New Holland E175C User manual

SERVICE MANUAL
E175C
Crawler Excavator
English
February 2013
Copyright © 2013 CNH Europe Holding S.A. All Rights Reserved.
SERVICE
MANUAL
E175C
Crawler Excavator
1/1
Part number 47494131A Part number 47494131A

SERVICEMANUAL
E175C
47494131A11/03/2013
EN
Find manuals at https://best-manuals.com

Contents
INTRODUCTION
Engine.......................................................................................10
[10.001]Engineandcrankcase.............................................................10.1
[10.202]Aircleanersandlines..............................................................10.2
[10.216]Fueltanks..........................................................................10.3
[10.254]Intakeandexhaustmanifoldsandmufer.........................................10.4
[10.400]Enginecoolingsystem.............................................................10.5
Hydraulicsystems.......................................................................35
[35.000]Hydraulicsystems..................................................................35.1
[35.102]Pumpcontrolvalves................................................................35.2
[35.106]Variabledisplacementpump.......................................................35.3
[35.300]Reservoir,cooler,andlters........................................................35.4
[35.352]Hydraulicswingsystem............................................................35.5
[35.353]Hydraulictravelsystem............................................................35.6
[35.354]Hydrauliccentraljoint..............................................................35.7
[35.355]Hydraulichandcontrol.............................................................35.8
[35.356]Hydraulicfootcontrol...............................................................35.9
[35.359]Maincontrolvalve................................................................35.10
[35.736]Boomhydraulicsystem..........................................................35.11
[35.737]Dipperhydraulicsystem..........................................................35.12
[35.738]Excavatorandbackhoebuckethydraulicsystem................................35.13
Framesandballasting.................................................................39
[39.101]Upperframe........................................................................39.1
[39.103]Swingringassembly...............................................................39.2
[39.140]Ballastsandsupports..............................................................39.3
Tracksandtracksuspension........................................................48
[48.100]Tracks..............................................................................48.1
47494131A11/03/2013
Find manuals at https://best-manuals.com

[48.130]Trackframeanddrivingwheels....................................................48.2
[48.134]Tracktensionunits.................................................................48.3
[48.138]Trackrollers........................................................................48.4
Cabclimatecontrol.....................................................................50
[50.200]Airconditioning.....................................................................50.1
Electricalsystems.......................................................................55
[55.000]Electricalsystem...................................................................55.1
[55.015]Enginecontrolsystem..............................................................55.2
[55.036]Hydraulicsystemcontrol...........................................................55.3
[55.051]CabHeating,Ventilation,andAir-Conditioning(HVAC)controls...................55.4
[55.100]Harnessesandconnectors.........................................................55.5
[55.302]Battery..............................................................................55.6
[55.640]Electronicmodules.................................................................55.7
[55.DTC]FAULTCODES....................................................................55.8
Booms,dippers,andbuckets.......................................................84
[84.100]Bucket..............................................................................84.1
[84.910]Boom...............................................................................84.2
Platform,cab,bodywork,anddecals.............................................90
[90.105]Machineshieldsandguards.......................................................90.1
[90.116]Fendersandguards................................................................90.2
[90.124]Pneumatically-adjustedoperatorseat..............................................90.3
[90.150]Cab.................................................................................90.4
47494131A11/03/2013
Find manuals at https://best-manuals.com

47494131A11/03/2013
Find manuals at https://best-manuals.com

INTRODUCTION
47494131A11/03/2013
1
Find manuals at https://best-manuals.com

Contents
INTRODUCTION
Safetyrules.....................................................................................3
Personalsafety.................................................................................4
Torque........................................................................................13
Basicinstructions-Importantnoticeregardingequipmentservicing.........................22
Basicinstructions-Howtousethemaintenancestandardandprecautions.................23
Basicinstructions-Preparationforperformancetests.......................................25
Basicinstructions-Precautionfordisassemblyandassembly...............................26
Basicinstructions-Installinghydraulicequipment...........................................28
Basicinstructions-Electricalequipmentprecautions........................................31
Capacities-Fluidsandlubricants............................................................32
Hydrauliccontamination......................................................................34
Productidentication-MachineOrientation(front,right,rear,left)...........................35
Productidentication..........................................................................36
47494131A11/03/2013
2
Find manuals at https://best-manuals.com

