NES NITO User manual

NITO
ELECTRIC SCOOTER
OWNER AND MAINTENANCE MANUAL

2
NITO ELECTRIC SCOOTER
Mobility for us means more freedom, fun and
environmental regard.
The NES electric scooter is an icon of style, unequalled in
performance, design and variety of options available.
THANKS FOR CHOOSING NITO
WELCOME
TO THE
ELECTRIC ERA

3
NES - OWNER AND MAINTENANCE MANUAL
WELCOME
TO THE
ELECTRIC ERA
MANUAL PURPOSE
The aim of this manual is to allow you to fully appreciate the
qualities of your NES scooter.
Contained here are information, warnings and advice on how to
use and maintain the vehicle correctly for maximum safety.
It is essential to read this manual completely before attempting
to ride the vehicle for the first time.

5
NES - OWNER AND MAINTENANCE MANUAL
TABLE OF CONTENTS
01
GENERAL GUIDELINES............................................8
SAFETY.........................................................................................9
PRELIMINARY CHECKS......................................................10
GUARANTEE ............................................................................10
VEHICLE IDENTIFICATION..............................................11
MOTOR IDENTIFICATION.................................................12
02
DESCRIPTION AND FEATURES .............................14
SCOOTER COMPONENTS ...............................................15
WHEEL COMPONENTS .....................................................16
ACCESSING OBD AND USB PORTS.............................17
INSTRUMENTATION.............................................................18
KEYLESS IGNITION..............................................................19
POWER ON AND OFF .........................................................19
START_ STOP PUSH-BUTTON...........................................19
DRIVING FUNCTIONS - LEVER AND CONTROL...20
DISPLAY FUNCTIONS.........................................................21
03
BATT ERY US E ............................................................22
BATTERY PROCEDURES FOR FIRST
SCOOTER USE ........................................................................23
RECHARGING OPERATIONS ..........................................23
RECHARGING WITH BATTERY CHARGER
CONNECTED DIRECTLY TO SCOOTER SOCKET..25
RECHARGING BY CONNECTING BATTERY
CHARGER TO BATTERY (AFTER REMOVAL)...........26
VEHICLE INACTIVITY .........................................................28
BATTERY INFORMATION..................................................29
PRECAUTIONS USING LITHIUM ION BATTERIES
.........................................................................................................29
04
MAINTENANCE.........................................................30
ROUTINE MAINTENANCE (BY USER).........................30
EXTRAORDINARY MAINTENANCE
(IN AUTHORISED SERVICE CENTRE)..........................33
TECH NICAL DATA ....................................................34
ACCESSORIES...........................................................36

6
NITO ELECTRIC SCOOTER
GENERAL
GUIDELINES
01
zRead these instructions carefully before starting to use your NES electric scooter.
zThis instruction manual must be conserved safely and consulted during the whole
lifetime of the product.
zTo drive the NES electric scooter you must be in possession of the appropriate
driving licence for the model chosen (NES 5 or NES 10).
zThe scooter is not suitable for use by persons with reduced physical, sensory or
mental capabilities.
zIn case of doubts or questions, please contact your local reseller or
the After-Sales NITO on the phone number [phone] or sending an email
to [email protected].
Failing to observe these instructions, wholly or in part, could result in serious damage to
persons, the vehicle or the environment. Under certain circumstances, it could render the
guarantee void.
The manufacturer reserves the right to make changes to the vehicle and to this manual for
the purpose of improvement without prior warning.

7
NES - OWNER AND MAINTENANCE MANUAL
Safety
zAlways wear a helmet, fastening it on correctly
(ensure it is approved).
zWhen carrying a passenger, before moving off
make sure they are wearing a helmet and that it is
fastened on correctly.
zDo not exceed the scooter’s maximum weight limit
of 150 kg, including loads.
zOn uneven roads, or in rainy, snowy or slippery
conditions you must reduce your speed and
increase the safety distance between you and other
vehicles. Proceed with utmost caution.
zAt night or in low visibility conditions always wear
reflective, florescent clothing to maximise your
visibility to other drivers. When changing lane or
turning, use appropriate signals and the horn when
necessary.
zBe attentive to the vehicles around you and do not
assume that other drivers can see you. Be always
ready to make an emergency stop or carry out a fast
manoeuvre to avoid obstacles.
zCarry out correct maintenance of the scooter to
maintain it always in a safe optimal riding condition.
zDriving under the influence of alcohol, drugs or
certain medicines is very dangerous for yourself
and for others, and is prohibited by law.
zAny modification that alters the performance or
main structure of the scooter is prohibited by law
and makes the vehicle no longer compliant with the
approval standards and therefore compromises
safety.

