NetComm NCT480 User manual

User Guide
NCT480
IP DSLAM

NCT480 IP DSLAM User Guide YML856 Rev3
2 www.netcomm.com.au
Safety and Precaution
Installation
• Use only the type of power source indicated on the marking labels.
• Use only power adapter supplied with the product.
• Do not overload wall outlet or extension cords as this may increase the risk of electric shock or fire. If the power cord is frayed, replace it with a new one.
• Proper ventilation is necessary to prevent the product overheating. Do not block or cover the slots and openings on the device, which are intended for
ventilation and proper operation. It is recommended to mount the product with a stack.
• Do not place the product near any source of heat or expose it to direct sunlight.
• Do not expose the product to moisture. Never spill any liquid on the product.
• Do not attempt to connect with any computer accessory or electronic product without instructions from qualified service personnel. This may result in
risk of electronic shock or fire.
• Do not place this product on unstable stand or table.
When in Use
• Power off and unplug this product from the wall outlet when it is not in use or before cleaning. Pay attention to the temperature of the power adapter.
The temperature might be high.
• After powering off the product, power on the product at least 15 seconds later.
• Do not block the ventilating openings of this product.
• When the product is expected to be not in use for a period of time, unplug the power cord of the product to prevent it from the damage of storm or
sudden increases in rating.
Service
Do not attempt to disassemble or open covers of this unit by yourself. Nor should you attempt to service the product yourself, which may void the user’s authority to
operate it. Contact qualified service personnel under the following conditions:
• If the power cord or plug is damaged or frayed.
• If liquid has been spilled into the product.
• If the product has been exposed to rain or water.
• If the product does not operate normally when the operating instructions are followed.
• If the product has been dropped or the cabinet has been damaged.
• If the product exhibits a distinct change in performance.
Caution
• Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment.
Copyright Notice
* 2005 All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any
purpose, without the express written permission of the seller.
Disclaimer
Information in this document is subject to change without notice. The statements, configurations, technical data, and recommendations in this
document are believed to be accurate and reliable, but are presented without express or implied warranty. The seller therefore assumes no
responsibility and shall have no liability of any kind arising from the supply or use of this document or the material contained herein.
Statement of Conditions
In the interest of improving internal design, operational function, and/or reliability, the seller reserves the right to make changes to the products
described in this document without notice.
The seller does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
In addition, the program and information contained herein are licensed only pursuant to a license agreement that contains restrictions on use and
disclosure (that may incorporate by reference certain limitations and notices imposed by third parties).
Trademarks
All other product or service names mentioned in this document may be trademarks of the companies with which they are associated.

YML856 Rev3 NCT480 IP DSLAM User GuideNCT480 IP DSLAM User Guide
www.netcomm.com.au 3
Contents
System Installation Guide.............................................................................................................................4
Web Management Operation Guide ............................................................................................................34
System Configuration Guide .......................................................................................................................90
Appendix A – Abbreviations and Acronyms ..............................................................................................155
Appendix B – System Connector Pin-Outs................................................................................................157
RJ-21 xDSL Connector Port Mapping ....................................................................................................157
Standard Telco Color Chart....................................................................................................................159
RJ-45 Management Ethernet Connector Pin-Outs ..................................................................................160
Local Console Connector Pin-Outs.........................................................................................................161
Appendix C – Legal and Regulatory Information ......................................................................................162

