ReadyNAS OS 6 Desktop Storage
Systems Installation Guide

2
Contents
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Basic Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Reformat Disks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3
Package Contents
ReadyNAS system
Resource CD
Ethernet cable Power adapter and power cord
(varies by model)
IMPORTANT: Read all safety warnings in the hardware manual for
your system before connecting the system to the power supply.

4
Basic Setup
After you follow these instructions, your ReadyNAS is ready to use in
a production environment. Setup takes approximately 15 minutes.
To set up your storage system:
1. Install all available disks that you want to use in your ReadyNAS
system.
Note: If you are using previously formatted disks that contain
data, you must reformat these disks before continuing. See
Reformat Disks on page 7.
For a list of supported disks, see the Hardware Compatibility List
at http://www.netgear.com/readynas-hcl.
For information about installing disks, see the hardware manual
for your system.
2. Place your system in a location that provides adequate
ventilation.
High-capacity disks can produce considerable heat. It is
important to ensure that the fan exhausts are unobstructed.
For a complete list of placement considerations, see the
hardware manual for your system.
3. Connect the power adapter to the power cord.
4. Connect the power adapter to the back of the system and plug
the power cord into a wall outlet or power strip.
5. Use an Ethernet cable to connect an Ethernet port on the
storage system to your network.
6. If necessary, press the Power button to turn on the system.
7. Wait for the Power LED to turn solid blue or for the status
display screen to display the system’s IP address.

5
8. Visit http://readycloud.netgear.com on a computer that uses the
same local area network (LAN) and Internet connection as your
ReadyNAS system.
Note: If your computer does not have Internet access, install and
run the RAIDar utility instead. RAIDar is on the resource CD that
came with your system.
9. Click the Discover button.
ReadyCLOUD automatically detects your ReadyNAS system on
the network.
Your new ReadyNAS system is marked with a NEW label.
10. Click the Setup button.

6
11. Select the mode that you want to use to set up your system.
•Option 1. Select ReadyCLOUD mode.
aSign in to ReadyCLOUD or create a user account.
bFollow the prompts to configure your ReadyNAS
system.
•Option 2. Select Offline mode.
An SSL certificate security warning displays. This warning
ensures an encrypted authentication and secure access to the
ReadyNAS local admin page for your storage system.
aAccept the certificate.
A login prompt displays.
bEnter admin for the user name, enter password for the
password, and click the OK button.
Note: You can change these credentials when you configure
your system. NETGEAR recommends that you change your
password as soon as possible.
The ReadyNAS local admin page displays in your
browser and launches a setup wizard.
cFollow the prompts of the setup wizard to configure your
ReadyNAS system.
The setup process is complete. You can begin using your ReadyNAS
storage system.

7
Reformat Disks
If you are using previously formatted disks that contain data, you
must reformat the disks before you can use them with your
ReadyNAS system.
Warning: This process erases all data and reformats all disks into a
single X-RAID2 volume. If you want to preserve the data on the disks,
you must back up the data to an external drive before using the disks
in your ReadyNAS storage system.
To reformat previously formatted disks:
1. If your system is powered on, gracefully power off the system.
See Additional Information on page 9.
2. Install the previously formatted disks.
For a list of supported disks, see the Hardware Compatibility List
at http://www.netgear.com/readynas-hcl.
For information about installing disks, see the hardware manual
for your system.
3. Using a straightened paper clip, press and hold the Reset button.
4. Press the Power button.
The system powers on.
5. Continue pressing the Reset button until the system enters boot
mode.
•If you have a 2-bay storage system, the Power, Disk 1,
Disk 2, and Backup LEDs light when the system is in boot
mode.
•If you have a 4-bay or 6-bay storage system, the status
display screen indicates that the system is in boot mode.

8
6. Select the factory default option from the boot menu.
•If you have a 2-bay storage system, do the following:
aScroll through the boot menu options by pressing the
Backup button.
bWhen only the Disk 1 LED is lit, press and release the
Reset button.
•If you have a 4-bay storage system, do the following:
aScroll through the boot menu options by pressing the
Backup button.
bWhen the status display screen shows the factory
default option, press and release the Reset button.
•If you have a 6-bay storage system:
aScroll through the boot menu options using the arrows on
the touchpad.
bWhen the status display screen shows the factory
default option, press the OK button.
The system initiates a short disk test that takes 2 to 5 minutes.
Then, a 10-minute time-out period begins. After 10 minutes, the
factory default process starts.
7. (Optional) Press the Backup or OK button to skip the 10-minute
time-out period and begin the factory default process immediately.
The system returns to its factory default settings and reformats all
installed disks for use with ReadyNAS OS 6.
When the factory default process is complete, the reformatted disks
are ready to use with your system.

9
Additional Information
To help keep your storage system healthy and prevent the risk of
data loss, follow these rules of usage:
•Never replace more than one disk at a time while the system is
powered on.
•If you need to power off your system, power it off gracefully, when
possible.
To gracefully power off a 2-bay storage system:
Press the Power button twice.
To gracefully power off a 4-bay or 6-bay storage system:
Press the Power button three times.
For more information about setting up, configuring, and using your
system, see the software and hardware manuals for your system.
Links to these manuals are included on the resource CD that came
with your system and are also available at
http://support.netgear.com/product/ReadyNAS-OS6 or through a link
in the product’s user interface.
