NETGEAR GC752XP Manual

Hardware Installation Guide
Insight Managed 28-Port and
52-Port Gigabit Ethernet Smart Cloud Switch
with 2 SFP 1G & 2 SFP+ 10G Fiber Ports (and
PoE on GC728XP and GC752XP Only)
Models
GC728X
GC728XP
GC752X
GC752XP
NETGEAR, Inc.
350 E. Plumeria DriveOctober 2018 San Jose, CA 95134, USA202-11955-01

Support
Thank you for purchasing this NETGEAR product. You can visit
https://www.netgear.com/support/ to register your product, get help, access the latest
downloads and user manuals, and join our community. We recommend that you use
only official NETGEAR support resources.
Compliance and Conformity
For regulatory compliance information including the EU Declaration of Conformity, visit
https://www.netgear.com/about/regulatory/.
See the regulatory compliance document before connecting the power supply.
Do not use this device outdoors. If you connect cables or devices that are outdoors to
this device, see http://kb.netgear.com/000057103 for safety and warranty information.
Trademarks
© NETGEAR, Inc., NETGEAR, and the NETGEAR Logo are trademarks of NETGEAR, Inc.
Any non-NETGEAR trademarks are used for reference purposes only.
Revision History
CommentsPublish DatePublication Part
Number
First publication.October 2018202-11955-01
2
Insight Managed 28-Port and

Contents
Chapter 1 Introduction
Overview................................................................................................7
Features.................................................................................................8
Safety Instructions and Warnings.....................................................10
Chapter 2 Hardware Overview
Hardware Description........................................................................14
Front Panel Models GC728X and GC728XP..............................14
Front Panel Models GC752X and GC752XP..............................15
Status LEDs.....................................................................................16
Back Panel.......................................................................................19
Switch Hardware Interfaces...............................................................20
RJ-45 Ports for 10/100/1000M BASE-T Ethernet Connectivity.20
SFP and SFP+ Ports for Fiber Connectivity.................................21
USB Port..........................................................................................21
Console Port...................................................................................22
Multifunction Reset Button...........................................................22
Chapter 3 Installation
Step 1: Prepare the Site.....................................................................24
Step 2: Protect Against Electrostatic Discharge.............................24
Step 3: Unpack the Switch.................................................................25
Step 4: Install the Switch....................................................................26
Install the Switch in a Rack............................................................26
Install the Switch on a Flat Surface...............................................27
Optional Step 5: Install SFP Transceiver Modules..........................27
Step 6: Connect Devices to the Switch............................................28
Step 7: Check the Installation...........................................................29
Step 8: Apply Power and Check the LEDs......................................29
Step 9: Manage the Switch................................................................30
Chapter 4 Applications
Aggregation and Backbone Switching............................................32
PoE Overview......................................................................................34
Aggregation and Backbone Switching With PoE...........................35
3

Chapter 5 Troubleshooting
Troubleshooting Chart.......................................................................38
PoE Troubleshooting Suggestions...................................................39
Additional Troubleshooting Suggestions.......................................39
4
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

1
Introduction
This hardware installation guide is for the following NETGEAR switch models:
•Insight Managed 28-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP 1G & 2
SFP+ 10G Fiber Ports, Model GC728X
•Insight Managed 28-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP 1G
& 2 SFP+ 10G Fiber Ports, 390W PoE, Model GC728XP
•Insight Managed 52-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP 1G & 2
SFP+ 10G Fiber Ports, Model GC752X
•Insight Managed 52-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP 1G
& 2 SFP+ 10G Fiber Ports, 505W PoE, Model GC752XP
The switch provides 24 or 48 Gigabit Ethernet RJ-45 copper ports, 2 dedicated Gigabit
SFP fiber ports, and 2 dedicated 10G SFP+ fiber ports.
Models GC728XP and GC752XP support Power over Ethernet Plus (PoE+) on all 24 or
48 RJ-45 copper ports so that you can let the switch provide power to PoE-capable
devices such as WiFi access points, VoIP phones, and IP security cameras. These models
can supply up to 30W PoE (IEEE 802.3at) to each port. Model GC728XP provides a
maximum PoE power budget of 390W across all active PoE+ ports. Model GC752XP
provides a maximum PoE power budget of 505W across all active PoE+ ports.
This hardware installation guide complements the installation guide that came with your
switch.
This chapter serves as an introduction to the switch and includes the following sections:
• Overview
• Features
• Safety Instructions and Warnings
Note: For more information about the topics that are covered in this manual, visit the
support website at netgear.com/support.
5

