Network Technologies ST-C5USBD-250 User manual

MAN087 Rev Date 10/22/2009
ST-C5USBD-250
250 FOOT DVI and USB Extender via
CAT5e/6
Installation and Operation Manual
XTENDE
X
®Series

i
TRADEMARK
XTENDEX is a registered trademark of Network Technologies Inc in the U.S. and other countries.
COPYRIGHT
Copyright © 2009 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
CHANGES
The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the
right to make changes in the product design without reservation and without notification to its users.

ii
TABLE OF CONTENTS
Introduction......................................................................................................................................................................1
Materials..........................................................................................................................................................................1
Features and Functions...................................................................................................................................................2
Installation .......................................................................................................................................................................3
Connecting The Local Unit ..........................................................................................................................................3
Connecting The Remote Unit ......................................................................................................................................4
Operating Instructions.....................................................................................................................................................5
Interconnection Cable Wiring Method.............................................................................................................................5
Technical Specifications..................................................................................................................................................6
Troubleshooting...............................................................................................................................................................6
Warranty Information.......................................................................................................................................................7
TABLE OF FIGURES
Figure 1- Local Unit CPU connections...............................................................................................................................................3
Figure 2- Local Unit power and CATx connections............................................................................................................................3
Figure 3- Remote Unit connections ...................................................................................................................................................4

NTI 250 FOOT USB AND DVI VIDEO EXTENDER
1
INTRODUCTION
The ST-C5USBD-250 (XTENDEX) USB Extender with DVI Video extends four USB devices and a single link DVI-D monitor up to
250 feet via two CAT5e/6/7 solid UTP cables. Each USB extender consists of a Local Unit that connects to a computer, and a
Remote Unit that connects to four USB devices and a monitor.
Features:
•Supports fully transparent USB connections –able to support all common hardware platforms including PC, SUN and
MAC and their associated peripherals.
•Extend devices such as keyboards, mice, printers, game controllers, USB flash drives, touch screen monitors,
whiteboards, etc.
•Supports computer resolutions to 1920x1200.
•Compliant with USB 2.0 specifications (low speed and full speed USB devices supported).
•Supports Plug-n-Play specification.
•Built in default EDID configuration table.
Local Unit
•Supports USB computers (PC, SUN and MAC) with DVI-D video.
•Multiplatform support: Windows 2000/XP/Vista/Windows 7/Server 2000/2003/2008, Solaris, Linux, FreeBSD,
and MAC OS 9/10
•One female DVI-D and one female USB Type B connectors.
Remote Unit
•One female DVI-D and four female USB Type A connectors.
•Supports low-speed and full-speed USB devices.
•Supports resolutions to 1920x1200.
MATERIALS
Materials supplied with this kit:
•NTI ST-C5USBD-250 Local Unit
•NTI ST-C5USBD-250 Remote Unit
•Two 90 - 240VAC @ 47 - 63Hz-5VDC/4A AC Adapters
•This manual
Materials Not supplied but REQUIRED:
¾CAT5e/6/7 solid unshielded twisted-pair cable(s) terminated with RJ45 connectors wired straight thru- pin 1 to pin 1, etc. (see
pg. 5 for proper EIA/TIA 568 B wiring method)
¾DVI male-male cables to connect the monitor to the Remote Unit and the computer to the Local Unit (Order NTI # DVI-IS-xx-
MM where x=3, 6, or 10 foot cable). Both DVI-I and DVI-D type cables can be used for this connection.
¾USB A-B cable to connect the USB port of the computer to the Local Unit (Order NTI # USB-AB-xM where x=1,2,3 or 5
meters)
Cables can be purchased from Network Technologies Inc by calling [phone] (800-RGB-TECH) in the US and Canada or
[phone] (worldwide).

