NEO PIZZA-GAS-12 User manual

MANUAL & SAFETY
INSTRUCTIONS
PIZZA-GAS-12
1

oIf you smell gas shut off the
appliance. Extinguish any open
flames. If odor continues call
your local gas supplier and fire
department
oBefore cleaning, make sure the
gas supply and control knob is
in the OFF position and that the
burner and oven has cooled.
Failure to follow these
instructions could result in fire
explosion or burn hazards
which could cause property
damage, personal injury or
death.
oDo not store spare LP-gas under or
near the appliance.
oNever fill the cylinder beyond 80
percent full.
oIf the information beyond is not followed
exactly, a fire causing death or serious
injury may occur.
oMinimal clearance from sides and back
of the unit to combustible construction,
36 inches from the front.
oDo not use the appliance under
overhead.
oOnly use the gas pressure regulator
supplied with this appliance.
oTurn of the gas supply at the cylinder
when the appliance is not in use.
oThis appliance is not intended for
commercial use.
oThis regulator is set for an outlet
pressure of 11 wc.
oDo not move the appliance when in use.
oThe appliance is not intended for and
should not be used as a heater.
oKeep children and pets away from
appliance at all times.
oSpiders and insects can nest inside the
burner of the appliance and disrupt gas
flow, inspect the burner at least once a
year.
oDo not store gas cylinder in a building,
garage or any other enclosed area.
oThis appliance is not intended to be
installed in or on recreational vehicles
and/or boats.
oDo not smoke whilst leak testing the
appliance. Never leak test in front of an
open flame.
oCheck the gas supply fittings before
each use. Do not use the appliance until
the connections have all been checked.
oKeep the fuel supply hose away from
any heated surfaces.
oThe use of alcohol, prescription and non
prescription drugs can impair the
consumers ability to safely assemble
the appliance and safely operate the
appliance.
oFor outdoor use only, do not store
inside unless the gas cylinder is
disconnected.
oMake sure the control knob is in
OFF position, and then turn the
liquid propane cylinder valve
ON by slowly turning counter
clock wise. Push in and slowly
turn the control knob anti clock
wise until you heat click and the
burner ignites. If burner doesn’t
light, turn the knob OFF, wait 5
minutes and reattempt lighting.
Lighting instructions:
Other important information:
Please read the safety manual carefully before using the appliance.
2

oThe parts which have been sealed by the
manufacturer should not be adjusted by the user.
oWhen the appliance is using LPG a LPG cylinder
should be used.
oThe LPG cylinder size: max diameter-350mm, max
height-400mm.
oThe appliance is to be installed with sufficient
ventilation to prevent the occurrence of
unacceptable concentrations of substances harmful
to health in the room in which the
appliance is installed.
oThe minimum distances between the appliance and
adjacent walls is 0.5m.
oThe hose for the appliance should not exceed 1.5m.
oThe appliance should be installed in a
suitably ventilated room.
Permanent supply of fresh air is required
so there is no accumulation of unburned
gases.
oThe gas supply tubing or hose shall comply with the
national requirements in force and shall be
periodically examined and replaced as necessary.
oThe hose should comply with the standard EN16436.
The regulator should comply with the standard
EN16129.
oThe hose and regulator assembly may not be
provided with the appliance in some regions.
oCheck and suitably clean the inside of the oven
before it is lit in order to avoid the emission of fire
from the oils that have accumulated during previous
cooking.
oThe burner outlets should be checked for
obstruction during previous cooking.
oThe burner outlets should be checked for obstruction
and cleaned regularly with a soft wire brush.
oIt is necessary to avoid obstruction and to allow for a
good combustion.
oThe position of the connection flexible tube so as
to ensure that it is not subjected to twisting.
BEFORE LIGHTING
Inspect the gas supply hose prior to turning on the gas.
If there is evidence of a cut, wear or abrasion, it must be
replaced prior to use. Screw the regulator onto the gas
cylinder. Leak check the hose and regulator
connections with soap and water solution before
lighting the appliance.
LP GAS CYLINDER WARNING
1. Do
not store spare liquid propane gas cylinder
under or near the appliance.
2. Never fill the cylinder beyond 80 percent capacity.
3. Liquid propane cylinder must be fitted with an
OVERFILL PROTECTION DEVICE (OPD).
4. If the information above is not followed exactly, a
fire resulting in death or serious injury may occur.
SAFETY PRACTICES TO AVOID
INJURY
When properly cared for, your oven will provide
a safe, reliable
service for years. However,
extreme care must be used as the oven
produces intense heat that can increase the
risk of accidents.
When using this oven basic practices must be
followed, including but not limited to following:
oDo not repair or replace any part of the oven
unless specifically recommended in this
manual. All other service should be referred
to a qualified technician.
oChildren should not be left alone or
unattended in an area where the oven is
being used. Do not allow children to sit,
stand or play around the oven at any time.
oNever let clothing or other flammables come
in contact with or too close to any burner or
hot surface until it has cooled.The fabric
could ignite, causing serious personal injury.
Never fill the cylinder beyond 80 percent
capacity.
oLiquid propane cylinder must be fitted with
an OVERFILL PROTECTION DEVICE
(OPD).
oIf the information above is not followed
exactly, a fire resulting in death or serious
injury may occur.
oFor personal safety, wear proper apparel.
Loose fittings garments or sleeves should
never be worn while using the oven. Some
synthetic fabrics are highly flammable and
should not be worn while cooking.
oDo not heat unopened food containers as a
buildup of pressure may cause the
containers to burst. When lighting the
burner, always pay close attention to what
you are doing.
oWhen using the oven, do not touch the outer
shell, stone baking board or immediate
surroundings as these areas become
extremely hot and could cause burns.
oDo not use the oven to cook extremely fatty
meats or other products which increase flare-
up.
oKeep the area surroundings the oven free
from combustible material including fluids,
trash and vapours such as gasoline or
charcoal lighter fluid.
oDo not obstruct the flow of combustion and
ventilation air.
oNever use the oven in extremely windy
conditions.
oThe temperature under the oven is high.
Do not place the oven on a table with
flammable table cloths, plastic or any other
inflammable materials.
3

