Neptronic SKE4-E Series Manual

SKE4-E-ESA-191018
Sea Hidifie
SKE4-E Series
Installation Instructions and User Manual
READ AND SAVE THESE INSTRUCTIONS

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 1 -
Foreword
Neptronic Company Overview
Fded  1976, ee a ae ca ha deg, aface ad dbe dc f
the HVAC industry. Our product line includes intelligent controllers, electronic actuators, actuated
valves, humidifiers and electric heaters.
Our products are designed and manufactured by over 250 dedicated employees in our 7,500 m2(80,000
ft2) state-of-the-art facility located in Montreal, Canada. Using a vertical integration model, our entire
manufacturing chain is under one roof, from software and hardware development, to SMT circuit board
assembly, to sheet metal fabrication, to product testing, ensuring that our products are engineered to
last.
We currently hold several national and international patents and with our continued commitment to
research and development, we provide innovative products and technologies for the ever-evolving
challenges of the HVAC industry. Exporting over 70% of our sales, we have an exclusive distribution
network around the globe that provides comprehensive solutions to our worldwide customers.
About the Manual
These installation and operation instructions have been developed to facilitate the installation of the
Steam Humidifier.
The strict application of these instructions will ensure the conformity of your installation and
operation as per the manufacturer's recommendations.
The application of these instructions is one of the conditions for the application of the
warranty.
The application of these instructions does not ensure, at any time conformity to procedures,
regulation or local codes, regarding electric installation and connection to local water
supply.
This product has been declared to conform to applicable European safety and electromagnetic
compatibility standards and directives and bear the CE mark. The certificate of conformity CE is
available upon request to the manufacturer.
2019©: All rights reserved. This document cannot be reproduced totally or partially by any means
whether, electronic, mechanical, photocopy, recording or other, without prior written authorization of
Neptronic.
Electricity
All work concerned with electrical installation MUST only be performed by skilled
and qualified technical personnel, such as an electrician or a technician with
appropriate training. The customer is always responsible for ensuring the suitability
of the technical personnel.
Please observe the local regulations concerning the provision of electrical
installations.
Correct Use
Neptronic systems and its products are designed only for humidification use. Any other application is
not considered appropriate for the intended purpose. The manufacturer cannot be made liable for any
damage resulting from incorrect use.
General Warranty
This product is subject to the terms and conditions described at http://www.neptronic.com/Sales-
Conditions.aspx.

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 2 -
Handling and Lifting
Lifting or handling MUST be carried out by trained and qualified personnel. Ensure that
the lifting operation has been properly planned, assessed for risk and that the
equipment has been checked by a competent Health & Safety representative, and
effective control measures are in place.
I  he ce eb  ee ha he ea ae aed  hadg
heavy goods and to enforce the relevant lifting regulations.
The Steam Humidifier MUST be handled and lifted with care at all times and remain in
its original packaging for as long as possible, prior to installation.
The Steam Humidifier package may be carried using a forklift from the underside.
Exercise caution before lifting to ensure that the load is balanced.
Unpacking
The Steam Humidifier is shipped inside carton boxes or in a wooden crate. Remove packing and
skids prior to commissioning.
Contents
Overview ................................................................................................................................................. 4
List of Accessories Supplied................................................................................................................ 4
Available Options................................................................................................................................. 4
Description of Systems........................................................................................................................ 4
Visual Overview ................................................................................................................................... 5
Standard Humidifier Unit ..................................................................................................................... 7
Dimensions and Weight ................................................................................................................... 7
Humidifier with Space Distribution Unit ............................................................................................... 8
Humidifier with Space Distribution Unit - Dimensions and Weight .................................................. 8
Weather Proof Enclosure .................................................................................................................... 9
Weather Proof Enclosure - Dimensions and Weight ....................................................................... 9
Output and Power Consumption - Humidifier.................................................................................... 10
Mechanical Installation..........................................................................................................................11
General Recommendations............................................................................................................... 11
Location ......................................................................................................................................... 11
Positioning ..................................................................................................................................... 12
Wall Mounting ................................................................................................................................ 13
Positioning - Humidifier with SDU ..................................................................................................... 16
Positioning and Mounting - Weather Proof Enclosure Unit ............................................................... 17
General Recommendations ...........................................................................................................17
Steam Dispersion System .................................................................................................................18
Steam Dispersion System Selection..............................................................................................18
Positioning S.A.M. and S.A.M.E2 .................................................................................................. 20
Placement of Steam Pipe in Horizontal Duct................................................................................. 21
Placement of Steam Pipe in Vertical Duct .....................................................................................22
Steam Output Connections ...................................................................................................................23