INTRODUCTION
Safetyrules
Personalsafety
Thisisthesafetyalertsymbol.Itisusedtoalertyoutopotentialpersonalinjuryhazards.Obeyall
safetymessagesthatfollowthissymboltoavoidpossibledeathorinjury.
ThroughoutthismanualyouwillndthesignalwordsDANGER,WARNING,andCAUTIONfollowedbyspecialin-
structions.Theseprecautionsareintendedforthepersonalsafetyofyouandthoseworkingwithyou.
Readandunderstandallthesafetymessagesinthismanualbeforeyouoperateorservicethemachine.
DANGERindicatesahazardoussituationwhich,ifnotavoided,willresultindeathorseriousinjury.
WARNINGindicatesahazardoussituationwhich,ifnotavoided,couldresultindeathorseriousinjury.
CAUTION,usedwiththesafetyalertsymbol,indicatesahazardoussituationwhich,ifnotavoided,could
resultinminorormoderateinjury.
FAILURETOFOLLOWDANGER,WARNING,ANDCAUTIONMESSAGESCOULDRESULT
INDEATHORSERIOUSINJURY.
Machinesafety
NOTICE:Noticeindicatesasituationwhich,ifnotavoided,couldresultinmachineorpropertydamage.
ThroughoutthismanualyouwillndthesignalwordNoticefollowedbyspecialinstructionstopreventmachineor
propertydamage.ThewordNoticeisusedtoaddresspracticesnotrelatedtopersonalsafety.
Information
NOTE:Noteindicatesadditionalinformationwhichclariessteps,procedures,orotherinformationinthismanual.
ThroughoutthismanualyouwillndthewordNotefollowedbyadditionalinformationaboutastep,procedure,or
otherinformationinthemanual.ThewordNoteisnotintendedtoaddresspersonalsafetyorpropertydamage.
47494131A11/03/2013
3
Find manuals at https://best-manuals.com

INTRODUCTION
Personalsafety
CarefullyreadthisManualbeforeproceedingwithmain-
tenance,repairs,refuellingorothermachineoperations.
Repairshavetobecarriedoutonlybyauthorizedandin-
structedstaff;specicprecautionshavetobetakenwhen
grinding,weldingorwhenusingmalletsorheavyham-
mers.
Notauthorizedpersonsarenotallowedtorepairorcarry
outmaintenanceonthismachine.Donotcarryoutany
workontheequipmentwithoutpriorauthorization.
Askyouremployeraboutthesafetyinstructionsinforce
andsafetyequipment.
Nobodyisallowedtoseatontheoperator’splaceduring
machinemaintenanceunlessheisaqualiedoperator
helpingwiththemaintenancework.
Ifitisnecessarytomovetheequipmenttocarryoutre-
pairsormaintenance,donotliftorlowertheequipment
fromanyotherpositionthantheoperator’sseat.
TULI12WEX2004AA1
Nevercarryoutanyoperationonthemachinewhenthe
engineisrunning,exceptwhenspecicallyindicated.
Stoptheengineandensurethatallpressureisrelieved
fromhydrauliccircuitsbeforeremovingcaps,covers,
valves,etc.
Allrepairandmaintenanceoperationsshouldbecarried
outwiththegreatestcareandattention.
Servicestairsandplatformsusedinaworkshoporinthe
eldshouldbebuiltincompliancewiththesafetyrulesin
force.
Anyfunctionaldisorders,especiallythoseaffectingthe
safetyofthemachine,shouldthereforeberectiedim-
mediately.
DANGER
Unexpectedmovement!
Makesureparkingbrakeisapplied.Secure
machinewithwheelchocks.
Failuretocomplywillresultindeathorserious
injury.D0013A
TULI12WEX2005AA2
Beforeperforminganyworkonthemachine,attacha
maintenanceinprogresstag.Thistagcanbeappliedon
theleft-handcontrollever,safetyleverorcabdoor.
TULI12WEX2006AA3
47494131A11/03/2013
4
Find manuals at https://best-manuals.com

