LS120, LS125 REPAIR MANUAL
CONTENTS
SECTION 00 -GENERAL INFORMATION
SECTION 10 -ENGINE
SECTION 29 -HYDROSTATIC TRANSMISSION
SECTION 33 -BRAKES AND CONTROLS
SECTION
35
-HYDRAULIC SYSTEM
SECTION 39 -FRAMES
SECTION 44 -AXLES AND WHEELS
SECTION 55 -ELECTRICAL SYSTEM
SECTION
82
-FRONT LOADER (BOOM AND MOUNTING PLATE)
SECTION 90 -PLATFORMS AND DECALS
The
sections
used
through
out
all New Holland
product
Repair manuals
may
not
beused
for
each product. Each Repairmanual
will
bemade
up
of
one
or
several books. Each
book
will
be labeled as
to
which
sections
are
in the overall Repair manual and
which
sections
are in each book.
The
sections
listed above are
the
sections
utilized
for
the LS120, LS125
Skid Steer.
© 2000
NEW
HOLLAND
NORTH
AMERICA,
INC.
..
Find manuals at https://best-manuals.com
Section
00 000
SECTION
00
-GENERAL INFORMATION
Chapter 1 - General Information
CONTENTS
Description Page
Introduction
.................................................................
00-2
About Improvements
.........................................................
00-2
Company Policy
.............................................................
00-3
Parts and Accessories
........................................................
00-3
Model Codes
................................................................
00-3
Precautionary Statements
.....................................................
00-4
Safety Precautions
...........................................................
00-5
General Safety Information
....................................................
00-7
Hardware Torque Specifications
...............................................
00-9
Installation
of
Adjustable Fittings in Straight Thread O Ring Bosses
...............
00-11
Hydraulic Tube and Fitting Information
.........................................
00-11
Pipe Thread Fitting Torque
........
'.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 00-12
Lubricants and.Coolants . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 00-12
Sealants
...........................................................
•.
. . . . . . 00-12
Machine Model and Serial Number Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 00-13
Properly Support a Raised Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 00-14
Properly Support Boom On Boom Lock Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 00-14
Raising Boom Without Hydraulic Oil Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 00-15
Raising Boom Without BatteryVoltage (12 Volts)
.............
;
.................
00-16
Reattaching Cylinders After Repair With Boom Resting On Boom Lock Pins . . . . . . . 00-18
Loading and Tie Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 00-19
Special Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 00-21
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 00-22
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 00-27
00-1
Find manuals at https://best-manuals.com
SECTION 00 -GENERAL INFORMATION
INTRODUCTION
This repair manual provides the technical informa-
tion needed to properly service and maintain the
Models LS120 and LS125 skid steers. Use it
in
conjunction with the operator's manual which is
supplied with the skid steer. Keep both manuals
available for ready reference.
The LS120 and LS125 have many similarities with
the major differences being engine horsepower and
lifting capacity.
Whenever working on New Holland equipment, left
and right sides of the machine are determined by
standing behind the unit, looking in the direction
of
travel.
The easiest and least time-consuming removal,
disassembly, and reassembly procedures are
detailed
in
the manual. Modifying these procedures
i~
not recommended.
NewHolland skid steersaredesigned with emphasis
on safety for operator protection. However, careless
and negligent operation can still result
in
serious
injury to persons or damage to property. Be sure to
read and follow all safety instructions
in
this manual.
Your New Holland dealer is interested
in
your
obtaining the most from your investment and will be
glad to answer any questions you may have about
yourskid steer. When majorservice is required, your
dealer's staff oftrained service technicians is ready
to serve you.
00-2
When in need of parts, always order genuine
New
Holland service partsfrom your New Holland dealer.
Be prepared to give your dealerthe model and serial
number
of
the engine and skid steer (the location
of
these numbers is described later
in
this section).
Record the serial numbers here:
Skid Steer Model ·
Skid Steer Serial Number
Engine Model
Engine Serial Number
A CAUTION A
This symbol
is
used throughout
this
book
whenever your
own
personal safety
is
involved.
Take
time to
be
careful!
ABOUT
IMPROVEMENTS
New Holland is continually striving to improve
its
products. We must, therefore, reserve the right to
make improvements or changes when it becomes
practical and possibleto do so, without incurring
any
obligation to make changes or additions to the
equipment sold previously.
ALL
SPECIFICATIONS
ARE
SUBJECT TO
CHANGE WITHOUT NOTICE.