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 3 -
Installation.......................................................................................................................................... 23
General Recommendations............................................................................................................... 23
S Trap Installation on the Steam Line............................................................................................ 24
Position of Steam Outputs.................................................................................................................25
Remote Installation - Humidifier with SDU ........................................................................................26
Wall Mounting the Remote SDU .................................................................................................... 27
Remote SDU Cover Installation (Option)....................................................................................... 28
Plumbing Connections .......................................................................................................................... 29
Water Supply Connections ................................................................................................................ 31
Water Drain Connections ..................................................................................................................32
Weather Proof Enclosure Plumbing Connection ...............................................................................33
Electrical Connections........................................................................................................................... 34
Power Supply Hole Locations ........................................................................................................... 35
Low Voltage Control Connections .....................................................................................................36
Printed Circuit Board......................................................................................................................36
Safety Contact Connections ..........................................................................................................37
Dry Contacts .................................................................................................................................. 37
ON/OFF Humidifier ........................................................................................................................ 38
Modulating Humidifier .................................................................................................................... 39
Network Communication................................................................................................................42
Controls Placement (Steam Dispersed into a Duct or AHU) .........................................................43
Controller Configuration ........................................................................................................................44
Control Panel Features...................................................................................................................... 44
Idle Screen ........................................................................................................................................ 45
Menu Access ..................................................................................................................................... 45
Menu Navigation and Configuration ..................................................................................................46
Menu - General .............................................................................................................................. 47
Menu - User Settings ..................................................................................................................... 50
Menu - Service............................................................................................................................... 51
Menu - Installation.......................................................................................................................... 52
Menu - Integration.......................................................................................................................... 55
List of Alarms .....................................................................................................................................58
Start-up Procedure................................................................................................................................ 60
Initial Verification ............................................................................................................................... 60
Start-Up .............................................................................................................................................61
Service .................................................................................................................................................. 62
Cleaning the Evaporation Chamber ..................................................................................................62
Troubleshooting .................................................................................................................................... 67
Exploded View and Bill of Material........................................................................................................ 68
Exploded View ...................................................................................................................................68
Bill of Material .................................................................................................................................... 70

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 4 -
Overview
List of Accessories Supplied
The following accessories are supplied with the SKE4 Steam Humidifier:
2 sets of keys.
2 adjustable collars per steam outlet for the connection of the steam hose.
1 hydraulic female compression fitting DN20 for the drain output of the evaporation
chamber.
1 hydraulic female elbow fitting DN15 for the drain output of the drip pan.
2 brackets and screws for wall mounting the humidifier (models SKE4-E05 to E80 only).
1 Installation Instructions and User Manual.
Available Options
The following options are available when purchasing a SKE4 humidifier:
Modulating control humidifier (Suffix M, i.e. SKE4-E20M)
Humidifier for a system supplied with Deionized water or Reverse Osmosis water, having
more than 0.1 ppm of dissolved solids
Space Distribution Unit mounted on humidifier (SDU) or remotely installed (SDU-REM)
Weather proof enclosure
BACnet Network Communication System
Ethernet (IP) option
Stainless steel humidifier cabinet
Description of Systems
System
Description
Evaporation Chamber
Removable metallic container in which steam is produced. It is the
most important part of the humidifier.
Space Distribution Unit
(SDU)
Integrated steam distribution unit to humidify air when there is no
duct system. Optional feature available for certain humidifier
models.
Multi-Steam System
Custom made system for steam distribution. This system is
designed for applications where absorption distances are very short
(less than 900 mm).
Steam Absorption Manifold
(S.A.M.)
Steam manifold adapted to air duct size. Allows steam absorption
for relatively short distance applications (less than 1500 mm).
Steam Absorption Manifold
with 2 Eyelets (S.A.M.E2)
Steam manifold with two eyelets, adapted for applications with
restricted air duct dimensions. Allows steam absorption for
relatively short distance applications (less than 1500 mm).

