Nederman L-PAK Series User manual

L-PAK Series
L-PAK 150/250 Standard
50Hz, 60Hz
2130224(00)2018-09-13
Original PLC manual
EN PLC MANUAL
PLCManual

L-PAK 150/250 Standard
3
Figures.................................................................................................................................................................. 4
English................................................................................................................................................................... 5

L-PAK 150/250 Standard
4
ESC OK
NEDERMAN
Hi Vacum Unit
L-PAK
OFF
TimeTo Service
2000 Hours
ESC OK
Hi Vacuum Unit
Standby
Waing For
Pilot Signal
Mo 15:33
2018-01-22
ESC OK
Hi Vacuum Unit
IDLING
Time To StandBy
T > 12:00m
ESC OK
Hi Vacuum Unit
Running
Time 05:33 Min
DIRTm 00:00 s
OTTmr 00:00 h
ESC OK
Hi Vacuum Unit
IDLING
Time To StandBy
T= 05:33m
PS
PS
ESC OK
Hi Vacuum Unit
Running
Time 05:33 Min
DIRTm < 10:00 s
OTTmr 00:00 h
ESC OK
Hi Vacuum Unit
Running
Time 06:33 Min
DIRTm > 10:00 s
OTTmr 00:00 h
ESC OK
Hi Vacuum Unit
IDLING
Time To StandBy
T < 12:00m
PS
Running
P = -20 kPa
IDLING
P = 0 kPa
PS
PS
Pilot signal OFF
Pilot signal On
Figures
1

L-PAK 150/250 Standard
5
EN
Table of contents
English
PLC Manual
1 Preface................................................................................................................................................................................ 6
2 Safety................................................................................................................................................................................... 6
3 Descripon ....................................................................................................................................................................... 6
4 Unit operaon ................................................................................................................................................................ 6
4.1 Soware with extended funconality............................................................................................... 6
4.2 Unit operaon modes................................................................................................................................. 7
5 PLC messages.................................................................................................................................................................. 7
5.1 Status messages............................................................................................................................................. 7
5.1.1 L-PAK O (O mode)....................................................................................................................... 8
5.1.2 L-PAK Standby (Standby mode)................................................................................................. 8
5.1.3 Running (Running mode).............................................................................................................. 8
5.1.4 Idling (Idling mode).......................................................................................................................... 8
5.1.5 Filter Cleaning..................................................................................................................................... 9
5.1.6 Status report........................................................................................................................................ 9
5.2 Warning messages........................................................................................................................................ 9
5.2.1 Time for service................................................................................................................................10
5.2.2 Warning! Fan Hi Temp .................................................................................................................10
5.3 Alarm messages ...........................................................................................................................................10
5.3.1 Alarm! Fan Hi Temp........................................................................................................................11
5.3.2 Alarm! Motor Protector Acvated ........................................................................................11
5.3.3 Alarm! Low Pressure CAS ...........................................................................................................11
6 PLC sengs ....................................................................................................................................................................12
6.1 Find a parameter and set its value ....................................................................................................12
6.2 Parameter sengs......................................................................................................................................13
6.2.1 Adjust the me and date............................................................................................................13
6.2.2 H-Meter 1............................................................................................................................................13
6.2.3 SSR_Time .............................................................................................................................................14
6.2.4 DIR_Time .............................................................................................................................................14
6.2.5 FCTmr .....................................................................................................................................................14
6.2.6 Clean cycle .........................................................................................................................................14
6.3 Standard Cleaning process ....................................................................................................................15
6.4 Warning-Alarm output Q4 .....................................................................................................................15
6.5 Standby (Ready) indicator ......................................................................................................................15

L-PAK 150/250 StandardEN
6
1 Preface
Read this manual carefully before installaon, use and service of this product. Replace
the manual immediately if lost. Nederman reserves the right, without previous noce, to
modify and improve its products including documentaon.
This product is designed to meet the requirements of relevant EC direcves. To maintain
this status, all installaon, maintenance and repair is to be done by qualied personnel
using only Nederman original spare parts and accessories. Contact the nearest authorized
distributor or Nederman for advice on technical service and obtaining spare parts. If there
are any damaged or missing parts when the product is delivered, nofy the carrier and the
local Nederman representave immediately.
2 Safety
This document contains important informaon that is presented as either a warning,
cauon or note. See the following examples:
WARNING! Risk of personal injury.
Warnings indicate a potenal hazard to the health and safety of personnel, and how that
hazard may be avoided.
CAUTION! Risk of equipment damage.
Cauons indicate a potenal hazard to the product but not to personnel, and how that
hazard may be avoided.
NOTE! Notes contain other informaon that is important for personnel.
3 Descripon
WARNING! Risk of personal injury.
See the User manual.
4 Unit operaon
4.1 Soware with extended funconality
L-PAK 150/250 Advanced comes with extended soware and standard Logo! PLC display
that allows a technician to easily set parameters and read status messages.
NOTE! If the soware is used in a logo without a display, it is not possible to change
parameter sengs.

