Nemtek WIZORD 4 User manual

E-WIZ
GOOD
CHECK
BAD
POWER
ON
FENCE
GATE
SERVICE
STATUS
FENCE
ELECTRIC FENCE ENERGIZER
GROUP OF COMPANIES
USER MANUAL
WIZORD 4
–
Electric Fence Energizer

2
WIZORD 4 –USER MANUAL Table of Contents
INTRODUCTION………………………………………………………………………….. 3
COMPANY PROFILE……………………………………………………………………… 3
GUARANTEE………………………………………………………………………………… 4
STANDARD OPERATING PROCEDURES…………………………………………… 5
STANDARD OPERATING PROCEDURES –Notes………………………………. 6
STANDARD OPERATING PROCEDURES –LED’s……………………………….. 7
FEATURES & FUNCTIONS……………………………………………………………… 8-9

3
WIZORD 4 Introduction & Company Profile
I N T R O D U C T I O N
Thank you for choosing our product! NEMTEK Electric Fence Energizers are
designed and manufactured to provide many years of reliable use, if installed
and maintained correctly. The guidelines provided in this manual will assist
you with the basic operation and maintenance of your WIZORD 4.
The WIZORD 4 is designed and manufactured in South Africa for the
international market. More information on our products, SABS test reports
and general information is available on our web site at:
http://www.nemtek.com.
C O M P A N Y P R O F I L E
The NEMTEK Group of Companies manufacture and distribute intelligent
electronic security and perimeter control systems and have been involved in
the security industry since 1990.
We have our own research and development team, designing and
manufacturing a full range of globally competitive electric fence energizers
and related products.
NEMTEK is continually updating its products according to international
standards in order to ensure the highest quality products and continuous
customer satisfaction.

4
WIZORD 4 Guarantee
G U A R A N T E E
The WIZORD 4 energizer, manufactured by IO Tech Manufacturing (Pty) Ltd,
is guaranteed for a period of one year from date of sale against defects due
to faulty workmanship or materials.
IO Tech Manufacturing (Pty) Ltd will, at its discretion, either repair or replace
a product that proves to be defective.
IO Tech Manufacturing (Pty) Ltd guarantees that the product, when properly
installed and used in line with the specification as determined by IO Tech
Manufacturing (Pty) Ltd from time to time, will execute its function of
generating a suitable potential. IO Tech Manufacturing (Pty) Ltd does not
guarantee that the operation of the product will be uninterrupted and totally
error free. Faulty units must be returned to Nemtek, Units 4 & 5, 64 Vervoer
Street, Kya Sand, Randburg, Gauteng, South Africa OR Nemtek Security
Warehouse, Unit 4, Meadowdale Park, Cnr. Herman & Dick Kemp Roads,
Meadowdale, Edenvale, Gauteng, South Africa. The buyer shall pay all
shipping and other charges for the return of the product to Nemtek or
Nemtek Security Warehouse.
L I M I T A T I O N O F G U A R A N T E E
The guarantee does NOT apply to defects resulting from acts of GOD,
modifications made by the buyer or any third party, misuse, neglect, abuse,
accident and mishandling.
E X C L U S I V E R E M E D I E S
The remedies provided herein are IO Tech Manufacturing (Pty) Ltd’s sole
liability and the buyer’s sole and exclusive remedies for breach of guarantee.
IO Tech Manufacturing (Pty) Ltd shall not be liable for any special, incidental,
consequential, direct or indirect damages, whether based on contact, tort, or
any other legal theory. The foregoing guarantee is in lieu of any and all other
guarantees, whether expressed, implied, or statutory, including but not
limited to warranties of merchantability and suitability for a particular
purpose.

5
WIZORD 4 Standard Operating Procedure
S T A N D A R D O P E R A T I O N
TURNING YOUR UNIT ON / OFF:
In the default state, the energizer can be turned on or off by holding the
plastic tab over the corresponding logo on the fascia of the unit. The unit will
beep once when turned on and twice when turned off.
FENCE STATUS INDICATION:
The unit will indicate that a condition is currently active (fence fault, gate
open, or service condition) if the corresponding LED is flashing; eg. if the
fence LED is flashing, the fence voltage is currently not satisfactory. If the
fence alarm indication LED is lit continuously, there was a fence alarm
condition previously but the fence voltage is now satisfactory. Similarly, if the
gate alarm indication LED is lit permanently, the gate opening time exceeded
the entry delay period but is now closed. If the gate indication LED is
flashing, the gate is still open.
ALARM INDICATION:
The fence and gate inputs are configured to trigger external alarms and the
internal buzzer. The service condition will activate the buzzer only. Be aware
that, should there be a prolonged power failure, the battery may run low and
cause the service light to flash. If the mains interruption is sufficiently long,
the unit will shut down and there will be no indication of mains failure.
TOGGLE FUNCTION:
In the event of the unit being switched off by the plastic tab while a fault is
active, the unit will silence all alarms. On turning the unit on again the
corresponding LED’s will indicate the fault, but no alarm outputs will be
triggered. This provides the user with the facility to leave the unit on if no
service personnel are available. Should the unit be turned off and on again,
the alarm outputs will activate after the default periods. On turning the unit
off again, the outputs will again be disabled. Users must be wary of this
toggle function. The user does not need to concern them self with the toggle
function if the unit is switched off and on again under normal conditions, as
per table 1 (i.e. No alarm condition active).
BUZZER:
The buzzer has a different cadence for the fence alarm and gate alarm.
SERVICE INDICATION:
The service indicator should remain off during normal operation. If it is lit
due to an obvious condition, such as prolonged mains failure, simply turn the
unit off and on again. Should the condition persist, refer to your installer.
The unit has built-in diagnostics to assist the installer.