Find manuals at https://best-manuals.com
SECTION 00 -GENERAL INFORMATION
COMPANY POLICY
Company policy, which is one
of
continuous improvement, reserves the right to make changes in design and
specifications at any time without notice and without obligation to modify units previously built.
All datagiven in this book is subjectto production variations. Dimensions and weights areapproximate onlyand
the illustrations do not necessarily show skid steers in standard condition.
PARTS AND ACCESSORIES
Genuine
NEW
HOLLAND parts and accessories have been specifically designed for HEW HOLLAND
MACHINES.
We would like to point outthat "NON-GENUINE" parts and accessories have not been examined and released
by
NEW
HOLLAND. The installation and
or
use
of
such products could have negative effects upon the design
characteristics
of
yourmachineandtherebyaffectitssafety. NEWHOLLANDis notliableforanydamagecaused
by the use
of
"NON-GENUINE" NEW HOLLAND parts and accessories.
MODEL CODES
Therange
of
Skid Steersdescribed in this manual is identified in thetextbytheenginehorsepowerPferdestarke.
(PS}. The skid steers listed below may not be available in all countries
or
markets.
ENGINE PS MODEL
P218 18.0 LS120
E673 16.5 LS125
00-3
Find manuals at https://best-manuals.com
SECTION 00 -GENERAL INFORMATION
PRECAUTIONARY STATEMENTS
PERSONAL SAFETY
Throughoutthis manual and on machinedecals, you
will
find precautionary statements ("CAUTION",
"WARNING", and
"DANGER")
followed by specific
instructions. These precautions are intended for the
personal safety
of
you and those working with you.
Please take the time to read them.
A CAUTION A
The word "CAUTION" is used where a safe
behavioral practice according to operating and
maintenance instructions and common safety
practices will protect the operator and others
from accident involvement.
A WARNING A
The word "WARNING" denotes a potential
or
hidden hazard which has a potential
for
serious
lniury.
It
is
used
to
warn operators and others
to
exercise every appropriate means
to
avoid a
surprise involvementwith machinery.
A DANGER A
The word "DANGER" denotes a forbidden
practice in connection with a serious hazard.
FAILURE TO FOLLOW THE "CAUTION",
"WARNING",
AND
"DANGER"
INSTRUCTIONS
MAY RESULT IN SERIOUS BODILY INJURY OR
DEATH.
00-4
MACHINE SAFETY
Additional precautionary statement ("IMPORTANT')
is followed by specific instructions. This statement is
intended for machine safety.
IMPORTANT:
The word "IMPORTANT' is used to
inform the reader
of
something he needs
to
knowto
prevent minor machine damage
if
a certain
procedure is notfollowed.
Find manuals at https://best-manuals.com
SECTION 00 -GENERAL INFORMATION
SAFETY PRECAUTION INFORMATION
A CAUTION A
Unsafe operating practices and improperuse
of
the skid steerand
its
attachments on the part
of
the operator can result in injuries. Observe the
following safety precautions at all times:
1.
For servicing, the skid steer should be on level
terrain, engine stopped with the wheels blocked
or
the entire skid steer solidly supported with
the wheels offthe ground before servicing any
component
of
the drive train.
2.
For servicing under the operator's seat,
remove the seat and pan assembly from the
skid steer.
3. Do
not
operate the skid steer unlesstheseat
is
in the operate position.
4.
Do
not
service the skid steer with a raised
boom unless the boom
is
resting on the
boom
lock
pins.
5.
Do
not
servicethe skid steerwith theengine
running unlessthe skid steer
is
properlyand
securely supported with all four wheels
off
the ground.
6.
Reinstall all shields removed
for
service.
7.
Never loosen any hydraulic connections
beforerelievingthepressureinthe hydraulic
system.
8. Wear eye protection such as goggles, etc
..
9.
Wear
ear protection such as ear plugs etc.
When
you feel
·the
noise level is uncomfortable.
10. If any servicing
or
adjustments require the
battery
to
be disconnected, disconnect the
(-)
negative ground cable.
11.
When servicing electrical components, dis-
connect
the(-)
negative ground cable.
12.
If
theelectricalcomponentsrequiresremoval
from the skid steer disconnect the
(-)
negative ground batterycable. This will
shut
off
power
to
theelectricalsystemandprevent
damage
to
the components
if
accidentally
grounded.
13.
If
welding
is
required on the skid steer
disconnect the
(-)
negative ground cable:
Failure
to
disconnect the battery may result
in damage
to
the electrical system and
components.
00-5
14.
If
welding
is
required on an attachment
remove the attachment from the skid steer.
