Net2Phone MAX IP10 User Guide
i
Table of Contents
1. MAX IP10 Overview.........................................................................................................................................................1
1.1. Features ........................................................................................................................................................................1
1.2. User Interface..............................................................................................................................................................1
1.3. Keys ................................................................................................................................................................................2
2. IP Phone Mode ...................................................................................................................................................................3
2.1. MakingaCall...............................................................................................................................................................3
2.1.1. Making a domestic or international Call in IP phone mode........................3
2.1.2. Making a “Max-to-Max” Call........................................................................4
2.2. Answering an Incoming Call...................................................................................................................................5
2.3. Redial (Available only when power is ON) ........................................................................................................5
2.4. Memory Dial.................................................................................................................................................................6
2.4.1. Making a Call using Memory Dial................................................................6
2.4.2. Storing a phone number in a memory slot..................................................7
2.5. SpeedDial ....................................................................................................................................................................7
2.5.1. Making a Call using speed dial....................................................................7
2.5.2. Mapping a phone number to a speed dial key............................................8
2.6. CallHold........................................................................................................................................................................9
2.7. Volume Control............................................................................................................................................................9
2.8. Mute.............................................................................................................................................................................10
3. Analog Phone Features..............................................................................................................................................10
3.1. Making an analog phone Call .............................................................................................................................10
3.2. Answering an incomingcall from analog phone line....................................................................................11
3.3. Redialing.....................................................................................................................................................................11
3.4. Hook-Flash / Ring Volume / Ring Type.............................................................................................................11
4. MAX IP10 Configuration.............................................................................................................................................12
4.1. View/Change Account Number...........................................................................................................................12
4.2. View/Change PIN Number...................................................................................................................................13
4.3. View/Change Analog Telephone Number (PSTN phone number).........................................................13
4.4. View/Change Network Mode...............................................................................................................................13
4.5. View/Change IP Address......................................................................................................................................14
4.6. View/Change Subnet Mask.................................................................................................................................14
4.7. View/ChangeGatewayAddress.........................................................................................................................15
4.8. View/Change Primary DNS.................................................................................................................................15
4.9. View/Change Secondary DNS............................................................................................................................16
4.10. View/Change Doorman1 IP Address................................................................................................................16
4.11. View/Change Doorman1 Port .............................................................................................................................16
4.12. View/Change Doorman2 IP Address................................................................................................................17
4.13. View/Change Doorman2 Port .............................................................................................................................17
4.14. View/Change TCP Start Port...............................................................................................................................17
4.15. View/Change UDP Start Port..............................................................................................................................18
4.16. View/Change Packet Mode .................................................................................................................................18
4.17. LCD Gain Control....................................................................................................................................................19
4.18. Remote Volume Control........................................................................................................................................19
4.19. Memory Dial Configuration..................................................................................................................................19
4.20. SpeedDialConfiguration......................................................................................................................................20
4.21. PPPoE User ID Configuration.............................................................................................................................20
4.22. PPPoE Password Configuration........................................................................................................................21
5. MAX IP10 Information .................................................................................................................................................21

Net2Phone MAX IP10 User Guide
1
Introduction
Conventions Used in this Guide
In this Guide, text that will be displayed onLCD screen is set in Courier font.
About This Guide
This User’s Guide is intended to help you set up and use the full features of the MAX IP10.
MAX IP10 supports maintenance interfaces of web-browser, telnet and keypad/LCD interface.
This Guide describes how to operate and configure MAX IP10 using keypad and LCD.
1. MAX IP10 Overview
1.1. Features
MAX IP10 supports following features:
-IP (Internet Protocol) phone operation with Net2Phone VOIP protocol
-Analog phone operation for local phone call
-Local configuration via keypad/LCD
-Remote configuration via Telnet or Web-browser
-S/W upgrade via FTP(New S/W notice will be displayed on LCD automatically)
-Volume control
-Mute/Redial/Speed-dial key
-Call Hold (holds IP phone call while using analog phone)
-PSTN fallback (auto -switching to analog phone mode in case of power failure)
-IP Addressing: static/dynamic IP support (DHCP)
-PPPoE support
-QoS support (Diffserv)
-RTP/RFC2833 support
-N2P account management
-Minute/Dollar balance display
-Call statistics
-Billing support (CDR generation)
1.2. User Interface
MAX IP10 supports following user interfaces:
-Handset / Speakerphone
-Keypad / LCD
-Ethernet port for PC & LAN
-Analog phone line port
-Tone/Pulse select switch
-Earpiece amplifier switch

