller does not support RAID 10 configured with 2TB and 3TB HDDs.
Hot plug insertion/removal is not supported with the on-board SATAnon-RAID controller.
3 TB HDDs are not supported with the on-board SATA non-RAID controller.
All hard drives within a RAID array should be of the same capacity.

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 14
4.2.2 3.5-inch Drive with RAID 0/1 Controller with 128 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (128MB, RAID 0/1)
Promise SuperTrak TX8760T-128
RAID 0/1/10, 128MB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s,
SATA 3Gb/s, LP / FH
N8103-128
RAID BBU
Recommended
RAID Battery Backup Unit
for Promise SuperTrak EX8760T and EX8768
N8103-140
Cable
Required
Internal SATA Cable
1x mini-SAS to 4x SATA
K410-240(00)
HDD Cage
3.5-inch HDD Cage
4 x 3.5-inch hot plug hard drive bays
(Standard)
HDD
4 slots available
160GB HDD
1 x 160 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-285
250GB HDD
1 x 250 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-279
500GB HDD
1 x 500 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-280
1TB HDD
1 x 1 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-282
2TB HDD
1 x 2 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-283
3TB HDD
1 x 3 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-336
NOTE:
All hard drives within a RAID array should be of the same capacity.

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 15
4.2.3 3.5-inch Drive with RAID 0/1 Controller with 256 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (256MB, RAID 0/1)
LSI MegaRAID SAS 9264-8i
RAID 0/1, 256MB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s, SATA 3Gb/s,
LP / FH
N8103-129
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9264
N8103-123
Cable
Required
Internal SATA Cable
1x mini-SAS to 4x SATA
K410-240(00)
HDD Cage
3.5-inch HDD Cage
4 x 3.5-inch hot plug hard drive bays
(Standard)
HDD
4 slots available
160GB HDD
1 x 160 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-285
250GB HDD
1 x 250 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-279
500GB HDD
1 x 500 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-280
1TB HDD
1 x 1 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-282
2TB HDD
1 x 2 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-283
NOTE:
All hard drives within a RAID array should be of the same capacity.
4.2.4 3.5-inch Drive with RAID 5/6 Controller with 256 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (256MB, RAID 0/1/5/6)
LSI MegaRAID SAS 9264-8i
RAID 0/1/5/6/10/50, 256MB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s,
SATA 3Gb/s, LP / FH
N8103-130
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9264
N8103-123
Cable
Required
Internal SATA Cable
1x mini-SAS to 4x SATA
K410-240(00)
HDD Cage
3.5-inch HDD Cage
4 x 3.5-inch hot plug hard drive bays
(Standard)
HDD
4 slots available
160GB HDD
1 x 160 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-285
250GB HDD
1 x 250 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-279
500GB HDD
1 x 500 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-280
1TB HDD
1 x 1 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-282
2TB HDD
1 x 2 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-283
NOTE:
All hard drives within a RAID array should be of the same capacity.

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 16
4.2.5 3.5-inch drive with RAID 5/6 Controller with 512 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID0/1/5/6)
Promise SuperTrak EX8760T-512
RAID 0/1/5/6/10/50, 512MB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s,
SATA 3Gb/s, LP / FH
N8103-134
RAID BBU
Recommended
RAID Battery Backup Unit
for Promise SuperTrak EX8760T and EX8768
N8103-140
Cable
Required
Internal SATA Cable
1x mini-SAS to 4x SATA
K410-240(00)
HDD Cage
3.5-inch HDD Cage
4 x 3.5-inch hot plug hard drive bays
(Standard)
HDD
4 slots available
160GB HDD
1 x 160 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-285
250GB HDD
1 x 250 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-279
500GB HDD
1 x 500 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-280
1TB HDD
1 x 1 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-282
2TB HDD
1 x 2 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-283
3TB HDD
1 x 3 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-336
NOTE:
All hard drives within a RAID array should be of the same capacity.
4.2.6 2.5-inch Drive with On-board SATA Controller
Category
Product Name / Description
Part Number
Storage Controller
On-board SATA Controller
4 x SATA ports, RAID 0/1/10 capable
(Standard)
Cable
Required
Internal SATA Cable
1x mini-SAS to 4x SATA
(Standard)
HDD Cage
2.5-inch HDD Cage
6 x 2.5-inch hot plug hard drive bays
(Standard)
HDD
4 slots
available
SATA
160GB HDD
1 x 160 GB, 2.5-inch, SATA2, 7,200 rpm
N8150-276
500GB HDD
1 x 500 GB, 2.5-inch, SATA2, 7,200 rpm
N8150-277
1TB HDD
1 x 1 TB, 2.5-inch, SATA2, 7,200 rpm
N8150-334
SSD
100GB SSD
1 x 100 GB, 2.5-inch, SATA2
N8150-707
NOTE
The on-board SATARAID controller is not supported on Linux operating systems.
All hard drives within a RAID array should be of the same capacity.