L-PAK 150/250 Standard
7
EN
4.2 Unit operaon modes
L-PAK 150/250 Advanced has the following four operaon modes:
1. O mode
2. Standby mode
3. Running mode
4. Idling mode
See Secon 5.1. Status messages for more informaon about each mode. How the unit
moves from one operaon mode to another is explained below. See also Figure 1 for a ow
chart showing how the unit goes through its four dierent operaon modes.
When the unit is in O mode, the unit can be put into Standby mode (the unit is ready)
with its motor o and the Filter Cleaning Valve (FCV) closed by pressing the Standby/
Running buon. While the unit is in Standby mode, the unit can be put back into O mode
again by pressing the Standby/Running buon.
The unit goes from Standby mode into Running mode when it receives a pilot signal by a
valve being opened at one or more work staons (in other words, someone starts to work).
The unit’s motor is now on and the FCV is closed. The DIR_Time and SSR_Time mers are
not started, see Secons 6.2.4. DIR_Time and 6.2.3. SSR_Time.
The unit stays in Running mode as long as there is an acve pilot signal. However, the unit
can sll be put into O mode by pressing the Standby/ Running buon.
Note that if only one workstaon is connected to the unit, or if only one work staon is
in use and work stops at that one staon, the pilot signal stops. If there is more than one
work staon connected to the unit, and more than one work staon is in use, the pilot
signal only stops if work stops at all workstaons (in other words, all valves close).
When the pilot signal stops, the DIR and SSR mers start. If work resumes at one or more
work staons within 10 seconds, the unit stays in Running mode. The DIR and SSR mers
are reset back to zero and are stopped.
If DIR_Time is set for 10 seconds (default), and the pause in work is longer than 10 seconds,
DIR_Time elapses. The unit then goes into Idling mode with its motor on and the FCV open.
If a new pilot signal is sent within 12 minutes, the unit goes back into Running mode. The
DIR and SSR mers are again reset to zero and are stopped. However, if SSR_Time is set for
12 minutes, which is the default seng, and there is no new pilot signal within 12 minutes,
SSR_Time also elapses.
The unit then goes into Standby mode unl it either receives a new pilot signal that puts
the unit back into Running mode, or the unit is turned o (in other words, put into O
mode) by pressing the Standby/Running buon.
5 PLC messages
The following secons show the dierent status, warning and alarm messages that can be
seen in the PLC display.
5.1 Status messages
The following status messages give informaon about what mode the unit is in or what
roune service is being performed.

L-PAK 150/250 StandardEN
8
5.1.1 L-PAK O (O mode)
The unit is in O mode, which is also the unit’s start menu. The unit can also go into O
mode if something is wrong, such as if an alarm is acvated. The pump motor is o, there is
no vacuum, the FCV is closed, and the unit cannot be acvated by a pilot signal.
ESC OK
Nederman
Hi Vacuum Unit
L-PAK
OFF
Time To Service
2000 hours
TimeToService: The amount of me unl next scheduled service. The
default seng is 2000 hours. See Secon 6.2.2. H-Meter 1.
5.1.2 L-PAK Standby (Standby mode)
The unit is in Standby mode and is ready. The pump motor is o, there is no vacuum, the
FCV is closed, and the unit is waing for a pilot signal to go into Running mode.
ESC OK
Hi Vacuum Unit
Standby
Waing For
Pilot Signal
Mo 15:33
2018-01-22
5.1.3 Running (Running mode)
The unit in Running mode. The pump motor is on and the unit generates a vacuum. The
FCV is closed.
ESC OK
Hi Vacuum Unit
Running
Time 05:33 Min
DIRTm 00:00 s
DIRTm: The amount of me before the unit goes into Idling mode. The
default is 10 seconds. See also Secon 6.2.4. DIR_Time.
OTTmr: If the Overme mer has been acvated, OTTmr shows the
elapsed me since the overme mer started.
Time: The number of minutes the fan engine has been running since the
last start.
5.1.4 Idling (Idling mode)
The unit in Idling mode. The pump motor is on, there is no vacuum, and the FCV is open.
The unit goes into Idling mode when there has been no pilot signal for the me set in DIR_
Time, see Secon 6.2.4. DIR_Time.
ESC OK
Hi Vacuum Unit
IDLING
Time To
StandBy
05:33m
Time to Standby: The amount of me unl the unit goes into Standby
mode. The default seng is 12 minutes. See Secon 6.2.3. SSR_Time.