Net2Phone MAX IP10 User Guide
2
1.3. Keys
Key Type Key Function
Menu Press [Menu] key to enter MAX IP10 configuration menu.
INFO Press [INFO]key to view account & other data.
During configuration, It functions as backspace (?).
N2P Press [N2P]key to call another MAX IP10.
During configuration, It functions as previous menu (|?).
PSTN/ SET Press [PSTN] key to Analog phone line call.
During configuration, It is used as [SET] key
REDIAL Press [REDIAL] key to redial the last dialed number.
MEMORY
DIAL Press [MEMORY]key and the memory location number (1~9) for quick dialing.
SPEED
DIAL Press one of [SPEED DIAL]keys (1~8) for quick dialing.
MUTE Press [MUTE] key to turn-off the microphone.
SPEAKER Press [SPEAKER] key to toggle the speakerphone On/Off.
VOLUME
UP Press [VOLUME UP] key to increase the volume level. It is also used for selecting menu items during
configuration.
Function
Key
VOLUME
DOWN Press [VOLUME DOWN]key to decrease the volume level. It is also used for selecting menu items during
configuration.
1Dial key 1(1 / ?! # $ % ^ & * ( ) _ + | { } : “< > ? `-= ;)
2Dial key 2(2 A a B b C c)
3Dial key 3(3 D e E e F f)
4Dial key 4(4 G g H h I i)
5Dial key 5(5 J jK k L l)
6Dial key 6(6 M m N n O o)
7Dial key 7(7 P p Q q R r S s)
8Dial key 8(8 T t U u V v)
9Dial key 9(9 W w X x Y y Z z)
0Dial key 0(0 space . , @)
*Dial key *
Dial Key
#Dial key #
Table 1-1. Descriptionsof MAXIP10 Key
Items Function
LCD LCD Displays menusandstatus of IP Phone on a 2-line by 16
character screen.
LAN Using an UTP-5 cable, connect the hub to this port.
PC Using an UTP-5 cable, connect your PC to this port.
LINE Connect the analog phone line from PBX/KTS to this
port.
Connector
Power Connect the power adapter (12V DC) to the power
connector.
Table 1-2. Descriptions of MAX IP10 LCD and Connector

Net2Phone MAX IP10 User Guide
3
2. IP Phone Mode
The default operation mode of MAX IP10 is IP phone mode (Internet phone mode), and there
are 8 operational features: Making an outbound call, answering an incoming call, redialing,
memory dialing, speed dialing, call hold, volume control, and mute.
?Note: MAX IP10 attempts to confirm the connection with OPAL server periodically, and if it
fails, thephone goes to analog phone mode, where you can make or answer a call via analog
phone line.
?Note: In IP phone mode, when there is a call from analog phone line, it switches to analog
phone mode. After the call is over, it returns to IP phone mode.
?Note: Using [PSTN] key, you can switch between IP phone mode and analog phone mode.
2.1. Making a Call
2.1.1. Making a domestic or international Call in IP phone mode
1) Lift handset or press [SPEAKER] key and listen for the dial tone. You will see LCD screen
like Figure 2-1.
Figure 2-1 Off Hook state
2) Dial the destination phone number. LCD screens the dialed number.
Figure 2-2 Dialing
When dialing a number in North America, dial: “1 + area code + number.”
When dialing a number outside North America, dial: “011 + country code + area code +
number.”
3) Press the [#] key after entering the phone number. MAX IP10 attempts to connect the call,
and you will see screen like Figure 2 -3 on the LCD.
Figure 2-3 Connecting
Enter Number
Enter Number
123456789
Connecting
…
123456789