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 5 -
Visual Overview
Left Side
Steam Outlet
Heating
Element
Connectors
Controller
Water Level
Sensor
Manual Drain
Valve
Water Inlet
Disconnect
Switch
Right Side
Access Door to
Low Voltage
Compartment
Printed Circuit
Board
Evaporation
Chamber
Access Panel to
High Voltage
Compartment
Rail Guide
Illustration 1 - Overview of the Humidifier (SKE4-E05 to E80)

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 6 -
Illustration 2 - Overview of the Humidifier (SKE4-E90 to E120)

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 7 -
Standard Humidifier Unit
B
A
C
Models SKE4-E05 to E80
B
A
C
Models SKE4-E90 to E120
Illustration 3 - SKE4 Steam Humidifier
Dimensions and Weight
Table 1 - Dimensions and Weight
Model
Dimensions of the Cabinet (mm)
Weight (kg)
A
B
C
Empty
Full
SKE4-E05
584
492
349
32
39
SKE4-E10
SKE4-E20
SKE4-E30
SKE4-E40
813
565
384
49
69
SKE4-E50
SKE4-E60
SKE4-E80
813
845
384
65
106
SKE4-E90
SKE4-E100
SKE4-E110
SKE4-E120
1219
838
619
145
200

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 8 -
Humidifier with Space Distribution Unit
Illustration 4 - Steam Humidifier with Space Distribution Unit
Humidifier with Space Distribution Unit - Dimensions and Weight
Table 2 - Dimensions and Weight of SDU
Model
Dimensions of the Cabinet (mm)
Weight (kg)
SDU
Weight
(kg)
A
B
C
D
E
Empty
Full
SKE4-E05
584
492
349
171
755
39
45
SDU4-1
7
SKE4-E10
813
565
384
197
1010
58
78
SDU4-2
9
SKE4-E20
SKE4-E30
SKE4-E40
813
565
384
289
1102
62
83
SDU4-3
14
B
C
A
E
D
SDU
Space
Distribution
Unit (option)
Steam
Humidifier

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 9 -
Weather Proof Enclosure
Steam
Outlet
Water Inlet
 NPT
(DN15)
Pan Drain
 (DN20)
Alphanumeric
Display
Window
A
B
C
Main Drain
 (DN20)
Disconnect
Switch
Handle
 (13 mm)
Models SKE4-E05 to E80
Main
Drain ⅞"
(DN22)
Water Inlet
½" NPT
(DN15)
Pan Drain
⅞" (DN22)
Steam Outlet
A
B
C
Alphanumeric
Display Window
Models SKE4-E90 to E120
Illustration 5 - Weather Proof Enclosure
Weather Proof Enclosure - Dimensions and Weight
Table 3 - Weather Proof Enclosure: Dimensions and Weight
Model
Dimensions of the Cabinet (mm)
Weight (kg)
Steam Outlet
Diameter (mm)
A
B
C
Empty
Full
SKE4-E05
854
651
410
45
52
35
SKE4-E10
1102
753
438
59
80
35
SKE4-E20
SKE4-E30
SKE4-E40
1102
753
438
59
80
51
SKE4-E50
SKE4-E60
SKE4-E80
1114
1032
438
89
129
76
SKE4-E90
SKE4-E100
1524
965
727
184
240
76
SKE4-E110
SKE4-E120
1524
965
727
184
240
100

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 10 -
Output and Power Consumption - Humidifier
Table 4 - Output and Power Consumption
Model
Steam
Consumption
Steam Output
Capacity
(kg/hr)
Power
(kW)
Amperage (A)
Qty
Diameter
(mm)
230/1
400/3
SKE4-E05
5
3.7
16
5.5
1
35
SKE4-E10
10
7.5
33
11
1
35
SKE4-E20
20
15
-
22
1
51
SKE4-E30
30
22
-
33
1
51
SKE4-E40
40
30
-
44
1
51
SKE4-E50
50
36
-
53
1
76
SKE4-E60
60
44
-
64
1
76
SKE4-E80
80
60
-
87
1
76
SKE4-E90
90
66
-
96
1
76
SKE4-E100
100
74
-
107
1
76
SKE4-E110
110
82
-
119
2
76
SKE4-E120
120
90
-
130
2
76
WARNING: For Modulating Humidifier, maintain the maximum power of the
electrical installations according to the information in Table 4 - Output and Power
Consumption.
Do not consider a possible reduction of steam output due to modulation.