15. Givecompleteand undivided attention
to
the
job
at hand
so
that complete control
of
the
skid steer
is
maintained at all times.
16. Drive
slowly
over rough ground and on
slopes,keepalert
for
holes,ditchesandother
irregularitiesthatmaycausetheskid steer
to
overturn.
17. Avoid steep hillside operation which could
cause the skid steer
to
overturn.
18. Nevertransportaloadedbucketatfullheight.
Operatetheskidsteerwiththeload as
low
as
possible
until
it
becomes necessary
to
raise
the boom
to
discharge the load
into
a
truck
• I
container, etc.
19. Reduce speed when turning
so
there
is
no
danger
of
the skid steer overturning.
20. Neverdrive
up
or
back
up
ahill
or
incline
with
a raised boom
or
the skid steer could over
turn.
21. Always
look
behind you before backing up
the skid steer.
22. Maintain proper transmission oil level
to
prevent loss
of
hydrostatic braking.
23. Do
not
allow passengers
to
ride on the skid
steerat anytime.
24. Do
not
allow children
to
operate the skid
steer
or
ride on the skid steer at anytime.
25. Do
not
allowanyone
to
operatetheskid steer
without proper instruction.
OSHA requires that all operators be
instructed on the proper operation
of
the
machine before they operate the unit.
26. Do
not
operate the skid steer in any position
other than while in the operator's seat with
the seat belt securely fastened.
27. Before starting the engine, be sure
that
all
operating controlsare in neutral and parking
brake is engaged. ·
28. Never operate the skid steer engine
in
a
closedbuildingwithoutadequateventilation.
Find manuals at https://best-manuals.com
SECTION 00 -GENERAL INFORMATION
29.
Refuel the skid steer outdoors with the
engine
shut
off. Replace the fuel cap
securely. Use an approved fuel container.
Do
not
smokewhen handlingfuel. Avoid spilling
fuel.
30. After operating the engine, never touch the
muffler, exhaustpipe, engine
or
radiatoruntil
they have had time
to
cool.
31. Dress appropriately-wear relativelytight-fit-
ting clothing when operating the skid steer.
Loose
or
torn clothing can catch in moving
parts
or
controls.
32. Before servicing the skid steer
or
any
of
its
attached equipment, be sure that the
attachments are lowered
to
the ground
or
that the boom arms are supported
by
the
boom lockpins.
33.
Do
not
work
underoverhangs, electricwires,
or
where there is danger
of
a slide.
34.
Wear an approved safetyhatwhen operating
the machine and while in any
work
area.
35. When driving the skid steer on a road
or
highway, use warning lights
or
warning
devices as may be required
by
local
or
state
government regulations. Headlights, warn-
ing lights and SMV signs are available
through
your
New Holland dealer.
36.
Keep the skid steer clean. Do
not
allow dirt,
debris
or
other articles
to
accumulate in the
cab, floor
or
footcontrol pedal area that may
hinder safe machine operation.
37. Never operate the skid steer with any
of
the
shielding removed.
38.
Never operate the skid steer without win-
dows and/orscreens in place.
39. Never extend any part
of
the bodyoutside
of
the operator's area.
40.
Always properly tie down the skid steer
to
a
truck
or
trailer before transport.
41.
Make sure all bystanders are at a safe
distance away from the skid steer before
starting the engine.
42.
Do
notallowanyone neartheskidsteerwhile
the engine is running and the
skid
steer
is
operational
..
00-6
43.
When using the skid steer
to
crane objects,
do
not
allow any person
to
ride on objects
being craned.
44.
Do
not
use the skid steer as a work platform
for
supporting materials.
45.
Do
not
lift
personnel
or
allow personnel
to
work
whilestanding inthe bucket
or
on other
attachments. This
is
not
a man-lift.
OSHA requirements
now
make
it
the employer's
responsibility
to
fully instruct each operator
in
the proper and safe operation
of
all operative
equipment. Bothemployerand employeeshould
thoroughly familiarize .themselves with the
following sections.
IMPORTANT: Be a safe operator. Before attempting
to
operate the skid
steer,
thoroughly acquaint
yourselfwith:
1.
The
safety information in the operator's
manual
and
the
skid
steer
safetymanual.
2. The operating instructions
in
the operator's
manual.
3.
The controls
on
the
skid
steer
and
their
operation.
A CAUTION A
Some.
pictures in
this
manual show safety
shields removed
or
open
to
show parts being
serviced
or
for
clarity.
All
shields should be
closed
or
replaced
prior
to
operating the
machine. A DANGER A
Fasten seat belt before starting engine!
