NEC R320c-E4 User manual

NEC Express Server
Express5800 Series
Express5800/R320c-E4
Model Number: N8800-173F, EXP320P
User’s Guide
Chapter 1 General Description
Chapter 2 Preparations
Chapter 3 Setup
Chapter 4 Appendix
30.004.01-101.02
September 2013, Second Edition
© NEC Corporation 2013
Express5800/R320c-M4
Model Number: N8800-174F, EXP320Q

Documents Provided with This Product
Express5800/R320c-E4, R320c-M4 User's Guide
2
Documents Provided with This Product
Documents for this product are provided as accompanying booklets ( ) and as electronic manuals (
PDF
) stored
within EXPRESSBUILDER DVD ( ).
Precautions for Use Describes points of caution to ensure the safe use of this server. Read
these cautions before using this server.
Getting Started Describes how to use this server, from unpacking to operations. Refer to
this guide as you begin for an overview of this server.
User’s Guide
Chapter 1: General Description Overviews, names, and functions of the server’s parts
Chapter 2: Preparations Installation of additional options, connection of peripheral devices, and
ideal location for this server
Chapter 3: Setting Up Your
Server
System BIOS configurations and summary of EXPRESSBUILDER
PDF
Chapter 4: Appendix Specifications and other information
Installation Guide
Chapter 1: Installing OS Installation of OS and drivers, and important information for installation
PDF
Chapter 2: Installing the
Bundled Software
Installation of bundled software, such as NEC ESMPRO
Maintenance Guide
Chapter 1: Maintenance Server maintenance and troubleshooting
Chapter 2 Configuring and
Upgrading the System Configure hardware and setup management tool associated with hardware
PDF
Chapter 3: Convenient
Features
Useful features and the detail of system BIOS settings, SAS
Configuration Utility, and EXPRESSBUILDER
Other documents
PDF
Provides the detail of NEC ESMPRO and the other features.
EXPRESSBUILDER

Contents
Express5800/R320c-E4, R320c-M4 User's Guide 3
Contents
Documents Provided with This Product ........................................................................................................2
Contents........................................................................................................................................................3
Notations Used in This Document.................................................................................................................5
Notations used in the text ..................................................................................................................5
Optical disk drives..............................................................................................................................5
Hard disk drives.................................................................................................................................5
Removable media..............................................................................................................................5
Abbreviations of Operating Systems..................................................................................................6
POST .............................................................................................................................................6
BMC .............................................................................................................................................6
Trademarks...................................................................................................................................................7
Regulatory Notices........................................................................................................................................8
Warnings and Additions to This Document..................................................................................................10
Latest editions..................................................................................................................................10
Precautions for Use (Be Sure to Read)...........................................................................................11
Safety precautions...........................................................................................................................11
Symbols used in this document and on warning labels ...................................................................12
Safety notes.....................................................................................................................................13
General.................................................................................................................................................... 13
Rack installation....................................................................................................................................... 14
Power supply and power cord use ..........................................................................................................15
Installation, relocation, storage, and connection ..................................................................................... 16
Cleaning and working with internal devices............................................................................................. 17
During operation...................................................................................................................................... 18
一般注意事項........................................................................................................................................... 19
機 架...................................................................................................................................................... 20
電源及電源線注意事項............................................................................................................................. 21
安裝，移動，保管及連接注意事項........................................................................................................... 22
清潔及操作內部設備時的注意事項........................................................................................................... 24
操作注意事項........................................................................................................................................... 25
Warning labels.................................................................................................................................26
External view ........................................................................................................................................... 26
Handling precautions (for proper operations)...................................................................................27
Chapter 1 General Description............................................................................................................................30
1. Preface...................................................................................................................................................31
2. Accessories............................................................................................................................................32
3. Standard Features..................................................................................................................................33
3.1 Features of the Server..............................................................................................................33
3.2 Fault-Tolerant Features.............................................................................................................35
3.3 Management Features..............................................................................................................38
3.4 Firmware and Software Version Management for Windows .....................................................39
4. Names and Functions of Components ...................................................................................................40
4.1 Front View ................................................................................................................................40
4.2 Front View (With front bezel removed) .....................................................................................41
4.3 Rear View.................................................................................................................................42
4.4 External View............................................................................................................................44
4.5 Optical Disk Drive.....................................................................................................................45
4.6 CPU/IO Module ........................................................................................................................46
4.7 CPU/IO Board...........................................................................................................................48
4.8 LEDs.........................................................................................................................................49