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 17
4.2.7 Up to four 2.5-inch Drive with RAID 0/1 Controller with 128 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (128MB, RAID 0/1)
Promise SuperTrak TX8760T-128
RAID 0/1, 128MB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s, SATA 3Gb/s,
LP / FH
N8103-128
RAID BBU
Recommended
RAID Battery Backup Unit
for Promise SuperTrak EX8760T and EX8768
N8103-140
Cable
Required
Internal SAS/SATA Cable
1x mini-SAS to 4x SATA
K410-240(00)
HDD Cage
2.5-inch HDD Cage
6 x 2.5-inch hot plug hard drive bays
(Standard)
HDD
4 slots
available
SAS
146.5GB HDD
1 x 146.5 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-374
300GB HDD
1 x 300 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-375
450GB HDD
1 x 450 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-376
600GB HDD
1 x 600 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-377
900GB HDD
1 x 900 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-332
73.2GB HDD
1 x 73.2 GB, 2.5-inch, SAS 6Gb/s, 15,000 rpm
N8150-378
146.5GB HDD
1 x 146.5 GB, 2.5-inch, SAS 6Gb/s, 15,000 rpm
N8150-379
300GB HDD
1 x 300GB, 2.5-inch, SAS 6Gb/s, 15,000 rpm
N8150-331
SATA
160GB HDD
1 x 160 GB, 2.5-inch, SATA2, 7,200 rpm
N8150-276
500GB HDD
1 x 500 GB, 2.5-inch, SATA2, 7,200 rpm
N8150-277
1TB HDD
1 x 1 TB, 2.5-inch, SATA2, 7,200 rpm
N8150-334
SSD
100GB SSD
1 x 100 GB, 2.5-inch, SATA2
N8150-707
NOTE:
All hard drives within a RAID array should be of the same capacity and rotation speed.
Mixing SAS and SATA hard drives in the same system is not supported.

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 18
4.2.8 Up to four 2.5-inch Drive with RAID 0/1 Controller with 256 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (256MB, RAID 0/1)
LSI MegaRAID SAS 9264-8i
RAID 0/1, 256MB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s, SATA 3Gb/s,
LP / FH
N8103-129
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9264
N8103-123
Cable
Required
Internal SAS/SATA Cable
1x mini-SAS to 4x SATA
K410-240(00)
HDD Cage
2.5-inch HDD Cage
6 x 2.5-inch hot plug hard drive bays
(Standard)
HDD
4 slots
available
SAS
146.5GB HDD
1 x 146.5 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-374
300GB HDD
1 x 300 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-375
450GB HDD
1 x 450 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-376
600GB HDD
1 x 600 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-377
900GB HDD
1 x 900 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-332
73.2GB HDD
1 x 73.2 GB, 2.5-inch, SAS 6Gb/s, 15,000 rpm
N8150-378
146.5GB HDD
1 x 146.5 GB, 2.5-inch, SAS 6Gb/s, 15,000 rpm
N8150-379
300GB HDD
1 x 300GB, 2.5-inch, SAS 6Gb/s, 15,000 rpm
N8150-331
SATA
160GB HDD
1 x 160 GB, 2.5-inch, SATA2, 7,200 rpm
N8150-276
500GB HDD
1 x 500 GB, 2.5-inch, SATA2, 7,200 rpm
N8150-277
1TB HDD
1 x 1 TB, 2.5-inch, SATA2, 7,200 rpm
N8150-334
SSD
100GB SSD
1 x 100 GB, 2.5-inch, SATA2
N8150-707
NOTE:
All hard drives within a RAID array should be of the same capacity and rotation speed.
Mixing SAS and SATA hard drives in the same system is not supported