This skid steer is a very stable unit
but
it
can be
upset
if
stopped suddenly when the bucket is
raised and loaded.
This skid steer is a very stable unit but
it
can be
upset
if
stopped suddenly when the bucket
is
raised and loaded.
Therefore,
do
not
start the engine before
securely fastening the seat belt, and carry the
load low.
Find manuals at https://best-manuals.com
SECTION 00 -GENERAL INFORMATION
GENERAL SAFETY INFORMATION
HANDLE FLUIDS SAFELY
When you work around fuel or other flammable
material, do notsmoke orwork near heaters or other
fire hazards.
Do not store flammable material
in
open containers.
Store flammable fluids away from fire hazards.
Do not incinerate or puncture pressurized contain-
ers.
Make sure machine is clean of dirt, grease, oil, and
debris.
Do not store oily rags; they can ignite and burn
spontaneously.
Keep a first aid kit and fire extinguisher handy.
Keep emergency numbers for doctors, ambulance
service, hospital, and fire department near your
telephone.
USE CARE AROUND HIGH-PRESSURE FLUID
LINES
Escapingfluid underpressurecan penetrate theskin
causing serious injury.
Avoid the hazard by relieving pressure before
disconnecting hydraulic or other lines.
Tighten all line connections before applying
pressure.
00-7
Check for leaks with a piece of cardboard.
Protect hands and body from high-pressure fluids.
Ifan accident occurs, see a doctorimmediately. Any
fluid injectedintotheskin mustbesurgicallyremoved
within a few hours or gangrene may result. Doctors
unfamiliar with this type of injury should reference a
knowledgeable medical source.
AVOID HEATING NEAR PRESSURIZED FLUID
LINES
Flammable spray can be generated by heating near
. pressurized fluid lines, resulting
in
severe burns to
yourself and bystanders.
Do not heat by welding, soldering, or using a torch
near pressurized fluid lines.
Pressurized lines can be accidentally cut or
damaged when heat goes beyond the immediate
flame area.
USE CARE IN HANDLING AND SERVICING
BATTERIES
Prevent Battery Explosions
Keep sparks, lighted matches, and open flame away
from the top ofthe battery. Battery gas can explode.
Nevercheck batterycharge byplacing ametal object
across the posts. Use a voltmeter or hydrometer.
Do notcharge afrozen battery; itmayexplode. Warm
the battery to 16° C (60° F).
A WARNING A
If any servicing or adjustments require the
battery to be disconnected, or welding is
required on the skid steer, disconnect the
(-)
negative ground cable. Failureto disconnectthe
battery
may
result in damage to the restraint
system and other electrical components.
If
welding on an attachment is required, first
remove the attachmentfrom the skid steer boom
attaching plate.
Find manuals at https://best-manuals.com
SECTION 00 -GENERAL INFORMATION
A WARNING A
Starting an engine with a booster battery
requires extreme care as batteries produce
explosive gases. The slightest spark can cause
an
explosion.
Followthese safety tips:
1. Always shield your eyes when charging
or
working near a battery. Always provide good
ventilation.
2.
Cover the battery with a piece
of
carpet
or
other heavy material.
Do
not
remove the
battery vent caps.
3.
Connectonecable
to
the (+) positiveterminal
of
theweak battery. Connectthe otherend
of
the cable to the (+) positive terminal of the
stronger battery.
4. Connect the second cable to the
(-)
negative
terminal of the stronger battery.
5. Connectthe remaining
(-)
negativecable end
to the engine block or starter .ground
terminal.
6. Reverse this procedure when disconnecting
the booster.
USE SAFE SERVICE PROCEDURES
Wear Protective Clothing
Wear close-fitting clothing.
Wear safety glasses orface shield as required:
Wear other safety equipment appropriate to the job.
Wear earplugs or earmuffs as required.
SERVICE MACHINE SAFELY
Use caution when working around moving parts.
If
seNicing requires the boom to be
in
the raised
position, remove any attachment from the boom
mounting plate and support the boom on the boom
lock pins. If servicing requires the complete skid
00-8
steerto be
in
the supported position, supportthe unit
with adequate jack stands or blocking with all four
wheels off the ground.
Ifservicing requires the engine to be operated, raise
the machine and properly support the unit with
adequatejackstands or blocking with all four wheels
off the ground.
--.
A CAUTION A
Before servicing the skid steer or any of its
attached equipment, be sure that the attach-
ments are lowered to the ground or the boom
arms are supported by the boom lock pins.
USE PROPER TOOLS
Use tools appropriate for the job.