Note: For technical specifications on the GC728X and GC728XP, visit
http://www.netgear.com/gc728X and see the data sheet under the Resources tab. For
technical specifications on the GC752X and GC752XP, visit
http://www.netgear.com/gc752X and see the data sheet under the Resources tab. For
switch documentation, visit downloadcenter.netgear.com.
6

Overview
The switch provides 24 or 48 Gigabit Ethernet copper ports, 2 dedicated Gigabit SFP
fiber ports, and 2 dedicated 10G SFP+ fiber ports. All copper ports use RJ-45 connectors.
The SFP ports require a standard small form-factor pluggable (SFP) gigabit interface
converter (GBIC, also referred to as a transceiver module), which is sold separately from
the switch. The switch integrates full-duplex, nonblocking switch fabric that provides
full-wire speed for all packet sizes.
The PoE+ models supports PoE on all copper ports with a maximum PoE power budget
of 390W (model GC728XP) or 505W (model GC752XP) across all active PoE+ ports.
Note: For information about application examples, see Applications on page 31.
The switch provides management options that let you discover the switch on the network
and configure, monitor, and control the switch:
•NETGEAR Insight app. Using the NETGEAR Insight app, you can discover the switch
on the network and add the switch to the NETGEAR Insight app so that you can set
up the switch in the network and manage and monitor the switch remotely from your
smartphone. You can choose from four methods to add the switch to the NETGEAR
Insight app: You can scan your network for the switch, scan the QR code or the
barcode of the switch, or add the serial number of the switch. For more information,
see the NETGEAR knowledge base articles at netgear.com/support.
•Insight Cloud portal. Using the NETGEAR Insight Cloud portal, you can set up the
switch in the network, perform advanced remote management, monitor the switch,
analyze the switch and network usage, and, if necessary, troubleshoot the switch
and the network.
•Local browser–based management interface. By default, the management mode
of the switch is set to NETGEAR Insight App. With this setting you can manage the
switch using the Insight app or the Insight Cloud portal. For complex tasks such as
integrating with an existing network of devices that are not managed through Insight,
and for debugging purposes, you can change the management mode of the switch
to PC Web-browser and access the local browser interface. In this mode, you can
change the settings of the specific device, but we recommend that you do not use
this mode to change settings that are Insight manageable because they would not
be synchronized with Insight or to the network location and other devices to which
you assigned the switch.
Hardware Installation Guide7Introduction
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

Note: Changes to Insight-manageable settings from the local browser interface
might also create conflicts with the rest of the Insight-managed network to which
the device is connected. While you manage the switch with the local browser
interface, you cannot use the Insight app or Insight Cloud portal. To reenable
management of the device remotely or through the cloud, you can return the
management mode to NETGEAR Insight App at any time so that you can manage
the switch with the Insight app or Insight Cloud portal.
For more information about the local browser interface, see the user manual, which
you can download from downloadcenter.netgear.com.
Note: The switch is designed for management by the NETGEAR Insight app on a
smartphone or tablet. Alternatively, you can manage the switch from the Insight
Cloud portal that is available from a web browser on your Windows-based computer,
Mac, or tablet. By default, the local browser interface is disabled and you cannot use
it while the switch is managed by the NETGEAR Insight app or Insight Cloud portal.
You can install the switch freestanding (on a desktop) or in a standard 19-inch rack,
using the included rack-mount kit. The switch is IEEE compliant and offers low latency.
All ports can automatically negotiate to the highest speed, which makes the switch very
suitable for a mixed environment with Gigabit Ethernet and Fast Ethernet.
For Gigabit Ethernet connections, use Category 5e (Cat 5e) or higher-rated Ethernet
cables terminated with RJ-45 connectors.
Features
The switch includes the following key hardware features:
•Twenty-four (models GC728X and GC728XP) or forty-eight (models GC752X and
GC752XP) Gigabit Ethernet ports.
•Two dedicated Gigabit SFP fiber ports.
•Two dedicated 10G SFP+ fiber ports.
•One USB port (for configuration files, firmware updates, and debug logs).
•One micro USB console and debug port. (Use this port only as directed and assisted
by technical support.)
•PoE+ on copper ports (models GC728XP and GC752XP):
-Twenty-four (model GC728XP) or forty-eight (model GC752XP) ports PoE+ (IEEE
802.3at)
-Total PoE power budget of 390W (model GC728XP) or 505W (model GC752XP)
Hardware Installation Guide8Introduction
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

