Nemtek MERLIN STEALTH M113S User manual

M113S
UsersManual
Revision1.0
Date:29January2007
GROUPOFCOMPANIES
MERLINSTEALTHM113S
–
ElectricFence Energizer
PDFcreated withpdfFactorytrialversion www.pdffactory.com

2
MERLINSTEALTHM113STableofContents
FOREWORD…..………………………………………………………………………….. 3
GUARANTEE…..………………………………………………………………………….. 4
INTRODUCTION…..……………………………………………………………………5
OPERATION WITHOUTAKEYPAD….……………………………………………5
OPERATION WITH AKEYPAD…………………………………………………….. 5
USING YOURKEYPADKEYPAD……………………………………………………..6-10
FENCEINDICATORLIGHTS………………………………………………………… 11
WHATTHEENERGIZERLIGHTSINDICATE…………………………………… 12
WHATTHEKEYPADLIGHTSINDICATE…………………………………………13
DOCUMENT REVISION HISTORY…………………………………………………. 14
No user serviceablepartsinside theenergizer.
PDFcreated withpdfFactorytrialversion www.pdffactory.com

3
MERLINSTEALTH M113S Foreword
FOREWORD
TheMerlinRangeofenergizers hasevolvedoverthepastfifteenyears.The
energizersaredesignedtocomplywiththelatestinternational specifications.
Inordertooffersomeproductflexibilitytheembeddedsoftwareinthe
energizersmaychange.Thelatestversionofdocumentationandenergizer
featurescanbe viewedonourwebsiteat: www.nemtek.com
TheM113SEnergizerhaspatentedenergycontrolandsafetyfeatures.Refer
anyquestionsandspecialrequirementstosuitablytrainedinstallers.
Electricfencingcanbelethal. Avoidheadcontactwiththe fence. Get
the installertoexplainthe optionsofcurrentlimitingresistors,the
enhancedsafetyfeaturesof the M113Sandthelow-voltage
operation of theenergizer.
PDFcreated withpdfFactorytrialversion www.pdffactory.com

4
MERLINSTEALTHM113S Guarantee
GUARANTEE
TheMerlinenergizer,manufacturedbyIOTechManufacturing(Pty)Ltd,is
guaranteedforaperiodofoneyearfromdateofsale againstdefectsdueto
faultyworkmanshipormaterials.
IOTechManufacturing(Pty)Ltdwill,at itsdiscretion, eitherrepairorreplace
a productthat provestobedefective.
IOTechManufacturing(Pty)Ltdguaranteesthat the product,whenproperly
installedandusedinlinewiththespecificationasdeterminedbyIOTech
Manufacturing(Pty)Ltdfromtimetotime,will executeitsfunctionof
generatingasuitable potential.IOTechManufacturing(Pty)Ltddoesnot
guaranteethattheoperationoftheproductwill beuninterruptedandtotally
errorfree.FaultyunitsmustbereturnedtoNemtek,Units4&5,64 Vervoer
Street,KyaSand,Randburg,Gauteng,SouthAfricaORNemtekSecurity
Warehouse,Unit4,MeadowdalePark,Cnr.Herman&DickKempRoads,
Meadowdale,Edenvale,Gauteng,SouthAfrica.Thebuyershall payall
shippingandotherchargesforthereturnoftheproduct toNemtekor
NemtekSecurityWarehouse.
LIM ITATIONOFGUARANTEE
TheguaranteedoesNOTapplytodefectsresultingfromactsofGOD,
modificationsmadebythebuyeroranythirdparty,misuse,neglect,abuse,
accidentandmishandling.
EXCLUSIVEREM EDIES
TheremediesprovidedhereinareIOTechManufacturing(Pty)Ltd’s sole
liabilityandthebuyer’s soleandexclusiveremediesforbreachofguarantee.
IOTechManufacturing(Pty)Ltdshallnotbeliable foranyspecial,incidental,
consequential,directorindirect damages,whetherbasedoncontact,tort,or
anyotherlegal theory.The foregoingguarantee isinlieuofanyandall other
guarantees,whetherexpressed,implied,orstatutory,includingbutnot
limitedtowarrantiesofmerchantabilityandsuitabilityforaparticular
purpose.
PDFcreated withpdfFactorytrialversion www.pdffactory.com

