NetComm NP3024 User manual

NetComm16or24portGigabitSwitch YML711Rev1
2www.netcomm.com.au
Contents
Chapter1:Introduction............................................................................................................................................. 4
GigabitEthernetTechnology ............................................................................................................... 4
SwitchingTechnology ......................................................................................................................... 5
VLAN (Virtual LocalArea Network) .................................................................................................. 6
Features .............................................................................................................................................. 7
Package Contents ................................................................................................................................ 8
Chapter 2: Installation .............................................................................................................................................. 9
RackMounting .................................................................................................................................... 9
Connecting Network Cable ............................................................................................................... 10
AC Power ......................................................................................................................................... 10
Chapter3: Identifying ExternalComponents ...........................................................................................................11
FrontPanel .........................................................................................................................................11
Rear Panel ......................................................................................................................................... 12
UnderstandingLED Indicators .......................................................................................................... 13
Power and System LEDs ...........................................................................................................13
Ports 1~16 or 1~24 Status LEDs ............................................................................................... 13
Chapter 4: Installing theWeb Management Utility ................................................................................................. 15
Discovery List .................................................................................................................................. 16
MonitorList ...................................................................................................................................... 17
Device Setting................................................................................................................................... 19
Toolbar ............................................................................................................................................. 21
File TAB .................................................................................................................................... 21
ViewTAB .................................................................................................................................. 21
OptionTAB ............................................................................................................................... 21
HelpTAB .................................................................................................................................. 21
Chapter5: Configuring the Switch ......................................................................................................................... 22
Login ................................................................................................................................................. 22
MainMenu........................................................................................................................................ 24
Setup Menu................................................................................................................................ 25
PortSettings.......................................................................................................................... 25
VLAN Settings (Virtual LocalArea Network) ...................................................................... 26
Trunk Setting ........................................................................................................................ 27
MirrorSetting ....................................................................................................................... 28
MaintenanceMenu..................................................................................................................... 28
Device Status ....................................................................................................................... 28
Statistic ................................................................................................................................. 29
SystemSetting ...................................................................................................................... 30
Trap Setting .......................................................................................................................... 31
Set Password ........................................................................................................................ 32
BackupSetting...................................................................................................................... 33
Reset Setting ......................................................................................................................... 33
Logout ........................................................................................................................................ 34

YML711Rev1 NetComm16or24portGigabitSwitch
www.netcomm.com.au 3
AppendixA: Technical Specifications .................................................................................................................. 35
General ............................................................................................................................................. 35
Performance ...................................................................................................................................... 36
Appendix B: Cable Connections ........................................................................................................................... 37
RJ-45 Ethernet Network ports........................................................................................................... 37
1000BASE-Tstraight through cable .......................................................................................... 38
1000BASE-T crossover cable ................................................................................................... 39
Appendix C: Registering your NetComm Product ................................................................................................ 40
ContactInformation .......................................................................................................................... 40
Trade marks and Notices .................................................................................................................. 40
Legal& RegulatoryInformation CopyrightInformation .................................................................... 41
CustomerInformation ................................................................................................................ 41
Warranty .................................................................................................................................... 42
Conditions and exclusions: ........................................................................................................ 43

NetComm16or24portGigabitSwitch YML711Rev1
4www.netcomm.com.au
Chapter 1: Introduction
Congratulations on your purchase of the NetComm 10/100/1000Mbps Gigabit Ethernet Web Smart
Switch, available in either 16-Port or 24-Port models. This device integrates 1000Mbps Gigabit
Ethernet, 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities in a highly flexible
package.
In this guide, the term “Switch” (first letter upper case) refers to your 16 or 24 Port 10/100/
1000Mbps Gigabit Ethernet Web Smart Switch, and “switch” (first letter lower case) refers to other
Ethernet switches.
This chapter describes the features of your new Switch and some background information about
Ethernet/Fast Ethernet/Gigabit Ethernet switching technology.
Gigabit Ethernet Technology
Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing the same packet structure, format,
and support for CSMA/CD protocol, full duplex, flow control, and management objects, but with a
tenfold increase in theoretical throughput over 100-Mbps Fast Ethernet and a hundredfold increase
over 10-Mbps Ethernet. Since it is compatible with all 10-Mbps and 100-Mbps Ethernet environ-
ments, Gigabit Ethernet provides a straightforward upgrade without wasting a company’s existing
investment in hardware, software and trained personnel.
The increased speed and extra bandwidth offered by Gigabit Ethernet is essential for coping with
network bottlenecks that frequently develop as computers and get faster and more applications
generate more traffic. Upgrading key components, such as your backbone and servers to Gigabit
Ethernet can greatly improve network response times as well as significantly speed up the traffic
between your subnets.
Gigabit Ethernet enables fast ethernet connections to support video conferencing, complex imaging,
and similar data-intensive applications. Likewise, since data transfers occur 10 times faster than Fast
Ethernet, servers outfitted with Gigabit Ethernet NIC’s are able to perform 10 times the number of
operations in the same amount of time.
In addition, the phenomenal bandwidth delivered by Gigabit Ethernet is the most cost-effective
method to take advantage of today’s and tomorrow’s rapidly improving switching and routing
internetworking technologies.

