Net2Phone MAX 4 User manual

MAX 4
VoIP Gateway.
User Guide
Version 0.90
TM

ii
The specifications and information regarding the products in this manual are subject to change without notice. All
statements, information, and recommendations in this manual are believed to be accurate but a represented without
warranty of any kind, express or implied. Users must take full responsibility for their application of any products.
The software license and limited warranty for the accompanying product are set forth in the information packet that
shipped with the product and are incorporated herein by this reference. If you are unable to locate the software license
or limited warranty, contact your Net2Phone representative for a copy.
The following information is for FCC compliance of Class A devices: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in which case users will be required to correct the
interference at their own expense.
The following information is for FCC compliance of Class Adevices: The equipment described in this manual generates
and may radiate radio-frequency energy. If it is not installed in accordance with Net2Phone's installation instructions, it
may cause interference with radio and television reception. This equipment has been tested and found to comply with
the limits for a Class Adigital device in accordance with the specifications in part 15 of the FCC rules. These
specifications are designed to provide reasonable protection against such interference in a residential installation.
However, there is no guarantee that interference will not occur in a particular installation.
Modifying the equipment without Net2Phone's written authorization may result in the equipment no longer complying
with FCC requirements for Class A or Class B digital devices. In that event, your right to use the equipment may be
limited by FCC regulations, and you may be required to correct any interference to radio or television communications
at your own expense.
You can determine whether your equipment is causing interference by turning it off. If the interference stops it was
probably caused by the Net2Phone equipment or one of its peripheral devices. If the equipment causes interference to
radio or television reception, try to correct the interference by using one or more of the following measures:
· Turn the television or radio antenna until the interference stops.
· Move the equipment to one side or the other of the television or radio.
· Move the equipment farther away from the television or radio.
· Plug the equipment into an outlet that is on a different circuit from the television or radio. (That is make certain the
equipment and the television or radio are on circuits controlled by different circuit breakers or fuses)
Modifications to this product not authorized by Net2Phone could void the FCC approval and negate your authority to
operate the product.
Notwithstanding any other warranty herein, all document files and software of these suppliers are provided "as is" with
all faults. Net2Phone and the above-named suppliers disclaim all warranties, expressed or implied, including, without
limitation, those of merchantability, fitness for a particular purpose and non-infringement or arising from a course of
dealing, usage, or trade practice.
In no event shall Net2Phone or its suppliers be liable for any indirect, special, consequential, or incidental damages,
including, without limitation, lost profits or loss or damage to data arising out of the use or inability to use this manual,
even if Net2Phone or its suppliers have been advised of the possibility of such damages.
Net2Phone MAX 4, net2phone, and the Net2Phone logo are registered trademarks of Net2Phone, Inc. in the US and
certain other countries. All other trademarks mentioned in this document are the property of their respective owners.

iii
Net2Phone MAX 4User Guide
Rev. 0.9Aug 2001
Copyright © 2001, Net2Phone, Inc. All rights reserved
The use, disclosure, modification, transfer, or transmittal of this work for any purpose, in any form, or by any means,
without the written permission of Net2Phone, is strictly forbidden.
Printed in Korea

iv
Table of Contents
1. Overview .............................................................................................................................................1
1.1 System Features ........................................................................................................................................1
1.2 About This Guide........................................................................................................................................1
1.3 Hardware Setup..........................................................................................................................................3
1.3.1 Hardware Requirements......................................................................................................................3
1.3.2 Additional Requirements......................................................................................................................3
1.3.3 The Hardware Setup Procedure...........................................................................................................3
1.4 Installing the MAX 4 Unit.............................................................................................................................5
2. Connecting Your Net2Phone MAX 4 to the LAN...................................................................................6
2.1 Connecting the MAX 4 to a DHCP LAN .......................................................................................................6
2.1.1 Obtaining the Net2Phone MAX 4™s DHCP IP Address via a Telephone Keypad..................................6
2.1.2 Connecting to the MAX 4 through a Serial Cable..................................................................................7
2.2 Connecting to a LAN with Static IP Addresses .............................................................................................9
2.2.1 Entering static IP address parameters from a telephone keypad...........................................................9
2.2.2 Entering Static IP Addresses via HyperTerminal................................................................................. 11
3. Logging in to the MAX Web Manager.................................................................................................15
4. Using the MAX Web Manager............................................................................................................18
4.1 Port Configuration..................................................................................................................................... 18
4.2 Network and Voice Configuration...............................................................................................................19
4.3 Account Configuration...............................................................................................................................21
4.4 Routing Table Configuration...................................................................................................................... 22
4.5 System Information and Commands.......................................................................................................... 25
4.6 Load Default Config.................................................................................................................................. 26
4.7 Show Log Messages.................................................................................................................................27
4.8 Restart System.........................................................................................................................................28
4.9 System Software Upgrade ........................................................................................................................29
5. Configuring Voice Messages..............................................................................................................30
5.1 Voice Message Files................................................................................................................................. 30
5.2 Recording a Custom Voice Message File...................................................................................................32
5.3 Voice Message File Upload/Download Procedure...................................................................................... 32
5.3.1 Voice Message File Download Procedure (For Win95/98/NT).............................................................33
5.3.2 Voice Message File Upload Procedure (For Win95/98/NT).................................................................34
Appendices...............................................................................................................................................35
Appendix A - Troubleshooting ............................................................................................................................... 35
A.1 Common mechanical installation problems and corrective actions .......................................................... 35
A.2 Common network connection problems ................................................................................................. 36
A.3 Common configuration problems........................................................................................................... 38
A.4 Problems using the MAX 4....................................................................................................................38
Appendix B - Technical Support............................................................................................................................ 39
Appendix C - System Specifications...................................................................................................................... 40
Appendix D - Approvals and Listings.....................................................................................................................42
Index ........................................................................................................................................................44