8
NITO ELECTRIC SCOOTER
zCheck that the instrument panel display
illuminates correctly and that the battery
charge level is correct.
zCheck that the direction indicators, scooter
and licence plate light are functioning correctly.
zExamine visually the state of wear of brake
pads on both brake callipers and ensure they
are being worn uniformly on both sides of the
disk.
zAt least once a month or when the tyres seem
deflated, check their pressure using a pressure
gauge and visually examine the state of wear
using a wear indicator. Always check tyre
pressure “from cold”.
zCheck the level of the brake liquid in the tank
found in the handlebar.
zAs required by law, the product is covered by a
guarantee for manufacturing defects encountered
within 2 years of the purchase date.
Preliminary checks
Guarantee
zCheck the saddle is closed correctly.
zCheck that the battery compartment is
closed correctly.

9
NES - OWNER AND MAINTENANCE MANUAL
Vehicle
identification
The vehicle identification label is
situated on the rear left of the body
and indicates: manufacturer’s name,
Roadworthy Certificate (RC) number,
vehicle power and weight.

10
NITO ELECTRIC SCOOTER
Motor
identification
The motor’s identification code is
shown in the image on the side here.

12
NITO ELECTRIC SCOOTER
The NES electric scooter is unbeatable in terms of performance, design and
personalisations when compared with other electrical scooters on the market
today.
72 different configurations are possible with fairings in four colours, board
wood and saddle finishes each in a choice of three different colours, and two
tyre colours.
Superior performance and design allow electrical mobility to reach
everywhere.
DESCRIPTION
AND FEATURES02

13
NES - OWNER AND MAINTENANCE MANUAL
Scooter
components
1REAR VIEW MIRRORS
2RIGHT HANDLE WITH THROTTLE CONTROL
AND FRONT BRAKE ACTIONING LEVER
3LEFT HANDLE WITH REAR BRAKE
ACTIONING LEVER
4FRONT LED HEADLIGHT
5LIFTABLE SADDLE FOR ACCESS TO HELMET
STORAGE COMPARTMENT (IF PRESENT)
6TWIN TUBE HYDRAULIC SHOCK ABSORBER
SITUATED BETWEEN CHASSIS AND SWINGARM
7REAR LED LAMP AND DIRECTION LIGHTS
8BRAKE DISKS
9REAR KNOBBED TYRE 130/90-10
10 FRONT KNOBBED TYRE 120/90-10
11 CENTRAL AND SIDE STAND
12 DIRECTION INDICATORS
13 BATTERY COMPARTMENT
14 BATTERY CHARGER
1 1
23
5
7
6
9
8
10
4
11
14
12
13

14
NITO ELECTRIC SCOOTER
1DUAL-PISTON FRONT BRAKE CALLIPER
ACTING ON PERFORATED STEEL DISK
2METAL BRAIDED HYDRAULIC HOSES
CONNECTING CALLIPER TO BRAKE PUMP
3FRONT ALLOY 10” DIAMETER RIM
4FRONT MUDGUARD BOLTED TO FORK
5TELESCOPIC FORK
6REFLECTOR
7REAR MUDGUARD BOLTED TO SWINGARM
8COIL SPRING SHOCK ABSORBER
9OSCILLATING SWINGAR HINGED
TO CHASSIS
10 DUAL-PISTON REAR BRAKE CALLIPER
ACTING ON PERFORATED STEEL DISK
11 METAL BRAIDED HYDRAULIC HOSES
CONNECTING CALLIPER TO BRAKE PUMP
WHEEL COMPONENTS
1
6
3
5
48
7
9
2
10
11