REVIEW SAFETY EQUIPMENT, SIGNS AND
SHIELDS
Replace missing or damaged safety decals.
Reinstall all shielding removed for seNicing.
Replace any damaged or missing shielding.
CONTROLS
Operateunitand check machinefunctions for proper
operation.
Check seat belt for proper operation, wear, and
damage -Replace as needed.
Check operator restraint system for proper opera-
tion.
Check boom lock for proper operation.
Check mechanical boom locks for proper operation.
Check parking brake for proper operation and
adjustment.
SECTION 00 -GENERAL INFORMATION
MINIMUM HARDWARE TIGHTENING TORQUES
IN FOOT POUNDS {NEWTON-METERS) FOR NORMALASSEMBLY APPLICATIONS
INCH HARDWARE AND LOCKNUT$
SAEGRADE2
SAEGRADE5
SAE
GRADES
LOCKNUTS
NOMINAL
UNPLATED PLATED UNPLATED PLATED UNPLATED PLATED GR.B GR.C NOMINAL
SIZE
or
W/ZnCr
or
W/ZnCr or W/ZnCr w/GR5 w/GR8 SIZE
PLATED PLATED PLATED BOLT BOLT
SILVER GOLD SILVER GOLD SILVER GOLD
1/4 55* (6.2) 72* (8.1) 86* (9.7) 112* (13) 121* (14) 157* (18) 61* (6.9) 86* (9.8) 1/4
5/16 115* (13) 149* (17) 178* (20) 229* (26) 250* (28) 324* (37)
125*(14)
176* (20) 5/16
3/8 17 (23) 22 (30) 26 (35)
34
(46)
37
(50) 48 (65)
19
(26)
26
(35) 3/8
7/16
27
(37) 35 (47)
42
(57) 54 (73)
59
(80) 77 (104)
30
(41) 42 (57) 7/16
1/2 42 (57) 54 (73) 64 (87) 83 (113)
91
(123) 117 (159) 45 (61) 64 (88) 1/2
9/16 60 (81) 77 (104)
92
(125) 120 (163) 130 (176) 169 (229) 65 (88) 92 (125) 9/16
5/8 83 (112) 107 (145) 128 (174) 165 (224)
180(244)
233 (316)
90
(122) 127 (172) 5/8
3/4 146 (198) 189 (256) 226 (306) 293 (397) 319 (432) 413 (560) 160 (217) 226 (306) 3/4
7/8 142 (193) 183 (248) 365 (495) 473 (641) 515 (698) 667 (904) 258 (350). 364 (494) 7/8
1 213 (289) 275 (373)
547
(742) 708 (960)
773
(1048) 1000 (1356)
386
(523) 545 (739) 1
NOTE: Torque values shown
with
*are inch pounds.
IDENTIFICATION
CAP SCREWS AND CARRIAGE BOLTS
0
SAEGRADE2
SAEGRADE5
SAE
GRADES
REGULAR NUTS
SAE
GRADE
5
SAE
GRADE 8
HEX
NUTS
HEX
NUTS
LOCKNUTS
/@-··-
GRADE IDENTIFICATION
GRADE
A
NO
NOTCHES
GRADE
B
ONE
CIRCUMFERENTIALNOTCH
GRADE
C
TWO
CIRCUMFERENTIAL NOTCHES •
GRADE
IDENTIFICATION
GRADE
A
NO
MARKS
GRADE
B THREE
MARKS
GRADE
C
SIX
MARKS
MARKS
NEED
NOT
BE
LOCATED
AT
CORNERS
GRADE A
NO
MARK
GRADE B LETTER B
GRADE C LETTER C
GRADE IDENTIFICATION
00-9
SECTION 00 -GENERAL INFORMATION
MINIMUM HARDWARE TIGHTENING TORQUES
IN FOOT POUNDS (NEWTON-METERS) FOR
NORMAL
ASSEMBLYAPPLICATIONS
METRIC HARDWARE AND LOCKNUTS
CLASS5.8
NOMINAL
CLASSS.8
CLASS 10.9
SIZE UNPLATED PLATED UNPLATED PLATED UNPLATED PLATED
W/ZnCr W/ZnCr W/ZnCr
M4 15* (1.7) 19* (2.2) 23* (2.6)
30*
(3.4) 33* (3.7) 42* (4.8)
M6
51* (5.8) 67* (7.6) .79* (8.9) 102* (12) 115* (13) 150* (17)
MB
124* (14) 159* (18) 195* (22) 248* (28) 274* (31) 354* (40)
M10
21
(28) 27 (36)
32
(43)
41
(56) 45 (61) 58 (79)
M12
36
{49) 46 (63) 55 {75) 72 {97) 79 {107) 102 (138)
M16
89
(121) 117 (158) 137 (186) 177 (240) 196 (266) 254 (344)
M20 175 (237) 226 (307) 277 (375) 358 (485) 383 (519) 495 (671)
M24 303 (411) 392 (531) 478 (648) 619 (839) 662 (897) 855 (1160)
NOTE: Torque values
shown
with
*are
inch
pounds.
