Neoware Capio User manual

Capio
QUICK-START GUIDE
1. Unpack
Your Capio is typically shipped with the following items:
• A keyboard
• A mouse
• A power cable
• A stand for stabilizing your Capio in a vertical orientation (attached).
• This Quick-Start Guide
2. Setup
Your Capio can be setup in either a horizontal or vertical orientation.
If you are using your Capio in a horizontal orientation:
• The USB ports should be on the right-hand side of the appliance.
• The appliance can be used to support your monitor.
• Apply the clear rubber feet to the bottom of the appliance chassis.
If you are using your Capio in a vertical orientation:
• The USB ports should be closer to the bottom of the appliance.
• The stand should be connected to the appliance.
3. Connections
Connect the supplied power cord, mouse, and keyboard to the ports labeled 1, 2, and 3 respectively. Connect your monitor’s cable to
the Video port (4).
1. Power Cord 4. Video Port 7. Serial Port
2. Mouse PS/2
3. Keyboard PS/2 5. Audio Line Out, Line In, Mic. 6. Parallel Port 8. 10/100 BaseT Ethernet Port
7 8654321
4. Power Up
In order to turn on your Capio, push in the circular on/off button on its front panel. To turn off your Capio, push the on/off button again.
1
1. Smart Card slot (reader optional)
2 3
2. Power Indicator 3. Network Activity Indicator
45
4. On / Off Button 5. USB Ports
Horizontal
V
e
r
t
i
c
a
l
www.neoware.com

5. Removing the stand
If you would like to use your Capio in a horizontal orientation you can remove the stand from the
appliance.
• Unplug the appliance and disconnect any cables attached to the ports on the rear of the
appliance.
• Turn the appliance upside down.
• Lift the release tab in the center of the stand.
• With the release tab lifted, push the stand towards the rear of the appliance until it can go
no further.
• Lift the stand away from the appliance and store it for future use.
6. More Information
For detailed information on configuring your appliance and creating connections to servers, please consult our online documentation
which can be downloaded at:
http://www.neoware.com/manuals.html
If you have any questions or are in need of technical support, please contact us at:
suppor[email protected]om, or +1.610.277.8300
FCC regulatory and safety information
Regulatory information Federal Communications Commission (FCC) (USA