5
INTRODUCTION
Theenergizershouldideallybeoperatedbymeansofa remote keypad.This
enablesthe usertohaveaccess tomanyenergizerfeaturesandoffers the
greatest security.Itcan,however,be operatedbymeansofa Nemtektabor
a remoteon/off switch.
OPERATIONWITHOUTAKEYPAD
Turningthe energizerOn/Off: Unlessthefeaturehasbeendisabledby
theinstaller,theenergizercanbe turnedOn orOff byholdingtheNemtek
plastictaboverthe correspondinglogoonthefascia oftheunit.Removethe
tabonnoticingthe energizerturningOnorOff.
Afteranalarm occurs:Switchtheunit off withthe Nemtektaborremote
key-switch. Thiswillsilence the siren(ifit hasnotalreadytimed-out),
internalbeeperandwill switchthestrobe off.Oneofthe alarmlightswill be
flashingorremainlittoindicatethesourceofthe alarm.Apermanentlylit
indicatornotifiestheuserthat thefault nolongerexist.Inthelattercase
simplyturningtheenergizerOnagainwillclearthememorycondition.A
flashingalarmlightillustratesthatthefaultconditionpersist.Inthiscase
rectifytheconditionwhichcausedthealarm.Toresetandclearthe memory
conditionturntheenergizerOnandOffandOnagain. Onlyifthealarm
conditionisresolvedwill the energizeroperate withoutalarmactivation.
OPERATIONWITH AKEYPAD
Theenergizermaybeoperatedvia a remote keypad.Inthiscase theNemtek
tabbecomesoptional.(Installerprogrammable).
Inordertoprovidedifferentaccess levelstotheenergizeranditsfunctions
differenttypesofuserare defined.
Amasteruserhasfullcontroloftheenergizerandmaybypass different alarm
functions.Themasterusermaychangethepinidentificationnumberforall
theusers.Thereisonlyone masteruserwithadefault PINof1234,user#0.
Therearethreenormal usersandthree reset users.
AnormalusermayturntheenergizerOn/Off andresetalarmconditionsbut
notchange thefunctionalityoftheenergizer.User#1,#2and#3.For
MERLINSTEALTH M113SIntroduction
PDFcreated withpdfFactorytrialversion www.pdffactory.com

6
securityreasonstheyhavenodefaultcodesandmustbeassignedbythe
masteruser.
Aresetusermayonlyreset thealarmsbut not change the On/Off state ofthe
energizer.User#4,#5,#6.Forsecurityreasonstheyhavenodefault codes
andmust beassignedbythemasteruser.
TheembeddedLinux platformwill bemadecommerciallyavailable during
2007that willprovideconnectivitytotheenergizeranda historyofall events
includinguserintervention.Thethreedifferentusers inthenormaloperators
allowsforthreeeighthourshiftstobemonitored.
Theenergizerwill restore itsconditiontoitspreviousstateshouldtherebe a
total powerfailurei.e.mainsfailure andbatteryflat.
Note that the Gate inputsareactiveevenwhenthe energizerisswitchedoff.
Use the GateBypass functionifthese inputsare tobeignored.
USINGYOURKEYPAD
SWITCHTHE FENCEON/OFF (Master/Normal User)
ToswitchthefenceOnorOff,enteryourfourdigit PINfollowed bythe # key.IftheredON
lightislitorflashing,thefenceisenergized.
•Don’tpauseformorethan5secondswhileenteringthedigits,orthecontrolpanel
willreject yourPINnumber.
•IfyoumakeamistakewhileenteringyourPIN,press the #keyandstart again.
•Anincorrect PINwillcausethecontrolpaneltobeep5times.
Thedefault master(User#0)PINis 1234.
AFTERANALARM OCCURS
EnteryourPIN(all users)andpress the #key.Thiswillsilencethebuzzerandsiren. Itwill
switchthefenceoff.Oneofthe ALARM lightswillflashorstay lit toindicatethesourceof
thealarm. Aflashingindicatorillustratesthatthefaultconditionpersists.Apermanentlylit
MERLINSTEALTH M113S UsingyourKEYPAD
PDFcreated withpdfFactorytrialversion www.pdffactory.com