IDENTIFICATION
HEX CAP SCREW AND CARRIAGE BOLTS
CLASSES 5.6 AND UP
MANUFACTURER'S IDENTIFICATION
PROPERTY
CLASS
HEX NUTS AND LOCKNUTS
CLASSES 05 AND
UP
MANUFACTURER'S IDENTIFICATION
PROPERTY
CLASS
CLOCK
MARKING
00-10
LOCKNUT
CL.8
W/CLS.8
BOLT
16* (1.8)
56* (6.3)
133* (15)
22 {30)
39 (53)
97
(131)
195 (265)
338 (458)
SECTION 00 -GENERAL INFORMATION
INSTALLATION
OF
ADJUSTABLE
FITTINGS IN STRAIGHT THREAD
0 RING BOSSES
1. Lubricatethe O ring by coating itwith alightoil or
petroleum. Install the O ring
in
the groove
adjacent to the metal backup washer which is
assembled at the extreme end
of
the groove,
4.
2. Installthefitting intothe SAEstraightthread boss
until the metal backup washer contacts the face
ofthe boss,
5.
NOTE: Do not over tighten and distort the metal
backup washer.
3. Position the fitting by turning out (counterclock-
wise} up to a maximum of one turn. Holding the
pad of the fitting with a wrench, tighten the
locknutand washer against the face ofthe boss,
6.
1
STANDARD TORQUE DATA FOR HYDRAULIC TUBES AND FITTINGS
TUBE
NUTS 0 RING BOSS PLUGS
FOR 37° FLARED FITTINGS ADJUSTABLE FITTING
LOCKNUT$, SWIVEL
JIC -37° SEATS
TORQUE
1ORQUE
TUBING THREAD NEWTON
SIZE
OD
SIZE METERS
mm
In. Min. Max.
4 6.4 1/4 7/16-20 12 16
5 7.9 5/16 1/2-20 16 20
6 9.5 3/8 9/16-18 29 33
8 12.7 1/2 3/4-18 47 54
10 15.9 5/8 7/8-14 72 79
12
19.1
3/4 1-1/16-12 104
111
14 22.2 7/8 1-3/16-12 122 136
16 25.4 1 1-5/16-12 149 163
20 31.8 1-1/4 1-5/8-12 190 204
24
38.1
1-1/2 1-7/8-12 217 237
32 50.8 2 2-1/2-12 305 325
These torques are not recommended for tubes of
12.7
mm
(1
/2"}
OD
and larger with wall thickness of
0.889
mm
(0.035"} orless. Thetorque
is
specifiedfor
0.889
mm
(0.035"} wall tubes on each application
individually.
Before installing and torquing 37° flared fittings,
clean the face of the flare and threads with a clean
00-11
FOOT
NEWTON
FOOT
POUNDS
METERS
POUNDS
Min. Max. Min. Max. Min. Max.
9 12 8 14 6 10
12 15 14 20 10 15
21
24 20 27 15 20
35 40 34
41
25 30
53 53 47 54 35 40
77 82
81
95 60 70
90 100 95 109 70 80
110
120 108 122 80 90
140 150 129 158 95
115
160 175 163 190 120 140
225 240 339 407 250 300
solventorLoctitecleanerand applyhydraulicsealant
Loctite no. 569 to the 37° flare and the threads.
Install fitting and torque to specified torque, loosen
fitting and retorque to specifications.
SECTION 00 -GENERAL INFORMATION
PIPE
THREAD
FITTING
TORQUE
1/2" -14
41
N·m (30
ft.
lbs.)
THREAD
SIZE
TORQUE
(MAXI-
MUM)
1/8" -27 13 N·m (10
ft.
lbs.)
1/4" -18 16 N·m (12
ft.
lbs.) .
3/8" -14 22 N·m (16
ft.
lbs.)
3/4"-14
54 N·m (40
ft.
lbs.)