NTI 250 FOOT USB AND DVI VIDEO EXTENDER
2
FEATURES AND FUNCTIONS
1. DVI Video In- DVI Female- for connecting cable from DVI video source
2. Power Connector- for connecting AC adapter
3. Pwr- LED for indicating the power is ON
4. USB CATx- RJ45 Female- for connecting CAT5e/6/7 cable from Remote Unit “USB CATx” connector
5. TxRx- LED for indicating communication through the USB CATx cable
6. USB CPU- USB Type B Female- for connecting a USB cable from a CPU for devices to be extended
7. DVI CATx-RJ45 Female- for connecting CAT5e/6/7 cable from Remote Unit “DVI CATx” connector
8. DVI Monitor - DVI Female- for connecting cable from DVI display
9. USB Pwr- LED for indicating that the USB ports are powered ON
10. USB DEVICES- USB Type A Female- for connecting supported USB devices
11. USB CATx- RJ45 Female- for connecting CAT5e/6/7 cable from Local Unit “USB CATx” connector
12. DVI CATx-RJ45 Female- for connecting CAT5e/6/7 cable from Local Unit “DVI CATx” connector
RJ45
"<USB>"
RJ45
"<USB>"
RJ45
"<USB>"
USB
TYPEB
RJ45
"<DVI>"
RJ45
"<USB>"
123 456 7
12
11 5
823 910
ST-C5USBD-250
LOCAL UNIT
FRONT VIEW
FRONT VIEW REAR VIEW
REAR VIEW
ST-C5USBD-250
REMOTE UNIT

NTI 250 FOOT USB AND DVI VIDEO EXTENDER
3
INSTALLATION
Connecting The Local Unit
1. Connect the Local Unit to the computer using an A-B USB cable. Connect the Type A connector to the computer and the
Type B connector end to the Local Unit at “USB CPU”.
2. Connect the Local Unit to the DVI-D port on the computer using a male-to-male single-link DVI cable.
Figure 1- Local Unit CPU connections
3. Connect an AC adapter to the power connector on the Local Unit and connect to power source. Check that power LED is lit.
The TX/RX LED should not be flashing at this time.
4. Connect a CAT5e/6/7 cable to the “DVI-CATx” connector, and another to the “USB-CATx” connector.
Figure 2- Local Unit power and CATx connections
CPU
RJ45
"<USB>"
USB
TYPEB
USB Type A Male
USB Type B
Male
USB-AB-xM
(Sold Separately)
DVI-D-MM-S-2M
(Sold Separately)
Mating Face of
DVI-I Male
ST-C5USBD-250 LOCAL UNIT
(Front View)
RJ45
"<USB>"
USB
TYPEB
ST-C5USBD-250 LOCAL UNIT
(Front View)
5VDC
ADAPTER
RJ45
"<DVI>"
RJ45
"<USB>"
ST-C5USBD-250 LOCAL UNIT
(Rear View)
RJ45
Connector
CAT5e/6/7 Cable
to Remote Unit
"DVI CATx"
RJ45
Connector
CAT5e/6/7 Cable
to Remote Unit
"USB CATx"

NTI 250 FOOT USB AND DVI VIDEO EXTENDER
4
Connecting The Remote Unit
1. Connect an AC adapter to the power connector on the Remote Unit and connect to power source. Check that power LED is lit.
The TX/RX LED should not be flashing at this time.
2. Connect the Remote Unit to a peripheral device using a USB A-B cable. The USB Type A connector will connect to any of the 4
USB Type A female ports on the Remote Unit. The USB Type B connector will connect the peripheral device.
3. Connect the Remote Unit to a DVI video display. The DVI cable from the display will connect to the DVI port on the Remote
Unit.
4. Connect the CAT5e/6/7 cables from the Local Unit to the same-named ports on the Remote Unit (“DVI CATx” to “DVI CATx”,
and “USB CATx” to “USB CATx” ). Once connected check that the Power LED on both receiver and transmitter is ON and
the “Tx/Rx” LEDs are both flashing, indicating that communication exists between the two units.
Figure 3- Remote Unit connections
Digital
Multi-Scan
Monitor
(Front View)
DVI-D Cable
Remote User Display
ST-C5USBD-250 Remote Unit
USB CAMERA
USB Keyboard USB MOUSE
5VDC
ADAPTER
CAT5e/6/7 Cable
to Local Unit
"DVI CATx"
CAT5e/6/7 Cable
to Local Unit
"USB CATx"
RJ45
"<USB>"
RJ45
"<USB>"
(Rear View)
ST-C5USBD-250 Remote Unit
USB Type A Male
Mating Face of
DVI-I Male
RJ45
Connector