•MAC table size of 16K entries.
•Switch fabric full-duplex nonblocking.
•Includes the following mounting hardware:
-Four rubber footpads for tabletop installation
-Rack-mount kit (brackets and screws) for rack installation
•Full NETGEAR Smart Managed Pro Switch features and functionality.
•Full compatibility with IEEE standards:
- IEEE 802.3 Ethernet
- IEEE 802.3u 100BASE-T
- IEEE 802.3ab 1000BASE-T
- IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX
- IEEE 802.3ae 10-Gigabit Ethernet Over Fiber (10GBASE-SR, 10GBASE-LR,
10GBASE-LRM, 10GBASE-ER, 10GBASE-LX4)
- IEEE 802.3aq 10-Gigabit over Fiber (10GBASE-LRM)
- IEEE 802.1Q VLAN tagging
-IEEE 802.3x Full-duplex flow control
- IEEE 802.3ad Link aggregation (LAG with LACP)
- IEEE 802.1ab LLDP
-IEEE 802.1p Class of Service (QoS)
- IEEE 802.1D Spanning Tree Protocol (STP)
- IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
- IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
- IEEE 802.1x RADIUS network access control
-IEEE 802.3az Energy Efficient Ethernet (EEE)
-IEEE 802.3af (PoE) (models GC728XP and GC752XP)
- IEEE 802.3at (PoE+) (models GC728XP and GC752XP)
•AutoSensing and autonegotiating capabilities for all ports.
•Auto Uplink™ technology is supported on all ports.
•Automatic address-learning function to build the packet-forwarding information
table. The table contains up to 16K Media Access Control (MAC) addresses.
Hardware Installation Guide9Introduction
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

•Store-and-forward transmission to remove bad packets from the network.
•Active flow control to minimize packet loss and frame drops.
•Half-duplex backpressure control.
•Per-port status LEDs and system status LEDs:
- System Power LED
- Cloud Connection LED
- PoE Max or Fault LED (models GC728XP and GC752XP)
- Fan LED
-Per-port link, speed, and activity LED for copper ports
-Per-port PoE status LED for copper ports (models GC728XP and GC752XP)
-Per-port link and activity LED for SFP and SFP+ fiber ports
•NETGEAR green power-saving features:
-Energy efficiency mode that fully conforms to the IEEE 802.3az standard
- Per-port automatic change to a lower power mode when the port link is down
Safety Instructions and Warnings
Use the following safety guidelines to ensure your own personal safety and to help
protect your system from potential damage.
To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment,
observe the following precautions:
•This product is designed for indoor use only in a temperature-controlled (0–45°C)
and humidity-controlled (90 percent maximum relative humidity, noncondensing)
environment.
Any device that is located outdoors and connected to this product must be properly
grounded and surge protected.
To the extent permissible by applicable law, failure to follow these guidelines can
result in damage to your NETGEAR product, which might not be covered by
NETGEAR’s warranty.
Hardware Installation Guide10Introduction
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