NCT480 IP DSLAM User Guide YML856 Rev3
4 www.netcomm.com.au
System Installation Guide
Chapter 1 – Preface......................................................................................................................................1
Purpose...................................................................................................................................................1
Organization.............................................................................................................................................1
Conventions.............................................................................................................................................1
Chapter 2 – Product Overview......................................................................................................................3
Introduction to the NCT480.......................................................................................................................3
Features............................................................................................................................................4
Field Applications...............................................................................................................................5
Service Applications...........................................................................................................................6
NCT480 System Overview.........................................................................................................................8
Front View .........................................................................................................................................8
Rear View........................................................................................................................................10
Side View ........................................................................................................................................10
Alarm I/O Module.............................................................................................................................10
System Management..............................................................................................................................10
Chapter 3 – Preparing for Installation ........................................................................................................13
Safety Requirements...............................................................................................................................13
Safety Guidelines .............................................................................................................................13
Preventing Electrostatic Discharge Damage.......................................................................................16
General Maintenance Guidelines.......................................................................................................16
Site Requirements ..................................................................................................................................17
Environmental Requirements ............................................................................................................17
Power .............................................................................................................................................18
Cabling ...........................................................................................................................................19
Rack Mounting ................................................................................................................................19
Tools and Equipment Required ................................................................................................................20
Unpacking the NCT480 System...............................................................................................................20
Verifying Contents ..................................................................................................................................21
Inspecting for Damage............................................................................................................................21
Chapter 4 – Installing the NCT480..............................................................................................................23
Installation Checklist ..................................................................................................................................23
NCT480 System Installation Procedures ....................................................................................................23
Measure Rack Space..............................................................................................................................23
Install the NCT480 Box Chassis...............................................................................................................24
Connecting a Console.............................................................................................................................24
Connecting the RJ-21 Subscriber Line Interface.......................................................................................25
Connecting the RJ-45 Network Uplink Interface........................................................................................27
Attach and Apply Power..........................................................................................................................28
Attach the Earth Ground..........................................................................................................................29
Chapter 5 – System Specifications.............................................................................................................30
Hardware Specification ...........................................................................................................................30
Software Specification ............................................................................................................................32

YML856 Rev3 NCT480 IP DSLAM User GuideNCT480 IP DSLAM User Guide
www.netcomm.com.au 5
CHAPTER 1 PREFACE
This preface discusses the following topic:
• Purpose
• Organization
• Conventions
Purpose
The purpose of this guide is to provide detailed information and description of NCT480 IP-DSLAM, which
includes both software and hardware architecture and other specific features.
Organization
This guide contains the following information:
• Preface
• Product Overview
• Preparing for Installation
• Installing the NCT480
• Appendix
Conventions
This section describes the conventions used in this guide.
Text in this style indicates a NOTICE. A note contains helpful suggestions or reference relay on the topical subjects.
Text in this style indicates a TIP. Performing the information described in the paragraph will help you solve a problem. The tip information
might not be troubleshooting or even an action, but could be useful information.
Text in this style indicates a CAUTION. In this situation, you might do something that could result in equipment damage or loss of data.
Text in this style indicates a DANGER. You are in situation that could cause bodily injury. Before you work on any equipment, you must
be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents.
NE/NEs mentions in this document mean NCT480 IP-DSLAM.

NCT480 IP DSLAM User Guide YML856 Rev3
6 www.netcomm.com.au
CHAPTER 2 PRODUCT OVERVIEW
This chapter provides an overview of the NCT480 IP-DSALM (Digital Subscriber line Access Multiplexer) and
the service application overview. This chapter contains the following sections:
• Introduction to the NCT480
• NCT480 System Overview
• System Management
Introduction to the NCT480
NCT480 mini IP-DSLAM is a revolutionary product with capabilities to interface directly with evolving IP
network in a cost effective manner. The Gigabit Ethernet Network uplink interfaces on the NCT480 IP-DSLAM
can directly connect to an Internet router or LAN Switch.
The NCT480 comes in compact size (1 U high) and can be used as desktop unit or can be mounted on the rack.
It can be fitted on rack with 19 inches in width and 23 inches in depth through the optional rack mount-kit.
The NCT480 is an advanced IP based DSLAM that can be used by service providers to offer broadband multi-
service features on the last mile access network on copper based local loop, it offers ADSL, ADSL2, and ADSL2+
interfaces and delivers advanced IP services that include QoS, multicast, subscriber management. These service
features prevent clogging and congestion of the bandwidth available to the users allowing smooth, easy and
efficient passage of video, voice and data packets across the networks, which also enables operators to increase
their revenues and maximize their profits manifold.
The feature rich design make NCT480 the most economical and suitable solution for next generation
broadband access platforms. It provides among other advantages easy maintenance and easy installation,
which in turn reduces operating cost and network down time to the service providers.
The NCT480 has 48 ADSL Subscriber ports and Network uplink interfaces consists of 2 pairs of Gigabit
Ethernet and mini-BGIC. Using various uplink settings, it is possible to stack the NCT480 units and aggregate
multiple units over a common network connection.
NCT480 mini IP DSLAM has a web interface for system management. Remote administration, remote
firmware upgrade, system configuration, fault and performance management, system diagnostics and
subscriber loop tests can all be performed be the web management interface of the NCT480 IP DSLAM.
Please refer to the Web Management Operation Guide in this user manual for further information.