L-PAK 150/250 Standard
9
EN
5.1.5 Filter Cleaning
The unit is cleaning its lter.
ESC OK
Filter
Cleanining
Cycles 1
Elapsed 0
Clean 00:00 s
Charge 00:00 s
Cycles: How many cleaning pulses will be carried out.
Elapsed: How many cleaning pulses are made.
Clean: Remaining me for cleaning pulse.
Charge: Remaining vacuum build me; the me unl cleaning pulse is
acvated.
5.1.6 Status report
1.
ESC OK
Thu 10:45
2018-02-01
ESC OK
ESC + C 9/9
ESC OK
Status Report 2
CASAlarm 1
ESC OK
Status Report 1
Sn: 2180523-0-EN
Starts 0
FLT M-Prot 0
FanTempHi 0
CleanePulse 0
ESC OK
NEDERMAN
Hi Vacum Unit
L-PAK Standard
OFF
TimeTo Service
2000 Hours
Press the down arrow once to show the me and date screen.
2. Press the right arrow unl the arrow screen appears.
1) Press Escape
ESC
and the up arrow at the same me to show the Status Report
screen.
2) Press Escape
ESC
and the up arrow at the same me to show the next Status
Report screen.
Sn Soware number– Revision- Language.
Starts The number of motor starts.
FLT M-Prot Number of mes motor overload protector has been acvated.
FanTempHi Number of mes Hi Temp Fan, thermostat has acvated fan Cooling.
CleanePulse Number of cleaning pulses by the cleaning valve.
CASAlarm How many mes Compressed Air Switch has alerted for low pressure.
5.2 Warning messages
If a warning is acvated, there is a problem that needs to be corrected, but the unit
connues to work.
When a warning is acvated, Output Q4 and White lamp buon “Filter Cleaning/ Test
start” ash with intervals, 1 second On/3 second O.
If the ush valve funcon is chosen, it disconnects Output Q4 as a warning/Alarm signal
output. See secon 6.5. Warning-Alarm output Q4.

L-PAK 150/250 StandardEN
10
5.2.1 Time for service
The me interval set in the ‘Service Interval Seng’ menu has expired. If this alarm is
acvated, the light in the Standby/Running buon is lit one second and then again in 7
seconds. This 1/7 on/o sequence connues unl the warning is reset.
Reset the alarm by rst pung the unit into O mode. Press the manual lter cleaning
buon for 10 seconds.
ESC OK
Hi Vacuum Unit
Time for
Service
Th 15:01
Reset OK 
5.2.2 Warning! Fan Hi Temp
The fan is overheated. The temperature is greater than 125°C, and the lter cleaning valve
is open to cool the fan. When the Fan-temperature is below 90°C, the lter cleaning valve
closes and vacuum is reestablished again.
When the fan cooling funcon acvates a mer start, which is shown in the display, if the
fan does not cool down when the mer elapses, the vacuum unit will stop and the Alarm
message, “Alarm Fan Hi Temp” is acvated.
ESC OK
Warning!
Fan Hi Temp
Fan Cooling
Acvated
Time To Stop
00:00 m
Time to Stop: Remaining me unl L-Pak is stopped.
5.3 Alarm messages
When an Alarm is acvated, Output Q4 and White lamp buon “Filter Cleaning/ Test start”
ash with intervals, 1 second On/1 second O. If an alarm is acvated, the unit goes into
O mode unl the problem is corrected. Specic Alarm Motor Protector Acvated, and
Alarm Fan Hi Temp are crical alarms and need to be Acknowledged by pressing ‘OK’
OK
.
Other Alarms such as Low Pressure CAS, Alarm Bin Level High and Alarm Filter Clogged are
not crical alarms and do not need to be Acknowledged.
If the ush valve funcon is chosen, it disconnects Output Q4 as a warning/Alarm signal
output. See secon 6.5. Warning-Alarm output Q4.