•Observe and follow service markings:
- Do not service any product except as explained in your system documentation.
- Opening or removing covers that are marked with the triangular symbol with a
lightning bolt can expose you to electrical shock. We recommend that only a
trained technician services components inside these compartments.
•If any of the following conditions occur, unplug the product from the electrical outlet
and replace the part or contact your trained service provider:
- The power cable, extension cable, or plug is damaged.
-An object fell into the product.
- The product was exposed to water.
- The product was dropped or damaged.
-The product does not operate correctly when you follow the operating
instructions.
•Keep your system away from radiators and heat sources. Also, do not block cooling
vents.
•Do not spill food or liquids on your system components, and never operate the
product in a wet environment. If the system gets wet, see the appropriate section in
your troubleshooting guide, or contact your trained service provider.
•Do not push any objects into the openings of your system. Doing so can cause fire
or electric shock by shorting out interior components.
•Use the product only with approved equipment.
•Allow the product to cool before removing covers or touching internal components.
•Operate the product only from the type of external power source indicated on the
electrical ratings label. If you are not sure of the type of power source required,
consult your service provider or local power company.
•To avoid damaging your system, be sure that the voltage selection switch (if provided)
on the power supply is set to match the power at your location:
-115V, 60 Hz in most of North and South America and some Far Eastern countries
such as South Korea and Taiwan
- 100V, 50 Hz in eastern Japan and 100V, 60 Hz in western Japan
-230V, 50 Hz in most of Europe, the Middle East, and the Far East
•Be sure that attached devices are electrically rated to operate with the power available
in your location.
Hardware Installation Guide11Introduction
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

•Use only the supplied DC power adapter. If you were not provided with a DC power
adapter, contact your reseller.
•To help prevent electric shock, plug the system and peripheral power cables into
properly grounded electrical outlets.
•The peripheral power cables are equipped with three-prong plugs to help ensure
proper grounding. Do not use adapter plugs or remove the grounding prong from
a cable. If you must use an extension cable, use a three-wire cable with properly
grounded plugs.
•Observe extension cable and power strip ratings. Make sure that the total ampere
rating of all products plugged into the extension cable or power strip does not
exceed 80 percent of the ampere ratings limit for the extension cable or power strip.
•To help protect your system from sudden, transient increases and decreases in
electrical power, use a surge suppressor, line conditioner, or uninterruptible power
supply (UPS).
•Position system cables and power cables carefully. Route cables so that they cannot
be stepped on or tripped over. Be sure that nothing rests on any cables.
•Do not modify power cables or plugs. Consult a licensed electrician or your power
company for site modifications.
•Always follow your local and national wiring rules.
Hardware Installation Guide12Introduction
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

2
Hardware Overview
This chapter describes the switch hardware features.
The chapter includes the following sections:
• Hardware Description
• Switch Hardware Interfaces
13

Hardware Description
The following sections describe the switch hardware features.
Front Panel Models GC728X and GC728XP
Model GC728X provides 24 10/100/1000BASE-T RJ-45 ports, 2 dedicated Gigabit SFP
fiber ports, and 2 dedicated 10G SFP+ fiber ports
Model GC728XP provides 24 10/100/1000BASE-T RJ-45 PoE+ ports, 2 dedicated Gigabit
SFP fiber ports, and 2 dedicated 10G SFP+ fiber ports.
The following figures show the front panels.
Figure 1. Front panel model GC728X
Figure 2. Front panel model GC728XP
Table 1. Front panel components
DescriptionNumber
Cloud Connection LED1a
Power LED1b
PoE Max or Fault LED for model GC728XP only1c
Fan LED1d
Recessed multifunction Reset button (see Multifunction Reset Button on page 22)
2
Hardware Installation Guide14Hardware Overview
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

Table 1. Front panel components (Continued)
DescriptionNumber
One micro USB console and debug port. Use this port only as directed and assisted by technical
support.
3
USB 2.0 port (see USB Port on page 21)4
Model GC728X. Twenty-four independent 10/100/1000BASE-T RJ-45 ports, numbered 1 through
24. Each port provides one LED that functions as the combined speed and activity LED.
Model GC728XP. Twenty-four independent 10/100/1000BASE-T RJ-45 PoE+ ports, numbered
1 through 24. Each port provides a left LED that functions as the combined speed and activity LED
and a right LED that indicates the PoE status.
5
Two dedicated Gigabit SFP fiber ports, numbered 25F and 26F, that can accept optional transceiver
modules. Each port provides a single LED that functions as the combined link and activity LED.
6
Two dedicated 10G SFP fiber ports, numbered 27F+ and 28F+, that can accept optional transceiver
modules. Each port provides a single LED that functions as the combined link and activity LED.
7
For information about the LEDs, see Status LEDs on page 16.
For information about optional transceiver modules, see SFP and SFP+ Ports for Fiber
Connectivity on page 21.
Front Panel Models GC752X and GC752XP
Model GC752X provides 48 10/100/1000BASE-T RJ-45 ports, 2 dedicated Gigabit SFP
fiber ports, and 2 dedicated 10G SFP+ fiber ports
Model GC752XP provides 48 10/100/1000BASE-T RJ-45 PoE+ ports, 2 dedicated Gigabit
SFP fiber ports, and 2 dedicated 10G SFP+ fiber ports.
The following figures show the front panels.
Figure 3. Front panel model GC752X
Hardware Installation Guide15Hardware Overview
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

