NETGEAR ReadyNAS 2120 User manual

ReadyNAS OS 6 Rack-Mount
Hardware Manual
Model
ReadyNAS 2120
ReadyNAS 2120 v2
ReadyNAS 2304
ReadyNAS 3130
ReadyNAS 3138
ReadyNAS 3220
ReadyNAS 3312
ReadyNAS 4220
ReadyNAS 4312
ReadyNAS 4360
June 2017
202-11272-09
350 E. Plumeria Drive
San Jose, CA 95134
USA

Support
Thank you for purchasing this NETGEAR product.You can visit www.netgear.com/support to register your
product, get help, access the latest downloads and user manuals, and join our community.We recommend that
you use only official NETGEAR support resources.
Conformity
For the current EU Declaration of Conformity, visit http://kb.netgear.com/app/answers/detail/a_id/11621.
Compliance
For regulatory compliance information, visit http://www.netgear.com/about/regulatory.
See the regulatory compliance document before connecting the power supply.
Trademarks
©NETGEAR, Inc., NETGEAR, and the NETGEAR Logo are trademarks of NETGEAR, Inc.Any non-NETGEAR
trademarks are used for reference purposes only.
2
ReadyNAS OS 6

Contents
Chapter 1 Getting Started
Additional Documentation......................................................................................9
Setup Location.......................................................................................................9
Supported Operating Systems...............................................................................9
Supported Browsers............................................................................................10
Diskless Storage System.....................................................................................10
Chapter 2 ReadyNAS 2120 and 2120 v2
Front Panel...........................................................................................................12
Rear Panel...........................................................................................................13
Status Information................................................................................................13
Power On and Shut Down....................................................................................14
Power On.........................................................................................................14
Preferred Shutdown........................................................................................15
Forced Shutdown............................................................................................15
Power State.....................................................................................................15
Boot Menu............................................................................................................15
Rack Mounting.....................................................................................................17
Chapter 3 ReadyNAS 2304
Front Panel...........................................................................................................19
Rear Panel...........................................................................................................20
Status Information................................................................................................21
Power On and Shut Down....................................................................................22
Power On.........................................................................................................23
Preferred Shutdown........................................................................................23
Forced Shutdown............................................................................................23
Power State.....................................................................................................23
Boot Menu............................................................................................................24
Rack Mounting.....................................................................................................25
Chapter 4 ReadyNAS 3130
Front Panel...........................................................................................................27
Rear Panel...........................................................................................................28
Status Information................................................................................................29
Power On and Shut Down....................................................................................30
Power On.........................................................................................................30
Preferred Shutdown........................................................................................30
Forced Shutdown............................................................................................31
Power State.....................................................................................................31
Boot Menu............................................................................................................31
Rack Mounting.....................................................................................................33
3

Chapter 5 ReadyNAS 3138
Front Panel...........................................................................................................35
Rear Panelrear panel...........................................................................................36
Status Information................................................................................................37
Power On and Shut Down....................................................................................38
Power On.........................................................................................................38
Preferred Shutdown........................................................................................38
Forced Shutdown............................................................................................39
Power State.....................................................................................................39
Boot Menu............................................................................................................39
Rack Mounting.....................................................................................................41
Chapter 6 ReadyNAS 3220 and 4220
Front Panel...........................................................................................................43
ReadyNAS 3220 Rear Panel...............................................................................44
ReadyNAS 4220 Rear Panel...............................................................................45
Status Information................................................................................................45
Boot Menu............................................................................................................47
Rack-Mount Setup...............................................................................................49
Installation.......................................................................................................49
Chapter 7 ReadyNAS 3312 and 4312
Front Panel...........................................................................................................53
ReadyNAS 3312 Rear Panel...............................................................................54
ReadyNAS 4312X Rear Panel.............................................................................55
ReadyNAS 4312S Rear Panel.............................................................................56
Status Information Front Panel.............................................................................56
Status Information Rear Panel.............................................................................58
Boot Menu............................................................................................................60
Rack-Mount Setup...............................................................................................62
Installation.......................................................................................................62
Chapter 8 ReadyNAS 4360
Front Panel...........................................................................................................65
Rear Panel...........................................................................................................66
Boot Menu............................................................................................................67
Rack-Mount Setup...............................................................................................69
Installation.......................................................................................................69
Chapter 9 Disks
Disk Tray...............................................................................................................71
Supported Disks..................................................................................................72
Previously Formatted Disks.................................................................................72
Reformat Previously Formatted Disks.............................................................72
Migrate a Volume.............................................................................................73
Add a Disk............................................................................................................74
Add a 3.5-Inch Disk.........................................................................................74
4
ReadyNAS OS 6

