netvox R718NL3 Series User manual

Model：R718NL3
Wireless Light Sensor and 3-Phase Current Meter
Wireless Light Sensor and
3-Phase Current Meter
R718NL3
User Manual

1
Table of Content
1. Introduction.......................................................................................................................................................................................2
2.Appearance........................................................................................................................................................................................2
3. Main Features ...................................................................................................................................................................................3
4. Set up Instruction..............................................................................................................................................................................4
5. Data Report.......................................................................................................................................................................................5
6. Installation ........................................................................................................................................................................................8
7. Information about Battery Passivation.............................................................................................................................................9
7.1 To determine whether a battery requires activation..................................................................................................................9
7.2 How to activate the battery.......................................................................................................................................................9
8. Important Maintenance Instruction ..................................................................................................................................................9

2
1. Introduction
The R718NL3 series is a Light Sensor and 3-Phase Current Meter device for Netvox ClassA type devices based on the LoRaWAN open protocol and is
compatible with the LoRaWAN protocol. R718NL3 series have different measuring range for different variety of CT.
It is divided into:
R718NL3 Wireless Light Sensor and 3-Phase Current Meter with 3 x 50A Solid Core CT (Range:1A-50A ±1%)
R718NL37 Wireless Light Sensor and 3-Phase Current Meter with 3 x 75AClamp-On CT (Range:1A-75A ±1%)
R718NL315 Wireless Light Sensor and 3-Phase Current Meter with 3 x 150A Clamp-On CT (Range:1A-150A ±1%)
R718NL325 Wireless Light Sensor and 3-Phase Current Meter with 3 x 250A Clamp-On CT (Range:1A-250A ±1%)
R718NL363 Wireless Light Sensor and 3-Phase Current Meter with 3 x630A Clamp-On CT (Range:10A-630A ±1%)
*The current is lower than the current measurement range, it will report 0 A
LoRa Wireless Technology:
LoRa is a wireless communication technology famous for its long-distance transmission and low power consumption. Compared with other
communication methods, LoRa spread spectrum modulation technique greatly extend the communication distance. It can be widely used in any use
case that requires long-distance and low-data wireless communications. For example, automatic meter reading, building automation equipment,
wireless security systems, industrial monitoring. It has features like small size, low power consumption, long transmission distance, strong
anti-interference ability and so on.
LoRaWAN:
LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and gateways from different
manufacturers.
2. Appearance
Light Sensor
Indicator
Function Key
CT

3
3. Main Features
Compatible with LoRaWAN protocol
2 sections ER14505 3.6V Lithium AA battery
Current detection
Illuminance detection (3 Lux- 220k Lux)
Protection level : Main body IP53, Sensor IP30
Compatible with LoRaWANTM Class A
Frequency hopping spread spectrum technology
Configuration parameters can be configured through third-party software platforms, data can be read and alarms can be set via SMS text and email
(optional)
Available third-party platform: Actility / ThingPark, TTN, MyDevices/Cayenne
Low power consumption and long battery life
Note:
Battery life is determined by the sensor reporting frequency and other variables, please refer to http://www.netvox.com.tw/electric/electric_calc.html
On this website, users can find battery life time for varied models at different configurations.

4
4. Set up Instruction
On/Off
Power on Insert batteries. (users may need a flat blade screwdriver to open)
Turn on Press and hold the function key for 3 seconds till the green indicator flashes once.
Turn off (Restore to factory setting) Press and hold the function key for 5 seconds till green indicator flashes for 20 times.
Power off Remove Batteries.
Note
1.The device will be off after removing the battery and insert it again.
2.It is suggested to wait for at least 10 seconds between turning the device on and off.
3.At 1st -5th second after power on, the device will be in engineering test mode.
Network Joining
If the device has never joined the
network
Turn on the device, and it will search for the network to join.
The green indicator light stays on for 5 seconds: joins the network successfully
The green indicator light remains off: fail to join the network
If the device has joined the network
and it is not set to default
Turn on the device, and it will search for the previous network to join.
The green indicator light stays on for 5 seconds: joins the network successfully
The green indicator light remains off: fail to join the network
If the device fails to join the network
(when the device is turned on)
For the first two minutes: the device will wake up every 15 seconds to send a join request.
After two minutes: the device will enter sleep mode and wake up every 15 minutes to send a join request.
Note: It is suggested to remove the batteries if the device is not in use to save power.
It is suggested to check the device verification information on the gateway
or consult your platform server provider when the device fails to join the network.
Function Key
Press the function key and hold the
pressing for 5 seconds
The device will be set to default and turned off
The green indicator light flashes for 20 times: success
The green indicator light remains off: fail
Press the function key once The device is in the network: green indicator light flashes once and sends a report
The device is not in the network: green indicator light remains off
Sleeping Mode
The device is turned on and in the
network
Sleep period: Min Interval.
When the reportchange exceeds setting value or the state changes: send a data report according to Min Interval.
The device is turned on but not in
the network
First two mins: wake up every 15 seconds to send request.
After two mins: enter sleeping mode and wake up every 15 minutes to send request.
Note: Suggest to remove batteries if the device is not used.
Suggest to check device verification on gateway.
Low Voltage Warning
Low Voltage 3.2V