Net2Phone MAX IP10 User Guide
4
4) If the connection attempt is success, you will hear ringback tone. If the connection attempt
fails, you will hear error tone and LCD screens the one offollowing messages corresponding to
the reason for the connection error. (Figure 2-4)
“CallFailed”
“Bad PIN / Account”
“Insufficient Funds”
“Account In Use”
“Busy”
“Duplicate PIN or Account”
Figure 2-4 Connection Error (Call Failed case)
5) When called party answers, you can begin speaking. You will see LCD screen like Figure 2-5.
Figure 2-5 Connection success
6) When the call is over, hang up or press [SPEAKER] key. On the LCD, you will see screen like
Figure 2-6.
Figure 2-6 On Hook state
2.1.2. Making a “Max-to-Max”Call
1) Lift handset or press [SPEAKER] key and listen for the dial tone. You will see LCD screen
like Figure 2-1.
2) Press the [N2P] key, then on the LCD, the digits ‘*72’will appear (Figure 2-7)
Figure 2-7 Virtual Number Dial State
3) Dial the Virtual Number of the destination Net2Phone device. LCD screens the dialed
number.
Figure 2-8 Virtual Number Dialing
Talk
123456789
Call Failed
Enter Number
*729876543210
Enter Number
*72
1234567890
Max IP Phone

Net2Phone MAX IP10 User Guide
5
4) Press the [#] key after entering the phone number. MAX IP10 attempts to connect the call,
and you will see screen like Figure 2-9 on the LCD.
Figure 2-9 Connecting
5) If the connection attempt is successful, you will hear ringback tone. If the connection
attempt fails, you will hear error tone and LCD will display one ofthe messages
corresponding to the reason for the connection error. (Figure 2-4)
6) When called party answers, you can begin speaking. On the LCD, you will see screen like
Figure 2-5.
7) When the call is over, hang up or press [SPEAKER] key. On the LCD, you will see screen
like Figure 2-6
2.2. Answering an Incoming Call
1) When the phone is ringing, you will see the LCD screen like Figure 2-10.
a) Call from PSTN connection (analog phone call)
b) Call from MAX-to-MAX connection (Net2Phone call)
c) MAX-to-MAX connection state
Figure2 -10 Ringing / Connection
2) Lift handset or use speakerphone by pressing [SPEAKER] key, then start speaking.
2.3. Redial (Available only when power is ON)
When you want to make a call with the last dialed number, follow these steps:
1) Lift handset or press [SPEAKER] key and listen for the dial tone. You will see the LCD
screen like Figure 2-1.
Connecting
…
*729876543210
PSTN C
all Mode
123456789
Caller ID
1234567890
Talk
1234567890

Net2Phone MAX IP10 User Guide
6
2) Press [REDIAL] key, then on the LCD, the last dialed number will appear (Figure 2-11)
Figure 2-11 Redialing
3) MAX IP10 attempts to connect the call, and you will see screen like Figure 2-3 on the LCD.
4) If the connection attempt is successful, you will hear the ringback tone. If the connection
attempt fails, you will hear the error tone and LCD will displayone of the messages
corresponding to the reason for the connection error. (Figure 2-4)
5) When called party answers, you can begin speaking. You will see screen like Figure 2-5 on
the LCD.
6) When the call is over, hang up or press [SPEAKER] key. On the LCD, you will see screen
like Figure 2-6.
2.4. Memory Dial
2.4.1. Making a Call using Memory Dial
There are 9 memory slots, 1 to 9. When you want to make a call with the phone number that is
stored in one of them, follow these steps:
1) Lift handset or press [SPEAKER] key and listen for the dial tone. On the LCD, you will see
screen like Figure 2-1.
2) Press [MEMORY] key. On the LCD, you will see screen like Figure 2-12.
Figure 2-12 Memory Dial Mode
3) Press a number (1-9) to choose the memory slot that stores the phone number to call, then
the phone number will be appear, like Figure 2-13.
Figure 2-13 Memory Dialing
4) MAX IP10 attempts to connect the call.
5) You will hear ringback tone.
6) When called party answers, you can beginspeaking.
7) When the call is finished, hang up or press [SPEAKER] key.
Enter Number
123456789
Memory Dial(1
-
9)
Enter Number
123456789