INTRODUCTION
Emergency
Bepreparedforemergencies.Alwayskeepatdisposalon
themachinearstaidkitandareextinguisher.Make
surethatthereextinguisherisservicedinaccordance
withthemanufacturer’sinstructions.
SMIL12WEX0174AA4
Equipment
Wearclosettingclothingandsafetyequipmentappropri-
ateforthejob:
•Safetyhelmet
•Safetyshoes
•Heavygloves
•Reectiveclothing
•Wetweatherclothing
Ifenvironmentconditionrequireitfollowingpersonal
safetyequipmentshouldbeathand:
•Respirators(ordustproofmasks)
•Earplugsoracousticearsprotections
•Goggleswithlateralshieldormasksforeyesprotection
Donotwearrings,wristwatches,jewels,unbuttonedor
appingclothingsuchasties,tornclothes,scarves,open
jacketsorshirtswithopenzipswhichcouldgetcaughtinto
movingparts.
TULI12WEX2008AA5
Engine-Radiator
Neverleavetheengineruninclosedspaceswithoutventi-
lationandnotabletoevacuatetoxicexhaustgases.Keep
theexhaustmanifoldandtubefreefromcombustionma-
terials.
Donotrefuelwiththeenginerunning,especiallyifhot,as
thisincreasesrehazardincaseoffuelspillage.
Neverattempttocheckoradjustthebeltswhentheen-
gineisrunning.
Neverlubricatethemachinewiththeenginerunning.
TULI12WEX2009AA6
47494131A11/03/2013
5
Find manuals at https://best-manuals.com

INTRODUCTION
Payattentiontorotarypiecesanddonotallowtoanyone
toapproachtoavoidbecomingentangled.
Ifhands,clothesortoolsgetcaughtinthefanbladesorin
thetransmissionbelt,thiscancauseamputations,violent
tearsandgenerateconditionofseriousdanger;forthis
reasonavoidtouchingortocomeclosetoallrotaryor
movingparts.
Aviolentjetofthecoolantfromtheradiatorcancause
damagesandscalds.
Ifyouaretocheckthecoolantlevel,youhavetoshut-off
theenginepreviouslyandtoletcooldowntheradiatorand
itspipes.Slowlyunscrewthecaptoreleasetheinside
pressure.
TULI12WEX2010AA7
Ifnecessary,removethecapwithhotengine,wearsafety
clothesandequipment,thenloosenthecapslowlytore-
lievethepressuregradually.
Whencheckingthefuel,oilandcoolantlevels,useex-
clusivelyexplosionproofclassiedlamps.Ifthiskindof
lampsarenotusedresorexplosionsmayoccur.
TULI12WEX2011AA8
Hydraulicsystems
Splashesofuidsunderpressurecanpenetratetheskin
causingseriousinjuries.
Avoidthishazardbyrelievingpressurebeforedisconnect-
inghydraulicorotherlines.
Relievetheresidualpressurebymovingthehydraulic
controlleversseveraltimes.
Tightenallconnectionsbeforeapplyingpressure.
Toprotecttheeyeswearafacialshieldorsafetygoggles.
Protectyourhandsandbodyfrompossiblesplashesof
uidsunderpressure.
Swallowinghydraulicoilisaseverehealthhazard.
TULI12WEX2012AA9
47494131A11/03/2013
6

INTRODUCTION
Whenhydraulicoilhasbeenswallowed,avoidvomiting,
butconsultadoctororgotoahospital.
Ifanaccidentoccurs,seeadoctorfamiliarwiththistype
ofinjuryimmediately.
Anyuidpenetratingtheskinmustberemovedwithinfew
hourstoavoidseriousinfections.
Flammablesplashesmayoriginatebecauseoftheheat
nearpipeswithuidsunderpressure,withtheresultof
seriousscaldsforthepersonshit.Donotweldoruse
torchesnearpipescontaininguidsorotherammable
materials.
Pipesunderpressurecanaccidentallybepiercedwhen
theheatexpandsbeyondtheareaimmediatelyheated.
Arrangeforreresistanttemporaryshieldstoprotect
hosesorothercomponentsduringwelding.
Haveanyvisibleleakagerepairedimmediately.
Escapingoilpollutestheenvironment.Soakupanyoil
thathasescapedwithaproperbindingagent.Sweep
upbindingagentanddisposeofitseparatelyfromother
waste.
Neversearchforleakageswiththengers,butuseapiece
ofcardboardandalwaysweargoggles.
Neverrepairdamagedpiping;alwaysreplaceit.Replace
hydraulichosesimmediatelyondetectinganydamageor
moistareas.
Alwaysstorehydraulicoilintheoriginalcontainers.
TULI12WEX2013AA10
47494131A11/03/2013
7