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 19
4.2.9 Up to four 2.5-inch Drive with RAID 5/6 Controller with 256 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (256MB, RAID 0/1/5/6)
LSI MegaRAID SAS 9264-8i
RAID 0/1/5/6/10/50, 256MB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s,
SATA 3Gb/s, LP / FH
N8103-130
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9264
N8103-123
Cable
Required
Internal SAS/SATA Cable
1x mini-SAS to 4x Fixed SAS
K410-240(00)
HDD Cage
2.5-inch HDD Cage
6 x 2.5-inch hot plug hard drive bays
(Standard)
HDD
4 slots
available
SAS
146.5GB HDD
1 x 146.5 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-374
300GB HDD
1 x 300 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-375
450GB HDD
1 x 450 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-376
600GB HDD
1 x 600 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-377
900GB HDD
1 x 900 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-332
73.2GB HDD
1 x 73.2 GB, 2.5-inch, SAS 6Gb/s, 15,000 rpm
N8150-378
146.5GB HDD
1 x 146.5 GB, 2.5-inch, SAS 6Gb/s, 15,000 rpm
N8150-379
300GB HDD
1 x 300GB, 2.5-inch, SAS 6Gb/s, 15,000 rpm
N8150-331
SATA
160GB HDD
1 x 160 GB, 2.5-inch, SATA2, 7,200 rpm
N8150-276
500GB HDD
1 x 500 GB, 2.5-inch, SATA2, 7,200 rpm
N8150-277
1TB HDD
1 x 1 TB, 2.5-inch, SATA2, 7,200 rpm
N8150-334
SSD
100GB SSD
1 x 100 GB, 2.5-inch, SATA2
N8150-707
NOTE:
All hard drives within a RAID array should be of the same capacity and rotation speed.
Mixing SAS and SATA hard drives in the same system is not supported.

CONFIGURATION GUIDE –NEC Express5800/R110d-1E
NEC Corporation Revision 2.3, May 2012 20
4.2.10 Up to four 2.5-inch Drive with RAID 5/6 Controller with 512 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID0/1/5/6)
Promise SuperTrak EX8760T-512
RAID 0/1/5/6/10/50, 512MB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s,
SATA 3Gb/s, LP / FH
N8103-134
RAID BBU
Recommended
RAID Battery Backup Unit
for Promise SuperTrak EX8760T and EX8768
N8103-140
Cable
Required
Internal SAS/SATA Cable
1x mini-SAS to 4x SATA
K410-240(00)
HDD Cage
2.5-inch HDD Cage
6 x 2.5-inch hot plug hard drive bays
(Standard)
HDD
4 slots
available
SAS
146.5GB HDD
1 x 146.5 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-374
300GB HDD
1 x 300 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-375
450GB HDD
1 x 450 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-376
600GB HDD
1 x 600 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-377
900GB HDD
1 x 900 GB, 2.5-inch, SAS 6Gb/s, 10,000 rpm
N8150-332
73.2GB HDD
1 x 73.2 GB, 2.5-inch, SAS 6Gb/s, 15,000 rpm
N8150-378
146.5GB HDD
1 x 146.5 GB, 2.5-inch, SAS 6Gb/s, 15,000 rpm
N8150-379
300GB HDD
1 x 300GB, 2.5-inch, SAS 6Gb/s, 15,000 rpm
N8150-331
SATA
160GB HDD
1 x 160 GB, 2.5-inch, SATA2, 7,200 rpm
N8150-276
500GB HDD
1 x 500 GB, 2.5-inch, SATA2, 7,200 rpm
N8150-277
1TB HDD
1 x 1 TB, 2.5-inch, SATA2, 7,200 rpm
N8150-334
SSD
100GB SSD
1 x 100 GB, 2.5-inch, SATA2
N8150-707
NOTE:
All hard drives within a RAID array should be of the same capacity and rotation speed.
Mixing SAS and SATA hard drives in the same system is not supported
