NETGEAR EX6150 AC1200 User manual

Quick Start
AC1200 WiFi Range Extender
Model EX6150

2
Getting Started
The NETGEAR WiFi Range Extender increases the distance of a WiFi
network by boosting the existing WiFi signal and enhancing the overall
signal quality over long distances. An extender repeats the signals from an
existing WiFi router or access point.
WiFi Range
Extender
Boosts the range
of your existing
WiFi and creates
a stronger signal
in hard-to-reach
areas
Existing WiFi
Sometimes your
router does not
provide the WiFi
coverage you need

3
Meet Your Extender
Before you install your extender, familiarize yourself with its LEDs,
buttons, and port.
Front Panel and Side Panel
Router Link LED Client Link LED
Power LED
WPS LED
Ethernet port
Access Point/Extender switch
Power On/O button
Factory Reset button
WPS button

4
LED Descriptions
LED Description
Router Link
LED
This LED indicates the connection between the extender and
the router or access point.
• Solid green. Best connection.
• Solid amber. Good connection.
• Solid red. Poor connection.
• O. No connection.
Client Link LED This LED indicates the connection between the extender and
your client device, such as a computer or WiFi device.
• Solid green. Best connection.
• Solid amber. Good connection.
• Solid red. Poor connection.
• O. No connection.
Power LED • Solid amber. The extender is booting.
• Solid green. The extender is powered on.
• O. The extender is powered o.
WPS LED • Solid green. WiFi security is enabled (WPA or WPA2).
• Blinking green. A WPS connection is in progress.
• O. WiFi security is not enabled.

5
Use the Extender in Extender Mode
In extender mode, the extender repeats the signals from an existing WiFi
router or access point.
Set the Access Point/Extender switch, place the extender, apply power,
and connect it to your WiFi network.
Set the Access Point/Extender Switch
To use the extender in extender mode, set the Access Point/Extender
switch to Extender .
Place the Extender and Apply Power
1. Place your extender in the same room as your WiFi router.
Proximity to the WiFi router is required only during the initial setup
process.
2. Plug the extender into an electrical outlet.
Wait for the Power LED to light green. This might take up to 60
seconds. If the Power LED does not light, press the Power On/Off
button on the side of the extender.

6
Connect to an Existing WiFi Network
To extend the range of your WiFi network, you must connect the extender
to your existing WiFi network. You can do this in one of two ways:
• Connect with WPS. For more information, see Connect with WPS on
page 6.
• Connect with web browser setup. For more information, see
Connect with Web Browser Setup on page 9.
Connect with WPS
Wi-Fi Protected Setup (WPS) lets you join a secure WiFi network without
typing the network name and password.
Note: WPS does not support WEP network security. If you are using WEP
security, follow the instructions in Connect with Web Browser Setup on
page 9.
1. Press the WPS button on the extender.
The WPS LED blinks.
2. Within two minutes, press the WPS button on your router or access
point.
The WPS LED on the extender lights solid green, the Router Link LED
lights, and the extender connects to your existing WiFi network.

7
If the Router Link LED does not light, try again. If it still does not light,
see Connect with Web Browser Setup on page 9.
3. If your WiFi router supports the 5 GHz band, repeat Steps 1 and 2 to
connect the extender to the 5 GHz band.
4. Unplug the extender and move it to a new location that is about
halfway between your router and the area with a poor router WiFi
signal.
The location that you choose must be within the range of your
existing WiFi router network.
5. Plug the extender into an electrical outlet and wait for the
Power LED to light green.
6. Use the Router Link LED to help you choose a spot where the
extender-to-router connection is optimal.
7. If the Router Link LED doesn’t light amber or green, plug the extender
into an outlet closer to the router and try again.
Keep moving the extender to outlets closer to the router until the
Router Link LED lights amber or green.

8
8. On your client device, such as a computer or WiFi device, find and
connect to a new extender WiFi network.
The extender creates two new extender WiFi networks. The
extender’s new WiFi network names are based on your existing WiFi
network name, with _2GEXT and _5GEXT at the end of the name.
For example:
• Existing WiFi network name. MyNetworkName
• New extender WiFi network names. MyNetworkName_2GEXT
and MyNetworkName_5GEXT
Use the same WiFi password that you use for your WiFi router.
9. Test the new extender WiFi network’s WiFi range by moving your
client device to the area with a poor router WiFi signal:
a. Leave your client device in the area with a poor router WiFi signal
and return to the extender.
b. Check the Client Link LED on the extender:
• If the Client Link LED is solid green or amber, your new
extender WiFi network reaches the area with a poor router
WiFi signal and your network setup is complete.
Router Extender Computer