Contents
Express5800/R320c-E4, R320c-M4 User's Guide
4
Chapter 2 Preparations .......................................................................................................................................50
1. Installing Internal Optional Devices ........................................................................................................51
2. Installation and Connection....................................................................................................................52
2.1 Installing/removing the front bezel............................................................................................52
2.2 Rack .........................................................................................................................................53
2.2.1 Installing Rack................................................................................................................................. 53
2.2.2 Installing the server to the rack....................................................................................................... 55
2.2.3 Removing the device from the rack ................................................................................................ 61
2.3 Tower Conversion Kit (N8843-004)...........................................................................................62
2.3.1 Installing the Tower Conversion Kit................................................................................................. 62
2.3.2 Installing the Rack-mount Model to the Tower Conversion Kit........................................................ 64
2.4 Connection ...............................................................................................................................68
2.4.1 Connecting to a uninterruptible power supply (UPS)...................................................................... 70
Chapter 3 Setup ..................................................................................................................................................71
1. Power ON...............................................................................................................................................72
1.1 POST Check.............................................................................................................................74
1.1.1 Flow of POST.................................................................................................................................. 74
1.1.2 POST Error Messages.................................................................................................................... 76
1.1.3 Behavior at Occurrence of Error ..................................................................................................... 76
2. SYSTEM BIOS –SETUP–......................................................................................................................77
2.1 Overview...................................................................................................................................77
2.2 Starting and Exiting SETUP Utility............................................................................................77
2.2.1 Starting SETUP............................................................................................................................... 77
2.2.2 Exiting SETUP ................................................................................................................................ 77
2.3 Description on On-Screen Items and Key Usage .....................................................................78
2.4 Cases that Require Configuration.............................................................................................80
3. EXPRESSSCOPE ENGINE 3................................................................................................................82
3.1 Overview...................................................................................................................................82
3.2 EXPRESSSCOPE ENGINE 3 Network configuration...............................................................83
4. EXPRESSBUILDER...............................................................................................................................85
4.1 Features of EXPRESSBUILDER..............................................................................................85
4.2 Using EXPRESSBUILDER.......................................................................................................85
5. Installing Software Components.............................................................................................................86
6. Power OFF.............................................................................................................................................87
Chapter 4 Appendix.............................................................................................................................................88
1. Specifications .........................................................................................................................................89

Notations Used in This Document
Express5800/R320c-E4, R320c-M4 User's Guide 5
Notations Used in This Document
Notations used in the text
In addition to safety-related symbols urging caution, 3 other types of notations are used in this document. These
notations have the following meanings.
Important Indicates critical items that must be followed when handling the hardware or operating
software. If the procedures described are not followed, hardware failure, data loss, and
other serious malfunctions could occur.
Note Indicates items that must be confirmed when handling the hardware or operating software.
Tips Indicates information that is helpful to keep in mind when using this server.
Optical disk drives
This server is equipped with one of the following drives, depending on the order at the time of purchase. These
drives are referred to as optical disk drives in this document.
DVD-ROM drive
DVD Super MULTI drive
Hard disk drives
Unless otherwise stated, hard disk drives (HDD) described in this document refer to the following.
Hard disk drives (HDD)
Removable media
Unless otherwise stated, removable media described in this document refer to both of the following.
USB memory
Flash FDD