YML856 Rev3 NCT480 IP DSLAM User GuideNCT480 IP DSLAM User Guide
www.netcomm.com.au 7
Features
NCT480 mini IP-DSLAM is designed to meet with industry standards in functionality, performance, and
reliability. As a compact IP-DSLAM platform, NCT480 can provide ADSL service for 48 users over existing
PSTN telephone wiring. More detailed features are listed below:
Hardware Features:
• Pizza box type supports 48 ADSL ports and build-in POTS splitter equipped available
• Cost effective access solution for always on high-speed Internet service application
• Existing twisted pair telephone line via POTS splitter/Low-Pass-Filter, it means ADSL and telephone
services can be provided concurrently
• Support service capacity expansion via units stacking
• Two pair of 10/100/1000 Ethernet and mini-GBIC uplink Network uplink interfaces
• One RS-232 serial console port
• One 10/100 Base T Ethernet management port
• Support non-blocking switching fabric and Wire-speed switching capability
• Alarm input IO interfaces
Software Features:
• Local system configuration and management through RS-232 console or the Ethernet management port
• Remote system configuration and management using Telnet or web management through GE network
uplink interfaces
• Embedded SNMP v1, v2c management agent with standard MIB-II
• Support TFTP firmware upgrade
• Support HTTP firmware upgrade
• Support Subscriber traffic isolation among ADSL line ports
• Support RFC 2684 bridge mode IPoE multi-protocol over AAL5
• Support RFC 2516 PPPoE packet forwarding
• Support QoS for IEEE 802.1p priority queues
• Support Subscriber rate limiting
• Support ADSL Line Profile and VLAN batch configuration
• Support IEEE 802.1Q VLAN tagging
• Support IEEE 802.1ad VLAN stacking and VLAN translation
• Manually configurable mapping between VLAN tag and ATM PVC
• Support IEEE 802.1D spanning tree bridging between Network uplink interface and any ADSL Subscriber
interface
• Support IGMP snooping and Multicast
• Support OAM F5 fault diagnostic
• Support MAC address access control
• Support IP/MAC packet filtering
• Support IEEE 802.3ad link aggregation on Network uplink interface through CLI

NCT480 IP DSLAM User Guide YML856 Rev3
8 www.netcomm.com.au
Field Applications
This section contains the most popular application scenarios for NCT480 IP-DSLAM, and helps operator to
understand how to implement and service with it.
Internet Service
With the ADSL CPE connecting to NCT480, IP traffic will be managed and monitored to ensure the connection
quality.
NCT480 min-IP DSLAM has ability to transport traffic with a variety of protocols from ADSL CPE or end user
PC to service applications such as PPPoE, PPPoA, IPoA, EoA and L2TP, L2F, PPTP, IP-Sec tunneling.
NCT480 IP-DSLAM
Figure 2-1 Internet Service Illustrate
Virtual Private Network Service
NCT480 can be beneficial for ISP (Internet Service Provider) who is offering VPN (Virtual Private Network)
service to corporations. NCT480 can be set up to provide value-add services to residential customers and
small-to-medium business by tunneling protocols to upper layer broadband router.
NCT480 IP-DSLAM
Figure 2-2 Virtual Private Network Service Illustrate

YML856 Rev3 NCT480 IP DSLAM User GuideNCT480 IP DSLAM User Guide
www.netcomm.com.au 9
Service Applications
This section describes various usages of NCT480 mini IP-DSLAM.
Uplink Aggregation
The NCT480 supports Network uplink aggregation complied in IEEE 802.3ad standard, this allow operator to
configure both of NCT480 GE uplink interfaces in a single logical interface to extending the bandwidth transmission.
NCT480 IP-DSLAM
Figure 2-3 NCT480 Link Aggregation Illustrate
Stacking Application
The NCT480 supports stacking in maximum of 4 units together via GE uplink interface, all units will share a
single source.
NCT480 IP-DSLAM with
GE Stacking
Figure 2-4 NCT480 Stacking Illustrate

