NETGEAR AX764 User manual

Installation
The 10 Gigabit BASE-LR LITE SFP+ module transmits at 10 G bps over
single mode fiber (SMF) for up to 2 Km.
Install the Module
NETGEAR switches automatically detect the AXM764 module. The module
can be inserted or removed while the switch is powered on.
¾To install a module:
1. Insert the module into one of the available SFP+ module slots, pressing
firmly to seat the module.
2. Make sure that the module latch is in the closed position.
3. Connect a single-mode LC to LC duplex cable to the module.
Remove the Module
You do not need to power o the switch before removing the module.
¾To remove a module:
1. Disconnect any cables from the module.
2. Pull down on the module latch.
3. Pull the module out of the module slot.
Specifications
Specifications Description
Wavelength 1310nm
Dimensions (H x W x D) .47 in. x .57 in. x 2.22 in. (11.85 mm x
14.55 mm x 56.50 mm)
Weight 0.04 lb (20 g)
Operating temperature 23 –158ºF (-5 – 85ºC)
Storage temperature -40 – 185ºF (-40 –85ºC)
Operative relative humidity 85% at 25ºC
Operating Distance Up to 2Km on legacy 9/125μm single
mode fiber cables.
Connectors LC
Max. power consumption 1.1W
MTBF 2310,000 hours (264 years)
Safety Certification FDA/CDRH, IEC-60825
Compliance RoHS
ProSAFE 10 Gigabit BASE-LR LITE SFP+
Single Mode Module
AX764

February 2015
Netgear, Inc.
350 East Plumeria Drive
San Jose, CA 95134, USA
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered
trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries.
Information is subject to change without notice. © NETGEAR, Inc. All rights reserved.
Regulatory Compliance
Certificate of Manufacturer/Importer
It is hereby certified that the NETGEAR model AX742 has been
suppressed in accordance with the condition set out in MBPT-
Amtsb|Vfg 243/1991 and vfg 46/1992. The operation of some
equipment (for example, test transmitters) in accordance with
regulation may, however, be subject to certain restrictions. Please
refer to the note in the operating instructions. Federal Oce for
Telecommunications Approvals has been notified of the placing of
this equipment on the market and has been granted the right to
test the series for compliance with regulation.
This device has been tested and found to comply with limits for
a Class A digital device, pursuant to part 15 of FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a commercial installation.
Support
Thank you for selecting NETGEAR products.
Aer installing your device, locate the serial number on the label of your
product and use it to register your product at https://my.netgear.com.
You must register your product before you can use NETGEAR telephone
support. NETGEAR recommends registering your product through the NETGEAR
website. For product updates and web support, visit http://support.netgear.
com.
NETGEAR recommends that you use only the ocial NETGEAR support
resources.
For the current EU Declaration of Conformity, visit http://support.netgear.com/
app/answers/detail/a_id/11621/.
For regulatory compliance information, visit http://www.netgear.com/about/
regulatory/.