Figure 4. Front panel model GC752XP
Table 2. Front panel components
DescriptionNumber
Cloud Connection LED1a
Power LED1b
PoE Max or Fault LED for model GC752XP only1c
Fan LED1d
Recessed multifunction Reset button (see Multifunction Reset Button on page 22)
2
One micro USB console and debug port. Use this port only as directed and assisted by technical
support.
3
USB 2.0 port (see USB Port on page 21)4
Model GC752X. Forty-eight independent 10/100/1000BASE-T RJ-45 ports, numbered 1 through
48. Each port provides one LED that functions as the combined speed and activity LED.
Model GC752XP. Forty-eight independent 10/100/1000BASE-T RJ-45 PoE+ ports, numbered 1
through 48. Each port provides a left LED that functions as the combined speed and activity LED
and a right LED that indicates the PoE status.
5
Two dedicated Gigabit SFP fiber ports, numbered 49F and 50F, that can accept optional transceiver
modules. Each port provides a single LED that functions as the combined link and activity LED.
6
Two dedicated 10G SFP fiber ports, numbered 51F+ and 52F+, that can accept optional transceiver
modules. Each port provides a single LED that functions as the combined link and activity LED.
7
For information about the LEDs, see Status LEDs on page 16.
For information about optional transceiver modules, see SFP and SFP+ Ports for Fiber
Connectivity on page 21.
Status LEDs
This section describes the status LED designations of the switch.
Hardware Installation Guide16Hardware Overview
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

Table 3. LEDs on the front panel of models GC728X and GC752X
DescriptionLED
Solid blue. The switch is connected to the cloud server and is set up to be
managed by the NETGEAR Insight app and Insight Cloud portal.
Off. The switch is not connected to the cloud server or is set up to be managed
by the local browser interface.
Cloud Connection LED
Solid green. The switch is powered on.
Solid amber. The switch is starting.
Off. Power is not supplied to the switch.
Power LED
Solid green. The fan is operating normally.
Solid amber. A problem occurred with the fan.
Fan LED
Off. No link is established.
Solid green. A valid 1 Gbps link is established.
Blinking green. The port is transmitting or receiving packets at 1 Gbps.
Solid amber. A valid 10 Mbps or 100 Mbps link is established.
Blinking amber. The port is transmitting or receiving packets at 10 Mbps or 100
Mbps.
RJ-45 LED
Link, speed, and activity for
Ethernet ports 1 to 24 (model
GC728X) or 48 (model GC752X)
Hardware Installation Guide17Hardware Overview
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

Table 3. LEDs on the front panel of models GC728X and GC752X (Continued)
DescriptionLED
Off. No SFP module link is established.
Solid green. A valid 1 Gbps link is established.
Blinking green. The SFP fiber port is transmitting or receiving packets at 1 Gbps.
Link/ACT LED
Link and activity for SFP fiber
ports 25F and 26F (model
GC728X) or 49F and 50F (model
GC752X)
Off. No SFP+ module link is established.
Solid amber. A valid 1 Gbps link is established.
Blinking amber. The SFP+ fiber port is transmitting or receiving packets at 1
Gbps.
Solid green. A valid 10 Gbps link is established.
Blinking green. The SFP+ fiber port is transmitting or receiving packets at 10
Gbps.
Link/ACT LED
Link and activity for SFP+ fiber
ports 27F+ and 28F+ (model
GC728X) or 51F+ and 52F+
(model GC752X)
Table 4. LEDs on the front panel of model GC728XP and GC752XP
DescriptionLED
Solid blue. The switch is connected to the cloud server and is set up to be
managed by the NETGEAR Insight app and Insight Cloud portal.
Off. The switch is not connected to the cloud server or is set up to be managed
by the local browser interface.
Cloud Connection LED
Solid green. The switch is powered on.
Solid amber. The switch is starting.
Off. Power is not supplied to the switch.
Power LED
Off. Sufficient (more than 7W of) PoE power is available.
Solid amber. Less than 7W of PoE power is available.
Blinking amber. At least once during the previous two minutes, less than 7W of
PoE power was available.
PoE Max/Fault LED
Solid green. The fan is operating normally.
Solid amber. A problem occurred with the fan.
Fan LED
Off. No link is established.
Solid green. A valid 1 Gbps link is established.
Blinking green. The port is transmitting or receiving packets at 1 Gbps.
Solid amber. A valid 10 Mbps or 100 Mbps link is established.
Blinking amber. The port is transmitting or receiving packets at 10 Mbps or 100
Mbps.
RJ-45 Left LED
Link, speed, and activity for
Ethernet ports 1 to 24 (model
GC728XP) or 48 (model
GC752XP)
Hardware Installation Guide18Hardware Overview
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