YML711Rev1 NetComm16or24portGigabitSwitch
www.netcomm.com.au 5
Switching Technology
Another approach to pushing beyond the limits of standard Ethernet technology is the development
of switching technology. Aswitch bridges Ethernet packets at the MAC address level of the Ethernet
protocol transmitting among connected Ethernet or Fast Ethernet LAN segments.
Switching is a cost-effective way of increasing the total network capacity available to users on a local
area network. Aswitch increases capacity and decreases network loading by dividing a local area
network into different segments, which don’t compete with each other for network transmission
capacity.
The switch acts as a high-speed selective bridge between the individual segments. The switch,
without interfering with any other segments, automatically forwards traffic that needs to go from one
segment to another. By doing this the total network capacity is multiplied, while still maintaining the
same network cabling and adapter cards.
Switching LAN technology is a marked improvement over the previous generation of network
bridges, which were characterized by higher latencies. Routers have also been used to segment local
area networks, but the cost of a router, the setup and maintenance required make routers relatively
impractical. Today switches are an ideal solution to most kinds of local area network congestion
problems.

NetComm16or24portGigabitSwitch YML711Rev1
6www.netcomm.com.au
VLAN (Virtual Local Area Network)
AVLAN is a group of end-stations that are not constrained by their physical location and can
communicate as if a common broadcast domain, a LAN. The primary reason for using a VLAN is to
reduce latency and the need for routers. Other VLAN benefits include:
Security Security is increased with the reduction of opportunity in
eavesdropping on a broadcast network, because data will
only be switched to those confidential users within the
VLAN.
Cost Reduction VLANs can be used to create multiple broadcast
domains, thus eliminating the need of expensive routers.
Port-based (or port-group) Port-based is the common method of implementing a
VLAN, and is the one supplied in the Switch.

YML711Rev1 NetComm16or24portGigabitSwitch
www.netcomm.com.au 7
Features
■Depending on your model, either 16 or 24×10/100/1000MbpsAuto-negotiation Gigabit Ethernet
ports
■All RJ45 ports support auto MDI/MDIX, so there is no need to use cross-over cables or an up-
link port
■Full/half duplex transfer mode for 10/100Mbps port
■Full duplex transfer mode for Gigabit port
■Wire speed reception and transmission
■Store-and-Forward switching scheme capability to support rate adaptation and ensure data
integrity
■Up to 4K unicast addresses entities per device, self-learning, and table aging
■272KBytes packet buffer
■Supports IEEE 802.3x flow control for full-duplex mode ports
■Supports port-base VLAN
■Supports port-base QoS
■Supports Trunking
■Supports Port-mirroring
■Supports Port-setting for Speed/Disable, Flow control
■Easy configuration via WEB Browser
■Easy setting via Web Management Utility
■Standard 19” Rack-mount size

NetComm16or24portGigabitSwitch YML711Rev1
8www.netcomm.com.au
Package Contents
Open the shipping cartons of the Switch and carefully unpacks its contents. The carton should
contain the following items:
■One 10/100/1000Mbps Gigabit
Ethernet Web Smart Switch
(available in either 16-Port or 24-
Port models)
■One AC power cord
■Four rubber feet (for desktop usage)
■CD-Rom with Web Management Utility
■User’s Guide and Package Contents Note
If any of the above items are missing or damaged, please contact your local reseller for replacement.
■Screws and two mounting brackets
(for rack mounting usage)

YML711Rev1 NetComm16or24portGigabitSwitch
www.netcomm.com.au 9
Chapter 2: Installation
The location where you install the switch stack may greatly affect its performance, therefore we
suggest you consider the following before you install your switch:
■Install the Switch in a fairly cool and dry place. See Technical Specifications for the acceptable
temperature and humidity operating ranges.
■Install the Switch in a site free from strong electromagnetic field generators (such as motors),
vibration, dust, and direct exposure to sunlight.
■Leave at least 10cm of space at the front and rear of the hub for ventilation.
■Install the Switch on a sturdy, level surface that can support its weight, or in an EIA standard-size
equipment rack. For information on rack installation, see the next section, Rack Mounting.
■When installing the Switch on a level surface, attach the rubber feet to the bottom of each device.
The rubber feet cushion the switch and protect the switch case from scratching.
Rack Mounting
The switch can be mounted in an EIA standard-size, 19-inch rack, which can be placed in a wiring
closet with other equipment. Attach the mounting brackets to the switch’s front panel (one on each
side), and secure them with the screws provided.
Figure 1. Combine the Switch with the provided screws
Then, use screws provided with the equipment rack to mount each switch in the rack.

