Allen-Bradley 1606-XLB36EH User manual

Installation Instructions
1606-XLB36EH SER B Power Supply 1-Phase, 24V, 1.5A, 36W
PU-463.015.38-xxB
EN
Before operating this device, please read this manual thoroughly and retain this manual for future reference! This device ma
y
only be installed and put into operation by qualified personnel. If
damage or malfunction should occur during operation, immediately turn power off and send device to the factory for inspection. The device does not contain serviceable parts. The information
presented in this document is believed to be accurate and reliable and may change without notice. For any clarifications the English translation will be used.
WARNING Risk of electrical shock, fire, personal injury, or death:
Turn power off before working on the device. Protect against inadvertent re-powering. Do not touch during power-on and immediately after power-off. Hot surfaces may cause burns. Do not open,
modify or repair the device. Use caution to prevent any foreign objects from entering the housing. Do not use in wet locations or in areas where moisture or condensation can be expected.
DE
Bitte lesen Sie diese Warnungen und Hinweise sorgfältig durch, bevor Sie das Gerät in Betrieb nehmen. Bewahren Sie die Anleitung zum Nachlesen auf. Das Gerät darf nur durch fachkundiges
und qualifiziertes Personal installiert werden. Bei Funktionsstörungen oder Beschädigungen schalten Sie sofort die Versorgungsspannung ab und senden das Gerät zur Überprüfung ins Werk.
Das Gerät beinhaltet keine Servicebauteile. Die angegebenen Daten dienen allein der Produktbeschreibung und sind nicht als zugesicherte Eigenschaften im Rechtssinne aufzufassen. Im
Zweifelsfall gilt der englische Text.
WARNUNG Missachtung nachfolgender Punkte kann einen elektrischen Schlag, Brände, schwere Unfälle oder Tod zur Folge haben:
Schalten Sie die Eingangsspannung vor Installations-, Wartungs- oder Änderungsarbeiten ab und sichern Sie diese gegen unbeabsichtigtes Wiedereinschalten. Gehäuse nicht während des
Betriebes oder kurz nach dem Abschalten berühren. Heiße Oberflächen können Verletzungen verursachen. Führen Sie keine Änderungen oder Reparaturversuche am Gerät durch. Gerät nicht
öffnen! Verhindern Sie das Eindringen von Fremdkörpern, wie z.B. Büroklammern und Metallteilen. Betreiben Sie das Gerät nicht in feuchter Umgebung oder in einer Umgebung, bei der mit
Betauung oder Kondensation zu rechnen ist.
FR
Veuillez lire ces instructions de montage et d'entretien avant de mettre l'alimentation sous tension. Conservez ce manuel qui vous sera toujours utile. Cette alimentation ne doit être installée que
par du personnel qualifié et compétent. En cas de dommage ou dysfonctionnement, coupez immédiatement la tension d’alimentation et retournez l’appareil à l’usine pour vérification. !
L’alimentation ne contient pas de pièces échangeables Les données indiquées dans ce document servent uniquement à donner une description du produit et n'ont aucune valeur juridique. En
cas de divergences, le texte anglais fait foi.
AVERTISSEMENT Prendre en compte les points suivants, afin d'éviter toute détérioration électrique, incendie, dommage aux personnes ou mort:
Mettre l’alimentation hors tension avant toute intervention sur celle-ci et s'assurer qu'il n'y a pas risque de redémarrage. Ne pas toucher le carter pendant le fonctionnement ou directement après
la mise hors tension. Surface chaude risquant d’entraîner des blessures. Ne pas ouvrir, modifier ou réparer l'alimentation. Veiller à ce qu'aucun objet ne rentre en contact avec l'intérieur de
l'alimentation (trombones, pièces métalliques). Ne pas faire fonctionner l'appareil dans un environnement humide ou dans un environnement où il peut y avoir de la condensation.