L-PAK 150/250 Standard
11
EN
5.3.1 Alarm! Fan Hi Temp
When the fan temperature passes above 125°C, a Warning Fan Hi Temp message is
displayed, and the lter cleaning valve opens to let air in to cool the fan.
If the lter-cleaning valve has been open to cool the fan more than 8 minutes, and the
temperature has not gone below 90°C. The unit shuts o and the message Alarm Fan Hi
Temp is displayed. Correct the problem, and press ‘OK’
OK
to reset the warning.
ESC OK
Alarm!
Fan Hi Temp
Vacuum Unit
Off
Th 11:23
Reset OK 
Th: The actual day and me when L-Pak was stopped.
5.3.2 Alarm! Motor Protector Acvated
The motor is overheated. Correct the problem, and press ‘OK’
OK
to reset the warning.
ESC OK
Alarm!
Motor
Protector
Acvated
Th 11:23
Reset OK 
Th: The actual day and me when L-Pak was stopped.
5.3.3 Alarm! Low Pressure CAS
This alarm is only shown when the Compressed Air Switch (CAS) is installed.
The compressed air level is low. When the accurate pressure is established, No reset is
required aer acve alarm message.
ESC OK
Alarm!
Compressed Air
Low Pressure
CAS<3Bar
Th 11:23
Th: The actual day and me when L-PAK was stopped.

L-PAK 150/250 StandardEN
12
6 PLC sengs
6.1 Find a parameter and set its value
ESC OK
NEDERMAN
Hi Vacum Unit
L-PAK Standard
OFF
TimeTo Service
2000 Hours
ESC OK
Thu 10:45
2018-02-01
ESC OK
Stop >
>
Setup >
Network >
Diagnoscs >
Program
ESC OK
Set Parameter
Program Name
ESC OK
H-Meter >
ZV-Detect >
SSR_Time >
DIRTmr >
OTTmr Z
WeekTmr >
Do the following to nd a parameter and set its value:
1. From the PLC status screen, press the down arrow to go to the date and me
screen.
2. Press ‘Escape’
ESC
to go to the main menu.
3. Press the down arrow to go to ‘Program’. Press ‘OK’
OK
to conrm.
4. Select ‘Set Parameter’. Press ‘OK’
OK
to conrm.
5. Use the up or down arrows to nd the parameter. Press ‘OK’
OK
to conrm.
6. Use the le and right arrows to select a value.
7. Use the up or down arrows to set the value. Press ‘OK’
OK
to conrm.
8. Press ‘Escape’
ESC
to go to the main menu.
9. Press ‘Escape’
ESC
to go to go to the date and me screen.
10. Press the up arrow to exit.
NOTE! There are several other input menus on the same level as the date and me screen.
If pressing the down arrow takes the PLC to one of those menus, use the le arrow to
get to the date and me screen.
NOTE! The blinking cursor shows the current value that can be changed.

L-PAK 150/250 Standard
13
EN
6.2 Parameter sengs
The following PLC displays show the dierent sengs that can be congured for the unit.
6.2.1 Adjust the me and date
ESC OK
Thu 10:45
2018-02-01
ESC OK
NEDERMAN
Hi Vacum Unit
L-PAK Standard
OFF
TimeTo Service
2000 Hours ESC OK
Stop >
Program >
Setup >
Network >
Diagnoscs >
ESC OK
Msg Config >
Start Screen >
Clock >
LCD >
Menu Language >
Switch to OP
ESC OK
Set Clock >
S/W me >
Sync > Thu 10:45
2018-02-01
ESC OK
Set Clock
Do the following to adjust the me and date:
1. From a PLC status screen, press the down arrow to go to the date and me screen.
2. Press ‘Escape’
ESC
to get to the main menu.
3. Press the down arrow to go to ‘Setup’. Press ‘OK’
OK
to conrm.
4. Press the down arrow to go to ‘Clock’. Press ‘OK’
OK
to conrm.
5. Press the down arrow to go to ‘Set Clock’. Press ‘OK’
OK
to conrm.
6. Use the le and right arrows to move to cursor to parameter value. Press ‘OK’
OK
to conrm.
7. Use the up or down arrows to set Time or Date. Press ‘OK’
OK
to conrm.
Weekday is automacally set by the date.
8. Press ‘Escape’
ESC
3 mes to go to the me screen.
9. Press the up arrow to exit.
NOTE! There are several other input menus on the same level as the date and me screen.
If pressing the down arrow takes the PLC to one of those menus, use the le arrow to
get to the date and me screen.
6.2.2 H-Meter 1
Menu for seng the service interval. The default value is 2000 hours.
ESC OK
H-Meter 1/1
MI =2000h:0m
OT =0h:15m
MN =1999h:45
MN Ext =2000
MI = Congured, me, between, maintenance interval
OT = Accumulated, total operang me
MN = Time le unl next maintenance
MI = 2000h: The amount of me between service intervals.
MI = 2000h: The amount of me between service intervals.