9
• If the Client Link LED is red, your new extender WiFi network
does not reach the area with a poor router WiFi signal.
You must move your client device closer to the extender until
the Client Link LED turns solid green or amber.
Connect with Web Browser Setup
1. Use a WiFi network manager on your client device, such as a computer
or WiFi device, to find and connect to the NETGEAR_EXT (SSID) WiFi
network.
After the connection with your client device is established, the Client
Link LED lights.
2. Launch a web browser.
3. Enter www.mywifiext.net in the address field of the browser.
The New Extender Setup page displays.
4. Click the NEW EXTENDER SETUP button.
The Create Account page displays.
5. Complete the fields on the Create Account page and click the NEXT
button.
6. Click the WIFI RANGE EXTENDER button.
The extender scans for WiFi networks in your area and displays a list.

10
7. Select a WiFi network to extend and click the NEXT button.
If you do not want to extend both WiFi bands, clear the 2.4GHz WiFi
Networks or the 5GHz WiFi Networks checkbox.
8. In the Password (network key) field, type the existing WiFi network
password (also called passphrase or security key) and click the NEXT
button.
9. Set the network name (SSID) and password for your extender and
click the NEXT button.
Wait for the page to display a list of new extender WiFi networks,
which might take up to one minute.
10. Connect your client device to the new extender WiFi network using
the extender SSID and password that you created in Step 9.
11. Make sure that your client device is successfully connected before you
click the Continue button.
12. Click the Continue button.
A message displays confirming that the extender is connected to the
new extender WiFi network.
13. Click the Next button.
The registration page displays.
14. Complete the registration fields and click the Finish button to
complete the setup.

11
If you do not want to register your extender, click the Skip
Registration link. Note that you must register your extender before
you can use NETGEAR telephone support.
The Status page displays.
15. Unplug the extender and move it to a new location about halfway
between your router and the area with a poor WiFi signal.
The location that you choose must be within the range of your
existing WiFi router network.
16. Plug the extender into an electrical outlet and wait for the
Power LED to light green.
17. Use the Router Link LED to help you choose a spot where the
extender-to-router connection is optimal.
18. If the Router Link LED doesn’t light amber or green, plug the extender
into an outlet closer to the router and try again.
Keep moving the extender to outlets closer to the router until the
Router Link LED lights amber or green.
19. Reconnect your client device to a new extender WiFi network.
Router Extender Computer

12
20. Test the new extender WiFi network WiFi range by moving your client
device to the area with a poor router WiFi signal:
a. Leave your client device in the area with a poor router WiFi signal
and return to the extender.
b. Check the Client Link LED on the extender:
• If the Client Link LED is solid green or amber, your new
extender WiFi network reaches the area with a poor router
WiFi signal and your network setup is complete.
• If the Client Link LED is red, your new extender WiFi network
does not reach the area with a poor router WiFi signal.
You must move your client device closer to the extender until
the Client Link LED turns solid green or amber.
Connect an Ethernet-Enabled Device
After the extender is connected to your existing WiFi network, you can
connect a wired device to the extender using an Ethernet cable. That
device can then access your existing network through the WiFi connection.
Extender
Blu-ray player
Router

13
Use the Extender in Access Point Mode
You can use the extender as a WiFi access point, which creates a new WiFi
hotspot by using a wired Ethernet connection.
1. Set the Access Point/Extender switch to Access Point .
2. Plug the extender into an electrical outlet and wait for the Power LED
to light green.
If the Power LED does not light, press the Power On/O button.
3. Use an Ethernet cable to connect the Ethernet port on the extender
to a router Ethernet LAN port or a remote Ethernet LAN jack with LAN
access.
The extender joins the LAN and creates a WiFi hotspot.

14
4. Use a WiFi network manager on your client device to find and join a
WiFi extender network.
When the extender is in access point mode, you can join one of the
following WiFi extender networks:
• 2.4 GHz network. NETGEAR_EXT
• 5 GHz network. NETGEAR_5GEXT
When you join the network, the extender Client Link LED lights
to show that you are connected.
5. Launch a web browser and enter www.mywifiext.net in the address
field.
The New Extender Setup page displays.
6. Click the NEW EXTENDER SETUP button.
The Create Account page displays.
7. Complete the fields on the Create Account page and click the NEXT
button.
8. Click the ACCESS POINT button.
The extender checks for an Internet connection.
9. Click the HOME NETWORK or PUBLIC NETWORK button.
10. When prompted, set the network name (SSID), security option, and
password for each access point network and click the NEXT button.

15
Your settings are applied and the extender is ready to be used as an
access point.
11. Use a WiFi network manager on your client device to connect to the
new access point WiFi network.
12. Click the Continue button.
A screen displays that says you successfully created an access point.
13. Click the Next button.
The registration page displays.
14. Follow the onscreen instructions to register your extender.
Access Extender Settings
After installation, you can log in to the extender to view or change the
extender’s settings.
1. Use a WiFi network manager on your client device, such as a computer
or WiFi device, to find and connect to a new extender WiFi network.
After the connection with the client device is established, the Client
Link LED lights.
2. Launch a web browser.
3. Enter www.mywifiext.net in the address field of the browser.
A login page displays.

16
4. Type your email and password and click the LOG IN button.
The Status page displays.
5. Make any needed changes.
Frequently Asked Questions
You can find more information about your product in the user manual,
which is available at http://support.netgear.com.
The web browser setup guide keeps asking me for my network
password (passphrase) or security key, and I am sure I have entered
the correct password. What can I do?
The extender is probably placed at the borderline of the range covered by
the router or access point. For more information, see Place the Extender
and Apply Power on page 5. If you are using WEP security, make sure
that you are typing the network password in the correct field.
Can I set up the extender in extender mode if I connect it to the
router or access point with an Ethernet cable?
No. The extender is designed to connect wirelessly to the router or access
point if it is in extender mode. If the extender is in access point mode, you
can connect it to the router or access point with an Ethernet connection.
For more information about access point mode, see Use the Extender in
Access Point Mode on page 13.

17
I forgot my login email and password. What can I do?
On the login page, click the Username & Password Help link to answer
the security questions you set up during the initial setup.
If you forgot the answers to your security questions, do the following to
set up your login credentials again:
1. Restore the extender to its factory default settings.
2. Launch a web browser.
3. Enter www.mywifiext.net in the address field of the browser.
The New Extender Setup page displays.
4. Click the NEW EXTENDER SETUP button.
The Extender Setup page displays.
How do I restore the extender to its factory default settings?
1. Use a sharp object such as a pen or straightened paper clip to press
and hold the Factory Reset button on the extender for at least five
seconds until the Power LED blinks amber.
2. Release the Factory Reset button and wait for the extender to
reboot.
The extender resets and returns to the factory default settings.

18
I enabled a wireless MAC filter, wireless access control, or access
control list (ACL) on my router. What should I do when installing
the extender?
When a client device connects through the extender to your router, the
MAC address of the client device shown on the router is translated to
another MAC address. If your router’s MAC filter, wireless access control,
or ACL is enabled, the client device connects to the extender but cannot
get an IP address from the extender and cannot access the Internet.
To allow your client device to receive an IP address from the extender and
access the Internet, you must provide the translated MAC address to the
router.
1. Log in to your router and disable the MAC filter, wireless access
control, or ACL.
For more information about how to disable your router’s MAC filter,
wireless access control, or ACL, see your router’s documentation.
2. Power on the extender and connect all of your client devices to the
extender network.
3. Make sure that the Router Link LED remains lit.
4. Log in to your extender:
a. Launch a web browser and in the address field, enter
www.mywifiext.net.
A login page displays.

19
b. Type your email and password and click the LOG IN button.
The Status page displays.
5. Select Settings > Connected Devices.
The Connected Devices page displays the MAC addresses and virtual
MAC addresses for the extender, wired devices, and WiFi devices that
are connected to the extender.
6. On the router, add the extender’s virtual MAC addresses and all the
virtual MAC addresses of the devices connected to the extender to
your router’s MAC filter table.
7. Enable the router’s MAC filter, wireless access control, or ACL.
I am connected to NETGEAR_EXT and launched a browser. Why
can’t I see the web browser setup guide?
Try these troubleshooting steps:
• Make sure that your computer is set up to use DHCP (most are).
• Make sure that the Client Link LED is green and that you are using a
valid IP address.
• Relaunch the web browser and type www.mywifiext.net in the
address field. Type your email and password and click the LOG IN
button.

September 2015
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134, USA
Support
Thank you for purchasing this NETGEAR product. You can visit
www.netgear.com/support to register your product, get help, access the latest
downloads and user manuals, and join our community. We recommend that you use only
ocial NETGEAR support resources.
Trademarks
© NETGEAR, Inc., NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc.
Any non-NETGEAR trademarks are used for reference purposes only.
Compliance
For the current EU Declaration of Conformity, visit:
http://support.netgear.com/app/answers/detail/a_id/11621/.
For regulatory compliance information, visit:
http://www.netgear.com/about/regulatory/.
See the regulatory compliance document before connecting the power supply.