ES
Conserve este manual como referencia para futuras consultas. La fuente de alimentación solo puede ser instalada y puesta en funcionamiento por personal cualificado. Por favor lea
detenidamente este manual antes de conectar la fuente de alimentación. Si se produce un fallo o mal funcionamiento durante la operación, desconecte inmediatamente la tensión de
alimentación. En ambos casos, el equipo debe ser inspeccionado en fábrica. La información presentada en este documento es exacta y fiable en cuanto a la descripción del producto y puede
cambiar sin aviso. En casa de duda, prevalece el texto inglés.
ADVERTENCIA Riesgo de descarga eléctrica, incendio, accidente grave o muerte:
Desconectar la tensión de red antes de trabajar en la fuente de alimentación. Evite una posible reconexión involuntaria. No tocar durante el funcionamiento ni inmediatamente después del
apagado. El calor de la superficie puede causar quemaduras graves. No realizar ninguna modificación o reparación de la unidad. No abrir la unidad. Evitar la introducción en la carcasa de
objetos extraños. No usar el equipo en ambientes húmedos. No operar el equipo en ambientes donde se espere la formación de rocío o condensación.
Product Description
The 1606-XLB36EH SER B is a DIN-rail mountable single-phase-input power supply, which provides a floating,
stabilized and galvanically separated SELV/PELV output voltage.
The output of the device fulfils the requirements for a limited power source according to NEC Class 2.
Intended Use
This device is designed for installation in an enclosure and is intended for commercial use, such as in industrial
control, process control, monitoring, measurement, Audio/Video, information or communication equipment or the
like.
Do not use this device in equipment where malfunction may cause severe personal injury or threaten human life.
If this device is used in a manner outside of its specification, the protection provided by the device may be
impaired.
Installation Instructions
Install device in an enclosure providing protection against electrical, mechanical and fire hazards.
Install the device onto a DIN-rail according to EN 60715 with the input terminals on the bottom of the device.
Make sure that the wiring is correct by following all local and national codes. Use appropriate copper cables that
are designed for a minimum operating temperature of 60°C for ambient temperatures up to +45°C, 75°C for
ambient temperatures up to +60°C and 90°C for ambient temperatures up to +70°C. Ensure that all strands of a
stranded wire enter the terminal connection.
The device is designed for pollution degree 2 areas in controlled environments. No condensation or frost is
allowed.
The enclosure of the device provides a degree of protection of IP20. The enclosure does not provide protection
against spilled liquids.
The isolation of the device is designed to withstand impulse voltages of overvoltage category III according to IEC
60664-1.
Technical Data
All values are typical figures specified at 230Vac, 50Hz input voltage, 24V 1.5A
output load, 25°C ambient temperature and after a 5 minutes run-in time unless
otherwise noted.
Output voltage DC 24V Nominal
Adjustment range 24 – 28Vdc Factory setting 24.1V
Output current 1.5 – 1.2A Below +60°C ambient
1.1 – 0.95A At +70°C ambient
Derate linearly between +60°C and +70°C
Input voltage AC AC 100 – 240V ±10%
Mains frequency 50 – 60Hz ±6%
Input current AC 0.63 / 0.38A At 120 / 230Vac
Power factor 0.53 / 0.46 At 120 / 230Vac
Input inrush current 14 / 40A pk At 120 / 230Vac, 40°C, cold
start
Efficiency 90.5 / 90.6% At 120 / 230Vac
Power losses 3.8 / 3.7W At 120 / 230Vac
Hold-up time 37 / 162ms At 120 / 230Vac
Temperature range -10 to +70°C
Max. wire size (litz wire) 2.5mm²
Max. wire size with ferrules 1.5mm²
Wire size AWG AWG 24-12
Max. wire diameter 2.3mm
Wire stripping length 10mm / 0.4inch
Size (wxhxd) 22.5x90x91mm Without DIN-rail
Weight 140g / 0.31lb

Rockwell Automation Support
For Technical Support, visit ROK.AUTO/SUPPORT.
The information in this document is believed to be accurate and reliable and may change without notice.