Net2Phone MAX IP10 User Guide
7
2.4.2. Storing a phone number in a memory slot
1) Press [MEMORY] key. On the LCD, you will see screen like Figure 2-14.
Figure 2-14 Memory Dial Edit Mode 1
2) Press [0]~[9] number keys to enter the digits. You can also enter alphabets or symbols by
pressing the number key multiple times. (Refer Table 1 -1) If you make a mistake, use the
[INFO] key to back up and correct the mistake.
Figure 2-15 Memory Dial Edit Mode 2
3) After entering the phone number, press the [MEMORY] key. On the LCD, you will see
screen like Figure 2-16.
Figure 2-16 Memory Dial Edit Mode 3
4) Press a dial number (1-9) to choose the memory slot where the phone number is to be
stored. On the LCD, you will see screen like Figure 2-17.
Figure 2-17 Memory Dial Edit Mode 4
2.5. Speed Dial
2.5.1. Making a Call using speed dial
You can also store phone numbers in speed dial keys as well as memory slots. There are 8
speed dial keys. When you want to make a call to the phone number stored in one of them,
follow these steps:
1) Lift handset or press [SPEAKER] key and listen for the dial tone.
2) Press the speed dial key for the desired phone number, and the phone number stored in
the speed dial key will appear. You will see screen like Figure 2-18 on the LCD.
Edit Number
Edit Number
*721234567890
Index
-
>
*721234567890
Index
-
> Memory 1
*721234567890

Net2Phone MAX IP10 User Guide
8
Figure 2-18 Speed Dialing
3) MAX IP10 attempts to connect the call.
4) You will hear ringback tone.
5) When called party answers, you can begin speaking.
6) When the call is finished, hang up or press [SPEAKER] key.
2.5.2. Mapping a phone number to a speed dial key
1) Press the [MEMORY] key. You will see screen like Figure 2-19 on the LCD.
Figure 2-19 Speed Dial Edit Mode 1
2) Press [0]~[9] number keys to enter the digits. You can also enter alphabets or symbols by
pressing the number key multiple times. (Refer Table 1 -1) If you make a mistake, use the
[INFO] key to back up and correct the mistake.
Figure 2-20 Speed Dial Edit Mode 2
3) After entering the phone number, press the [MEMORY] key, On the LCD, you will see
screen like Figure 2-21.
Figure 2-21 Speed Dial Edit Mode 3
4) Press a speed dial key (1-8) where the phone number is to be mapped. On the LCD, you
will see screen like Figure 2 -22.
Figure 2-22 Speed Dial Edit Mode 4
Enter Number
123456789
Edit Number
Edit Number
*721234567890
Index
-
>
*721234567890
Index
-
> Speed 1
*721234567890

Net2Phone MAX IP10 User Guide
9
2.6. Call Hold
When you want to put connected Net2Phone call on hold and receive the incoming call from
analog phone line, follow these steps:
1) Press [PSTN] key. On the LCD, you will see screen like Figure 2-23.
Figure 2-23 Analog phone Mode
2) To retrieve the call, press [PSTN] key again. Then you will see screen like Figure 2-24 on
the LCD. You are connected back to the Net2Phone call.
Figure 2-24 IP phone Mode
2.7. Volume Control
You can control the ring/tone/handset/speaker volumes within each context.
1) Tone volume control
Lift handset or press [SPEAKER] key, and adjust the tone volume using [VOLUME UP] and
[VOLUME DOWN] keys.
a. Handset Tone Volume Control
b. Speaker Tone Volume Control
Figure2 -25 Tone Volume Control
2) Ring volume control
When the phone is ringing, adjust the ring volume using [VOLUME UP] and [VOLUME
DOWN] keys.
Figure2 -26 Ring Volume Control
PSTN Call Mode
1234567890
Talk
123456789
Handset Tone
Low ¦¦¦¦¦¦ High
Speaker Tone
Low ¦¦¦¦¦¦ High
Ring Volume
Low ¦¦¦¦¦¦ High