Before installing and tightening pipe fittings, clean
the threads with a clean solvent or Loctite cleaner
and apply sealant Loctite no. 567 for all fittings
including stainless steel or no. 565 for most metal
fittings. For high filtration/zero contamination sys-
tems use no. 545.
LUBRICANTS
AND
COOLANTS
Application New Holland Part No. Specification
Final Drive chain case 1 qt. -#9613313 API Service SH/CG-4 10W-30
Hydraulic{fransmission 2.5 gal. -#9613314
1 L - #9613358
20 L - #9613360
All lubrication fittings Tube -#9613310 High viscosity lithium base grease
Engine 1 qt. -#9613313 API Service SH/CG-4 10W-30
2.5 gal. -#9613314 Refer to Operator's Manual for
1 L - #9613358 Temperature/Oil usage Chart
20 L - #9613360
Cooling System -LS125 1 gal. -#FGCC2701
OS
Antifreeze/Water 50/50 Mixture
(Ethylene Glycol)
SEALANTS
New
Holland Part
Description No. Typical Applications Strength Color
Thread Lock L22200 (222) Small screws and Low Purple
hardware
L24231 (242) Nuts &Bolts Medium Blue
L29000 (290) Wicking Type Medium Green
L26231 (262) Nuts &Bolts High Red
Thread Sealants L54531 (545) Hydraulic/Pneumatic Non-fouling
L56531 (565) Pipe Sealant Controlled
strength
L56747 (567) Pipe Sealant High Temperature
Silicones L81724 (3.5 oz. tube) Ultra Blue RTV Gasket Non-corrosive Blue
L58775 Ultra Blue RTV Gasket Non-corrosive Blue
(10.2 oz. cartridge)
L82180 (3.35 oz. tube) Ultra Blue RTV Gasket Non-corrosive Black
L59875 Ultra Blue RTV Gasket Non-corrosive Black
(10.2 oz. cartridge)
00-12
SECTION 00 -GENERAL INFORMATION
MODEL AND SERIAL NUMBER LOCATION
Theskidsteermodelandserialnumbertag islocated
on the inside on the left boom support post
at
1.
LS120 Engine -P218 gasoline engine model and
serial number is located at
1,
on the engine shroud
at
the flywheel end
of
engine.
LS125 Engine-E673 diesel engine model and serial
islocatedonthetop,flatsurface
of
theinjectionpump
at
1.
00-13
19985051 ------------
L
N:W
HOLLAI\D
2
3
4
SECTION
00
-GENERAL INFORMATION
PROPERLY SUPPORT A RAISED MACHINE
If servicing, neutral adjustment, final drive adjust-
ment
or
repairs, requirethemachine
to
beraisedwith
all four wheels off the ground, securely support the
machine with adequate jack stands
or
blocks as
shown.
Supportthemachineat 1,
to
thefront
of
thefinal drive
cases and to the rear
at
2, making surethe supports
areon
the
flatareaof
the
final drivecases. Makesure
the supports
do
not contact the wheels
or
tires.
PROPERLY SUPPORT BOOM ON BOOM
LOCKPINS
Before servicing the machine
or
any
of
its attached
equipment, be surethatthe attachments are lowered
to the ground or the boom arms are supported bythe
boom lockpins,
1.
Ifboom is
to
beraised on boomlockpins, removeany
attachment. Opening a hydraulic line could cause a
mounted attachment
to
dump over unexpectedly.
A DANGER A
Never work beneath a loader or boom when it is
. held up only by the hydraulic system. A broken
hydraulic line could cause the boom to descend
rapidly.
Always actuate the boom lock before leaving a
machinewith theboom upand/orwhenservicing
or repairing the unit with the boom up. Failure
to
do
so
could result in serious
injury
or
death.
PROCEDURE:
1.
RAISE
THE
BOOM,
EXTEND THE
BOOM
LOCK
PINS,
1,
AND
LOWER
THE
BOOM
ON
THE
BOOM
LOCKPINS.
2.
AFTER
STOPPING
THE ENGINE
AND
BE-
FORE
UNBUCKLING THE
SEAT
BELT
AND
DISMOUNTING
FROM
THE
SKID
STEER,
TURN
"ON"
THE
IGNITION SWITCH.
3.
PUSH
BOTH
THE
BOOM
AND BUCKET
PEDALS
TO
RELIEVE ALL HYDRAULIC
PRESSURE
IN
BOTH
CIRCUITS.
4.
TURN
"OFF" THE IGNITION SWITCH.
5.
SET THE
PARKING
BRAKE.