Rockwell Automation maintains current product environmental compliance information on its website at rok.auto/pec.
Allen-Bradley, Rockwell Software, and Rockwell Automation are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their companies.
www.rockwellautomation.com
Power, Control and Information Solution Headquarters
Americas: Rockwell Automation, 1201 South Second Street, Milwaukee, WI 53204-2496 USA, Tel: [phone], Fax. [phone]
Europe/Middle East/Africa: Rockwell Automation NV, Pegasus Park, De Kleetlaan 12a, 1831 Diegem, Belgien, Tel: [phone], Fax [phone]
Asia Pacific: Rockwell Automation,Level 14, Core F, Cyberport 3, 100 Cyberport Road, Hong Kong, Tel: [phone], Fax [phone]
Turkey: Rockwell Otomasyon Ticraet A.Ş., Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, Istanbul, Tel: [phone] (EEE Yönetmeliğine Uygundur)
Publication 1606-IN056A-EN-E - June 2020
DIR 10005140928 (Version 01)
Copyright © 2020 Rockwell Automation, Inc. All Rights Reserved..
The device is designed as “Class of Protection” II equipment according to IEC 61140.
The device is suitable to be supplied from TN, TT or IT mains networks. The continuous voltage between the
input terminal and the PE potential must not exceed 300Vac.
A disconnecting means shall be provided for the input of the device.
The device is designed for convection cooling and does not require an external fan. Do not obstruct airflow and
do not cover ventilation grid!
The device is designed for altitudes up to 5000m (16400ft). Above 2000m (6560ft) the overvoltage category is
reduced to level II and a reduction in output current is required.
Keep the following minimum installation clearances: 40mm on top, 20mm on the bottom, 0mm left and right side.
Increase the 0mm to 15mm in case the adjacent device is a heat source.
The device is designed, tested and approved for branch circuits up to 20A without additional protection device. If
an external fuse is utilized, do not use circuit breakers smaller than 6A B- or 4A C-Characteristic to avoid a
nuisance tripping of the circuit breaker.
The maximum surrounding air temperature is +70°C (+158°F). The operational temperature is the same as the
ambient or surrounding air temperature and is defined 2cm below the device.
The device is designed to operate in areas between 5% and 95% relative humidity.
Functional Description
The output is electronically protected against no-load, overload and short circuit and can supply any kind of loads,
including inductive and capacitive loads. Capacitive loads should not be larger than 5400µF with 1.5A or 7300µF
with 0.75A additional resistive load.
Do not apply return voltages from the load to the output terminals higher than 35V.
The output voltage can be adjusted with a small flat-blade screwdriver on the front of the unit.
The green DC-OK LED reports an output voltage above 18V of a running device.
At heavy overloads (when output voltage falls below 14V), the device delivers continuous output current for 60ms.
After this, the output is switched off for 400ms before a new start attempt is automatically performed. This cycle is
repeated as long as the overload exists.
Do not parallel devices for higher output currents.
Same devices can be connected in series for higher output voltages. It is allowed to connect as many outputs in
series as needed, providing the sum of the output voltage does not exceed 150Vdc.
In case of an internal defect, a redundant circuit limits the maximum output voltage to 32V. The output shuts
down. To attempt a restart, turn the input power off for at least 90s.
Functional Diagram
Input
Fuse
&
Input
Filter
Output Over-
Voltage
Protection
Input
Rectifier
&
Inrush
Limiter
Output
Voltage
Regulator
+
+
-
-
Output
Filter
V
OUT
Power
Converter
L
N
DC-ok
LED
Output Characteristic
Output voltage
3A
24V
Output current
14V
0V
1A 2.5A0A
Adjustment range
28V
A
B
0.5A 1.5A
A: continuous current
B: intermittent current
2A
Temperature Range
Allowed output current at 24V
Ambient temperature
0A
-10
A: continuous
B: short term (max. 60s)
1.5A
+60 +70°C
1.1A
A
B