Notations Used in This Document
Express5800/R320c-E4, R320c-M4 User's Guide
6
Abbreviations of Operating Systems
Windows Operating Systems are referred to as follows.
Refer to Chapter 1 inInstallation Guide for detailed information.
Notations in this document Official names of Windows
Windows Server 2008 R2 Standard
Windows Server 2008 R2 Windows Server 2008 R2 Enterprise
Windows Server 2008 Standard
Windows Server 2008 *1 Windows Server 2008 Enterprise
Windows Server 2003 R2 Standard x64 Edition
Windows Server 2003 R2 x64 Edition Windows Server 2003 R2 Enterprise x64 Edition
Windows Server 2003 R2 Standard
Windows Server 2003 R2 *2 Windows Server 2003 R2 Enterprise
Windows Server 2003 Standard
Windows Server 2003 *2 Windows Server 2003 Enterprise
Windows 7 Professional 64-bit(x64) Edition
Windows 7 Windows 7 Professional 32-bit(x86) Edition
Windows Vista Business 64-bit(x64) Edition
Windows Vista Windows Vista Business 32-bit(x86) Edition
Windows XP Professional x64 Edition
Windows XP Windows XP Professional
Windows PE *3 Windows Preinstallation Environment
*1: Includes 64-bit and 32-bit Editions unless otherwise stated.
The following appears on EXPRESSBUILDER.
Windows Server 2008 64-bit Edition: Windows Server 2008 x64
Windows Server 2008 32-bit Edition: Windows Server 2008 x86
*2: Unless otherwise stated, Windows Server 2003 R2 and Windows Server 2003 are collectively referred to as
Windows Server 2003.
*3: Used as an installation platform only.
POST
POST described in this document refer to the following.
Power On Self-Test
BMC
BMC described in this document refer to the following.
Baseboard Management Controller

Trademarks
Express5800/R320c-E4, R320c-M4 User's Guide 7
Trademarks
EXPRESSSCOPE is a registered trademark of NEC Corporation.
Microsoft, Windows, Windows Server, and MS-DOS are registered trademarks or trademarks of Microsoft Corporation in the United
States and other countries. Intel, Pentium, and Xeon are registered trademarks of Intel Corporation of the United States. AT is a
registered trademark of International Business Machines Corporation of the United States and other countries. Adaptec, its logo, and
SCSI Select are registered trademarks or trademarks of Adaptec, Inc. of the United States. LSI and the LSI logo design are
trademarks or registered trademarks of LSI Corporation. Adobe, the Adobe logo, and Acrobat are trademarks of Adobe Systems
Incorporated. DLT and DLTtape are trademarks of Quantum Corporation of the United States. PCI Express is a trademark of
Peripheral Component Interconnect Special Interest Group.
Copyright © 2010 VMware, Inc. All rights reserved. This product is protected by U.S. and international copyright and
intellectual property laws. VMware products are covered by one or more patents listed at
http://www.vmware.com/go/patents.
VMware is a registered trademark or trademark of VMware, Inc in the United States and/or other
jurisdictions. All other marks and names mentioned herein may be trademarks of their respective
companies.
All other product, brand, or trade names used in this publication are the trademarks or registered trademarks of their respective
trademark owners.

Regulatory Notices
Express5800/R320c-E4, R320c-M4 User's Guide
8
Regulatory Notices
FCC Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his own expense.
Industry Canada Class A Emission Compliance Statement
This Class A digital apparatus complies with Canadian ICES-003.
Avis de conformité à la réglementation d'Industrie Canada
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
CE / Australia and New Zealand Statement
This is a Class A product. In domestic environment this product may cause radio interference in which case the
user may be required to take adequate measures (EN55022).
BSMI Statement
Korean KC Standards
Registration NO. : KCC-REM-NEC-EXP320Q
Basic Model Number : EXP320Q
Trade Name or Registrant :NECCORPORATION :
Equipment Name : FT Server
Manufacturer : NEC CORPORATION
Turkish RoHS information relevant for Turkish market
EEE Yönetmeliğine Uygundur.

