User Manual
Orbi Whole Home Tri-Band
Mesh WiFi 6 System
Orbi Router Model RBR850
Orbi Satellite Model RBS850
Orbi Router Model RBR840
Orbi Satellite Model RBS840
NETGEAR, Inc.
350 E. Plumeria DriveApril 2020
San Jose, CA 95134, USA202-11974-06

Support and Community
Visit netgear.com/support to get your questions answered and access the latest
downloads.
You can also check out our NETGEAR Community for helpful advice at
community.netgear.com.
Regulatory and Legal
Si ce produit est vendu au Canada, vous pouvez accéder à ce document en français
canadien à https://www.netgear.com/support/download/.
(If this product is sold in Canada, you can access this document in Canadian French at
https://www.netgear.com/support/download/.)
For regulatory compliance information including the EU Declaration of Conformity, visit
https://www.netgear.com/about/regulatory/.
See the regulatory compliance document before connecting the power supply.
For NETGEAR’s Privacy Policy, visit https://www.netgear.com/about/privacy-policy.
By using this device, you are agreeing to NETGEAR’s Terms and Conditions at
https://www.netgear.com/about/terms-and-conditions. If you do not agree, return the
device to your place of purchase within your return period.
Trademarks
© NETGEAR, Inc., NETGEAR, and the NETGEAR Logo are trademarks of NETGEAR, Inc.
Any non-NETGEAR trademarks are used for reference purposes only.
2
Orbi Whole Home Tri-Band Mesh WiFi 6 System

Contents
Chapter 1 Overview
Orbi router overview............................................................................9
Orbi router hardware features........................................................9
Orbi router LED behavior.............................................................10
Orbi satellite overview.......................................................................11
Orbi satellite hardware features...................................................11
Orbi satellite LED behavior...........................................................12
Connect your router...........................................................................13
Place your Orbi satellite.....................................................................13
Sync your Orbi satellite with your Orbi router................................14
Chapter 2 Connect to the Network and Access the Router
Connect to the network.....................................................................16
Wired connection..........................................................................16
WiFi connection.............................................................................16
WiFi connection using WPS..........................................................17
Types of logins....................................................................................17
Router and satellite labels.................................................................17
Set up and manage with the NETGEAR Orbi app..........................18
Use a web browser to access the router..........................................19
Use the automatic Internet setup option....................................19
Log in to the Orbi router web interface......................................20
Change the language........................................................................21
Chapter 3 Specify Your Internet Settings
Manually set up the Internet connection.........................................23
Specify an Internet connection without a login..............................23
Specify an Internet connection that uses a login............................24
Manage an IPv6 Internet connection...............................................26
Requirements for entering IPv6 addresses.................................26
Specify IPv6 Internet connections................................................26
Use auto detection for an IPv6 Internet connection..................27
Use auto configuration for an IPv6 Internet connection...........28
Set up an IPv6 6rd tunnel Internet connection...........................29
Set up an IPv6 6to4 tunnel Internet connection.........................31
Set up an IPv6 pass-through Internet connection......................33
3

Set up an IPv6 fixed Internet connection....................................33
Set up an IPv6 DHCP Internet connection..................................34
Set up an IPv6 PPPoE Internet connection..................................36
Change the MTU size.........................................................................38
Chapter 4 Control Access to the Internet
Allow or block access to your network............................................41
Use keywords to block Internet sites...............................................42
Delete keywords that are used to block Internet sites...................43
Avoid blocking on a trusted computer............................................44
Block services from the Internet.......................................................44
Manage network access control lists...............................................46
Schedule when to block Internet sites and services......................46
Set up security event email notifications.........................................47
Chapter 5 Optimize Performance
Enable or disable Wi-Fi Multimedia Quality of Service.................51
Improve network connections with Universal Plug and Play........52
Chapter 6 Specify Network Settings
View or change WAN settings..........................................................55
Manage Dynamic DNS.......................................................................56
Set up a new Dynamic DNS account...........................................56
Specify a Dynamic DNS account that you already created......57
Change the Dynamic DNS settings.............................................58
Set up a default DMZ server..............................................................59
Change the router’s device name....................................................60
Change the LAN TCP/IP settings......................................................60
Use the router as a DHCP server......................................................62
Disable the DHCP server feature in the router...............................63
Manage reserved LAN IP addresses................................................64
Reserve an IP address....................................................................64
Edit a reserved IP address............................................................65
Delete a reserved IP address entry..............................................65
Manage custom static routes............................................................66
Set up a static route.......................................................................66
Edit a static route...........................................................................67
Delete a static route.......................................................................68
Specify basic WiFi settings................................................................69
Change the WiFi password or security level...................................70
Set up a guest WiFi network.............................................................71
Change your region...........................................................................72
Use the router as a WiFi access point only......................................73
Set up router mode............................................................................74
4
Orbi Whole Home Tri-Band Mesh WiFi 6 System