5
5. Data Report
Data report configuration and sending period are as following:
Min. Interval
(Unit:second)
Max. Interval
(Unit:second) Reportable Change Current Change≥ Reportable Change
Current Change＜
Reportable Change
Any number between
30~65535
Any number between
Min.~65535 Can not be 0. Report per Min. Interval
Report
per Max. Interval
The device will immediately send a version packet report along with an uplink packet including current,illuminance and battery voltage.
The device sends data in the default configuration before any configuration is done.
Default setting:
Maximum time: Max Interval =15 min (900 s)
Minimum time: Min Interval =15 min (900 s) *Please configure more than 30 seconds
CurrentChange:0x0064 (100 mA)
IlluminanceChange: 0x0064 (100 Lux)
Light sensor support 3 ranges of Illuminance:
0x00, 3~65000 Lux (default)
0x01, 3~130000 Lux
0x02, 3~220000 Lux
Note:
(1) The device report interval will be programmed based on the default firmware which may vary.
(2) The interval between two reports must be the minimum time.
(3) If MinTime configuration less than 30 seconds, it will configure 30 seconds.
(4) R718NL3 series would take about 15 seconds for the CT to sample and process the collected value, If the current changes frequently, the
sampling result might be wrong.
Please refer Netvox LoRaWAN Application Command document and Netvox Lora Command Resolver http://www.netvox.com.cn:8888/page/index to
resolve uplink data.

6
Example of Report configuration
FPort：0x07
Bytes 1 Byte 1 Byte Var(Fix =9 Bytes)
CmdID DeviceType NetvoxPayLoadData
CmdID– 1 byte
DeviceType– 1 byte – Device Type of Device
NetvoxPayLoadData– var bytes (Max=9bytes)
(1) Configure report parameters MinTime = 1min, MaxTime = 1min, CurrentChange = 100mA, IlluminanceChange = 100Lux
Downlink: 0199003C003C0064006400
The device returns:
8199000000000000000000 (Configuration succeeded)
8199010000000000000000 (Configuration failed)
(2) Read device configuration parameters
Downlink: 0299000000000000000000
The device returns:
8299003C003C0064006400 (current device configuration parameters)
Example for MinTime/MaxTime logic
Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange=0.1V
MaxTime MaxTime
Sleeping(MinTime) Sleeping(MinTime)
Note: MaxTime=MinTime. Data will only be report according to MaxTime (MinTime) duration regardless BatteryVoltageChange value.
Description Device CmdID Device
Type NetvoxPayLoadData
ConfigReportReq
R718NL3
0x01
0x99
MinTime
(2bytes Unit:s)
MaxTime
(2bytes Unit:s)
CurrentChange
(2byte Unit:1mA)
Illuminancechange
(2bytes Unit:1Lux)
Reserved
(1Bytes,Fixed 0x00)
ConfigReportRsp 0x81 Status
(0x00_success)
Reserved
(8Bytes,Fixed 0x00)
ReadConfig
ReportReq 0x02 Reserved (9Bytes,Fixed 0x00)
ReadConfig
ReportRsp 0x82 MinTime (2bytes Unit:s)
MaxTime
(2bytes Unit:s)
CurrentChange
(2byte Unit:1mA)
Illuminancechange
(2bytes Unit:1Lux)
Reserved
(1Bytes,Fixed 0x00)
Wake up and collects data
REPORTS 3.6V
Wakes up and collects data
REPORTS 3.6V
Wakes up and collects data
REPORTS 3.6V