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 11 -
Mechanical Installation
General Recommendations
WARNING: Risk of electric shock. Disconnect the appliance from electric supply before
commencing installation.
Note: Mechanical installation must conform to local codes and regulations.
Location
WARNING: The SKE4 series is designed for indoor installation only.
For outdoor installation, the SKE4 must be installed using a Neptronic weather proof
enclosure (see Positioning and Mounting - Weather Proof Enclosure Unit on page 17).
Failure to follow these guidelines will void the warranty.
Consider the following points before deciding the location for the SKE4 Steam Humidifier:
Plan a location that is easy to access and permits an easy inspection and servicing of the
humidifier.
Do not install the humidifier where failure of the appliance could cause damage to the
building structure or to other expensive equipment.
Ensure that the location is well ventilated and that the ambient temperature is less than
30°C.
Consider the total steam line length between the humidifier and the steam distributor
based on the steam line material type:
oFor flexible steam hose, total steam line must not exceed 5 meters. For longer
distances, use insulated hard piping.
oFor insulated hard piping, the total steam line is determined by the humidifier
capacity: 0.67 m for each kg/hr capacity of the humidifier, with a maximum of 15 m.
For longer steam line runs, consult factory.

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 12 -
Positioning
Ensure that the front panel, the left side (plumbing compartment) and the right side
(electrical compartment) are accessible in order to permit servicing.
Leave a clearance of at least 1.2 m to the front panel and 0.3 m on the left and right sides
of the humidifier.
Leave a clearance of at least 0.5 m on top of the humidifier.
For models SKE4-E05 to E80:
oMount the humidifier at a minimum height of 0.6 m above floor level.
oLeave a clearance of at least 0.25 m under the humidifier for installation of water
supply, drain piping and electrical connections.
For models SKE4-E90 to E120:
oThese models are designed to be installed directly on the floor. Adjustable legs
are provided in order to ensure proper level.
oProvide a level, solid foundation and ensure that the floor beneath the humidifier
is water proof to withstand any water spillage during servicing or in the event of a
problem.
Illustration 6 - Positioning the Humidifier

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 13 -
Wall Mounting
CAUTION: Risk of malfunction. The humidifier must be placed at an equal level.
CAUTION: Risk of overheating. Do not block the ventilation openings located on
the cabinet.
Before proceeding, check the strength of the chosen support or wall (brick, concrete, stud partition wall)
on which the humidifier will be mounted. See the Dimensions and Weight section (page 7) to know the
weight of the unit.
Illustration 7 - Mounting Bracket Positioning
Table 5 - Positioning Lines of Mounting Brackets
Model
Dimensions (mm)
A
B
C
D
E
SKE4-E05
584
492
467
467
22
SKE4-E10
SKE4-E20
SKE4-E30
SKE4-E40
813
565
540
540
22
SKE4-E50
SKE4-E60
SKE4-E80
813
845
718
540
22
Note: Models SKE4-E90 to E120 cannot be wall mounted and must be properly
secured to the ground using the adjustable legs.

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 14 -
To wall mount the humidifier, perform the following steps:
1. Place the top bracket (supplied) on the support or wall as per the dimensions specified in
Table 5 - Positioning Lines of Mounting Brackets.
2. Drill 4 screws (not supplied) into the slotted holes of the top bracket, to secure the bracket
to the support or wall.
3. Place the bottom bracket (supplied) on the support or wall as per the dimensions
specified in Table 5 - Positioning Lines of Mounting Brackets.
4. Drill 4 screws (not supplied) into the slotted holes of the bottom bracket, to secure the
bracket to the support or wall.
Screws
(by others)
Top Bracket
Bottom
Bracket
Illustration 8 - Mounting Bracket Attachment