7
indicatornotifiestheuserthatthefault no longerexists.Inthelattercase simplyturningthe
energizeronagainwillclearthememorycondition.Iftheflashingalarmconditioncannotbe
resolved,thealarmwillbe activatedirrespectiveofthenumberoftimestheunitisturnedOn
orOff.TheMasterusercanbypassalarmconditions.Aresetuserwillonlyresetthealarm
outputsandnotchangetheOn/Off stateoftheenergizer.
CHANGE THE VOLTAGE ON THE FENCE
EnteryourPIN(masteronly)andpress the *key,enterthedigit 3,thenpress the #key.
Whenthefenceisonandinlowvoltagemode,thered ON lightwillflash. Thered ON light
willstay permanentlylitifthefenceisinhighvoltagemode.Usethelowvoltagemodewhen
childrenareinthefencevicinity.
BYPASSTHE FENCEALARM
EnteryourPIN(masteronly)andpress the *key,enterthedigit 1,thenpressthe #key.
The FENCEALARM lightwillstart flashingslowlytoconfirmthefencealarmisbypassed.
Tocancelthebypass,repeatthesamesequenceofkeys.
BYPASSTHE SIRENANDSTROBELIGHT(SILENTALARM)
EnteryourPIN(masteronly)andpress the *key,enterthedigit 4,thenpressthe #key.
Thebeeperinthecontrolpanelwillstill beactive.
UN-BYPASSTHE SIRENANDSTROBELIGHT
EnteryourPIN(masteronly)andpress the * key,enterthedigit 7,thenpress the #key.
MAKETHE GATEALARM IMMEDIATE(BothGates)
EnteryourPIN(masteronly)andpress the *key,enterthedigit 2,followedbythedigit 7,
thenpressthe #key.The GATEALARM lightwillstart flashing,withacadenceofoneflash
every5seconds,to confirmthegatealarmisimmediate.
MERLINSTEALTH M113S UsingyourKEYPAD
PDFcreated withpdfFactorytrialversion www.pdffactory.com

8
MAKETHE GATEALARM IMMEDIATE(Gate1)
EnteryourPIN(masteronly)andpress the *key,enterthedigit 2,followedbythedigit 7,
followedbythedigit 1,thenpressthe #key.The GATEALARM lightwillstartflashing,
withacadenceofoneflashevery5seconds,toconfirmthegatealarmisimmediate.
MAKETHE GATEALARM IMMEDIATE(Gate2)
EnteryourPIN(masteronly)andpress the *key,enterthedigit 2,followedbythedigit 7,
followedbythedigit 2,thenpressthe #key.The GATEALARM lightwillstartflashing,
withacadenceofoneflashevery5seconds,toconfirmthegatealarmisimmediate.
MAKETHE GATEALARM DELAYED(BothGates)
EnteryourPIN(masteronly)andpress the *key,enterthedigit 2,followedbythedigit 4,
thenpressthe #key.Thedefaultgatedelayis4minutes.
MAKETHE GATEALARM DELAYED(Gate1)
EnteryourPIN(masteronly)andpress the *key,enterthedigit 2,followedbythedigit 4,
followedbythedigit 1,thenpress the #key.Thedefaultgatedelayis30seconds.
MAKETHE GATEALARM DELAYED(Gate2)
EnteryourPIN(masteronly)andpress the *key,enterthedigit 2,followedbythedigit 4,
followedbythedigit 2,thenpress the #key.Thedefaultgatedelayis30seconds.
BYPASSTHE GATEALARM(Gate1andGate2)
EnteryourPIN(masteronly)andpress the *key,enterthedigit 2,thenpressthe #key.
The GATEALARM lightwillstartflashingslowlytoconfirmthatthegatealarmisbypassed.
Tocancelthebypass,repeatthesamesequenceofkeys.
BYPASSTHE GATEALARM (Gate1)
EnteryourPIN(masteronly)andpress the *key,enterthedigit 2,followedbythedigit 1,
thenpressthe #key.Tocancelthebypass,repeatthesamesequenceofkeys.
MERLINSTEALTH M113S UsingyourKEYPAD
PDFcreated withpdfFactorytrialversion www.pdffactory.com

9
BYPASSTHE GATEALARM (Gate2)
EnteryourPIN(masteronly)andpress the *key,enterthedigit 2,followedbythedigit 2,
thenpressthe #key.Tocancelthebypass,repeatthesamesequenceofkeys.
TURNTHE GATECHIME ON (Gate1)
EnteryourPIN(masteronly)andthe *key,enterthedigit 2,enterthedigit 8,enterthe
digit 1,thenpressthe #key.Ifthechimeison,thekeypadwill beepthreetimesifthe
gateopensandtwiceifit closes.
TURNTHE GATECHIME OFF (Gate1)
EnteryourPIN(masteronly)andthe *key,enterthedigit 2,enterthedigit 8,enterthe
digit 2,thenpress the #key.Noaudibleindicationofgateopeningorclosing.
TURNTHE GATECHIME ON (Gate2)
EnteryourPIN(masteronly)andthe *key,enterthedigit 2,enterthedigit 8,enterthe
digit 3,thenpressthe #key.Ifthechimeison,thekeypadwill beepthreetimesifthe
gateopensandtwiceifit closes.
TURNTHE GATECHIME OFF (Gate2)
EnteryourPIN(masteronly)andthe *key,enterthedigit 2,enterthedigit 8,enterthe
digit 4,thenpress the #key.Noaudibleindicationofgateopeningorclosing.
BYPASSTHE SERVICEALARM
EnteryourPIN(masteronly)andpress the *key,enterthedigit 9,thenpressthe #key.
The SERVICEALARM lightwill startflashingslowlytoconfirmthattheservicealarmis
bypassed.Tocancelthebypass,repeatthesamesequenceofkeys.Theenergizerwill
indicateaservicealarmifthebatteryvoltageislow.
MERLINSTEALTH M113S UsingyourKEYPAD
PDFcreated withpdfFactorytrialversion www.pdffactory.com