Add a 2.5-Inch Disk.........................................................................................78
Replace a Disk.....................................................................................................81
Replace a 3.5-Inch Disk..................................................................................82
Replace a 2.5-Inch Disk..................................................................................85
Chapter 10 Maintenance
Access the Inside of the Storage System............................................................89
Access the Inside of the Storage System on a ReadyNAS 2120, 3130 or
3138................................................................................................................89
Access the Inside of the Storage System on a ReadyNAS 3220, 3312, 4220,
4312, or 4360..................................................................................................90
Replace a Fan......................................................................................................93
Replace a Fan on a ReadyNAS 2120, 3130 or 3138......................................94
Replace a Fan on a ReadyNAS 3220, 3312, 4220, or 4312...........................96
Replace a Fan on a ReadyNAS 4360.............................................................96
Replace the On-Board Battery.............................................................................97
Replace the On-Board Battery on a ReadyNAS 2120, 3130 or 3138.............98
Replace the On-Board Battery on a ReadyNAS 3220, 3312, 4220, 4312, or
4360................................................................................................................99
Appendix A Defaults andTechnical Specifications
Factory Default Settings.....................................................................................101
ReadyNAS 2120 and 2120 v2 Technical Specifications....................................101
General:.........................................................................................................101
Physical dimensions (h x w x d):...................................................................102
Physical weight:.............................................................................................102
Power consumption:......................................................................................102
Electrical:.......................................................................................................102
Environmental requirements:........................................................................102
Certifications:................................................................................................102
ReadyNAS 2304 Technical Specifications.........................................................103
General:.........................................................................................................103
Physical dimensions (h x w x d):...................................................................103
Physical weight:.............................................................................................103
Power consumption:......................................................................................103
Electrical:.......................................................................................................103
Environmental requirements:........................................................................103
Certifications:................................................................................................104
ReadyNAS 3130 Technical Specifications.........................................................104
General:.........................................................................................................104
Physical dimensions (h x w x d):...................................................................104
Physical weight:.............................................................................................104
Power consumption:......................................................................................104
Electrical:.......................................................................................................105
Environmental requirements:........................................................................105
Certifications:................................................................................................105
ReadyNAS 3138 Technical Specifications.........................................................105
General:.........................................................................................................105
5
ReadyNAS OS 6

Physical dimensions (h x w x d):...................................................................105
Physical weight:.............................................................................................105
Power consumption:......................................................................................106
Electrical:.......................................................................................................106
Environmental requirements:........................................................................106
Certifications:................................................................................................106
ReadyNAS 3220 Technical Specifications.........................................................106
General:.........................................................................................................106
Physical dimensions (h x w x d):...................................................................107
Physical weight:.............................................................................................107
Power consumption:......................................................................................107
Electrical:.......................................................................................................107
Environmental requirements:........................................................................107
Certifications:................................................................................................107
ReadyNAS 3312 Technical Specifications.........................................................107
General:.........................................................................................................107
Physical dimensions (h x w x d):...................................................................108
Physical weight:.............................................................................................108
Power consumption:......................................................................................108
Electrical:.......................................................................................................108
Environmental requirements:........................................................................108
Certifications:................................................................................................108
ReadyNAS 4220 Technical Specifications.........................................................108
General:.........................................................................................................109
Physical dimensions (h x w x d):...................................................................109
Physical weight:.............................................................................................109
Power consumption:......................................................................................109
Electrical:.......................................................................................................109
Environmental requirements:........................................................................109
Certifications:................................................................................................109
ReadyNAS 4312 Technical Specifications.........................................................110
General:.........................................................................................................110
Physical dimensions (h x w x d):...................................................................110
Physical weight:.............................................................................................110
Power consumption:......................................................................................110
Electrical:.......................................................................................................110
Environmental requirements:........................................................................110
Certifications:................................................................................................111
ReadyNAS 4360S and 4360X Technical Specifications....................................111
General:.........................................................................................................111
Physical dimensions (h x w x d):...................................................................111
Physical weight:.............................................................................................111
Power consumption:......................................................................................111
Electrical:.......................................................................................................112
Environmental requirements:........................................................................112
Certifications:................................................................................................112
Safety Warnings.................................................................................................112
Electrical Safety Precautions.............................................................................114
General Safety Precautions...............................................................................114
6
ReadyNAS OS 6

Electrostatic Discharge Precautions..................................................................115
Rack-Mount Precautions....................................................................................115
7
ReadyNAS OS 6