15
NES - OWNER AND MAINTENANCE MANUAL
Accessing OBD
and USB ports
The basic model of the NES scooter comes fitted
with an USB port, an OBD port for accessing
diagnostics information and a battery recharging
socket.
To access the sockets, open the bay by simply
pressing on the side.
The USB port with led indicator and OBD port are
active only when the scooter is in ON mode.
1BATTERY CHARGER SOCKET
2OBD PORT
3USB PORT
2
1
3

16
NITO ELECTRIC SCOOTER
1HORN PUSH-BUTTON
2DIRECTION INDICATORS
3REAR BRAKE CONTROL LEVER
4HEADLIGHT/FLASHING
INDICATORS SWITCH
5DI SPL AY
6FRONT BRAKE CONTROL LEVER
7THROTTLE CONTROL
8DRIVE MODE SELECTOR
9FOUR HAZARD LIGHTS BUTTON
10 HORNPUSH-BUTTON
INSTRUMENTS AND
CONTROLS POSITIONING
Instrumentation
2 10
5
1 7
6
34
9
8

17
NES - OWNER AND MAINTENANCE MANUAL
The NES scooter has a keyless ignition that can be used for
activating the electric steering lock and anti-theft mechanism.
Pressing , he system is set to ON mode and the "READY"
icon appears on the display.
The power button remains active for 5 seconds (for safety
reasons) after pressing the Lock open key .
To power on first press the key and then the Start_Stop push-
button or press twice and then the key on the remote
controller.
To power off press the Start_Stop push-button.
Keyless ignition
Start_Stop Push-button
Power ON and OFF
Lock open key:
anti-theft and steering lock off
Lock closed key:
anti-theft and steering lock on
START: ignition

18
NITO ELECTRIC SCOOTER
1LEFT HANDLE (DRIVING
FUNCTION ONLY)
2REAR BRAKE LEVER
3HIGH-LOW BEAM HEADLIGHT
SWITCH
4DIRECTION INDICATOR SELECTOR
(PRESS TO CANCEL)
5HORN BUTTON (MAINTAINED
PRESSURE)
6FRONT BRAKE LEVER
7RIGHT HANDLE, THROTTLE
ACTIVATED BY ROTATING
HANDLE (ON RELEASE THE
SCOOTER TENDS TO SLOW
DOWN)
8LOW, ECO AND SPORT DRIVING
MODES SELECTOR
94 HAZARD LIGHTS PUSH-BUTTON
10 HORNPUSH-BUTTON (WITH
MAINTAINED ACTION)
DRIVING FUNCTIONS LEVER
AND CONTROL
1
2
5
4
3
6
8
7
10
9

19
NES - OWNER AND MAINTENANCE MANUAL
1BATTERY CHARGE LEVEL
2JOURNEY TOTAL MILEAGE IN KMS
3SPEED INDICATOR
4CONTROL UNIT TEMPERATURE
INDICATOR
5DIRECTION INDICATORS
6ENGINE FAILURE INDICATOR
7HIGH-LOW BEAM LIGHT INDICATOR
8"READY " SYSTEM STATUS
Display functions
The digital display provides all the information
on vehicle status.
55
6
8
3
1
2
4
7

20
NITO ELECTRIC SCOOTER
BATTERY USE
03
The NES scooter comes fitted with a Lithium battery with an autonomy of 90* / 80** km
in ECO mode (NES 5 and NES 10), with a lifetime of approx 1000 recharging cycles.
A number of factors affect battery autonomy:
zUse on urban or extra-urban roads requiring continual use of the throttle.
zUse of the scooter outside normal riding conditions.
zUse on roads with a steep slope or particularly uneven surfaces.
zProlonged thermal shocks.
* Test performed at constant speed, 20 kph in ECO mode and 35 kph in SPORT,
on a flat road with a 75 kg driver.
** Test performed at constant speed, 35 kph in ECO mode and 50 kph in SPORT,
on a flat road with a 75 kg driver.