10
MANUAL BATTERY TEST
EnteryourPIN(masteronly)andpress the *key,enterthedigit 6,thenpressthe #key.
Thekeypadwillbeepfourtimesindicatingthebatterytesthasstarted.Thistestdisablesthe
mainsinputfor20minutesandmonitorsthebatteryvoltage.Ifthebatteryvoltagefalls
belowanacceptablelevelduringthistestthebatteryservicelightwillcomeon, provided the
bypassisnotenabled,andindicatesthebatteryneedsreplacing.Itisadvisabletohavethe
energizerrunninginHighVoltagemodeduringthistest.Itisadvisabletotestbattery
conditionatleasttwiceayear.(Iftheautobatterytestfeatureisenabledbytheinstaller,the
timingsequencewillbere-initiated.)
CHANGINGAUSER PIN
EnteryourmasterPIN,press the*key,enterthedigit 0,thenpress the#key.Enterthe
usernumber(0-6),andpushthe#key.Usernumber0isthemasterPINthathassystem
configurationrightsi.e.bypassofalarmconditionsetc.Enterthatuser’snewPINandpress
the#key.EnterthenewPINagainandpressthe#key.IfthenewPINisaccepted,the
controlpanelwill beep fourtimes.Ifyoumakeamistakewhileprogramming,orifthe
systemrejectsthenewPIN,thecontrolpanelwillbeep fivetimes.
ALTERINGTHE KEY-PADINDICATORBRIGHTNESS:
Thebrightness ofthekeypadscanbe increasedordecreased bypressingandholdingthe1
or7keysrespectively.Thekey-padwillbeepwhiletheindicatorbrightness ischanging.No
userPINisrequiredforthisoperation.
MasterPIN
User(0-6)
NewPIN
NewPIN
MERLINSTEALTH M113S UsingyourKEYPAD
PDFcreated withpdfFactorytrialversion www.pdffactory.com

11
MERLINS WhattheEnergizerlightsindicate
FENCEINDICATORLIGHTS
TheM113Senergizermonitorsthefencewitheverypulse.Afiniteamountofenergyisused
to excitethefence.Dependingonthecurrentmagnitudeofafencepulseasecondpulsemay
beusedtoexcitethefenceandeffectivelydoubletheoutputenergy.Theoccurrenceofthe
secondpulseisindicated bytheilluminatingoftheHIGHPOWER indicator.
UndernormalfenceoperatingconditionstheGOODindicatorshouldflashonceasecond.As
thefencebecomesloadedduetoexcessivevegetationormoisturetheCheckindicatormay
start flashing.Iftheloadingbecomessevere,theHIGHPOWERindicatorwillalsostart
flashingandpossiblytheALARMindicatoras well.Whenthisoccursthevoltageonthefence
maychange considerablybecausetheavailableoutputenergyhasdoubled.Thefence
indicatorlightsmay cyclebetweenALARM/CHECKandGOODas theeffectiveness ofthe
fenceismaintained.Shouldthefenceloadingbesuchthatthefencevoltageisinsufficientto
beadeterrentthentheALARMindicatorwillremainlitorhaveafastflashandthealarm
outputs,ifenabled,willactivate.
FENCE1 Fencevoltage acceptable
Fencevoltage questionable.Inspect fenceanddo
maintenance.
Iflit permanentlythefencedroppedbelowacceptable
voltagelevels.Flashingintermittentlyinconjunctionwiththe
HIGHPOWERindicatorindicatessevereloadingonthe
fence.
HIGH POWER Anindicationthattheoutputenergyoftheenergizerisbeing
doubledduetofenceloading.
ContinuousoperationoftheHIGHPOWERindicatoristo beavoided.Eitherthereisexcessive
vegetationorfaultonthefence.TheHIGHPOWERindicatorwillonlyflashbrieflyifashort is
presentedto theenergizer.Theenergizerwoulddetectthisas apotentialhead/bodyshock
thatcanbe lethalandreduce,orifinstallerconfiguredstop,anyfurtherenergyfromexciting
thefence.
MERLINSTEALTH M113S FenceIndicatorLights
PDFcreated withpdfFactorytrialversion www.pdffactory.com