NTI 250 FOOT USB AND DVI VIDEO EXTENDER
5
OPERATING INSTRUCTIONS
Once installation is completed verify that the power is present at all devices in the system. If the computer was ON during the set
up it might be necessary to reboot the computer. The display should react as if it were directly connected to the computer.
The USB peripheral devices should be ready for use. The “USB PWR” LED should be illuminated if the USB ports are powered
ON.
INTERCONNECTION CABLE WIRING METHOD
The connection cable between the remote and local is terminated with RJ45 connectors and must be wired according to the
EIA/TIA 568 B industry standard. Wiring is as per the table and drawing below.
Pin Wire Color Pair Function
1 White/Orange 2 T
2 Orange 2 R
3 White/Green 3 T
4 Blue 1 R
5 White/Blue 1 T
6 Green 3 R
7 White/Brown 4 T
8 Brown 4 R
Distances and Resolutions for CAT5e/CAT6 and CAT7 solid wire Cables
Unshielded Twisted Pair (UTP) and Shielded Twisted Pair (STP)
UTP CABLE DISTANCE (feet) RESOLUTION
100 1920x1200 at 60Hz
150 1280x1024 at 60Hz
200 1024x768 at 60Hz
CAT5e UTP
230 1024x768 at 60Hz
100 1920x1200 at 60Hz
150 1920x1200 at 60Hz
CAT6 UTP
200 1600x1200 at 60Hz
100 1920x1200 at 60Hz
150 1920x1200 at 60Hz
200 1600x1200 at 60Hz
550 MHz
CAT6 UTP
250 1024x768 at 60Hz
100 1280x1024 at 60Hz
150 1280x1024 at 60Hz
CAT6 STP
200 1280x1024 at 60Hz
150 1920x1200 at 60HzCAT7 STP 200 1920x1200 at 60Hz
For best results, CAT6 550 MHz UTP solid cable is recommended.
T
1
+
R
2
-
T
3
+
R
4
-
T
5
+
R
6
-
T
7
+
R
8
-
Pair 2 Pair 1 Pair 4
Pair 3

NTI 250 FOOT USB AND DVI VIDEO EXTENDER
6
TECHNICAL SPECIFICATIONS
Models with VGA Video
Video Compatibility DVI-D Single-link
Video Connectors DVI-I Female
USB Connector Type USB Type B (Local)
USB Type A (x4) (Remote)
Video Data Rate 1.65 Gbps
Resolution 1920 x 1200 @ 60 Hz
USB max data rate 12Mbps
USB compatibility 2.0 (low speed and full speed devices)
General
Interconnect Cable CAT5e/6/7 Solid STP/UTP EIA/TIA 568 B wiring w/ male RJ45 connectors
Remote and Local Unit Power 90-240VAC at 50 or 60Hz-5VDC/4.0A via AC Adapters (2)
Dimensions WxDxH (In.) (Loca and Remotel ) 5.5x3.5x.1
TROUBLESHOOTING
Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting specifications. We
make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this
product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise. If the
answer is not found in the chart, please check the FAQs (Frequently Asked Questions) at our website at
http://www.networktechinc.com or contact us directly for help at 1-800-742-8324 (800-RGB-TECH) in US & Canada or 1-330-562-
7070 worldwide. We will be happy to assist in any way we can.
Problem Cause Solution
No Video •Video Cable not connect properly
•No Power
•Monitor connected after computer
was booted
•Check all cable connections
•Check power supplies. Power LEDs should be
illuminated
•Reboot the computer
No USB support USB or USB CATx cables are not
connected properly Check all cable connections
No USB and no Video USB and DVI CATx cables are
connected to opposite ports Make sure CATx cables are between same-named ports (“DVI CATx” and “USB CATx”)

NTI 250 FOOT USB AND DVI VIDEO EXTENDER
7
WARRANTY INFORMATION
The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network
Technologies Inc at [phone] (800-RGB-TECH) or [phone] or visit our website at http://www.networktechinc.com
for information regarding repairs and/or returns. A return authorization number is required for all repairs/returns.
MAN087 Rev. 10/22/09
PRODUCT: ST-C5USBD-250
SERIAL NO.:
DATE: INSPECTED BY:
