Neilsen CT3744 User manual

PORTABLE SPRAY BOOTH
WITH EXTRACTOR CT3744
ORIGINAL INSTRUCTIONS
Cannon Tools Limited
Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
SAVE THESE INSTRUCTIONS AND PRECAUTIONS.
READ ALL PRECAUTONS AND INSTRUCTIONS BEFORE USE.

1
EC DECLARATION OF CONFORMITY
We CANNON TOOLS LTD
20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K.
Declare that the following machine complies with the appropriate basic safety
and health requirements of the EC Directive based on its design and type, as
brought into circulation by us.
In case of alteration of the machine, not agreed upon by us, this declaration
will lose its validity.
Product description: PORTABLE SPRAY BOOTH
WITH EXTRACTOR
Model: CT3744
Applicable EC Directives:
EC- Low Voltage Directive 2014/35/EU
EC -Directive on electromagnetic compatibility(EMC) 2014/30/EU
Harmonized standards
EN 61000-6-3, EN 61000-6-1, EN 61000-3-2, EN 61000-3-3:2013
EN 60335-1
20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Mr. Gurcharan Tony Singh Sanghera
Managing Director
CANNON TOOLS LTD
2018-07-31

2
Features:
1. The spray booth can be fold and deploy, smart in size, light in weight.
2. It has small power, with big air flow, no need of ventilation pipe, it save
energy and protect environment.
3. It has high density filter net, can filter most of the paint and moisture. No
pollution.
4. It has wire and plug inside, it can be draw out when in need of usage, and
shrink the wire automaticly by press the buttom.
5. With full transparent booth, and the two machines can be conbined
together for big toys.
6. It has light on/off switch, it will light when the machine turn on. Low noise,
about 47 db.
7. It has a revolving plate, and has hand on the top, convenient to use.
Specification:
Power: 25W
Air flow: 3 m3/min
Noise level: 47 db.
Extend dimension: 42X48X34 CM
Shrink dimension: 42X15X25 CM
Spare part list:

3
1
Fan
7
Working plate
13
Revolving plate
2
Paint filter net
8
Left cover board
14
Handle
3
Wire shrink device
9
Right cover board
15
Extractor case
4
Shrink wire door
10
Front cover board
16
Light on/off Switch
5
Top cover board
11
Front left cover board
17
Shrink button
6
Cover board
12
Front right cover board
18
Rubber feet
Operation directory:
1 .When the product
fold, above there is a
carry handle, beneath
there are four rubber
foot. The product is
convenient for carrying.
2.Open the small door
for plug, there is a
power cord which can
be extend to 1.7meter.
3.Deploy the machinery.
Open up the front cover
board of working room,
as the top cover board
of extractor.
4.Pull out the front
worktable.
5. Put the worktable
flatwise.
6. Peploy the left and
right side cover board
upto 90°.

4
Safety instructions and hazard warnings
Please read the entire operating instructions before using the products for the
first time.They contain important information about the correct operation.
The guarantee/warranty will be void if damage is incurred resulting from non
-compliance with the operating instructions.Liability for any and all conseq-
uential damage is excluded!
We do not assume any liability for damage to progerty or personal injury
caused by improper use or the failure to observe the safety instructonslln
such cases the guarantee/warranty will be void.
The unauthorised convcrsion,modification of disassembly of the products
is inadmissible because of safety and approval reasons (CE).
7. Rath eri sh lift the
front work bedplate,
open the frond left and
right side cover board,
uniform left and right
side plank from outside
to inside,put the front
worktable flatewise.
8. Put down the small
gap of top cover of
machinery (cover of
work room) fasten to the
left and right booth side.
At the same time push
down four small gap of
cover board and fast to
the tour side cover
board protruding button.
9. The front of left and
light cover board can be
put flatwise outside, and
also can be remove
outside. The remove
one can extend the
operate space. Move
two cover board can
combine two machines
together, it can be
folded and deployed by
hands without any tools.
10. After pulling the
power cord, the small
door can be closed.
There is a small hole
for power cord, and will
not affect the use of two
machines.
11.Before deploying
and pack away,please
press the shrink button,
the power cord will
retract automatically,
then close the small
door; the step of deploy,
according to the reverse
order of fold.
12.When put two set
together to use, only to
dismantle the right side
booth side of left set
and left booth side of
right set, then put
together two sets
together.

5
The product is not a toy and must be kept out of the reach of children.
Particular care must therefore be exercised if children are present.
The product must get damp or wet,it is only intended for use in dry,indoor
locatoins(not bathrooms or similarly damp areas).There is a risk of a fatal
electric shock.
Do not expose the product or its accessories to damp or extremely high or
low temperatures.
Do not leave packing materials unattended.They may become dangerous
playing material for children.
Dropping,falling,pressure or tensile forces could destroy or at least limit
the function of the product.
Never position the device in the vicinity of combutiblc or easily inflam-
mable materials,e.g.curtains!
Always make sure that the rotary table on which the object is placed is
located in the center of the housing!
The device should continue to run for approx 6 to 2 minutes after each
application,which ensures the self-cleaning of the device!
Always turn the device off and pull the mains plug when the device is not
in use!
If the filter is contaminated with substantial amounts of paint,it can no
longer work efficiently and must be replaced with a clean filter.
To prevent health damage,never use poisonous ,flammable or explosive
paints or materials!
Always ensure proper ventilation!
To not impair the extraction performance,you may not extend the extraction
pipe!
In commercial institutions,the accident prevention regulations of the
Employer’s liability insurance association for electrical systems and
operating facilities are to be observed.
In schools, training centres,hobby and self-help workshops,the use of the
product must be supervised by trained personnel in a responsible manner.
If you have reason to assume that safe operation is no longer possible,
disconnect the device immediately and secure it against inadvertent
operation it.
It can be assumed that safe operation is no longer possible if:
-the device shows visible signs of damage,
-the device no longer functions
-after a longer period of storage under unfavourable conditions or
-following heavy stress during transportation.
Instruction manual
Please read this Instruction Manual carefully and thoroughly before operating
the spray booth extension hose to receive optimum results.
1. Features:
a. Smart, light, easy combine and dismounting.

6
b. Thc hose length can be extended from 0.7 to 1.7 meter, and free bend.
c. The long flat exhaust outlet can be press from both side of 25mm
windows gap or door gap.
2. Spare part list
3. Operation directory:
1 .When use the extension hose, please take one layer of filter net (Spare
part 2, there is total two layer of filter net inside) from the CT3744 spray
booth, only one filter net needed.
2. Take off 4 pes screw as well as the fan protector on the back of the spray
booth CT3744. See picture 1.
3. Use the 4 screw on the plastic sleeve (spare part 19) with the spray booth
CT3744. See picture 2.
4.Screw on the soft screw sleeve (spare part 20) with extension hose (spare
part 22), and connect the extension hose to exhaust port (spare
part 23). See picture 3.
5. Put the hose clamp on soft screw sleeve (spare part 20), and lock on the
plastic sleeve (spare part 19). See picture 4.
6. Extend the hose according to your requirement, and put the exhaust port
out of window or door. See picture 5.

7
CANNON TOOLS LTD
Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K.
Made in China