Regulatory Notices
Express5800/R320c-E4, R320c-M4 User's Guide 9
Disposing of your used product
In the European Union
EU-wide legislation as implemented in each Member State requires that used electrical and
electronic products carrying the mark (left) must be disposed of separately from normal household
waste. This includes Information and Communication Technology (ICT) equipment or electrical
accessories, such as cables or DVDs.
When disposing of used products, you should comply with applicable legislation or agreements
you may have. The mark on the electrical and electronic products only applies to the current
European Union Member States.
Outside the European Union
If you wish to dispose of used electrical and electronic products outside the European Union,
please contact your local authority and ask for the correct method of disposal.

Warnings and Additions to This Document
Express5800/R320c-E4, R320c-M4 User's Guide
10
Warnings and Additions to This Document
1. Unauthorized reproduction of the contents of this document, in part or in its entirety, is
prohibited.
2. The contents of this document may change without prior notice.
3. Do not make copies or alter the document content without permission from NEC Corporation.
4. Every effort has been made to ensure the completeness of this document. However, if you
have any concerns, or discover errors or omissions, please contact your retailer.
5. Regardless of these 4 items, NEC Corporation does not take responsibility for effects resulting
from operations.
6. The sample values used in this document are not the actual values.
Keep this document nearby so that you may refer to it as necessary.
Latest editions
This document was created based on the information available at the time of its creation. The screen images,
messages and procedures may differ from the actual screens, messages and procedures. Substitute as
appropriate when content has been modified.
The most recent version of User’s Guide, as well as other related documents, is also available for download
from the following website.
http://www.nec.com/

Precautions for Use (Be Sure to Read)
Express5800/R320c-E4, R320c-M4 User's Guide 11
Precautions for Use (Be Sure to Read)
The following provides information required to use your server safely and properly. For details of names in this
section, refer to Names and Functions of Components in this document.
Safety precautions
Follow the instructions in this document for the safe use of NEC Express server.
This User’s Guide describes hazardous parts of the server, possible hazards, and how to avoid them. Server
components with possible danger are indicated with a warning label placed on or around them (or, in some
cases, by printing the warnings on the server).
In User’s Guide or on warning labels, WARNING or CAUTION is used to indicate a degree of danger. These
terms are defined as follows:
WARNING Indicates there is a risk of death or serious personal injury
CAUTION Indicates there is a risk of burns, other personal injury, or property damage
Precautions and notices against hazards are presented with one of the following three symbols. The individual
symbols are defined as follows:
Attention This symbol indicates the presence of a hazard if
the instruction is ignored.
An image in the symbol illustrates the hazard type.
Prohibited
Action This symbol indicates prohibited actions. An image
in the symbol illustrates a particular prohibited
action.
Mandatory
Action This symbol indicates mandatory actions. An
image in the symbol illustrates a mandatory action
to avoid a particular hazard.
(Electric shock risk)
(Do not disassemble)
(Example)
(Example)
(Example)
(Disconnect a plug)

Precautions for Use (Be Sure to Read)
Express5800/R320c-E4, R320c-M4 User's Guide
12
(A label example used in this User’s Guide)
Symbols used in this document and on warning labels
Attentions
Indicates the presence of electric shock
hazards. Indicates the presence of mechanical parts that can result in bodily injury.
Indicates the presence of a hot surface o
r
component. Touching this surface could
result in bodily injury.
Indicates the presence of mechanical parts
that can result in pinching or other bodil
y
injury.
Indicates there is a risk of explosion. Indicates the presence of laser beam that
cause blindness.
Indicates there is a risk of fire or fumes. Indicates a general notice or warning that
cannot be specifically identified.
Prohibited Actions
Do not disassemble, repair, or modify the
server. Otherwise, an electric shock or fire
may be caused.
Do not touch the server with wet hand.
Otherwise, an electric shock may be caused.
Do not touch the component specified by
this symbol. Otherwise, an electric shock o
r
burn may be caused.
Do not use the server in the place where
water or liquid may pour. Otherwise, an
electric shock or fire may be caused.
Do not place the server near the fire.
Otherwise, a fire may be caused. Indicates a general prohibited action that cannot be specifically identified.
Mandatory Actions
Unplug the power cord of the server.
Otherwise, an electric shock or fire may be
caused.
Indicates a mandatory action that cannot be
specifically identified. Make sure to follo
w
the instruction.
Make sure equipment is properly grounded.
Otherwise, an electric shock or fire may be
caused.
WARNING
Use only the specified outlet
Use a grounded outlet with the specified voltage. Use of an improper power source
may cause a fire or a power leak.
Symbol to draw
attention Description of a warning Term indicating a degree of danger