Generate a new backhaul password................................................75
Set up a bridge for a port group or VLAN tag group....................75
Set up a bridge for a port group..................................................76
Set up a bridge for a VLAN tag group........................................77
Get Multi-Gig Internet with Internet port aggregation..................78
Chapter 7 Manage Your Network
Update the router and satellite firmware........................................81
Check for firmware updates.........................................................81
Manually update firmware............................................................82
Manually update satellite firmware..............................................82
Manually update router firmware................................................83
Change the admin password............................................................84
Enable admin password reset...........................................................84
Reset the admin password................................................................85
View router status and usage information.......................................86
Display Internet port statistics...........................................................86
Check the Internet connection status..............................................87
View satellite status............................................................................88
View and manage logs of router activity.........................................89
View devices connected to the network or edit device
information..........................................................................................90
View devices connected to the network.....................................90
Edit device information on the Attached Devices page...........91
View satellites connected to the network or edit satellite
information..........................................................................................91
View satellites connected to the network...................................91
Edit satellite information that displays on the Attached Devices
page.................................................................................................92
Monitor Internet traffic.......................................................................93
Manage the router configuration file...............................................94
Back up settings.............................................................................95
Restore configuration settings.....................................................95
Erase the current configuration settings.....................................96
Set up remote management.............................................................96
Use remote access..............................................................................98
Remotely access your router using the Orbi app...........................98
Chapter 8 Customize Internet Traffic Rules for Ports
Manage port forwarding to a local server.....................................100
Set up port forwarding to a local server...................................100
Add a custom port forwarding service.....................................101
Edit a port forwarding service....................................................102
Delete a port forwarding entry..................................................103
5
Orbi Whole Home Tri-Band Mesh WiFi 6 System

How the router implements the port forwarding rule.............103
Application example: Make a local web server public...........104
Manage port triggering...................................................................104
Add a port triggering service.....................................................105
Disable port triggering or change the time-out period.........106
Application example: Port triggering for Internet Relay Chat.106
Chapter 9 Use VPN to Access Your Network
Set up a VPN connection.................................................................109
Specify VPN service in the router...................................................109
Install OpenVPN software...............................................................110
Install OpenVPN software on your Windows-based computer.110
Install OpenVPN software on your Mac computer..................113
Install OpenVPN software on an iOS device............................114
Install OpenVPN software on an Android device....................114
Use a VPN tunnel on your Windows-based computer................115
Use VPN to access your Internet service at home........................117
Set up VPN client Internet access in the router........................117
Block VPN client Internet access in the router.........................118
Use a VPN tunnel to access your Internet service at home....118
Chapter 10 Troubleshooting
Quick tips...........................................................................................120
Sequence to restart your network.............................................120
WiFi settings.................................................................................120
Network settings..........................................................................120
The router and satellite do not sync..............................................120
You cannot log in to the router.......................................................121
You cannot access the Internet.......................................................122
Troubleshoot Internet browsing.....................................................123
Troubleshoot PPPoE........................................................................124
Troubleshoot WiFi connectivity......................................................124
Troubleshoot your network using the ping utility........................125
Test the LAN path to your router...............................................125
Test the path from your computer to a remote device...........126
Chapter 11 Supplemental Information
Factory settings for Orbi routers....................................................129
Factory settings for Orbi router model RBR850......................129
Factory settings for Orbi router model RBR840......................131
Factory settings for Orbi satellites..................................................132
Factory settings for Orbi satellite model RBS850....................133
Factory settings for Orbi satellite model RBS840....................134
Technical specifications for Orbi routers......................................136
6
Orbi Whole Home Tri-Band Mesh WiFi 6 System