Table 4. LEDs on the front panel of model GC728XP and GC752XP (Continued)
DescriptionLED
Off. The port is not delivering PoE power.
Solid green. The port is delivering PoE power.
Solid amber. A PoE fault occurred.
RJ-45 right LED
Off. No SFP module link is established.
Solid green. A valid 1 Gbps link is established.
Blinking green. The SFP fiber port is transmitting or receiving packets at 1 Gbps.
Link/ACT LED
Link and activity for SFP fiber
ports 25F and 26F (model
GC728XP) or 49F and 50F
(model GC752XP)
Off. No SFP+ module link is established.
Solid amber. A valid 1 Gbps link is established.
Blinking amber. The SFP+ fiber port is transmitting or receiving packets at 1
Gbps.
Solid green. A valid 10 Gbps link is established.
Blinking green. The SFP+ fiber port is transmitting or receiving packets at 10
Gbps.
Link/ACT LED
Link and activity for SFP+ fiber
ports 27F+ and 28F+ (model
GC728XP) or 51F+ and 52F+
(model GC752XP)
Back Panel
The back panel contains a Kensington lock for an optional security cable and an AC
power connector. All models integrate an internal power supply, require AC power,
and come with a power cord.
The back panels for models GC728X, GC728XP, and GC752X are identical.
Note: The maximum current draw varies between the models from 1A to 10A.
Figure 5. Back panel models GC728X, GC728XP, and GC752X
The back panel for model GC752XP differs from the other models.
Figure 6. Back panel model GC752XP
Hardware Installation Guide19Hardware Overview
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch

Switch Hardware Interfaces
The following sections describe the hardware interfaces on the switch.
RJ-45 Ports for 10/100/1000M BASE-T Ethernet Connectivity
All RJ-45 copper ports support autosensing. When you insert a cable into an RJ-45 port,
the switch automatically ascertains the maximum speed (10 Mbps, 100 Mbps, or 1 Gbps)
and duplex mode (half-duplex or full-duplex) of the attached device. All ports support
a Category 5e (Cat 5e) cable (or higher-rated Ethernet cable) terminated with an 8-pin
RJ-45 connector.
To simplify the procedure for attaching devices, all RJ-45 ports support Auto Uplink
technology. This technology allows attaching devices to the RJ-45 ports with either
straight-through or crossover cables.
When you insert a cable into the switch’s RJ-45 port, the switch automatically performs
the following actions:
•Senses whether the cable is a straight-through or crossover cable.
•Determines whether the link to the attached device requires a normal connection
(such as when you are connecting the port to a computer) or an uplink connection
(such as when you are connecting the port to a router, switch, or hub).
•Automatically configures the RJ-45 port to enable communications with the attached
device. The Auto Uplink technology compensates for setting uplink connections
while eliminating concern about whether to use crossover or straight-through cables
when you attach devices.
All RJ-45 copper ports on model GC728XP and model GC752XP support Power over
Ethernet (PoE+).
Hardware Installation Guide20Hardware Overview
Insight Managed 28-Port and 52-Port Gigabit Ethernet (PoE+) Smart Cloud Switch