NetComm16or24portGigabitSwitch YML711Rev1
10 www.netcomm.com.au
Figure 2. Mount the Switch in the rack
Connecting Network Cable
The Switch supports 1000Mbps Gigabit Ethernet that runs in Auto-negotiation mode, 10Mbps
Ethernet or 100Mbps Fast Ethernet that runs both in half and full duplex mode, and 1000Mbps
Gigabit Ethernet that runs in full duplex mode using four pair of Category 5 Cable.
☞Important Note:
Some Category 5 cables are only prepared with two pairs (4 wires) of
interconnection wires which are not suitable for Gigabit Ethernet over
Category 5 cables.
In order to use the full performance of this switch in Gigabit mode, please
ensure that your cabling uses four pairs (8 wires). The switch’s RJ-45 ports
are Auto-MDI and will auto negotiate between 10Mbps, 100Mbps and
1000Mbps depending on the type of cable and connection. The Switch can
auto transform to MDI-II or MDI-X, so there is no need to use cross-over
cables or an up-link port.
AC Power
The Switch usesAC power 240VAC, 50 Hz. The power switch is located at the rear of the unit
adjacent to the AC power connector and the system fan. The Switch may be turned on without
having any or all LAN segment cables connected.

YML711Rev1 NetComm16or24portGigabitSwitch
www.netcomm.com.au 11
Chapter 3: Identifying External Components
This chapter describes the front panel, rear panel, and LED indicators of the Switch.
Front Panel
The figure below shows the front panels of the 16-Port Switch and the 24-Port Switch.
Front panel of 16-port Gigabit Ethernet Switch
Front panel of 24-port Gigabit Ethernet Switch
LED Indicator: Comprehensive LED indicators display the status of the
switch and the network (see the following LED Indica-
tors section).
Gigabit Ethernet Ports (1~16 or 1~24): Depending on which model you have purchased, the
Switch has 16 or 24 Gigabit twisted pair ports, supported
auto negotiable 10/100/1000Mbps and auto MDI/MDIX
crossover detection function. This supplies true “plug
and play” capability. These ports operate in half-duplex
mode for 10/100Mbps and full- duplex mode for 10/100/
1000Mbps.
Note: When the port is set to “Forced Mode”, the Auto MDI/MDIX feature will be
disabled.

NetComm16or24portGigabitSwitch YML711Rev1
12 www.netcomm.com.au
Rear Panel
Figure 4. Rear panel of the Switch
Power Switch: The Power Switch controls the power to the unit and can
be turned on after the power cable is connected.
AC Power Connector: This is a three-pronged connector that supports the
power cord. Plug in the female connector of the provided
power cord into this connector, and the male into a
power outlet. Supported input voltages range from 240V
AC at 50Hz.
Reset: The Reset button will restore the unit to its factory
defaults.
Note: Be sure that you record your Switch’s settings before pressing the Reset
button, as any changes to the default will be lost.

YML711Rev1 NetComm16or24portGigabitSwitch
www.netcomm.com.au 13
Understanding LED Indicators
The front panel LEDs provides instant status feedback, and assists with monitoring and trouble-
shooting the Switch when necessary.
Figure 5. LED indicators of the Switch
Power and System LEDs
POWER : Power Indicator
On : When the Power LED is on, the Switch is receiving
power.
Off : When the Power LED is off, the Switch is not receiving
power.
SYSTEM : Management Indicator
Blinking : When the CPU is working, the System LED will blink.
On/Off : When the CPU is not working, the System LED will be
off.
Ports1~16 or 1~24StatusLEDs
Link/ACT : Link/Activity
On : When the Link/ACT LED is on, the respective port is
successfully connected to an Ethernet network.
Blinking : When the Link/ACT LED is blinking, the port is
transmitting or receiving data on the Ethernet network.
Off : When the Link/ACT LED is off, there is no link.

NetComm16or24portGigabitSwitch YML711Rev1
14 www.netcomm.com.au
1000Mbps
On : When the 1000Mbps LED is on, the respective port is
connected to a 1000Mbps Gigabit Ethernet network.
Off : When the 1000Mbps LED if off, the respective port is
connected to a 10Mbps Ethernet or 100Mbps Fast
Ethernet network
100Mbps
On : When the 100Mbps LED is on, the respective port is
connected to a 100Mbps Fast Ethernet network.
Off : When the 100Mbps LED is off, the respective port is
connected to a 10Mbps Ethernet or 1000Mbps Gigabit
Ethernet network.