Technical specifications for Orbi router model RBR850.........136
Technical specifications for Orbi router model RBR840.........138
Technical specifications for Orbi satellites....................................139
Technical specifications for Orbi satellite model RBS850......139
Technical specifications for Orbi satellite model RBS840......141
7
Orbi Whole Home Tri-Band Mesh WiFi 6 System

1
Overview
The Orbi™ Mesh WiFi System creates dedicated high-speed WiFi connections to your
Internet service. The Orbi router (model RBR850 or model RBR840) connects to your
modem or gateway. The Orbi satellite (model RBS850 or model RBS840) extends the
WiFi signal throughout your home.
This manual describes how to manage your Orbi Mesh WiFi System from your Orbi
router web interface. You can manage your Orbi satellite from the Orbi router web
interface.
This chapter contains the following sections:
• Orbi router overview
• Orbi satellite overview
• Connect your router
• Place your Orbi satellite
• Sync your Orbi satellite with your Orbi router
For more information about the topics covered in this manual, visit the support website
at https://www.netgear.com/support/.
Note: This manual might refer to the Orbi router (model RBR850 or model RBR840) as
the router and refer to the Orbi satellite (model RBS850 or model RBS840) as the satellite.
8

Orbi router overview
The following sections are an overview of the Orbi router hardware features and LED
behavior.
Orbi router hardware features
The following figures shows the Orbi router hardware features.
Figure 1. Orbi router front and back views
1 32 4 5
6
7
1. Router LED
2. Sync button
3. Internet port
4. Ethernet ports 1–4
You can use Ethernet Port 1 and the Internet port to set up Internet port aggregation
(also called WAN link aggregation). For more information, see Get Multi-Gig Internet
with Internet port aggregation on page 78.
5. Power LED
6. Reset button
7. Power connector
User Manual9Overview
Orbi Whole Home Tri-Band Mesh WiFi 6 System

Orbi router LED behavior
The Orbi router has a LED on the front and a Power LED on the back.
The following table describes the LED behavior for the router's Power LED.
Table 1. Power LED behavior
DescriptionLED color
Power is on.Solid green
The router is booting.Solid amber
The router's firmware is resetting to its factory
default settings.
Blinking amber
The router's firmware is corrupted.Blinking red
Power is not suppliedOff
The following table describes the LED behavior for an router LED that is on the front of
the router.
Table 2. Router LED behavior
DescriptionLED color
The router is booting or someone pressed the
Sync button.
Pulsing white
The router is resetting to its factory default
settings.
Solid white
The router cannot connect to the Internet.Solid magenta
The router finished booting and is working
normally.
Off
User Manual10Overview
Orbi Whole Home Tri-Band Mesh WiFi 6 System

Orbi satellite overview
The following sections are an overview of the Orbi satellite hardware features and LED
behavior.
Orbi satellite hardware features
The following figures shows the Orbi satellite hardware features.
1 32 4
5
6
Figure 2. Orbi satellite front and back views
1. Satellite LED
2. Sync button
3. Ethernet ports 1–4
4. Power LED
5. Reset button
6. Power connector
User Manual11Overview
Orbi Whole Home Tri-Band Mesh WiFi 6 System

Orbi satellite LED behavior
The Orbi satellite has a LED on the front and a Power LED on the back.
The following table describes the LED behavior for the satellite's Power LED.
Table 3. Power LED behavior
DescriptionLED color
Power is on.Solid green
The satellite is booting.Solid amber
The satellite's firmware is resetting to its factory default settings.Blinking amber
The satellite's firmware is corrupted.Blinking red
Power is not suppliedOff
The following table describes the LED behavior for an satellite LED that is on the front
of the satellite.
Table 4. Satellite LED behavior
DescriptionLED color
The satellite is booting.Pulsing white
The connection between the satellite and router is good.
The LED lights blue for three minutes and then turns off.
Blue
The connection between the satellite and router is fair.
The LED lights amber for three minutes and then turns off.
Amber
The satellite failed to sync with the router.Magenta
The satellite synced with the router and is working normally.Off
User Manual12Overview
Orbi Whole Home Tri-Band Mesh WiFi 6 System