12
WHATTHEENERGIZER LIGHTSINDICATE
Condition: Power
Light On Light
Fence
Good
Fence
Check
Fence
Alarm
GateLight
(1or2)
HighPower
Light
Service
Light
Remarks
FENCEGOOD ON ON SLOW
FLASH OFF
OFF OFF OFF OFF Fence on, working
properly
FENCEOFF ON OFF OFF OFF OFF OFF OFF OFF Fence off, working
properly
FENCEOFFON OFF
FAST
FLASH
Fence turned
offwithalarm
condition
active
MAINSFAILURE OFF Systemon
batterypower
LOW VOLTAGE
MODE SLOW FLASH Energizer
switchedto
lowvoltage
FENCECHECK SLOW
FLASH
MAYFLASH
CheckFence
Remove
vegetation
FENCEALARM FAST
FLASH MAYFLASH Problemon fence
FENCEBYPASS SLOW
FLASH Fence alarm switchedoff
GATEOPEN FAST
FLASH Gate isopen
GATEBYPASS SLOW
FLASH Gate alarm switchedoff
GATE
IMMEDIATE
1FLASH
EVERY5
SECONDS
Appropriate
gateinput isin
immediate
mode.
SILENTALARM 1SHORT
FLASHEVERY
5SECONDS
Siren orstrobe
lightnot
activatedby
alarm!
GATE2
CONTROLS
FENCEVOLTAGE
Gate2
LONG
FLASH
EVERY5
SECONDS
Gate 2closed:
fenceinlow-
voltagemode
Gate 2open:
fenceinhigh-
voltagemode
BATTERY
VOLTAGELOW
OFF Nomains,
Faultyfuse
ALARMMEMORY (ON) (ON) (ON) Old alarm.
EnterPIN #
SERVICEALARM
BYPASS
SLOW FLASH Service alarm
switchedoff
SERVICEALARM FAST
FLASH
Nomains,
batteryflat,
faultyfuse
MERLINSTEALTH M113S WhattheEnergizerlights indicate
PDFcreated withpdfFactorytrialversion www.pdffactory.com

13
WHAT THEKEYPADLIGHTSINDICATE
Condition:
Power
Light Good Light
On
Light
Fence
Light
Gate
Light(1
or2)
Service
Light Remarks
FENCEGOOD ON ON ON OFF OFF OFF Fenceon, working
properly
FENCEOFF ONOFF OFF OFF OFF OFF Fenceoff,working
properly
FENCEOFF
ON SLOW
FLASH OFF Fenceturnedoffwith alarmconditionactive
MAINS
FAILURE OFF Systemonbatterypower
LOW
VOLTAGE
MODE SLOW
FLASH Energizerswitchedto low fencevoltage
FENCE
ALARM OFF FAST FLASH Problemonfence
FENCE
BYPASS SLOW FLASH Fencealarmswitched off
GATEOPEN FAST
FLASH Gateisopen
GATEBYPASS SLOW
FLASH Gatealarmswitchedoff
GATE
IMMEDIATE 1FLASH
EVERY5
SECONDS Appropriategateinputis
inimmediatemode.
SILENT
ALARM
1SHORT
FLASH
EVERY5
SECONDS
Sirenorstrobelightnot
activated byalarm!
GATE2
CONTROLS
FENCE
VOLTAGE
Gate2LONG
FLASH
EVERY5
SECONDS
Gate2closed:fencein
low-voltagemode
Gate2open: fencein
high-voltagemode
ALARM
MEMORY (ON) (ON) (ON) Oldalarm. EnterPIN#
SERVICE
ALARM
BYPASS SLOW
FLASH
SERVICE
ALARM FAST FLASH No main,batteryflat, faultyfuse
MERLINSTEALTH M113S WhattheKeypadlights indicate
PDFcreated withpdfFactorytrialversion www.pdffactory.com

14
MERLINSTEALTH M113S DocumentRevisionHistory
DOCUMENTREVISIONHISTORY
Revision1.0
29 January2007
Endofdocument
PDFcreated withpdfFactorytrialversion www.pdffactory.com