Page 1
1. Overview
1.1 System Features
Congratulations on your purchase of the Net2Phone MAX 4!
The Net2Phone MAX 4 is a VoIP device that allows you to make multiple outgoing calls over the
Internet using a single Ethernet LAN connection. The Net2Phone MAX 4 works like a gateway to
convert the analog signal from your telephone to VoIP (Voice over Internet Protocol). It then uses the
LAN’s broadband connection to send calls over the Internet via Net2Phone’s service platform. Since
Net2Phone calls bypass most of the PSTN (Public Switched Telephone Network), the result is
significant savings on long-distance communications services.
The MAX 4 is a desktop device that connects directly into the existing LAN through an RJ-45 port. It
supports up to four analog telephones, each connected to the unit through an individual FXS port
(analog telephone port), and is intended for use by mid to large-sized groups.
The FXS port’s functionality includes placing outgoing calls and receiving incoming calls from other
Net2Phone devices. Optionally, FXS ports may be connected to the analog trunk card on PBX, APBX,
or KPS (Key Phone System) systems.
The Net2Phone MAX 4 features several proprietary QoS (Quality of Service) enhancements, including
ŸG.168 echo cancellation
ŸVoice activity detection (VAD)
ŸComfort noise generation (CNG)
ŸDynamic jitter buffer control
1.2 About This Guide
This User Guide, as well as the other instructional literature that accompanies the Net2Phone MAX 4, is
intended for people who have a moderate degree of experience installing networking equipment such
as routers, hubs, servers, and switches, and are familiar with basic wiring and cabling practices.
In addition to this User Guide, the MAX 4 is shipped with three product manuals:
ŸA Quick Start Guide that describes hardware installation, cabling, and configuration for a
basic, uncomplicated installation with FXS ports only.
ŸA Hardware Installation Guide that describes hardware installation, cabling, and safety-related
issues.
ŸA Command Reference Guide for advance configuration of the MAX 4 through a serial
connection.

Page 2
This guide is organized as follows:
ŸSection 1: Overview
ŸSection 2: Connecting Your Net2Phone MAX 4 to the LAN
ŸSection 3: Logging in to the MAX Web Manager.
ŸSection 4: Using the MAX Web Manager.
ŸSection 5: Configuration voice message

Page 3
1.3 Hardware Setup
1.3.1 Hardware Requirements
To use the Net2Phone MAX 4, you will need
ŸA Net2Phone MAX 4 unit
ŸA corded or cordless analog telephone and from one to three ancillary phones
ŸA Local Area Network (LAN) with a broadband connection which may not have proxy server
caching
ŸA PC or Mac workstation with any recent Web browser, connected to the LAN (for initial
setup and administration)
ŸA Net2Phone account number and PIN
1.3.2 Additional Requirements
To configure and manage the unit, you will need:
ŸAn IP address, netmask, and gateway address for the MAX 4 (if your LAN uses static
addresses).
ŸA Net2Phone account number and PIN (available from your reseller).
ŸA PC or Mac workstation with any recent Web browser, connected to the LAN, for initial setup
and system management.
ŸOptional: a PBX, APBX, or KPS with an analog trunk card installed.
1.3.3 The Hardware Setup Procedure
1.3.3.1 The Hardware Installation Guide
A Hardware Installation Guide that describes hardware installation, cabling, and safety-related
issues was provided along with your MAX 4 unit. Please read that manual in its entirety before
beginning your hardware installation. Make sure you completely understand the issues
discussed and, in particular, the safety warnings given.
1.3.3.2 Steps in the Hardware Setup Procedure
The steps you will follow to set up your Net2Phone MAX 4 are:
1. Install the MAX 4 unit in its location and connect the cabling.
2. Configure the LAN settings on the MAX 4 so that it communicates with your LAN.