Connect your router
Power on your router and connect it to a modem.
To cable your router:
1. Unplug your modem’s power, leaving the modem connected to the wall jack for
your Internet service.
If your modem uses a battery backup, remove the battery.
2. Plug in and turn on your modem.
If your modem uses a battery backup, put the battery back in.
3. Connect your modem to the Internet port of your router with the Ethernet cable that
came with your router.
4. Connect the power adapter to your router and plug the power adapter into an outlet.
5. If the Power LED does not light, make sure that the power adapter is properly
connected to your router and power outlet.
Place your Orbi satellite
Your Orbi satellite must be within range of your Orbi router’s WiFi signal in order for it
to sync with your router. Use your satellite's LED to help you determine where to place
your satellite.
User Manual13Overview
Orbi Whole Home Tri-Band Mesh WiFi 6 System

Sync your Orbi satellite with your Orbi router
The Orbi satellite that comes with your Orbi router is preset to automatically find and
sync to your Orbi router's WiFi signal.
To sync your satellite:
1. Place your satellite.
For more information, see Place your Orbi satellite on page 13.
2. Connect the satellite to a power source.
The satellite LED pulses white. The satellite automatically finds the Orbi router’s WiFi
signal and attempts to sync to the Orbi router.
The satellite LED lights one of the following colors:
•Blue. The Orbi router and satellite successfully synced, and the connection
between the router and satellite is good.
•Amber. The connection with the router is fair. We recommend that you move
the Orbi satellite closer to the Orbi router and try again.
3. If the satellite LED lights magenta, do the following:
a. Unplug your Orbi satellite, move the satellite closer to the router.
b. Plug the satellite back in, and wait two minutes for the LED to turn blue or amber.
4. If the satellite LED still does not turn blue or amber, do the following:
a. Press the Sync button on the back of the router.
b. Within two minutes press the Sync button on the back of the satellite.
c. Wait two minutes for the LED to turn blue or amber.
User Manual14Overview
Orbi Whole Home Tri-Band Mesh WiFi 6 System

2
Connect to the Network and Access
the Router
This chapter contains the following sections:
• Connect to the network
• Types of logins
• Router and satellite labels
• Set up and manage with the NETGEAR Orbi app
• Use a web browser to access the router
• Change the language
15

Connect to the network
You can connect to the Orbi network through a wired or WiFi connection. If you set up
your computer to use a static IP address, change the settings so that it uses Dynamic
Host Configuration Protocol (DHCP).
Wired connection
You can connect your computer to the router using an Ethernet cable and join the
router’s local area network (LAN).
To connect your computer to the router with an Ethernet cable:
1. Make sure that the router is receiving power (its Power LED is lit).
2. Connect an Ethernet cable to an Ethernet port on your computer.
3. Connect the other end of the Ethernet cable to one of the router’s Ethernet ports.
Your computer connects to the local area network (LAN). A message might display
on your computer screen to notify you that an Ethernet cable is connected.
WiFi connection
If you're installing your Orbi router for the first time, you can connect to the router's
WiFi network by scanning the QR code on your router with the camera app on your
mobile device. To scan the QR code with your camera app, your mobile device must
have iOS version 11 or later or Android version 10 or later.
You can also manually find and select the Orbi router's WiFi network from your
WiFi-enabled computer or mobile device.
To find and select the WiFi network:
1. Make sure that the router or satellite is receiving power (its Power LED is lit).
2. On your WiFi-enabled computer or mobile device, find and select the WiFi network.
The WiFi network name is on the router label. The WiFi network name is the same
for the router and the satellite in the Orbi WiFi System.
Note: If you bought the router and the satellite separately, their default WiFi network
names are different.
3. Join the WiFi network and enter the WiFi password.
The password is on the router label.
Your WiFi-enabled computer or mobile device connects to the WiFi network.
User Manual16Connect to the Network and
Access the Router
Orbi Whole Home Tri-Band Mesh WiFi 6 System