Net2Phone MAX IP10 User Guide
10
3) Handset/Speakerphone volume control
When the call is connected, adjust the handset or speakerphone volume using [VOLUME
UP] and [VOLUME DOWN] keys.
Figure 2-27 Handset(Ear) or Speakerphone Volume Control
2.8. Mute
When you want to turn-off the microphone on both handset and speakerphone, follow these
steps:
1) Press [MUTE] key. You will see an LCD screen like Figure 2-28.
Figure 2-28 Mute Mode
2) To turn-on the microphone, press [MUTE] key again.(Figure2 -29)
Figure 2-29 IP phone Mode
3. Analog Phone Features
MAX IP10 can also operate in analog phone mode. There are only 3 operational features:
Making a call, answering an incoming call, and redialing.
?Note: Redialing feature is available only with power on.
?Note: Even if power is down, the phone can still operate, but nothing is displayed on LCD.
?Note: If [PSTN] key is pressed twice, it attempts switching to IP phone mode by connecting to
Internet, but if it fails, the phone will remain in analog phone mode.
3.1. Making an analog phone Call
1) Press the [PSTN] key for switching to the analog phone mode. On the LCD, you will see
screen like Figure 3-1. (1234567 : Analog phone number assigned to the phone.)
Figure 3-1analog phone mode
Mute
1234567890
Talk
123456789
Ear Volume
Low ¦¦¦¦¦¦ High
PSTN Call Mode
1234567
Speaker Volume
Low ¦¦¦¦¦¦ High

Net2Phone MAX IP10 User Guide
11
2) Lift handset.
3) Dial destination phone number.
4) MAX IP10 attempts to connect the call through the analog phone line.
5) You will hear ringback tone.
6) When called party answers, you can begin speaking.
7) When the call is over, hang up.
3.2. Answering an incoming call from analog phone line
If the phone is ringing, then lift handset or press [SPEAKER] key to start speaking.
3.3. Redialing
When you want to make an analog phone call with the last dialed number in analog phone
mode, follow these steps:
1) Press the [PSTN] key to switch to analog phone mode. You will see screen like Figure 3 -1 on
the LCD.
2) Lift handset or press [SPEAKER] key.
3) Press the [REDIAL] key to dial the last dialed number.
4) MAX IP10 attempts to connect the call through the analog phone line.
5) You will hear ringback tone.
6) When called party answers, you can begin speaking.
7) When the call is over, hang up.
*** Note: Last dialed number is erased when the analog phone cable is disconnected.
3.4. Hook-Flash / Ring Volume / Ring Type
When you want to send hook-flash signal while holding the handset, press the [MEMORY] key.
When the phone is ringing, you can adjust the ring volume using [5] ~ [8] keys. [5] is for the
lowest volume and [8] is for the highest volume.
*** Ring volume is set to default when the analog phone line is disconnected.
When the phone is ringing, you can change the ring melody type using [1] ~ [4] keys.
*** Ring melody type is set to default when the analog phone line is disconnected.

Net2Phone MAX IP10 User Guide
12
4. MAX IP10 Configuration
Before attempting to make a outbound call, or to answer an incoming call, MAX IP10 must be
configured with several parameters.
?Note: There are 22 parameter fields you need to configure. Press the [MENU] key to access
each field one after another. You can modify the field using number keys and confirm the
change using the [SET] key.
?Note: In case you finish modifying the account parameters (account number and pin number)
or network parameters (IP address), the phone will automatically rebootusing the changed
parameters.
?Note: Besides the operation parameter fields, there are memory dial configuration menu and
speed dial configuration menu where you can store the phone numbers used in memory dialing
and speed dialing.
To enter the config uration menu, you must type in the menu access code.Press the [MENU]
key. You will see LCD screen like Figure 4-1. Type in the menu access code and '#' key. The
default access code is '123'. The menu access code can be modified via web-browser.
Figure 4-1Accesscodescreen
4.1. View/Change Account Number
1) Press the [MENU] key once. You will see an LCD screen like Figure 4-2.
Figure 4-2Editing Account Number
2) Press [0]~[9] number keys to enter the digits. If you make a mistake, use [INFO] keyas
‘backspace’key and correct the mistake.
3) After entering all the digits of the account number, press the [SET] key to confirm the change.
4) Press the [MENU] key to go to the next field.
1.Account Number
1234567890
[Access Cod
e?]