Page 4
3. Log in to the MAX 4 Web Manager.
4. Finish configuring your FXS ports via the Web Manager.
5. Test your installation by making an Internet telephone call.

Page 5
1.4 Installing the MAX 4 Unit
Install the unit in a well-ventilated area. If it is to be placed on a surface be sure that all four rubber feet
are in place to allow for proper air circulation. Do not place objects in excess of 20 pounds on top of the
unit.
Please refer to the Net2Phone MAX 4 Hardware Installation Guide and observe the safety
precautions listed.
Figure 1
Proceed with installation as follows:
1. Connect the analog telephones to the RJ-11 ports.
2. Connect the RJ-45 LAN port to a hub or switch.
3. If your installation includes a PBX, connect it as illustrated in Figure 1.
4. Plug the Net2Phone MAX 4 into your power outlet and turn the unit on.

Page 6
Your Net2Phone MAX 4 hardware setup is now complete. The next step is to connect the unit to your
LAN so that you can browse the MAX Web Manager.
2. Connecting Your Net2Phone MAX 4 to the LAN
Whether your LAN uses DHCP or static addresses, you can set the MAX 4’s LAN configuration in either
of two ways:
ŸVia a touch-tone keypad,or
ŸThrough the unit’s console (serial) port
Section 2 will explain how to set the MAX 4’s LAN configuration using either method.
2.1 Connecting the MAX 4 to a DHCP LAN
Section 2.1 explains how to connect your Web browser to the Net2Phone MAX 4 if your LAN uses
DHCP addressing. If your LAN uses static IP addresses, skip to Section 2.2, below.
The Net2Phone MAX 4’s default configuration is for DHCP (Dynamic Host Configuration Protocol).
Therefore, if your LAN is using DHCP, the Net2Phone MAX 4’s IP address parameters were configured
automatically when you connected it to the LAN. In this case, you only need to know the IP address that
was assigned to the unit by the LAN before you can browse the MAX Web Manager, MAX 4’s Web-
based configuration system. If your LAN is using DHCP, configuring the Net2Phone MAX 4 will entail
the following steps:
1. Obtain the MAX 4’s current IP address.
2. Log in to the MAX Web Manager.
3. Set the required configuration parameters in the MAX Web Manager.
2.1.1 Obtaining the Net2Phone MAX 4™s DHCP IP Address via a Telephone Keypad
For many users, the handiest way to query the MAX 4’s current IP address will be from a telephone
keypad. To use this procedure you will need a standard analog corded or cordless touch-tone
telephone.
1. Get a pencil and paper to write down the IP address.
2. Connect your telephone to any FXS (RJ-11) port on the Net2Phone MAX 4.
3. Pick up the telephone handset and dial ***1. The voice prompt responds, ”Your address is…”
and the IP address is announced.
4. 4. Write down the address and hang up the telephone. If you need to hear the address again,
hang up the telephone, then repeat step 3.

Page 7
You are now ready to finish setting up the Net2Phone MAX 4 using the MAX Web Manager.
Proceed to Section 3, Logging in to the MAX Web Manager.
2.1.2 Connecting to the MAX 4 through a Serial Cable
Although the serial connection allows you to set many of the Net2Phone MAX 4’s parameters, this
section will only explain how to connect to the MAX and obtain its DHCP IP address. The remaining
configuration tasks can then be completed more easily via the MAX Web Manager.
2.1.2.1 Using HyperTerminal
For this procedure you will need a standard serial cable (D-sub 9-pin, male-to-female, straight-
through connection) as shown in Figure 2, and a PC or Mac running the HyperTerminal terminal-
emulator program (or an equivalent), which is included in Microsoft operating systems. It is usually
found in the Programs menu, under Accessories.
Figure 2
1. With the power to the Net2Phone MAX 4 turned OFF, connect the cable from the unit’s
serial or console port to one of the PC’s serial ports. Note which of the PC’s serial ports you
are using.
2. Launch HyperTerminal and set up a new connection.
3. In the dialog box, specify the appropriate serial port, and set the serial communication
parameters as follows:
Baud rate 19200
Parity None
Character size 8
Stop Bit 1
Flow Control None
4. Turn on power to the Net2Phone MAX 4 then press the Enter Key on your PC. The boot
messages are displayed, followed by the command prompt MAX:>.