L-PAK 150/250 StandardEN
14
6.2.3 SSR_Time
Menu for seng the SSR mer. The SSR mer is for the amount of me before the unit
goes from Idling mode to Standby mode when the pilot signal disappears.
ESC OK
SSR_Time 1/1
T = 12:00m
Ta = 00:00
T = 12:00m: Time before SSR_Time is acvated. The default seng is 12
minutes. The minimum seng is 5 minutes.
Ta = 00:00: The elapsed me since the pilot signal disappeared.
6.2.4 DIR_Time
Menu for seng the DIR mer. The DIR mer is the amount of me before the unit goes
from Running mode into Idling mode when the pilot signal disappears.
ESC OK
DIRTmr 1/1
T = 10:00s
Ta = 00:00
T = 10:00s: Time before DIR_Time is acvated. The default seng is 10
seconds The minimum seng is 5 seconds.
Ta = 00:00: The elapsed me since the pilot signal disappeared.
6.2.5 FCTmr
Menu for acvang and seng me between mer controlled lter cleaning.
ESC OK
FCTmr 1/1
Stat = ON
TH = 01:00s
TL = 60:00m
Stat =On Filter Cleaning mer acvated Default is On.
TH=01:00s: Do not change the default seng of 1 second.
TL=60:00m: Time between automac lter cleanings. The default seng
is 60 minutes.
Ta=00:00: The elapsed me since the last automac cleaning was
acvated.
6.2.6 Clean cycle
Menu for seng the opening and closing mes for the “FCV” Filter Cleaning Valve.
FCV cleaning cycle repeats X mes depend on value of parameter ‘On’.
This funcon is always acve when lter cleaning takes place.
ESC OK
Clean Cyc 1/1
Tch = 05:00s
Tpu = 01:00s
On = 1
Cnt =0
Tch = Vacuum Building me (Charge Time): Default is 5 seconds.
Tpu = Clean pulse me. Default 1 second.
On = Number of cleaning pulses.
Cnt = 0: Elapsed cleaning pulses.
NOTE! For the parameter ‘On’, the minimum value = 1.
NOTE! If On is set to 0, No lter cleaning is performed.
Time duraon for a cleaning cycle below:
Example: 1 Cleaning pulse
On=1, Tch=5, Tpu=1 → On * (Tch + Tpu) = 1*(5+1) =6s where Tch=05:00s and Tpu=01:00s.
The default me for a complete cleaning cycle is 6 seconds.

L-PAK 150/250 Standard
15
EN
Example: 2 Cleaning pulses
On=2, Tch=5, Tpu=1 → On * (Tch + Tpu) = 2*(5+1) =12s where Tch=05:00s and Tpu=01:00s.
The default me for a complete cleaning cycle is 12 seconds
6.3 Standard Cleaning process
The lter cleaning process is always acvated aer the pilot signal (PS) or (PSIFC) has
disappeared and DIR Time has elapsed.
If ushing funcon is acvated, ushing will be done before lter cleaning takes place.
The lter cleaning valve opens and the lter cleaning process generates a preset number of
cleaning pulses. The unit then goes into Idle mode keeping cleaning valve open.
See funcon in secon 6.2.6. Clean cycle to set numbers of pulses and related parameters.
See funcon in secon 6.2.5. FCTmr to acvate Timer controlled Filter cleaning.
6.4 Warning-Alarm output Q4
Potenal free output Terminal X1:33-34.
When an alarm is acvated, Output Q4 and White lamp buon on the control box side
ash with interval 1 second on / 1 second o .
Warning -Alarm Output Q4, switch with an interval 1 second on / 1 seconds O, if one or
more of the alarms listed below are acve:
• The fan temperature is over 125°C see secon 5.3.1. Alarm! Fan Hi Temp.
• The motor is overheated see secon 5.3.2.Alarm!MotorProtectorAcvated.
• The compressed air level is low see secon 5.3.3. Alarm! Low Pressure CAS.
Warning -Alarm Output Q4, switch with an interval 1 second on /3 seconds O, if one or
more of the warnings listed below are acve:
• Warning Fan Hi Temp see 5.2.2. Warning! Fan Hi Temp.
6.5 Standby (Ready) indicator
The H1 lamp/Output DO1 acts as a Standby (unit ready) indicator. The H1 Lamp/DO1 is
acvated when the unit is in Standby mode or the fan is running. The H1 lamp/Output DO1
is available on terminal X1:3 and X1:4 for remote indicaon.

www.nederman.com