NCT480 IP DSLAM User Guide YML856 Rev3
10 www.netcomm.com.au
Service Provider Demarcation
The NCT480 has ability to separate the traffics where it belongs by assigning different VLAN ID, the GE uplink
of NCT480 could be operated as individual interface of another.
NCT480 IP-DSLAM
Figure 2-5 NCT480 Service Provider Demarcation Illustrate

YML856 Rev3 NCT480 IP DSLAM User GuideNCT480 IP DSLAM User Guide
www.netcomm.com.au 11
NCT480 System Overview
NCT480 Series mini IP-DSLAM is built in 1.96 inch (1 U) high, 10.2 inch (26 cm) deep, and 17.7 inch wide
(23 inch bracket available) compact design. Pluggable build-in splitter is optional.
Front View
The Figure 2-6 shows the front panel of the NCT480 mini IP-DSLAM.
Figure 2-6 NCT480 Front Panel
The Table 2-1 shows the LED status of the NCT480 Series mini IP-DSLAM.
The Table 2-2 shows the front panel connector description of the NCT480 mini IP-DSLAM.
LED State Function
Power LED
PWD Green solid System power normal
Off System fault
Error LED
Error/Debug Green Solid Boot fault or system operate in debug mode
Off System running normal
DSL Status LED (port 1 ~ port 48)
1 ~ 48 Green solid per port The ADSL link is currently connect
Green blinking Handshaking
Off Link down or port disable
GE 1 / GE 2
Orange LED Orange blinking Interface port is activate
Off Interface port is inactivate
Green LED Green solid Interface port is link
Off No cable connected, port disabled, or port
fault
Table 2-1 NCT480 Front Panel LED Status

NCT480 IP DSLAM User Guide YML856 Rev3
12 www.netcomm.com.au
Connector Descriptions
GE1/GE2 10/100/1000 Ethernet interface or mini-GBIC optical interface.
M-Eth Management Ethernet interface to provide out-band management.
Console RJ-45 serial interface to provide command line environment.
Alarm I/O Provide external or internal operation alarm.
Line – J1 The 1 ~ 24 ADSL port connect to subscriber line
Line – J2 The 25 ~ 48 ADSL port connect to subscriber line
POTS – J1 The 1 ~ 24 voice port connect to PSTN
POTS – J2 The 25 ~ 48 voice port connect to PSTN
Table 2-2 NCT480 Front Panel Connector

YML856 Rev3 NCT480 IP DSLAM User GuideNCT480 IP DSLAM User Guide
www.netcomm.com.au 13
Rear View
The Figure 2-7 shows the rear panel of the NCT480 mini IP-DSLAM.
Figure 2-7 NCT480 Rear View
The equipment has provision for a permanently connected Protective Earthing Conductor.
Side View
The Figure 2-8 shows the Left-hand Side view of the NCT480 mini IP-DSLAM.
Figure 2-8 Left-hand Side View
The Figure 2-9 shows the Right-hand Side view of the NCT480 mini IP-DSLAM.
Figure 2-9 Right-hand Side View
Alarm I/O Module
The Alarm I/O Module contains alarm I/O relay.
Digital I/O Pin Description
Output Pin (for alarm output receptacle)
CO Common pin
NO Circuit with normal open pin
NC Circuit with normal close pin
Input Pin (for alarm input relay)
1 (+), 2 (-) First pair of input signal terminal
3 (+), 4 (-) Second pair of input signal terminal
5 (+), 6 (-) Third pair of input signal terminal
7 (+), 8 (-) Fourth pair of input signal terminal
Table 2-3 NCT480 Alarm I/O Relay Pin Description for Hardware revision 7 face panel