Page 8
NOTE: MAX is the default system-name with which the unit is shipped. You can replace this
name with a name that you select, such as “MY_MAX:>”. To change the system name, see
Section 4.5 in this Guide, System Information and Commands, or Section 2.5 in the
Net2Phone MAX 4 Command Reference Guide.
5. Press the Enter key. The Login: prompt is displayed.
6. Three default user IDs are provided:
ŸRoot
ŸManager
Ÿsysadm
Type one of these user IDs at the Login: prompt, followed by the Enter key. For example,
type root, followed by the Enter key. The Password: prompt appears.
7. At the Password: prompt, type the default password, n2p, followed by the Enter key.
The command line prompt MAX:> appears. You are now logged in.
NOTES:
ŸNet2Phone MAX 4 allows three and only three management user names.
ŸYou can change any user’s password, but you cannot delete or create additional
users.
ŸUser names and passwords are CASE SENSITIVE.
2.1.2.2 Obtaining the MAX’s DHCP IP address via HyperTerminal
If your LAN uses static addresses, refer to Section 2.3 in this Guide, Entering Static IP Addresses
via HyperTerminal.
1. Make a serial connection from your computer to the MAX 4 (refer to Section 2.1.1, above.)
2. After logging in to the MAX 4, type “/config/ip” at the command prompt. The active
directory changes to “/config/ip”and the prompt becomes MAX:/config/ip>.
3. Type “c” followed by the Enter key. The current IP parameters are listed on the screen.
4. Scroll up with the ↑key, if necessary, to see the parameter listing.
You are now ready to finish setting up the Net2Phone MAX 4 using the MAX Web
Manager. Proceed to Section 3, Logging in to the MAX Web Manager.

Page 9
2.2 Connecting to a LAN with Static IP Addresses
This section explains how to connect your Web browser to the Net2Phone MAX 4 if your LAN uses
static IP addresses, using either a telephone keypad or serial connection. The process will entail the
following steps:
1. Disable DHCP in the MAX 4.
2. Enter a static IP address.
3. Enter a net mask address.
4. Reset the MAX 4.
5. Log in to the MAX Web Manager.
6. Set the required configuration parameters in the MAX Web Manager.
2.2.1 Entering static IP address parameters from a telephone keypad
If your LAN uses static IP addresses, the most practical way to set up the MAX 4 is to enter an IP
address and a net mask address from a telephone keypad. You can then finish setting up the unit
while browsing the MAX Web Manager.
2.2.1.1 Disabling DHCP in the Net2Phone MAX 4
Since the Net2Phone MAX 4 is shipped with DHCP enabled, you need to disable DHCP to use
static IP addresses. To disable DHCP, proceed as follows:
1. Connect an analog telephone to any RJ-11 port on the MAX 4.
2. Lift the handset and dial ***5 (the disable DHCP parameter code). The voice prompt
announces, “DHCP is disabled now. Please press pound”.
3. Press the pound key (#) (Important!).
4. Hang up the telephone.

Page 10
2.2.1.2 Entering an IP address from a telephone keypad
Ask your LAN administrator for the IP address that will be assigned, the LAN’s net mask address,
domain name, and any other IP parameters that can be provided.
To enter the IP address:
1. Lift the telephone handset and dial ***2 (the IP address parameter code). The voice prompt
responds, “Please enter your IP address.”
2. Dial the numbers for the IP address you wish to enter on the telephone keypad. Use the
star key (*) to replace the periods in the address and end with the pound key (#).
For example, if you want to enter the IP address “192.168.172.19”, you would enter
192*168*172*19# from your telephone keypad.
The voice prompt responds, “Your address is…“ and repeats the address you entered.
3. If the new address is correct, simply hang up the telephone. If the new address is incorrect,
hang up the telephone and repeat from step 1, above.
4. Reset the Net2Phone MAX 4 to activate the changes. To do this, power-off the unit, wait 10
seconds, and turn it on again. DHCP is now disabled.
You are now ready to finish setting up the Net2Phone MAX 4 using the MAX Web Manager.
Proceed to Section 3, Logging In to the MAX Web Manager.
2.2.1.3 Entering a netmask address from a telephone keypad
To enter a netmask address:
1. Lift the handset and dial ***3 (the netmask parameter code). The voice prompt responds,
“Please enter your netmask.”
2. Proceed as in step 2, above, entering the desired netmask address from the telephone
keypad.
The voice prompt responds, “Your address is…“ and repeats the address you entered.
3. Proceed as in step 3, above.
4. Reset the Net2Phone MAX 4 as directed in Step 4 in Section 2.2.1.2, above.
The new net mask address is now in effect.
If you are using static IP addresses, you are now ready to finish setting up the Net2Phone MAX 4
using the MAX Web Manager. Proceed to Section 3, Logging in to the MAX Web Manager.
2.2.1.4 2.2.1.4 Re-enabling DHCP from a telephone keypad
If you need to re-enable DHCP in the Net2Phone MAX 4, proceed as follows:

Page 11
1. Lift the handset and dial ***4 (the enable DHCP parameter code). The voice prompt
announces, “DHCP is enabled now. Please press pound.”
2. Press the pound key (#).
3. Reset the Net2Phone MAX 4 as directed in Step 4 in Section 2.2.1.2, above.
DHCP is now enabled.
The telephone keypad configuration parameter codes are as follows:
Read IP address ***1 DHCP disable ***5
Assign static IP address ***2 DHCP enable ***4
Assign netmask ***3
2.2.2 Entering Static IP Addresses via HyperTerminal
Although many of the Net2Phone MAX 4’s IP parameters can be set manually through the serial
connection, if desired, this section will only show you how to set the IP address and netmask
parameters. The procedure is as follows.
2.2.2.1 Turning DHCP Off (or On) from HyperTerminal
The MAX’s default DHCP setting is DCHP enabled. Before you can enter a static IP address, you
must first disable DHCP. (The same procedure is used to re-enable it, if necessary.)
1. Follow the procedures in Section 2.1.2.1 and 2.1.2.2, above, to start your HyperTerminal
connection. Logging into the MAX 4.
2. After logging in from the root directory, type “/config/ip“followed by Enter key to move
to the /config/ip directory.
3. From the MAX:/config/ip> prompt, type “dhcp disable“followed by Enter key to
change DHCP setting.
4. Type “/config“followed by Enter key to move to /config directory.
5. Type “save“followed by Enter key to save your new DHCP mode.
6. Type “/sys/reset“.
7. At the confirmation line, type “y“followed by Enter to proceed.
8. After rebooting the MAX 4, DHCP function is Off

Page 12
2.2.2.2 Entering an IP Address
In step 3 of Section 2.1.2.2, the menu illustrated in Figure 3appears:
Figure 3
To connect to the MAX Web Manager, you will need to enter at least an IP address and netmask.
To enter the MAX’s IP parameters from this menu:
1. At the Enter <parameter>: prompt, enter 1 to change the IP Address. The Enter IP
Address prompt appears (Figure 4).
2. At the Enter IP Address: prompt, enter the IP address you wish to assign, followed by
Enter key.
The MAX confirms your entry. The confirmation scrolls by quickly, so you need to scroll up to see it.
Figure 4
3. Repeat the process from step 1, above, entering 2to change the Netmask.

Page 13
4. When you finish making changes, reset the Net2Phone MAX 4 to activate the changes.
You may either:
lType /system/reset at the command line, or
lPower -off the unit, wait 10 seconds, and turn it on again.

Page 14
5. (Optional) Ping the MAX from a PC, as illustrated below, using the new IP address, to
confirm that the correct parameters have been entered and stored successfully.
Figure 5
The new IP address and netmask are now in effect. If you are using static IP addresses, you are
now ready to finish setting up the Net2Phone MAX 4 using the MAX Web Manager. Proceed to
Section 3, Logging In to the MAX Web Manager.

Page 15
3. Logging in to the MAX Web Manager
Before you can log in to the MAX Web Manager, you need to know its current IP address. Refer to the
procedures in Section 2 to obtain its IP address via a telephone keypad or serial connection.
Reminder:
ŸIf you want to query the unit from a telephone keypad, see section 2.1.1, Obtaining the MAX 4’s
DHCP IP Address via a Telephone Keypad.
ŸIf you want to query the unit through a serial cable, see section 2.1.2, Connecting to the MAX 4
through a Serial Cable.
Once you know the Net2Phone MAX 4’s IP address, you are ready to log in to the unit through a Web
browser as follows:
1. Open a new browser window and enter the Net2Phone MAX 4’s IP address in the address box.
The MAX Web Manager Door page appears.
Figure 6

Page 16
2. When the Introduction page is displayed, click the “enter - Open the door” area.
The Network Password dialog box appears.
Figure 7
3. Enter your user name and password.
NOTE: The default user name is root and the default password is n2p.