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 15 -
5. Secure the humidifier to the top bracket, by placing the back inserts into the open slots
located on the edge of the center of the top bracket.
Illustration 9 - Top Mounting Bracket Connection
6. Open the front door of the humidifier to gain access to the slotted holes located in the
back of the cabinet. Verify that the holes are aligned with the ones located in the center of
the bottom bracket.
7. From inside the humidifier, drill 2 (models SKE4-E05 to E40) or 4 (models SKE4-E50 to
E80) screws (supplied) into the center of the bottom bracket, in order to secure the
humidifier to the support or wall.
Illustration 10 - Bottom Mounting Bracket Connection

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 16 -
Positioning - Humidifier with SDU
The SDU must be installed in an environment where the air is relatively clean. This will
prevent the blower from getting clogged with dust.
The humidifier must be mounted such that the SDU fan section is at least 2 m above the
floor.
Allocate a minimum clearance of 0.45 m from the ceiling to avoid ceiling and wall
condensation.
If additional ventilation is not present, ensure that the fan has a clearance of at least 1.35
m from the ceiling. Proper ventilation must be observed to avoid ceiling and wall
condensation.
Illustration 11 - SDU Mounted on Humidifier
Maintenance of the SDU
Clean the blower if there is an accumulation of dust.

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 17 -
Positioning and Mounting - Weather Proof
Enclosure Unit
Use 8 bolts and washers (not supplied) to
secure the humidifier to the floor/roof.
12" (30 cm)
minimum
20" (51cm)
minimum
42" (107cm)
minimum
12" (30 cm)
minimum
Illustration 12 - Weather Proof Enclosure Positioning
General Recommendations
Plan a location that is easy to access and permits an easy inspection and servicing of the
humidifier.
Do not install the humidifier where failure of the appliance could cause damage to the
building structure or to other expensive equipment.
Maintain the following minimum clearances while installing to enable access for
inspection and servicing.
Side
Minimum Clearance
Top
51 cm
Both sides
30 cm
Front
107 cm
The humidifier is designed to be installed directly on the floor/roof or a curb.
Provide a level, solid foundation for the humidifier.
Ensure that the floor/roof beneath the humidifier is water proof to withstand any water
spillage during servicing or if a problem occurs.
Attach the SKE4 enclosure securely and safely, by securing the base plate to the ground
with the use of 8 bolts and washers (not supplied), as per the sizes indicated in the
following table.
Model
Bolt Diameter
SKE4-E05 to SKE4-E80
8mm
SKE4-E90 to SKE4-E120
12mm

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 18 -
Steam Dispersion System
Steam Dispersion System Selection
In order to prevent the accumulation of condensation in air ducts, Neptronic has designed four basic
configurations of steam distribution systems to provide the most economical solution for any particular
application.
Steam Absorption Manifold (S.A.M.) Horizontal Duct
The S.A.M. system is suitable for installations where absorption distances are short, less than 1500
mm, and/or low duct temperatures are in effect.
Illustration 13 - Steam Absorption Manifold (S.A.M) Horizontal Duct
Steam Absorption Manifold (S.A.M.E2) Horizontal Duct
The S.A.M.E2 system is suitable for installations where absorption distances are short, less than 1500
mm, and/or low duct temperatures are in effect. S.A.M.E2 are used in applications with restricted duct
dimensions.
Illustration 14 - Steam Absorption Manifold (S.A.M.E2) Horizontal Duct
air
900
air

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 19 -
Steam Absorption Manifold (S.A.M. or S.A.M.E2) Vertical Duct
S.A.M. or S.A.M.E2 systems for vertical ducts are used when the absorption distances are normal and
the requirement is for an economical and efficient solution.
Illustration 15 - Steam Absorption Manifold (S.A.M. or S.A.M.E2) Vertical Duct
Multi-Steam System
The Multi-Steam system is used in critical locations in air handling systems, particularly where
absorption distances are very short, less than 900 mm, or where low air duct temperatures are present.
The Multi-Steam is custom made to the dimensions of the duct or AHU.
Instructions to install the Multi-Steam system are described in a specific installation instructions
manual enclosed with the Multi-Steam system.
Illustration 16 - Multi Steam System
S.A.M.
S.A.M.E2.
45°
45° 45°
air
air
air
