RIGHT ANGLE NewFixed HEIGHT WORKSTATION User manual

PAGE 1 OF 3
VERSION DATED: 12/4/12
TOOLS REQUIRED FOR ASSEMBLY:
CORDLESS DRILL WITH
#2 PHILLIPS HEAD DRIVER BIT OR
#2 SQUARE HEAD DRIVER BIT
7/32" HEX HEAD BIT OR ALLEN
WRENCH PROVIDED
TAPE MEASURE
LEVEL
NewFixed™ HEIGHT ORKSTATION ASSEMBLY INSTRUCTIONS:
STEP 1: LAY THE WOR SURFACE 1 ON A PROTECTED SURFACE WITH THE
PILOT HOLES AND INSERTS FACING UP. DETERMINE FROM DIAGRAM 1
BELOW WHICH PILOT HOLES YOU WILL USE TO ASSEMBLE YOUR WOR -
STATION. THE WOR SURFACE IS A UNIVERSAL DESIGN WITH HOLES PRE-
DRILLED FOR MULTIPLE WOR STATION MODELS. FOR NewFixed WOR -
STATIONS, USE ONLY THE PRE-DRILLED PILOT HOLES AS INDICATED.
DISREGARD HOLES INDICATED "DO NOT USE." THESE ARE NOT APPLICABLE
TO THIS MODEL.
INSTRUCTION # 51310
READ ALL THE INSTRUCTIONS BEFORE BEGINNING
HARD ARE PACK # 52226
STEP 1
PILOT HOLES
NewFixed RIGHT COLUMN
NewFixed RIGHT COLUMN
PILOT HOLES (2) DO NOT USE
(3-5) PILOT HOLES; DO NOT USE.
DO NOT USE ON NewFixed
DO NOT USE ON NewFixed DO NOT USE
PILOT HOLES (2)
DO NOT USE
NewFixed LEFT COLUMN
NewFixed LEFT COLUMN
PILOT HOLES (2)METAL INSERTS
BOTTOM VIEW OF WOR SURFACE. SIZES VARY
DIAGRAM 1
METAL INSERTS (8) DO NOT USE
METAL INSERTS
1
6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: [phone] FAX: [phone]
.raproducts.com
K&A MANUFACTURING

6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: [phone] FAX: [phone]
.raproducts.com
K&A MANUFACTURING
DETAIL A
PRE-INSTALLED
T-SLOT PLATE
A
2
3
4
5WOR SURFACE SUPPORT
FOOT
6
LEVELING GLIDE
OR CASTER
STEPS 2-5
7
1
WIDELY
SPACED
HOLES
PAGE 2 OF 3
VERSION DATED: 12/4/12
STEP 2: PLACE THE COLUMN ASSEMBLIES 2 AND 3 ON THE WOR -
SURFACE WITH THE FEET FACING UP. THE WIDELY SPACED HOLES IN
THE WOR SURFACE SUPPORTS FACE THE CENTER OF THE WOR -
SURFACE.
STEP 3: WITH THE HELP OF AN ASSISTANT, PLACE (4) STAR WASHERS 5
ON (4) SOC ET SCREWS 6 . INSERT THESE THROUGH THE HOLES ON
EACH END OF THE CROSS SUPPORT 4 . THREAD THEM INTO THE
HOLES IN THE T-SLOT PLATES THAT ARE PRE-INSTALLED IN THE COLUMN
ASSEMBLIES 2 AND 3 . SEE DETAIL A. DO NOT FULLY TIGHTEN.
STEP 4: LEVEL THE CROSS SUPPORT 4 AT 4" FROM THE BOTTOM OF
THE WOR SURFACE SUPPORTS AS SHOWN IN THE DETAIL AT THE
LOWER RIGHT. FULLY TIGHTEN THE SOC ET SCREWS 6 . USE THE HEX
HEAD DRIVER BIT OR THE ALLEN WRENCH PROVIDED 10 . SPECIAL
EXCEPTION: ON WORKSTATIONS ON WHICH THE LifeBalance
STATION IS BEING INSTALLED, THE CROSS SUPPORT SHOULD BE
ATTACHED RESTING ON THE FEET OF THE COLUMN ASSEMBLIES TO
ALLOW FOR CLEARANCE OF THE EQUIPMENT.
STEP 5: INSERT (2) END CAPS 7 INTO THE ENDS OF THE CROSS
SUPPORT 4 .
READ ALL OF THE
INSTRUCTIONS
BEFORE BEGINNING.
NOTE: SOME OF THE SCREWS IN THE HARDWARE
PAC SHIPPED WITH THIS WOR STATION WILL NOT
BE NEEDED.
ITEM # PART # DESCRIPTION QTY.
1 VARIES WOR SURFACE 1
2 VARIES NewFixed™ COLUMN ASSEMBLY LEFT HAND 1
3 VARIES NewFixed™ COLUMN ASSEMBLY RIGHT HAND 1
4 VARIES NewHeights™ 36" CROSS SUPPORT (31" ACTUAL) 1
5 52477 3/8 INTERIOR TOOTH STAR WASHER 4
6 52470 3/8-16 x 3/8 BUTTON HEAD SOC ET SCREW 4
7 800411 NewHeights™/HOVER END CAP 2
8 51708 M5 x 18mm SQ/PH/WSHR HEAD WOOD SCREW VARIES
9 VARIES 42" OR 54" U-CHANNEL (60" & 72" WOR STATIONS) 1
10 52498 7/32" ALLEN WRENCH 1
SEE EXCEPTION IN STEP 4
LOCATION
CROSS SUPPORT
LOCATING THE CROSS SUPPORT
4
4.00" FROM BOTTOM
OF WOR SURFACE
SUPPORT

6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: [phone] FAX: [phone]
.raproducts.com
K&A MANUFACTURING
(OR CASTER)
2
3
1
WOR SURFACE SUPPPORT
8
LEVELING GLIDE
NOTE: CROSS SUPPORT IS NOT SHOWN
ON THIS VIEW SO OTHER COMPONENTS
ARE VISIBLE.
PAGE 3 OF 3
VERSION DATED: 12/4/12
STEP 5: ALIGN THE HOLES IN THE WOR SURFACE SUPPORTS WITH THE PILOT HOLES IN THE WOR SURFACE 1 .
DO NOT USE THE METAL MACHINE SCREW INSERTS IN THE WOR SURFACE TO ATTACH THE WOR SURFACE
SUPPORTS. SEE THE DIAGRAM ON PAGE 1. THESE ARE USED FOR A DIFFERENT STYLE OF WOR STATION.
ATTACH THE COLUMN ASSEMBLIES 2 AND 3 TO THE WOR SURFACE USING (16) WOOD SCREWS 8 . DO
NOT OVERTIGHTEN THE SCREWS. USE A LOW TORQUE SETTING ON THE DRILL.
STEP 6: WITH THE HELP OF AN ASSISTANT, STAND THE WOR STATION UPRIGHT IN ITS FINAL LOCATION. LEVEL THE
WOR STATION IF REQUIRED BY TURNING THE LEVELING GLIDES CLOC WISE (FROM THE TOP) ON THE LOW
CORNERS OF THE UNIT. IF YOUR WOR STATION HAS CASTERS, TURN THE BOLTS AT THE TOP OF THE CASTERS
CLOC WISE TO LEVEL THE UNIT.