7
Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.
MaxTime
Sleeping(MinTime) sleeping sleeping sleeping
0H 15th M 30th M 45th M 1H 2H
Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.
MaxTime
sleeping sleeping ...
0H 15th M 30th M 45th M 1H 1H 10th M 1H 25th M 1H 40th M 1H 55th M 2H 10th M
Notes :
1) The device only wakes up and performs data sampling according to MinTime Interval. When it is sleeping, it does not collect data.
2) The data collected is compared with the last data reported. If the data variation is greater than the ReportableChange value, the device reports
according to MinTime interval. If the data variation is not greater than the last data reported, the device reports according to MaxTime interval.
3) We do not recommend to set the MinTime Interval value too low. If the MinTime Interval is too low, the device wakes up frequently and the
battery will be drained soon.
4) Whenever the device sends a report, no matter resulting from data variation, button pushed or MaxTime interval, another cycle of
MinTime/MaxTime calculation is started.
Wakes up and
collects data
3.6V
Does not report
Wakes up and
collects data
3.6V
Does not report
Wakes up and
collects data
3.6V
Does not report
Wakes up and
collects data
REPORTS 3.6V
Wakes up and
collects data
REPORT 3.6V
Wakes up and
collects data
REPORTS 3.6V
Wakes up and collects data
3.5V |3.5-3.6|=0.1
REPORTS 3.5V
Wakes up and
collects data
3.5V
Does not report
Wakes up and
collects data
3.5V
Does not report
Wakes up and
collects data
3.5V
Does not report
Wakes up and
collects data 3.5V
Does not report
Wakes up and
collects data
3.5V
Does not report
Wakes up and
collects data
REPORTS 3.5V
Wakes up and
collects data
3.6V
Does not report
Users push the button,
REPORTS 3.5V.
Recalculate MaxTime.

8
6. Installation
This product comes with waterproof function.
When using it, the back of it can be adsorbed on the iron surface, or the two ends can be fixed to the wall with screws.
When installing the current transformer, separate the fire and neutral wires, and take out the fire wire separately and start the measurement according to
the wiring below.
Note:
Please do not disassemble the device unless it is required to replace the batteries.
Do not touch the waterproof gasket, LED indicator light, function keys when replacing the batteries. Please use suitable screwdriver to tighten the
screws (if using an electric screwdriver, it is recommended to set the torque as 4kgf) to ensure the device is impermeable.

9
7. Information about Battery Passivation
Many of Netvox devices are powered by 3.6V ER14505 Li-SOCl2 (lithium-thionyl chloride) batteries that offer many advantages including low
self-discharge rate and high energy density.
However, primary lithium batteries like Li-SOCl2 batteries will form a passivation layer as a reaction between the lithium anode and thionyl chloride
if they are in storage for a long time or if the storage temperature is too high.
This lithium chloride layer prevents rapid self-discharge caused by continuous reaction between lithium and thionyl chloride, but battery passivation
may also lead to voltage delay when the batteries are put into operation, and our devices may not work correctly in this situation. As a result, please
make sure to source batteries from reliable vendors, and the batteries should be produced within the last three months.
If encountering the situation of battery passivation, users can activate the battery to eliminate the battery hysteresis.
7.1 To determine whether a battery requires activation
Connect a new ER14505 battery to a 68ohm resistor in parallel, and check the voltage of the circuit.
If the voltage is below 3.3V, it means the battery requires activation.
7.2 How to activate the battery
a. Connect a battery to a 68ohm resistor in parallel
b. Keep the connection for 6~8 minutes
c. The voltage of the circuit should be ≧3.3V
8. Important Maintenance Instruction
Kindly pay attention to the following in order to achieve the best maintenance of the product:
• Keep the device dry. Rain, moisture, or any liquid, might contain minerals and thus corrode electronic circuits. If the device gets wet, please dry it
completely.
• Do not use or store the device in dusty or dirty environment. It might damage its detachable parts and electronic components.
• Do not store the device under excessive heat condition. High temperature can shorten the life of electronic devices, destroy batteries, and deform or
melt some plastic parts.
• Do not store the device in places that are too cold. Otherwise, when the temperature rises to normal temperature, moisture will form inside, which will
destroy the board.
• Do not throw, knock or shake the device. Rough handling of equipment can destroy internal circuit boards and delicate structures.
• Do not clean the device with strong chemicals, detergents or strong detergents.
• Do not apply the device with paint. Smudges might block in the device and affect the operation.
• Do not throw the battery into the fire, or the battery will explode. Damaged batteries may also explode.
All of the above applies to your device, battery and accessories. If any device is not working properly, please take it to the nearest authorized service
facility for repair.