1
Getting Started
Congratulations on your purchase of a NETGEAR ReadyNAS®storage system.This manual describes the
physical features of the ReadyNAS OS 6 rack-mount storage system.
This chapter contains the following sections:
•Additional Documentation
•Setup Location
•Supported Operating Systems
•Supported Browsers
•Diskless Storage System
For more information about the topics that are covered in this manual, visit the support website
at http://support.netgear.com/product/ReadyNAS-OS6.
Note
8

Additional Documentation
For detailed information about configuring, managing, and using your ReadyNAS storage system, see the
ReadyNAS OS 6 Software Manual, which is available at http://support.netgear.com/product/ReadyNAS-OS6.
For additional product support information, visit http://support.netgear.com/product/ReadyNAS-OS6.
Setup Location
Your ReadyNAS storage system is intended for installation in a restricted access location (dedicated
equipment rooms, service closets, and the like) only.
Keep the following considerations in mind as you install your system:
•Ambient operating temperature. If the system is installed in a closed or multiunit rack assembly, the
ambient operating temperature of the rack environment might be greater than the ambient temperature
of the room.Therefore, consider installing the equipment in an environment compatible with the maximum
rated ambient temperature. See Defaults and Technical Specifications on page 100.
•Reduced airflow.Mount the equipment into a rack so that the amount of airflow required for safe
operation is not compromised.
•Mechanical loading.Mount the equipment into a rack so that a hazardous condition does not arise
due to uneven mechanical loading.
•Circuit overloading. Consider the equipment's connection to the power supply circuitry and the effect
that any possible overloading of circuits might create on overcurrent protection and power supply wiring.
Consider equipment nameplate ratings when addressing this concern.
•Reliable grounding.This product requires reliable grounding to be maintained at all times.To ensure
this, ground the rack itself. Pay particular attention to power supply connections other than the direct
connections to the branch circuit (for example, the use of power strips).
•Clearance. Leave enough clearance in front of the rack (about 25 inches) to enable you to open the
front door completely and in the back of the rack (about 30 inches) to allow for sufficient airflow and
ease in servicing.
Supported Operating Systems
The ReadyNAS storage system is supported on the following systems:
•Microsoft Windows 10 (32 and 64 bit)
•Microsoft Windows 8.1 (32 and 64 bit)
•Microsoft Windows 8 (32 and 64 bit)
•Microsoft Windows 7 (32 and 64 bit)
•Microsoft Server 2012 (64 bit)
•Microsoft Server 2008 R2 (64 bit)
•Apple OS X 10.7 or later
•Linux, UNIX, Solaris
Getting Started
9
ReadyNAS OS 6

•Apple iOS
•Google Android
Supported Browsers
The ReadyNAS local admin page supports the following browsers:
•Microsoft Edge
•Microsoft Internet Explorer 9.0 and later
•Apple Safari, 5.0 and later
•Google Chrome 20 and later
•Mozilla Firefox 14 and later
If you experience difficulty accessing the local admin page or if you notice unexpected behavior, try using
another browser.For more information about the ReadyNAS local admin page, see the ReadyNAS OS 6
Software Manual, which is available at http://support.netgear.com/product/ReadyNAS-OS6.
Diskless Storage System
If you purchased a ReadyNAS storage system without a preinstalled disk drive or drives, you must add at
least one disk to your system before you use the system.You can add a 3.5-inch hard disk drive, a 2.5-inch
hard disk drive, or a 2.5-inch solid-state drive to an empty disk bay. For information about how to install a
disk, see Add a Disk on page 74.
Use only supported SATA hard disk drives (HDDs) or solid-state drives (SSDs) in your ReadyNAS storage
system. If you use disks that are not supported, NETGEAR technical support will not provide assistance.
For a list of supported disks, see the NETGEAR Hardware Compatibility List at
http://www.netgear.com/readynas-hcl.
If you are adding a previously formatted disk to your storage system, see the instructions in Previously
Formatted Disks on page 72.
Getting Started
10
ReadyNAS OS 6

2
ReadyNAS 2120 and 2120 v2
This chapter describes the physical features of the ReadyNAS 2120 and the 2120 v2 storage systems.It includes
the following sections:
•Front Panel on page 12
•Rear Panel on page 13
•Status Information on page 13
•Power On and Shut Down on page 14
•Boot Menu on page 15
•Rack Mounting on page 17
11