WiFi connection using WPS
You can connect to the router’s WiFi network with Wi-Fi Protected Setup (WPS) or you
can find and select the WiFi network.
To use WPS to connect to the WiFi network:
1. Make sure that the router is receiving power (its Power LED is lit).
2. Check the WPS instructions for your computer or WiFi device.
3. Press the Sync button on the router.
4. Within two minutes, on your WiFi-enabled computer or mobile device, press its WPS
button or follow its instructions for WPS connections.
Your computer or mobile device connects to the WiFi network.
Types of logins
Separate types of logins serve different purposes. It is important that you understand
the difference so that you know which login to use when.
Types of logins:
•Internet service login. The login that your Internet service provider (ISP) gave you
logs you in to your Internet service. Your service provider gave you this login
information in a letter or some other way. If you cannot find this login information,
contact your service provider.
•WiFi network key or password. Your router and satellite are preset with the same
WiFi network name (SSID) and password for WiFi access. This information is on the
router label and the satellite label.
•Router login. This logs you in to the router interface from a web browser as admin.
Router and satellite labels
The Orbi router and satellite label shows the router’s or satellite's MAC address and
serial number. The label also includes a QR code you can scan during the setup to
connect to the Orbi setup network. The following is an example of what the router or
satellite label might look like:
User Manual17Connect to the Network and
Access the Router
Orbi Whole Home Tri-Band Mesh WiFi 6 System

Made in China
Set up and manage with the NETGEAR Orbi
app
You can use the NETGEAR Orbi app to set up and access your Orbi network.
To find the app, scan a QR code or search for NETGEAR Orbi in the Apple App Store
or Google Play Store.
For more information about the Orbi app, visit
https://www.netgear.com/home/apps-services/orbi-app.
Note: If you do not want to use the NETGEAR Orbi app, you can use the Orbi router
web interface to set up your Orbi devices. For more information about how to access
your Orbi router web interface, see Use a web browser to access the router on page
19.
To set up your Orbi WiFi system with the Orbi app:
1. Download the NETGEAR Orbi app on your mobile device.
2. On your mobile device, open the WiFi connection manager.
3. Locate and connect your mobile device to your Orbi WiFi network.
Your preset Orbi WiFi network and password displays on the Orbi router label. You
can change the WiFi credentials after the setup.
4. Launch the Orbi app and follow the setup instructions.
User Manual18Connect to the Network and
Access the Router
Orbi Whole Home Tri-Band Mesh WiFi 6 System

Use a web browser to access the router
When you connect to the network (either with WiFi or with an Ethernet cable), you can
use a web browser to access the router to view or change its settings. The first time you
access the router, the NETGEAR installation assistant automatically checks to see if your
router can connect to your Internet service.
Use the automatic Internet setup option
You can set up your router automatically, or you can use a web browser to access the
router and set up your router manually. Before you start the setup process, get your ISP
information and make sure that the computers and devices in the network use the
settings described here.
When your Internet service starts, your Internet service provider (ISP) typically gives you
all the information needed to connect to the Internet. For DSL service, you might need
the following information to set up your router:
•The ISP configuration information for your DSL account
•ISP login name and password
•Fixed or static IP address settings (special deployment by ISP; this setting is rare)
If you cannot locate this information, ask your ISP to provide it. When your Internet
connection is working, you no longer need to launch the ISP login program on your
computer to access the Internet. When you start an Internet application, your router
automatically logs you in.
Installation and basic setup takes about 15 minutes to complete.
To automatically set up your router:
1. Power on your router.
2. Make sure that your WiFi-enabled computer or mobile device is connected to the
router with an Ethernet cable (wired) or wirelessly with the preset WiFi security
settings listed on the label.
Note: If you want to change the router’s WiFi settings, use a wired connection to
avoid being disconnected when the new WiFi settings take effect.
3. Launch a web browser.
User Manual19Connect to the Network and
Access the Router
Orbi Whole Home Tri-Band Mesh WiFi 6 System