Precautions for Use (Be Sure to Read)
Express5800/R320c-E4, R320c-M4 User's Guide 13
Safety notes
This section provides notes on using the server safely. Read this section carefully to ensure proper and safe use
of the server. For symbols, refer to Safety precautions.
General
WARNING
Do not use the server for services where human life may be at stake or high reliability is required.
This server is not intended for use in medical, nuclear, aerospace, mass transit or other applications where
human life may be at stake or high reliability is required, nor is it intended for use in controlling such
applications. We disclaim liability for any personal injury and property damages caused by such use of this
server.
Do not use the server if any smoke, odor, or noise is present.
If smoke, odor, or noise is present, immediately turn off the server and disconnect the power plug from the
outlet, then contact the store where you purchased the product or your maintenance service company.
Using the server in such conditions may cause a fire.
Do not insert needles or metal objects.
Do not insert needles or metal objects into ventilation holes in the server or openings in the optical disk
drive. Doing so may cause an electric shock.
Use a rack that conforms to the designated standard
This server can be mounted onto a 19-inch rack that conforms to EIA standards. Do not mount the server
onto any rack that does not conform to EIA standards. Doing so may cause a server malfunction, personal
injury, or damage to peripheral devices. For more information about racks that can be used with the
server, consult with your maintenance service company.
Use the server only under the specified environment
Do not install the server rack in any environment that is not suitable for installation.
Installation in an unsuitable environment is harmful for the server and other systems installed in the rack
and may cause fire or personal injury due to the rack falling. For a detailed explanation on installation
environments or seismic reinforcement, consult with the instruction manual supplied with the rack or your
maintenance service company.
CAUTION
Keep water or foreign matter away from the server.
Do not let any liquid such as water or foreign materials including pins or paper clips enter the server.
Failure to follow this warning may cause an electric shock, a fire, or failure of the server. When such things
accidentally enter the server, immediately turn off the power and disconnect the power plug from the
outlet. Do not disassemble the server, and contact the store where you purchased the product or your
maintenance service company.

Precautions for Use (Be Sure to Read)
Express5800/R320c-E4, R320c-M4 User's Guide
14
Rack installation
CAUTION
Do not attempt to carry or install the server alone
More than two people are required to carry or install the rack. Otherwise, the rack may fall, resulting in
personal injury or damage to peripheral devices. In particular, tall racks such as a 44U rack become
unstable unless steadied with a stabilizer. Make sure that two or more people hold the rack to carry or
install the rack.
Do not install with the load weight distributed unevenly
To avoid unevenly distributing the load of the rack and server, install a stabilizer or connect multiple racks
to distribute the weight. Otherwise, the rack may fall, resulting in personal injury.
Do not install components alone, and check the door hinge pins of the rack
Two or more people are required to install the rack components such as the door or rails. When installing
the door, make sure that both upper and lower hinge pins are held in place. Incomplete attachment may
cause components to fall off as well as personal injury.
Do not extend any device from the rack that is not stabilized
When extending a device from the rack, make sure that the rack is stable (by using a stabilizer or seismic
reinforcement). Otherwise, the rack may fall, resulting in personal injury.
Do not extend more than one device out of the rack
Extending multiple devices from the rack may cause the rack to fall, resulting in personal injury. Extend
only one device at one time.
Do not exceed the rated capacity of the power supply when connecting devices
To prevent burn injuries, fire, and damage to the server, make sure the load on the branch circuit that
supplies power to the rack will not exceed the rated load. For inquiries regarding the installation or wiring of
the power supply system, consult with the company that performed the installation or wiring, or the power
company that services your area.