Front Panel
The following figure shows the front panel of the ReadyNAS 2120 and 2120 v2 storage systems.
Figure 1. Front panel
1. Drive bays
2. Control panel
3. Mounting bracket
4. Fault LED
5. Disk Activity LED
6. Disk tray (For more information, see Disk Tray on page 71.)
The following figure shows the control panel in more detail.
Figure 2. Control panel
1. USB 2.0 port
2. Reset button
3. Error LED
4. LAN 1 and LAN 2 LEDs
5. Power LED
6. Power button
ReadyNAS 2120 and 2120 v2
12
ReadyNAS OS 6

Rear Panel
The following figure shows the rear panel of the ReadyNAS 2120 and the 2120 v2 storage systems.
Figure 3. Rear panel
1. Power cable socket
2. Power switch
3. System exhaust fans
4. eSATA ports
5. USB 3.0 ports
6. LAN ports with LED status indicators
Status Information
Youcan obtain information about thestatusof yourReadyNAS 2120or2120 v2 storagesystem by reviewing
the LEDs listed in the following table.
Table 1. Status information
DescriptionIndicator
The Disk Activity LEDs indicate these states:
•Solid blue.A disk is present.
•Blinking.The disk is active.
•Off. No disk is present.
Disk Activity LED (disk tray,
top)
The Fault LEDs indicate these states:
•Solid red.The disk was removed, failed, or is resynchronizing.
•Off. No disk is active.
Fault LED (disk tray, bottom)
ReadyNAS 2120 and 2120 v2
13
ReadyNAS OS 6

Table 1. Status information (Continued)
DescriptionIndicator
The Error LED indicates these states:
•Solid red.The system needs attention. Use the local admin page to determine
the problem.For more information, see the ReadyNAS OS 6.5 Software Manual,
which is available at http://support.netgear.com/product/ReadyNAS-OS6.
•Off.The system is healthy.
Error LED (front panel)
The LAN LEDs indicate these states:
•Solid blue.An Ethernet cable is connected.
•Blinking.The Ethernet link is active.
•Off.There is no Ethernet connection.
LAN 1 and LAN 2 LEDs
(front panel)
Two LED status indicators are built into each LAN port. One LED is green and one
is amber.They indicate port speed and activity as follows:
•Green on, amber off. 1000 Mbps connection speed, no activity.
•Green blinking, amber off. 1000 Mbps connection speed, activity.
•Green off, amber on. 10 Mbps or 100 Mbps connection speed, no activity.
•Green off, amber blinking. 10 Mbps or 100 Mbps connection speed, activity.
•Green off, amber off. No connection.
LAN port LEDs (rear panel)
The Power LED indicates these states:
•Solid green.The system is powered on.
•Blinking.The system is powering on or powering off.
•Off. Power is not supplied to the system.
Power LED (front panel)
Power On and Shut Down
This section describes how to power on and shut down your system.If you must shut down the system, use
one of the preferred shutdown methods whenever possible.
Power On
To power on the system:
1. Connect the system to a power supply.
2. Move the Power switch to the On position.
The Power switch is located on the back panel of the system.
ReadyNAS 2120 and 2120 v2
14
ReadyNAS OS 6

Depending on the system's last power state, the system might power on automatically.
For more information, see Power State on page 15.
Note
3. If necessary, press the Power button on the front panel of the system.
The system powers on.
Preferred Shutdown
You can gracefully shut down your system by using the Power button or the ReadyNAS local admin page.
For information about how to gracefully shut down your system using the ReadyNAS local admin page, see
the ReadyNAS OS 6.5 Software Manual, which is available at
http://support.netgear.com/product/ReadyNAS-OS6.
To gracefully shut down your system using the Power button:
1. Press the Power button on the front panel of the system.
The Power LED blinks, prompting you to confirm the shutdown.
2. Press the Power button again.
The system shuts down gracefully.
Forced Shutdown
Perform a forced shutdown only if the storage system is not responding.
To perform a forced shutdown:
•Flip the Power switch to the Off position.
The Power switch is located on the back panel of the system.
The system shuts down.
Power State
If the power supply is interrupted due to a power failure, the system returns to its last state once the power
supply is restored, as follows:
•If the system was powered on at the time of the power failure, the system powers on when the power
supply is restored.
•If the system was powered off at the time of the power failure, the system remains off when the power
supply is restored.
Boot Menu
Use the boot menu to restart or troubleshoot your ReadyNAS storage system.Your storage system provides
the following boot modes:
ReadyNAS 2120 and 2120 v2
15
ReadyNAS OS 6