YML711Rev1 NetComm16or24portGigabitSwitch
www.netcomm.com.au 15
Chapter 4: Installing the Web Management Utility
Refer to the following instructions to install the Web Management Utility and set up your Switch.
1. Insert the provided NetComm CD in the CD-ROM Drive.
2. From the Start menu on the Windows desktop, choose Run.
3. In the Run dialog box, type D:\Web Management Utility\setup.exe (where D:\ is the letter of
your CD-ROM drive) and click OK.
4. Follow the on-screen instructions to install the utility.
5. Upon completion, go to Program Files -> web_management_utility and execute the Web
Management utility. (Figure 6.)
Figure 6. Web Management Utility
The Web Management Utility is divided into four areas: Discovery List, Monitor List, Device Setting
and Toolbar function. Refer to the following sections for details on each area.

NetComm16or24portGigabitSwitch YML711Rev1
16 www.netcomm.com.au
Discovery List
The Discover List displays the devices available for Web management in the connected network.
By pressing the “Discovery” button, you can list all the Web Management devices in the discovery
list.
Highlight a device and press the “Add to monitor list” button, or double-click on the device listing,
to select a device in the Discovery List for monitoring in the Monitor List.
The following fields are included in the Discovery List:
MAC Address : Shows the device MAC Address.
IP Address : Shows the current IP address of the device.
Protocol version: Shows the version of the Utility protocol.
Product Name : Shows the device product name.
System Name : Shows the appointed device system name.
Location : Shows where the device is located.
Trap IP : Shows the IP where the Trap is to be sent.
Subnet Mask : Shows the Subnet Mask set of the device.
Gateway : Shows the Gateway set of the device.

YML711Rev1 NetComm16or24portGigabitSwitch
www.netcomm.com.au 17
Monitor List
All the Web Smart Device in the Monitor List can be monitored; you can also receive the trap and
show the status of the device.
The following fields are included in the Monitor List:
Symbol : An “S” indicates a system device that is currently being
monitored.
An “X” indicates a device that is not currently connected.
IP Address : Shows the current IP address of the device.
MAC Address : Shows the device MAC Address.
Protocol version: Shows the version of the Utility protocol.
Product Name : Shows the device product name.
System Name : Shows the appointed device system name.
Location : Shows where the device is located.
Trap IP : Shows the IP where the Trap is to be sent.
Subnet Mask : Shows the Subnet Mask set of the device.
Gateway : Shows the Gateway set of the device.
ViewTrap : The Trap function can receive the events that happen
from the Web Management Switch in the Monitor List.
There is an indicator icon beside the “View Trap” button. When the indicator icon is green, there is
no trap being transmitted. When the indicator icon is red, there is a new trap being transmitted,
which can be viewed by clicking on the button. (Figure 7)
Figure 7. View trap
When the “View Trap” button is clicked, a Trap Information window will be displayed. This
window shows the trap information including the Symbol, Time, Device IP and the Event that
occured. (Figure 8)

NetComm16or24portGigabitSwitch YML711Rev1
18 www.netcomm.com.au
The symbol represents a new trap signal record, and will disappear after you review and
click on the event record.
Figure 8. Trap Information
Note: In order to receive Trap information, the Switch has to be configured with
Trap IP and Trap Events in the Web browser. Refer to the Trap Setting
Menu for more information.
Add Item : To add a device to the Monitor List manually, enter the IP
Address of the device that you want to monitor.
Delete Item : To delete the device in the Monitor List.

YML711Rev1 NetComm16or24portGigabitSwitch
www.netcomm.com.au 19
Device Setting
The Device Setting panel allows you to control the configuration of your new Switch.
Configuration Setting: The Configuration Setting allows you to set the IP
Address, Subnet Mask, Gateway, Set Trap to (Trap IP
Address), System name and Location.
Select the device in the Discovery list or Monitor List and
the click on the Configuration Setting button. The
Configuration Setting window will be displayed (refer to
Figure 9). After completing the details, type a password
and press the “Set” button to apply the changes.
Figure9. Configuration Setting
Password Change: The password can be changed by clicking on the
“Password Change” button. Enter the original password
and the new password and confirm it. Click on the “Set”
button to apply the change.
Figure 10. Password Change

NetComm16or24portGigabitSwitch YML711Rev1
20 www.netcomm.com.au
Firmware Upgrade: To upgrade your Switch’s firmware, click on the
“Firmware Upgrade” button and enter the firmware path.
Do not turn your device off during the firmware upgrade
process.
Figure 11. Firmware Upgrade
Web Access : Double click the device in the Monitor List or select a
device in the Monitor List and press the “Web Access”
button to access the device in your Web browser.