NCT480 IP DSLAM User Guide YML856 Rev3
14 www.netcomm.com.au
System Management
Operator can provision and manage the NCT480 IP-DSALM through the following system management mode:
CLI – Command line management
LCT – A complete SNMP basis NMS (Element Management System) provides GUI operation under Client-
Server architecture through in-band or out-band IP interface. (This SNMP IP DSLAM management utility is
only applicable to NCT480 firmware R1.43 or older)
Web Management Interface – NCT480 mini IP DSLAM has a web interface for system management. Remote
administration, remote firmware upgrade, system configuration, fault and performance management, system
diagnostics and subscriber loop tests can all be performed be the web management interface of the NCT480
IP DSLAM. Web management is only applicable to NCT480 running firmware R2.0 or later. Web management
of NCT480 IP DSLAM is only compatible under Internet Explorer 6.0 environment.
Changes will be subjected to firmware revision in the future)
Local Management
The NCT480 provide Ethernet interface for CLI connection at local maintenance and operation. An RJ-45 to
DB-9 can be used to connect NCT480 to PC via serial port. The NCT480 can also be locally managed by its
inbuilt web interface through management port Eth-3 with factory default IP address of 192.168.1.1/24.
IP Network Management
The NCT480 provides out-band management thought management Ethernet interface or its GE interface with
proper IP address to associate in the layer 3 network.

YML856 Rev3 NCT480 IP DSLAM User GuideNCT480 IP DSLAM User Guide
www.netcomm.com.au 15
CHAPTER 3 PREPARING FOR INSTALLATION
This chapter tells you how to prepare for the installation of the NCT480 mini IP-DSLAM.
The chapter contains the following sections:
• Safety Requirements
• Site Requirements
• Tools and Equipment Required
• Unpacking the NCT480 System
• Verify Contents
• Inspecting for Damage
Safety Requirements
This section describes safety requirement of NCT480 system. Before you install the NCT480 system, ensure
that all the criteria in this section are met. The section describes the following safety requirements:
• Safety Guidelines
• Preventing Electrostatics Discharge Damage
• General Maintenance Guidelines

NCT480 IP DSLAM User Guide YML856 Rev3
16 www.netcomm.com.au
Safety Guidelines
Before working on the equipment, be aware of standard safety guidelines and the hazards that are involved
in working it electrical circuitry to prevent accidents. Adhere to the following cautions and warnings and those
throughout the guide for safe and hazard-free installation.
Only trained and qualified personnel should be allowed to install or replace this equipment.
Before removing the equipment, disconnect the telephone-network cables to avoid contact with telephone-network voltages.
Do not work on system or connect or disconnect cables during periods of lightning activity.
Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from
lightning.
Read the power instructions before you connect the system to its power source.
For safety reason, the ground wire must connect to safety (earth) ground at supply side of the AC wiring; ensure that the host is
connected to earth ground during the normal use.
To reduce the risk of electric shock when servicing any individual unit, disconnect the power cord or cords that connect the unit to the
AC power strip or DC bus bar.
Two people are required to lift the box. Grasp the box underneath the lower edge and lift with both hands. To prevent injury, keep your
back straight and lift with your legs, not your back.
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system
remains stable. The following guidelines are provided to ensure your safety:
• When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the heaviest component at the
bottom of the rack
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the unit in the rack
Ethernet cable must be shielded when used in a central office environment.
This unit is intended for installation in restricted access areas, A restricted access area is where access can only be gained by service
personnel through the use of a special tool, lock and key, or other means of security, and is controlled by the authority responsible for
the location.
To reduce the risk of fire, use only No. 36 AWG or larger telecommunication line cord.
Use copper conductors only.
Never touch un-insulated telephone wires or terminals unless the telephone line has been disconnected at the network interface.
Use caution when installing or modifying telephone lines.
Before working on equipment that is connected to power lines, remove jewelry (including rings, necklaces, and watches). Metal objects
will heat up when connected to power and ground and can cause serious burns or weld the metal object to the terminals.
To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telephone-network voltage (TNV) circuits. LAN ports
contain SELV circuits and WAN ports contain TNV circuits. Some LAN and WAN ports both use RJ-45 connectors. Use caution when
connecting cables.
Ultimate disposal of this product should be handled according to all national laws and regulations.
Do not use this product near water; for example, near bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a
swimming pool.
Do not use this product near water; for example, near bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a
swimming pool.
Never install telephone RJ-21 connector in wet locations unless the connector is specifically designed for wet locations.
Do not use a telephone to report a gas leak in the vicinity of the leak.