Precautions for Use (Be Sure to Read)
Express5800/R320c-E4, R320c-M4 User's Guide 15
Power supply and power cord use
WARNING
Do not hold the power plug with a wet hand.
Do not disconnect/connect the plug while your hands are wet. Failure to follow this warning may cause an
electric shock.
Do not connect the ground wire to a gas pipe.
Never connect the ground wire to a gas pipe. Failure to follow this warning may cause a gas explosion.
CAUTION
Plug in to a proper power source.
Use a grounded outlet with the specified voltage. Use of an outlet with a voltage other than that specified
causes fire and electrical leakage. Do not install the server in any environment that requires an extension
cord. Connecting to a cord that does not conform to the power supply specs of the server causes
overheating, resulting in fire.
If you want to use an AC cord set with a ground wire of class 0I, be sure to connect the ground wire before
inserting the power plug into the outlet. Before disconnecting the ground wire, be sure to disconnect the
power plug from the output.
Do not connect many cords into a single outlet by using extension cords.
The electric current exceeding the rated flow overheats the outlet, which may cause a fire.
Insert the power plug into the outlet as far as it goes.
Heat generation resulting from a halfway inserted power plug (imperfect contact) may cause a fire. Heat
will also be generated if condensation is formed on dusty blades of the halfway inserted plug, increasing
the possibility of fire.
Do not use any unauthorized interface cable.
Use only the interface cables provided with the server. Electric current that exceeds the amount allowed
could cause fire. Also, observe the following precautions to prevent electrical shock or fire caused by a
damaged power cord.
Do not stretch the cord harness
Do not bend the power cord.
Do not twist the power cord
Do not step on the power cord.
Uncoil the power cord before use
Do not secure the power cord with staples or
equivalents
Do not pinch the power cord
Keep chemicals away from the power cord
Do not place any object on the power cord
Do not alter, modify, or repair the power cord
Do not use a damaged power cord (replace the
damaged power cord with a power cord of the
same standard. For information on replacing
the power cord, contact the store where you
purchased the product or a maintenance
service company)

Precautions for Use (Be Sure to Read)
Express5800/R320c-E4, R320c-M4 User's Guide
16
CAUTION
Do not use the attached power cord for any other devices or usage.
The power cord that comes with your server is designed aiming to connect with this server and to use with
the server, and its safety has been tested. Do not use the attached power cord for any other purpose.
Doing so may cause a fire or an electric shock.
Do not pull out a cable by gripping the cable part.
Pull a cable straight out by gripping the connector part. Pulling a cable by gripping the cable part or
applying extra pressure to the connector part may damage the cable part, which may cause a fire or
electric shock.
Installation, relocation, storage, and connection
CAUTION
Do not attempt to lift the server by yourself
Some servers weigh up to 51 kg depending on the server components. Carrying the server by yourself
may damage your back. At least two people should securely hold the server from the bottom when
carrying it. Do not attempt to lift the server while the front bezel attached. Doing so causes the front bezel
to fall off the server, resulting in personal injury.
Do not install the server in any place other than specified.
Do not install the server in the following places or any place other than specified in this User's Guide.
Failure to follow this instruction may cause a fire.
A dusty place
A humid place such as near a boiler
A place exposed to direct sunlight
An unstable place
Do not use the server in an environment where corrosive gas is present
Do not install the server in a place subject to corrosive gases including sodium chloride, sulfur dioxide,
hydrogen sulfide, nitrogen dioxide, chlorine, ammonia, or ozone. Do not install the server in an
environment that contains dust, chemicals that accelerate corrosion such as NaCl or sulfur, or conductive
materials. Failure to follow this warning may cause the wiring on the printed wiring board to short-circuit,
leading to fire. If you have any questions, contact the store where you purchased the product or a
maintenance service company.
Do not install the server while the cover is removed
Do not install the server to a rack while the cover or other relevant items removed. Not only will the cooling
effect within the server decrease, causing the server to malfunction, but also may allow dust to enter the
server, resulting in fire or electrical shock.
Do not get your fingers caught in the rails
When mounting/removing the server onto/from the rack, be careful to avoid getting your fingers caught in
the rails or cutting your fingers on the rails.