Net2Phone MAX IP10 User Guide
13
4.2. View/Change PIN Number
1) After entering the account number, press the [MENU] key. You will see Figure 4-3 on the
LCD.Theasterisk ‘*’is displayed as many as the digits of PIN for security.
Figure 4-3Editing Pin Number
2) Press [0]~[9] number keys to enter the digits. If you make a mistake, use [INFO] key as
‘backspace’key and correct the mistake.
3) After entering all the digits of the pin, press the [SET] key to confirm the change.
4) Press the [MENU] key to go to the next field or the [N2P] key to go to the previous field.
4.3. View/Change Analog Telephone Number (PSTN phone number)
When MAX IP10 is in the analog phone mode, the analog phone number is displayed as user’s
PSTN phone number. User can enter this telephone number for reference.
1) After entering the PIN, press the [MENU] key. You will seeLCD screen like Figure 4-4.
Figure4 -4Editing PSTN Number
2) Press [0]~[9] number keys to enter the digits. If you make a mistake, use [INFO] key as
‘backspace’key and correct the mistake.
3) After entering all the digits of the telephone number, press the [SET] key to confirm the
change.
3) Press the [MENU] key to go to the next field or the [N2P] key to go to the previous field.
4.4. View/Change Network Mode
1) After entering the telephone number, press the [MENU] key. You will see LCD screen like
Figure 4-5.
?? If the network mode is‘DHCP*’, and there is a DHCP server on the network that the
MAX IP10 is connected to, it will automatically assign the IP Address, Subnet Mask and
DefaultGateway, andDNS address.
2. Pin
****
3.PSTN Number
1234567

Net2Phone MAX IP10 User Guide
14
?? If the network mode is‘PPPOE*’, and there is a PPPoE server on the network that the
MAX IP10 is connected to, it will automatically assign the IP Address, Subnet Mask and
DefaultGateway, andDNS address.
?? If the network mode is‘STATIC*’, then you have to assign the IP Address, Subnet Mask
and Default Gateway, and DNS address by yourself.
Figure4 -5Configuring Network Mode
2) Press [VOLUME UP]/[VOLUME DOWN] to change the configurations. If it is different from the
current setting, ‘*’will disappear
3) Press the [SET] key to confirm the change. The asterisk ‘*’will appear when the change is
applied.
4) Press the [MENU] key to go to the next field or the [N2P] key to go to the previous field.
?The network parameters like IP address, Subnet, Gateway, Primary DNS, and Secondary
DNS can be modified only if network mode is ‘STATIC’.
4.5. View/Change IP Address
1) After entering the network mode, press the [MENU] key. You will see LCD screen like Figure
4-6.
Figure 4-6Editing IP Address
2) Press [0]~[9] number keys to enter the digits. Pause for 1 second between digits when
entering. The period ‘.’can be entered by pressing [0] key twice quickly. If you make a
mistake, use [INFO] key as ‘backspace’key and correct the mistake.
3) After entering all the digits of the IP address, press the [SET] key to confirm the change.
4) Press the [MENU] key to go to the next field.
4.6. View/Change Subnet Mask
4. Network Mode
STATIC*
4. Network Mode
DHCP
4. Network Mode
PPPOE
5. IP Address
168.188.43.7