00-14
5
6
SECTION 00 -GENERAL INFORMATION
RAISING BOOM WITHOUT HYDRAULIC OIL
FLOW
(Engine or Hydraulic System Not Functioning)
1.
Remove any attachment from the boom
mounting plate.
2.
Block the rear ofthe skid steer under the rear of
lower main frame,
1,
as
shown.
This will prevent the front wheels from raising
during boom lifting.
3. Attach a fork lift or overhead hoist to the main
boom, 1 and lifting device,
2.
Attach chain or strap securely to prevent
unhookingduring boom lifting. Position the chain
or strap at 1 to prevent damage to the boom
cylinder hydraulic hoses and tubes.
A CAUTION A
Attach suitable chains or straps capable of
handlingtheweightoftheboom, 227
kg
(500lbs).
Attach chains securely to prevent them from
coming loose during fluting ofthe boom.
4.
With
an
operator sitting
in
the operator's seat
with the seat belt buckled.
5.
Turn the ignition key to the
"ON"
position. Press
the toe ofthe left foot pedal, boom control, into
the boom float position.
6.
Slowly raisethe boom abovethe boom lockpins,
1.
7.
Operator sitting
in
seat, engage the boom lock
pins,
1.
8.
Lowerthe boom
and
rest
on
the boom lock pins,
1.
9.
Return the boom control to the "NEUTRAL"
position.
10.
Turn the ignition key
to
the "OFF" position.
A CAUTION A
The operator must not leave the operator's seat
untiltheboom is resting soli~lyonthe boom lock
pins. The boom could drop suddenly if lifting
devices should fail.
00-15
a C
□□□□□□□
□□□□□□□
□□□□□□□
_D
_goop
□□
D
--=--'JI
0 0 0 9
l
-·==-~,
20001505 1
7
8
SECTION 00 -GENERAL INFORMATION
RAISING BOOM WITHOUT BATTERY
VOLTAGE (12 VOLTS)
1. Remove any attachment from the boom
mounting plate.
2. Block the rear
of
the skid steer under the rear of
lower main frame,
1,
as shown.
This will prevent the front wheels from raising
during boom lifting.
3. Attach a fork lift or overhead hoist to the main
boom, 1 and lifting device, 2.
Attach chain or strap securely to prevent
unhookingduring boom lifting. Positionthechain
or strap at 1 to prevent damage to the boom
cylinder hydraulic hoses and tubes.
A CAUTION A
Attach suitable chains or straps capable of
handlingtheweightofthe boom, 227
kg
(500lbs).
Attach chains securely to prevent
them.
from
coming loose during lifting of the boom.
4. Removethe rod end (top) pivot pins,
1,
from both
cylinders. Byremove retaining hardware, 2, from
pivot pin and boom.
00-16
a
ti
□□□□□□□
I
□□□□□□□
I
□□□□□□□
0
□□□
po
□
- -
--c=:==----
-..-c:c..._..7
-·====-==./
1
20001505
10
11
12
SECTION 00 -GENERAL INFORMATION
5.
Support the cylinders on the tires, 1, as shown.
6.
With an operator sitting
in
the operator's seat
with the seat belt buckled.
7.
Slowlyraise the boom abovethe boom lock pins,
1.
8.
Operator sitting
in
seat, engage the boom lock
pins, 1.
9.
Lowerthe boom and rest on the boom lock pins,
1. A CAUTION A
The operator must not leave the operator's seat
untiltheboomisresting solidlyonthe boom lock
pins. The boom could drop suddenly if lifting
devices should fail.
00-17
13
14
This manual suits for next models
1
Table of contents
Other New Holland Compact Loader manuals
New Holland
New Holland L465 Operating instructions
New Holland
New Holland W130C Tier 4 User manual
New Holland
New Holland 200 Series User manual
New Holland
New Holland Super Boom C185 User manual
New Holland
New Holland LB75.B User manual
New Holland
New Holland W130B Instruction manual
New Holland
New Holland W50 Instruction manual
New Holland
New Holland Super Boom L180 User manual
New Holland
New Holland Super Boom L180 Operating instructions
New Holland
New Holland LB90.B Instruction manual
New Holland
New Holland 200 Series User manual
New Holland
New Holland 300 Series User manual
New Holland
New Holland 700TL User manual
New Holland
New Holland 790CP User manual
New Holland
New Holland L213 User manual
New Holland
New Holland LW170 User manual
New Holland
New Holland W190C Tier 4 User manual
New Holland
New Holland W270D Tier 2 User manual
New Holland
New Holland W110D Stage IV User manual
New Holland
New Holland LS140 Operating instructions