•Normal. Initiates a normal boot process, just like booting using the Power button.
•Factory default.Initiates a short disk test that takes approximately 5 minutes. After the disk test, a
10-minute time-out period begins.During the 10-minute time-out period, you can choose to power off
the storage system without causing any data loss, and the factory default process is canceled.If you
choose not to power off the storage system, after the 10-minute time-out period, the factory default
process begins.
WARNING:
The factory default reboot process resets the storage system to factory
settings, erases all data, resets all defaults,and reformats the disk to X-RAID.
To start the factory default process immediately, press the Reset button during the
10-minute time-out period.
Note
•OS reinstall.Reinstalls the firmware from the internal flash to the disks.Use the OS reinstall boot mode
when the system crashes and corrupts some configuration files.OS reinstall boot mode also resets
some settings on your storage system, such as Internet protocol settings and the administrator password,
to defaults.
•Tech support. Boots into a low-level diagnostic mode.Use the tech support boot mode only when a
NETGEAR technical support representative instructs you to do so.
•Volume read only. Mounts a volume as read-only.Use this option when you are attempting to rescue
data off a disk during a disaster recovery.
•Memory test. Performs a memory test.The pass or fail result is reported using the storage system's
LEDs.Contact a NETGEAR technical support representative to interpret memory test results.
•Test disk. Performs an offline full disk test.This process can take four hours or more, depending on
the size of your disks.Any problems are reported in the system logs, which you can view using the local
admin page.For more information about viewing the system logs, see the ReadyNAS OS 6.5 Software
Manual.
To access the boot menu:
1. Power off your system.
2. Using a straightened paper clip, press and hold the Reset button.
3. Press the Power button on the front panel of the system.
The system powers on.
4. Continue to press the Reset button for about five seconds until the Power LED is solid green and the
Error LED, LAN 1 LED, and LAN 2 LED are blinking.
5. Press and release the Reset button to scroll through the boot mode menu.
Each press and release scrolls forward to the next item in the boot mode menu.
The storage system shows the boot mode options using the LEDs, as described in the following table:
ReadyNAS 2120 and 2120 v2
16
ReadyNAS OS 6

Status IndicatorBoot Mode
Power
LED
LAN 2
LED
LAN 1
LED
Error
LED
Description
Error LED and both LAN LEDs blink.Power
LED lights.
Boot menu
LAN 2 and Power LEDs light.Normal
LAN 1 and Power LEDs light.Factory default
Both LAN LEDs and the Power LED light.OS reinstall
Error and Power LEDs light.Tech support
Error, LAN 2, and Power LEDs light.Volume read only
Error, LAN 1, and Power LEDs light.Memory test
All four LEDs light.Test disk
Legend:
•Solid:
•Blinking:
•Off:
6. Press and hold the Reset button for five seconds to confirm your boot menu selection.
The system boots in the selected boot mode.
Rack Mounting
You can rack-mount the ReadyNAS 2120 and 2120 v2 storage systems using the included rack-mount ears.
Alternatively, you can use the optional sliding rail kit, order number RRAIL04-10000S. For instructions, see
the 1U Rail Installation Guide, which is available at http://support.netgear.com/product/ReadyNAS-OS6.
ReadyNAS 2120 and 2120 v2
17
ReadyNAS OS 6

3
ReadyNAS 2304
This chapter describes the physical features of the ReadyNAS 2304 storage system. It includes the following
sections:
•Front Panel on page 19
•Rear Panel on page 20
•Status Information on page 21
•Power On and Shut Down on page 22
•Boot Menu on page 24
•Rack Mounting on page 25
18

Front Panel
The following figure shows the front panel of the ReadyNAS 2304.
Figure 4. Front panel
1. Drive bays with disk status LEDs
2. Control panel
The following figure shows the control panel in more detail.
Figure 5. Control panel
1. USB 3.0 port
2. Reset button
3. Health LED
4. LAN LED
5. Unit identifier (UID) LED
6. Power LED
7. Unit identifier (UID) button
8. Power button
Each drive bay features a latch that releases the pop-out tray handle, as shown in the following figure.
ReadyNAS 2304
19
ReadyNAS OS 6

Figure 6. Drive bay
1. Disk tray handle
2. Disk Present LED
3. Disk tray release latch
4. Disk Activity or Fault LED
WARNING:
No matter how many hard drives are installed in your system,ensure that all drive
trays remain in the drive bays to maintain proper airflow.
Rear Panel
The following figure shows the rear panel of the ReadyNAS 2304 storage system.
Figure 7. Rear panel
1. Power cable socket
2. Power switch
3. Three system exhaust fans
4. Unit Identifier (UID) button
5. Unit Identifier (UID) LED
6. Two 1-gigabit LAN ports with LED status indicators
7. Two USB 3.0 ports
ReadyNAS 2304
20