Net2Phone MAX IP10 User Guide
15
1) After entering the IP Address, press the [MENU] key. You will see LCD screen like Figure 4-7.
Figure 4-7Editing Subnet Mask
2) Press [0]~[9] number keys to enter the digits. Pause for 1 second between digits when
entering. The period ‘.’can be entered by pressing [0] key twice. If you make a mistake, use
[INFO] key as ‘backspace’key and correct the mistake.
3) After entering all the digits of the subnet mask, press the [SET] key to confirm the change.
4) Press the [MENU] key to go to the next field.
4.7. View/Change Gateway Address
1) After entering the subnet mask, press the [MENU] key. You will see LCD screen like Figure
4-8.
Figure 4-8Editing Gateway Address
2) Press [0]~[9] number keys to enter the digits. Pause for 1 second between digits when
entering. The period ‘.’can be entered by pressing [0] key twice. If you make a mistake, use
[INFO] key as ‘backspace’key and correct the mistake.
3) After entering all the digits of the gateway address, press the [SET] key to confirm the
change.
4) Press the [MENU] key to go to the next field.
4.8. View/Change Primary DNS
1) After entering the gateway address, press the [MENU] key. You will see an LCD screen like
Figure 4-9.
Figure 4-9Editing Primary DNS
2) Press [0]~[9] number keys to enter the digits. Pause for 1 second between digits when
entering. The period ‘.’can be entered by pressing [0] key twice. If you make a mistake, use
[INFO] key as ‘backspace’key and correct the mistake.
3) After entering all the digits of the primary DNS, press the [SET] key to confirm the change.
4) Press the [MENU] key to go to the next field.
6. Subnet Mask
255.255.255.0
7.Gateway
168.188.43.254
8.Primary DNS
168.188.10.9

Net2Phone MAX IP10 User Guide
16
4.9. View/Change Secondary DNS
1) After entering the primary DNS, press the [MENU] key. You will see LCD screen like Figure
4-10.
Figure 4-10 Editing Secondary DNS
2) Press [0]~[9] number keys to enter the digits. Pause for 1 second between digits when
entering. The period ‘.’can be entered by pressing [0] key twice. If you make a mistake, use
[INFO] key as ‘backspace’key and correct the mistake.
3) After entering all the digits of the secondary DNS, press the [SET] key to confirm the change.
4) Press the [MENU] key to go to the next field.
4.10.View/Change Doorman1 IP Address
1) Press the [MENU] key until menu number 10 appears. You will see LCD screen like Figure 4-
11.
Figure 4-11 Editing Doorman1 IP address
2) Press [0]~[9] number keys to enter the digits. You can also enter alphabets or symbols by
pressing the number key multiple times. (Refer Table 1-1) Pause for 1 second between digits
when entering.The period ‘.’can be entered by pressing [0] key twice. If you make a
mistake, use the [INFO] key to back up and correct the mistake.
3) After entering all the digits of the Doorman1 IP address, press the [SET] key to confirm the
change.
4) Press the [MENU] key to go to the next field.
?Doorman IP address edit mode supports left (‘*’) and right (‘#’) arrow key to input character
strings that is longer than LCD size.
4.11.View/Change Doorman1 Port
1) After entering the Doorman1 IP address, press the [MENU] key. You will see LCD screen
like Figure 4-12.
Figure 4-12 Editing Doorman1 Port Number
9.Secondary DNS
168.188.128.46
10.Doorman1 IP
?.net2phone.com
11.Doorman1 Port
6801