YML856 Rev3 NCT480 IP DSLAM User GuideNCT480 IP DSLAM User Guide
www.netcomm.com.au 17
Preventing Electrostatic Discharge Damage
Electrostatic discharge (ESD) is a transfer of electrostatic charge between bodies of different electrostatic
potentials, such as an operator and a piece of electrical equipment. It occurs when electronic components are
improperly handled, and it can damage equipment and impair electrical circuitry. Electrostatic discharge is
more likely to occur with the combination of synthetic fibers and dry atmosphere.
Use an antistatic strap during removing and replacing NCT480 units.
Always use an ESD ankle or wrist strap and ensure that it makes good skin contact.
To properly guard against ESD damage and shocks, the wrist strap and cord must operate effectively.
Do not touch any exposed contact pins or connector shells of interface ports that do not have a cable attached. If cables are connected
at one end only, do not touch the exposed pins at the unconnected end of the cable.
This equipment is intended for use in residential and commercial environments only.
Periodically check the resistance value of the antistatic strap, which should be between 1 and 10 megohms (Mohms).
General Maintenance Guidelines
The following maintenance guidelines apply to NCT480 system units:
Keep the NCT480 box area clear and dust-free during and after installation.
If you remove the chassis cover for any reason, store it in a safe place.
Do not perform any action that creates a hazard to people or makes equipment unsafe.
Keep walk areas clear to prevent falls or damage to equipment.

NCT480 IP DSLAM User Guide YML856 Rev3
18 www.netcomm.com.au
Site Requirements
This section describes requirements for the site in which the NCT480 system is to be installed. Before you install
the NCT480 system, ensure that all the criteria in this section are met. The section describes the following:
• Environmental Requirements
• Power
• Cabling
• Rack Mounting
Environmental Requirements
To have proper operation of the NCT480 system depends on a proper environment. This section describes
environmental requirements for the site in which you intend to install the NCT480 system.
Temperature Humidity and Altitude
The system can tolerate a wide range of temperatures. Table 3-1 shows the recommendation for temperature,
humidity, and altitude conditions in a central office (CO) environment.
Environmental Specifications Descriptions
Temperature 0º to 45ºC – Operating
-15º to 70ºC – Storage
Humidity 5 to 95% (non condensing)
Altitude 0 to 10,000 ft (0 to 3048 m)
Table 3-1 CO Operating Environment Requirements
To prevent the system from overheating, do not operate it in an area that exceeds the maximum recommended ambient
temperature of 45ºC.

YML856 Rev3 NCT480 IP DSLAM User GuideNCT480 IP DSLAM User Guide
www.netcomm.com.au 19
Ventilation
The NCT480 fans maintain a suitable operating temperature for the internal circuitry. Ensure that the air
intake vents at the left side of the box and the air exhaust vents on the right side of the box are not obstructed
in anyway.
Figure 3-1 NCT480 Ventilation Control Diagram
Field Description
Fan unit 4
Air flow 7 (CFM)
Air pressure 3 (mmH20)
Speed per fan 6000 (RPM)
Noise level 26 (dBA)
Table 3-2 System Air-Flow Specification
Space
The NCT480 system fits in either a 19-inch (48.26 cm) wide rack or a 23-inch (58.42 cm) wide rack.
The NCT480 is 1.96 inches (1U) in height and 10.2 inches (26 cm) in depth. Depending on your configuration
type, plan accordingly so that the CO rack accommodates your needs.
Power
The NCT480 mini IP-DSLAM using built-in power converter unit, the built-in power converter unit is required a
VDC power source for it needs. The voltage is from -36 VDC to -60 VDC with power consumption of 85W.
Before you connect the system to a power source, verify that the power source is properly grounded and that
it falls within the internal power supply rating.

NCT480 IP DSLAM User Guide YML856 Rev3
20 www.netcomm.com.au
Cabling
For detailed information on the required cables, refer to “Appendix System Connector Pin-Outs”.
NCT480 Cabling
The Figure 2-2 illustrates the NCT480 system cabling.
Figure 3-2 NCT480 Cabling Diagram
Rack Mounting
Mount your NCT480 system in a rack is highly recommend. Ensure that vertical rivet spacing on the rack rails
meets standard EIA-310-C or ETS300 requirements.
NCT480 fits into a 19 inch wide rack or an ETSI 600 mm wide (23 inch) cabinet by replacing the ear bracket.
Figure 3-3 NCT480 Mounting Diagram.