6
WIZORD 4 Standard Operating Procedures -Notes
NOTES:
1. The energizer will, under normal conditions, provide the fence with a
pulse at the rated energy level. Should a mains failure occur, the
energizer will automatically switch to a reduced energy level. This
enables the unit to operate without mains for extended periods of time
(i.e. with a good battery the unit should be able to operate for
approximately twenty hours). Batteries should be checked on a bi-
annual basis.
2. A functional energizer will only turn itself off under two conditions,
namely: prolonged mains failure where battery damage has occurred,
or abnormal heat being generated within the energizer.
3. There are no “user-serviceable” parts within the energizer. Please
refer all problems to qualified service personnel.
4. It is possible that, under mains failure conditions, the energizer will
operate at reduced energy levels and the fence status display will not
be fully lit. The mains should be restored first before checking the
physical fence condition.
5. Keep the fence clear of vegetation and do a periodical check for any
slack fence strands, etc.

7
WIZORD 4 Standard Operating Procedures –LED’s
The status of the energizer and the fence is displayed on the
front panel of the energizer, as follows:
Under normal operating conditions:
Conditions that if ignored, will sound the alarm:
T
A
B
L
E
1
T
A
B
L
E
2
T
A
B
L
E
3
T
A
B
L
E
4
GOOD
CHECK
BAD
POWER
ON
FENCE
GATE
SERVICE
STATUS
FENCE
(Mains present, battery charging)
(Fence energized)
(No fence alarm)
(No gate alarm)
(No service condition)
If all are flashing, fence is operating correctly
(Restore mains
-
see Note 1)
(Turn energizer on
-
see Note 2)
(Alarm condition)
(Alarm condition)
(Possible installer intervention required
-
see Note 3)
(Check later
-
see Note 4)
(
Concern
-
see Note 4)
(Service fence
-
see Note 4)
(Service fence)
(Alarm / Fence faulty)
LED OFF LED PERMANENTLY LIT –Fault
occurred but is now gone
LED FLASHING –Fault still
present
POWER
ON
FENCE
GATE
SERVICE
STATUS
GOOD
CHECK
BAD
FENCE
GOOD
CHEC
K
BAD
FENCE
STATUS
POWER
ON
FENCE
GATE
SERVICE

8
WIZORD 4 Features & Functions
F E A T U R E S & F U N C T I O N S
INTEGRATED UNIT:
For energizers designed from a security perspective, the fence monitoring is
an integral part of the product. The energizer is an integrated energizer,
battery charger and fence monitor with a siren and strobe light output.
LIGHTNING PROTECTION:
The mains and high voltage outputs are protected against lightning and
power surges. It also protects the unit against abnormally high potential
differences between the high voltage and mains ground.
INTERFERENCE SUPPRESSION / LOW EMI RADIATION:
The unit has been tested to comply with the latest international requirements
CISPR14-2/1997.
REMOTE KEY-SWITCH:
The energizer can be wired to a remote on/off switch. There is only one
external input and the selection of gate or remote on/off is exclusive.
EARTH LOOP MONITORING:
For additional security, the facility to use earth loop monitoring is provided
for.
EXTENDED OPERATION DURING MAINS FAILURE:
The unit detects the mains failure and reduces the fence output energy.
AUXILIARY 12VDC OUTPUT:
A 12 Volts DC fused output is available to supply any auxiliary equipment like
a radio remote receiver. The current must not exceed 0.5 amps.

9
WIZORD 4
Features & Functions Cont’d
GATE INPUT:
Gate delay entry of four minutes or immediate entry alarm.
SIREN OUTPUT:
12VDC output for siren available.
STROBE LIGHT OUTPUT:
12VDC output for strobe light available.
WEATHER PROOF HOUSING:
The unit enclosure is made of high quality weather resistant material.
ARMED RESPONSE RADIO CONNECTABLE:
The system has the facility to be connected to an armed response radio.
BATTERY BACKUP:
The unit is supplied standard with a 12V 7AH rechargeable battery.
UNIT UPGRADEABLE:
The unit can be upgraded to allow:
ØHigh & low voltage fence monitoring
ØMultiple keypad & pin numbers
ØEnergizer synchronization
ØProgrammable fence voltage
ØProgrammable gate delay
ØProgrammable fence delay
27/9/06
Rev 1.4