PARTS LIST
1. Neo Gas Pizza Oven
2. Stone Baking Board
ASSEMBLY
Before assembly, please make sure all parts are present. If any part is missing or
damaged, do not attempt to assemble the appliance. Contact customer service
for replacement parts.
1.Unfold legs
2.Insert the stone baking board
4

3.Connecting gas hose to Neo Gas Pizza Oven
Depending on your region the hose may be pre-assembled.
3a. Connecting gas hose directly to Neo Gas Pizza Oven
3b i). Connecting barb to Neo Gas Pizza Oven
This is a push on gas fitting. Please ensure that the black switch is in the
horizontal position. Depress the button located below the black switch and
press the regulator on to the tank value until it locks into place.
5
3b ii). Connecting gas hose to barb
This gas fitting is counterclockwise. Make sure that the tank is completely
switched off and screw the regulator as far as possible into the gas tank.

CONNECTING THE LIQUID PROPANE GAS CYLINDER
1. The cylinder valve should be in OFF position.
2. Also make sure the burner valve is in OFF position.
3. Inspect the valve connections, port and regulator assembly. Remove
debris and inspect the hose for damage.
4. When connecting the regulator assembly to the valve, use your hand to
tighten the nut clockwise until it stops. Use of a wrench could damage the
quick coupling nut and result in a hazardous situation.
5. Open the cylinder valve fully by turning the valve counterclockwise.
6. Before lighting the oven, use a soap and water solution to check all
connections for leaks.
7. If a leak is found, turn the cylinder valve OFF, and do not use the oven
until local liquid propane dealercan make repairs.
8. Turn the oven burner valve OFF and make sure the oven is cool.
9. Turn the liquid propane cylinder valve OFF by turning clockwise until it
stops.
10. Detach the regulator assembly from the cylinder valve by turning the quick
coupling nut counterclockwise.
11. Place dust cap for cylinder valve outlet whenever the cylinder is not in use.
6
WARNING
•Always keep the gas bottle in upright position.
• The size for 20 lbs LP gas cylinder is 12.2 inches in diameter and 17.9 inches tall.
• If the appliance is not in use, the gas must be turned off at the supply cylinder.
• The cylinder used must include a collar to protect the cylinder valve.
• The minimum distance for the appliance and the 20lb gas tank is 40 inches apart.
To connect the liquid propane gas cylinder:

LEAK TESTING
GENERAL
Although the gas connections of the appliance are leak
tested prior packing and shipment, a complete test must
be performed at the installation site. Before each use,
check all the gas connections for leak testing using the
procedure listed below. If the smell of gas is detected at
any time, you should immediately stop using and check
the entire system for leaks.
BEFORE TESTING
Make sure all packing material has been removed from
the appliance.
Make a solution of one part liquid detergent and one part
water. You will need a spray bottle,
brush or rag to apply the solution to the fittings.
TO TEST
1.Turn the burner valve OFF
2.Turn the liquid propane cylinder valve on
counterclockwise to open the valve.
3.Apply the soap solution to all gas fittings. Soap
bubbles would appear where a leak is present.
4.If a leak is present, immediately turn the gas supply
OFF and tighten leaky fittings.
5.Turn the gas back ON and recheck.
6.Should the gas continue to leak from any of the
fittings, turn the gas supply OFF and contact customer
service.
OPERATING INSTRUCTIONS
USING THE OVEN
Each burner is rated at 4.0KW. To begin:
1.Make sure the oven has been leak tested
and properly placed.
2.Remove any remaining packing material.
3.Light the burner using the LIGHTING
INSTRUCTIONS below.
LIGHTING INSTRUCTION
1.Make sure the control knob is in OFF
position, and then turn the liquid propane
cylinder valve ON by slowly turning counter
clockwise.
2.Push in and slowly turn the control knob
anticlockwise until you hear a click and the
burner ignites.
3.If burner doesn't light, turn the knob OFF,
wait 5 minutes and repeat the lighting.
CARE AND MAINTENANCE
Store HNS-P200 out of direct sunlight and
indoors where possible and when storing for
extended periods of time. This
should not be exposed to harsh weather
conditions such as snow, heavy rain and
strong winds.
Wait for Neo Gas Pizza Oven to cool
completely before moving.
The outer shell of the Neo Gas Pizza Oven
may fade over time and through use. This
will not affect performance.
Stone baking board
1. DO NOT use the stone over an open flame.
2. Avoid extreme temperature change to the stone.
3. DO NOT place frozen foods on a hot stone.
4. The stone is fragile and can break if bumped or dropped.
5. The stone is very hot during use and stays hot for a long time after use.
6. DO NOT cool the stone with water when the stone is hot.
7. After cleaning the stone with water, please dry the stone before use.
(This can be done in a conventional oven at 60°C (140°F) for 2 hours.)
7
the oven

TROUBLESHOOTING
Problem
Possible Cause
Prevention/Solution
Burner will not light
1. No gas flow
2. Coupling nut and regulator not
fully connected
3. Obstruction of gas flow
4. Disengagement of burner to
valve
5. Incorrect assembly
1. Check to see if propane tank is
empty
2. Turn the coupling nut about one-half
to three quarters additional turn until
solid stop. Tighten by hand only – do
not use tools
3. Clear burner tube
4. Reengage burner and valve
5. Check steps in assembly instructions
Sudden drop in gas flow or low
flame
1. Out of gas
1. Check for gas in propane tank
2. Turn off gas control knob, wait
30 seconds and light oven. If
flames are still low, turn off gas
control knob and propane tank
valve. Disconnect regulator.
Reconnect regulator and
leak test. Turn on propane tank
valve, wait 30 seconds and then
light oven.
Flames blow out
1. High or gusting winds
2. Low on propane gas
1. Turn front of oven away from wind
2. Refill propane tank
3. Refer to sudden drop in gas flow
above
Flare-up
1. Grease buildup
2. Excessive fat in meat
3. Excessive cooking temperature
4. Excess flour on the
cooking surface
1. Clean oven
2. Trim fats from meat before cooking
3. Adjust (lower) temperature
accordingly
4. Brush remnant flour from
cooking surface
5. Flip stone
Flashback (fire in burner
tube, roaring
sound from burner)
1. Burner and/or burner tubes
are blocked
2. Pressure drops during ignition
1. Turn gas control knob off. Clean
burner and/or burner tubes.
2. Turn off oven, ensure the tank
valve is fully open (if applicable)
and relight.
8
If you are unable to find a solution to your problem via the troubleshoot page,
please feel free to contact customer service at: [email protected]