Precautions for Use (Be Sure to Read)
Express5800/R320c-E4, R320c-M4 User's Guide 17
CAUTION
Do not apply any weight on the server when it is extended from the rack
Do not apply force on the server when it is extended from the rack. Doing so cause the frames to bend,
which makes it impossible to be mounted on the rack. It also may cause the server to fall, resulting in
personal injury.
Do not attempt to connect or disconnect the interface cable while the power cord is plugged into
an outlet
Be sure to unplug the power cord from a power outlet before connecting/disconnecting any interface cable
to/from the server. If the server is off-powered but its power cord is plugged to a power source, touching a
cable or connector may cause an electric shock or a fire resulted from a short circuit.
Use only the specified interface cable.
Use only interface cables provided by NEC and locate a proper device and connector before connecting a
cable. Using an authorized cable or connecting a cable to an improper destination may cause a short
circuit, resulting in a fire.
Also, observe the following notes on using and connecting an interface cable.
Do not use any damaged cable connector.
Do not step on the cable.
Do not place any object on the cable.
Do not use the server with loose cable connections.
Do not use any damaged cable.
Cleaning and working with internal devices
WARNING
Do not disassemble, repair, or alter the server.
Never attempt to disassemble, repair, or alter the server on any occasion except as described in this
document. Failure to follow this warning may cause not only malfunction of the server but also an electric
shock or fire.
Do not attempt to remove lithium, NiMH, or Li-ion batteries.
The server contains the lithium, NiMH, or Li-ion battery. Do not remove the battery. Placing a battery close
to a fire or in the water may cause an explosion.
When the server does not operate appropriately due to the dead battery, contact the store you purchased
the product or your maintenance service company. Do not attempt to disassemble the server to replace or
recharge the battery by yourself.
Disconnect the power plug before cleaning the server.
Be to power off the server and disconnect the power plug from a power outlet before cleaning or
installing/removing internal optional devices. Touching any internal device of the server with its power cord
connected to a power source may cause an electric shock even of the server is off-powered.
Occasionally disconnect the power plug from the outlet and clean the plug with a dry cloth. Heat will be
generated if condensation is formed on a dusty plug, which may cause a fire.

Precautions for Use (Be Sure to Read)
Express5800/R320c-E4, R320c-M4 User's Guide
18
CAUTION
High temperature
Components including internal hard disk drives in the server are extremely hot just after the server is
turned off. Allow the surface to cool before installing/removing.
Secure cables or cards in place
Be sure to secure the power cord, interface cables, and cards in place. Incomplete installation causes a
loose connection, resulting in smoke or fire
During operation
CAUTION
Do not pull out or remove the server from the rack.
Do not pull the server out of the rack or remove it from the rack. In addition to causing equipment to not
function properly, separating the server from the rack may result in personal injury.
Avoid contact with the server during thunderstorms.
Do not touch any part of the server including the cables when a thunderstorm is approaching. Also, do not
connect or disconnect any devices. There may be a risk of electric shock from lightning strike.
Keep animals away from the server.
Keep animals such as pets away from the server. Pet hair or other waste enters the server, which may
cause a fire or electric shock.
Do not leave the optical disk drive tray open.
Dust may get in the server when the tray is open, which may result in a malfunction. In addition, bumping
the open tray could cause personal injury.
Do not remove the server from the rack while it is operating.
Do not pull out or remove the server from the rack while the server is running. In addition to causing
equipment to not function properly, separating the server from the rack may result in personal injury.
Do not place any object on top of servers.
Separating the server from the rack may result in personal injury and damage to nearby personal
belongings.
Do not get yourself caught in the fan
Keep your hands and hair away from the cooling fan at the rear of the server during operation. Failure to
observe this warning may cause your hands or hair to catch in the fan, resulting in personal injury.

