Netafim ICU User manual

Netafim USA CMT
NETAFIM ICU - INTERNET
CELLULAR MODEM
•Real Port Installation
•ICU Connections

2
NETAFIM ICU CELLULAR MODEM
The Netafim ICU Cellular Modem
Model Number 00107-004960 includes:
• Cellular Modem
• Two Indoor Antennas
• Power Supply
• CD with Instructions and PC software
Important:
The ICU Modem is ready to use.
It is pre-configured by Netafim USA and includes a Verizon Cellular
Data Plan with Static IP Address.
The account will to be transferred to the customer within 30 days of
plan activation.
For additional information contact your Netafim USA Dealer.

3
NETAFIM ICU CELLULAR MODEM
Additional Items - Order Separately:
• External antenna for Cellular Modem
Model Number 00107-004970
•6 ft. Cable with 9DB female 9 pin plug for NMC
Controllers - direct communication
Model Number00107-011205
• NMC Pro Communication Radio Card RS232
Model Number 74340-009110
• NMC Junior Communication RS232 Card
Model Number 74340-006600

4
The Real Port is a PC software that creates a Virtual Com Port on
your PC.
The IP Address of the ICU will be assigned to this Virtual Com Port.
The Cellular Modem connected to your NMC Controller will select
one of the Com Port numbers not in use and this will be the Virtual
Com Port.
The Virtual Com will be selected on the NMC Net PC software for
communication with your remote controller.
Note: To communicate with your remote NMC Controller, the PC
needs to have Internet service.
REAL PORT SOFTWARE INSTALLATION

5
32 Bytes
64 Bytes
1. Insert the Netafim CD and open the Real Port File
2. If your PC has 32 Bytes run the Setup32.exe file and if
your PC has 64 Bytes run the Setup64.exe file
REAL PORT SOFTWARE INSTALLATION

6
REAL PORT SOFTWARE INSTALLATION
On Set-up Screen select
“Add a New Device”
Click “Next”

7
Select “IP”
Type in Static IP that is on the ICU modem
white label
Select a Comm Port that is not in use (this
port will show up in NMC Net)
All other information on this screen is
allocated by default and should not need
any input
Click “Finish”
Com 2
Com 2
COMPUTER PORT SET-UP

8
This step is only used to verify that the
Real Port is set up correctly. Skip this or
use to troubleshoot.
On the PC find the “Device
Manager” and Click the
Hardware Tab
Click the “Device Manager”
CHECKING COM PORT PC ALLOCATION

9
Expand “Multi-port Serial Adapters”
Right Click on “Standard Real Port” Select “Properties”
Click on “Advanced”
Open Device Manager on the PC
Connections will show the Real Port status.
“Connected” means that the Real Port is communicating
with the Netafim ICU Cellular Modem.
This step is only used to verify that the Com Port is
set up correctly. Skip this or use to troubleshoot.
CHECKING COM PORT PC ALLOCATION

10
Connections between the ICU Cellular Modem and the NMC Controllers
ICU Modem
1. Connect the antennas to the
modem. When the external
antenna is required, it
needs to be connected on
the Primary Cellular.
2. Connect the Netafim Direct
Plug to the modem
3. Connect the power supply
to the modem and twist ¼
turn clockwise. The green
LED power will light.
4. After a few seconds the
signal strength LED will light
NETAFIM ICU CELLULAR MODEM