Net2Phone MAX IP10 User Guide
17
2) Press [0]~[9] number keys to enter the digits. If you make a mistake, use the [INFO] key to
back up and correct the mistake.
3) After entering all the digits of the Doorman1 port number, press the [SET] key to confirm the
change.
4) Press the [MENU] key to go to the next field.
4.12.View/Change Doorman2 IP Address
1) After entering the Doorman1 port number, press the [MENU] key. You will see LCD screen
like Figure 4-13.
Figure 4-13 Editing Doorman2 IP address
2) Press [0]~[9] number keys to enter the digits. You can also enter alphabets or symbols by
pressing the number key multiple times. (Refer Table 1 -1) Pause for 1 second between
digits when entering. The period ‘.’can be entered by pressing [0] key twice. If you make
a mistake, use the [INFO] key to back up and correct the mistake.
3) After entering all the digits of the Doorman2 IP address, press the [SET] key to confirm the
change.
4) Press the [MENU] key to go to the next field.
?Doorman IP address edit mode supports left (‘*’) and right (‘#’) arrow key to input character
strings that is longer than LCD size.
4.13.View/Change Doorman2 Port
1) After entering the Doorman2 IP address, press the [MENU] key. You will see LCD screen like
Figure 4-14.
Figure 4-14 Editing Doorman2 Port Number
2) Press [0]~[9] number keys to enter the digits. If you make a mistake, use the [INFO] key to
back up and correct the mistake.
3) After entering all the digits of the Doorman2 port number, press the [SET] key to confirm the
change.
4) Press the [MENU] key to go to the next field.
4.14.View/Change TCP Start Port
1)Afterentering the Doorman2 port number, press the [MENU] key. You will see LCD screen
like Figure 4-15.
12.Doorman2 IP
?.net2phone.com
13.Doorman2 Port
6801

Net2Phone MAX IP10 User Guide
18
Figure 4-15 Editing TCP Start Port
2) Press [0]~[9] number keys to enter the digits. If you make a mistake, use the [INFO] key to
back up and correct the mistake.
3) After entering all the digits of the TCP start port number, press the [SET] key to confirm the
change.
4) Press the [MENU] key to go to the next field.
4.15.View/Change UDP Start Port
1) After entering the Tport start number, press the [MENU] key. You will see LCD screen like
Figure 4-16.
Figure 4-16 Editing UDP Start Port
2) Press [0]~[9] number keys to enter the digits. If you make a mistake, use the [INFO] key to
back up and correct the mistake.
3) After entering all the digits of the UDP start port number, press the [SET] key to confirm the
change.
4) Press the [MENU] key to go to the next field.
4.16.View/Change Packet Mode
1) Press the [MENU] key until the menu number 16 appears. You will see LCD screen like
Figure 4-17.
Figure4 -17 Editing Packet Mode
2) Press [VOLUME UP]/[VOLUME DOWN] to change the configurations. If it is different from the
current setting, ‘*’will disappear
14.Tport Start
4000
15.Vport Start
21000
16.Packet Mode
AUTO*
16.Packet Mode
N2P
16.Packet Mode
RTP

Net2Phone MAX IP10 User Guide
19
3) Press the [SET] key to confirm the change. The asterisk ‘*’will appear when the change is
applied.
4) Press the [MENU] key to go to the next field or the [N2P] key to go to the previous field.
4.17.LCD Gain Control
When you want to change LCD gain (contrast), follow these steps:
1) Press the [MENU] key untilthe title “17. LCD Gain”is displayed. You will see LCD screen like
Figure 4-18.
Figure 4-18 Editing LCD Gain
2) Use [VOLUME UP] and [VOLUME DOWN] keys to adjust LDC gain.
3) Press the [MENU] key until the IP Phone displays the “MAX IP10”screen.
4.18.Remote Volume Control
When you want to control Remote Volume (Loudness at the other side of the call), follow these
steps:
1) Press the [MENU] key untilthe title “18. Remote Volume ”is displayed. You will see LCD
screen like Figure 4-19.
Figure 4-19 Editing Remote Volume
2) Use [VOLUME UP] and [VOLUME DOWN] keys to adjust remote volume.
5) Press the [MENU] key until the IP Phone displays the “MAX IP10”screen.
4.19.Memory Dial Configuration
You can store phone numbers into memory slots and dial directly from the memory directory.
When you want to program memory dial, follow these steps:
1) Press the [MENU] key untilthe title “19. Memory Dial”is displayed. You will see LCD screen
like Figure 4-20.
Figure 4-20 Memory Dial Configuration-1
17.LCD Gain
¦¦¦¦¦¦¦¦
18.Remote Volume
Low ¦¦¦¦¦¦ High
19. Memory Dial
Press Set Key...