Precautions for Use (Be Sure to Read)
Express5800/R320c-E4, R320c-M4 User's Guide 19
安全注意事項
本節講述安全使用本伺服器所需的注意事項。為了您正確安全地使用本伺服器，請仔細閱讀該節內容。符號
的相關說明請參考“安全標示（SAFETY INDICATIONS）＂說明。
一般注意事項
WARNING
請勿用於危及人命和需要高度可靠性的操作上。
請勿安裝本伺服器於醫療設備、原子能設備、航空宇宙機器、運輸設備等會危及人命以及需要高
度可靠性的設備和機器上，也勿使用本伺服器來控制這些機器。如果將本伺服器用於這類系統的
設備及機器，所造成人身事故及財產損失等後果，本公司概不負責。
發生冒煙、異味、雜音時請勿使用。
發生冒煙、異味、雜音等時，請立即關閉電源，並將電源插頭從插座上拔下。然後請與您的服務
代表聯繫。繼續使用會導致火災。
伺服器內請勿插入鐵絲和金屬片。
請勿將金屬片和鐵絲等異物插入通氣孔或軟碟機或光碟機的縫隙。有觸電的危險。
請勿在未指定的場所使用本產品。
請安裝伺服器於標準EIA 19吋的機架，請勿在不適當的場所安裝伺服器於機架。
否則，可能造成伺服器及機架內的其他系統受到不良影響，且機架脫落可能導致火災或者人身傷
害。有關安裝環境和防震技術的詳細事項請參閱附帶的用戶手冊或與經銷商或維護服務公司聯
繫。
請參照相關標準安裝伺服器於機架。
請依照EIA標準安裝伺服器於機架內。請勿安裝伺服器於除了標準EIA 19吋以外的任何機架或不
適當的機架。否則可能引起伺服器操作不正確或人員傷害或周圍壞境設備的損害，請聯繫您伺服
器的機架服務代表。
CAUTION
伺服器內請勿進水和異物。
伺服器內請勿進水或有外來異物(如針或夾子等)，否則可能導致火災、觸電或伺服器故障。一旦
有異物進入，請立即關閉電源，將電源插頭從插座拔下來。請勿自行拆卸，請聯繫您的服務代表。

Precautions for Use (Be Sure to Read)
Express5800/R320c-E4, R320c-M4 User's Guide
20
機 架
CAUTION
請勿一個人單獨搬運或安裝伺服器。
請至少一人以上搬運或安裝機架，否則可能造成機架掉落導致人員傷害或損壞周圍設備，特別是高
機架(如44U機架)必須用固定器來維持其穩定度，所以需要超過一人以上的人來搬運或安裝機架。
安裝伺服器時，請勿集中一個地方來承載所有的重量。
在機架上加裝固定器來避免單一地方承載重量或同時安裝更多機架來分散承載重量，否則機架可能
倒下造成人員傷害。
請勿一個人單獨安裝伺服器零件。
請至少一人以上安裝包含如機架的門或托盤等零件，否則可能造成部份零件掉落損壞或人員傷害。
請完全插入鏈栓。
當安裝機架門時，請確認機架門上方及下方的鏈栓已完全插入機架，否則可能造成機架門掉落損壞
或人員傷害。
請勿在機架不穩固時抽出設備。
在抽出設備之前請確認機架式是穩固的(使用穩固器或者通過抗震技術固定)。
請勿從機架抽出超過一個以上的設備。
同時抽出超過一個以上的設備可能導致機架傾倒。一次只能從機架抽出一個設備。
請勿配線超過伺服器的電源功率。
為了避免發熱、火災和設備損壞，請務必確保不要超過線路的額定負載。有關電力設備的安裝和電
線的更多資訊請聯繫電工或者當地的電力公司。