INTRODUCTION
Hosesandtubes
Alwaysreplacehosesandtubesiftheconeendorthe
endconnectionsonthehosearedamaged.
Wheninstallinganewhose,looselyconnecteachend
andmakesurethehosetakesupthecorrectpositionbe-
foretighteningtheconnections.Clampsshouldbetight-
enedsufcientlytoholdthehosewithoutcrushingandto
preventchang.
Afterhosereplacementtoamovingcomponent,check
thatthehosedoesnotfoulbymovingthecomponent
throughthecompleterangeoftravel.Besureanyhose
whichhasbeeninstalledisnotkinkedortwisted.
Hoseconnectionswhicharedamaged,dented,crushed
orleaking,restrictoilowandtheproductivityofthecom-
ponentsbeingserved.Connectorswhichshowsignsof
movementfromtheoriginalpositionhavefailedandwill
ultimatelyseparatecompletely.
Ahosewithafrayedoutersheathwillallowthewaterpen-
etration.Concealedcorrosionofthewirereinforcement
willsubsequentlyoccuralongthehoselengthwithresul-
tanthosefailure.
Ballooningofthehoseindicatesaninternalleakagedueto
structuralfailure.Thisconditionrapidlydeterioratesand
totalhosefailuresoonoccurs.
Kinked,crushed,stretchedordeformedhosesgenerally
sufferinternalstructuraldamagewhichcanresultinoil
restriction,areductioninthespeedofoperationandulti-
matehosefailure.
Free-moving,unsupportedhosesmustneverbeallowed
totoucheachotherorrelatedworkingsurfaces.This
causeschangwhichreduceshoselife.
TULI12WEX2014AA11
O-rings
ReplaceO-rings,sealringsandgasketswheneverthey
aredisassembled.
NevermixnewandoldsealsorO-rings,regardlessof
condition.AlwayslubricatenewsealringsandO-rings
withhydraulicoilbeforeinstallationtorelevantseats.
ThiswillpreventtheO-ringsfromrollingoverandtwisting
duringmountingwhichwilljeopardizesealing.
47494131A11/03/2013
8

INTRODUCTION
Battery
Batteriesgiveoffexplosivegases.
Neverhandlenakedamesandunshieldedlightsources
nearbatteries,neversmoke.
Topreventanyriskofexplosion,observethefollowing
instructions:
•Whendisconnectingthebatterycables,alwaysdiscon-
nectthenegative(-)cablerst.
•Toreconnectthebatterycables,alwaysconnectthe
negative(-)cablelast.
•Nevershort-circuitthebatteryterminalswithmetalob-
jects.
•Donotweld,grindorsmokenearabattery.
Batteryelectrolytecausessevereburns.Thebatterycon-
tainssulphuricacid.Avoidanycontactwiththeskin,eyes
orclothing.
TULI12WEX2015AA12
Antidote:
•EXTERNAL:Rinsewellwithwater,removinganysoiled
clothing.
•INTERNAL:Avoidvomiting.Drinkwatertorinseyour
mouth.Consultadoctor.
•EYES:Rinseabundantlywithwaterfor15minandcon-
sultadoctor.
•Whentheelectrolyteofabatteryisfrozen,itcanex-
plodeifyouattempttochargethebatteryorifyoutryto
starttheengineusingaboosterbattery.Alwayskeep
thebatterychargedtopreventtheelectrolytefreezing.
Providegoodventilationwhenchangingabatteryorusing
abatteryinanenclosedspace.Alwaysprotectyoureyes
whenworkingnearabattery.
TULI12WEX2016AA13
Neversettoolsdownonthebattery.Theymayinduce
ashortcircuit,causingirreparabledamagetothebattery
andinjuringpersons.
Neverwearmetalnecklaces,braceletsorwatchstraps
whenworkingonthebattery.Themetalpartsmayinduce
ashortcircuitresultinginburns.
Disposeofusedbatteriesseparatelyfromotherwastein
theinterestsofenvironmentalprotection.
TULI12WEX2017AA14
47494131A11/03/2013
9

INTRODUCTION
Flammableliquids
Whenhandlingammableliquids:
•Donotsmoke.
•Keepawayfromunshieldedlightsourcesandnaked
ames.
Fuelsoftenhavealowashpointandarereadilyignited.
Neverattempttoextinguishburningliquidswithwater.
Use:
•Drypowder
•Withcarbondioxide
•Withfoam
Waterusedforextinguishingpurposeswouldvaporizein-
stantaneouslyoncontactwithburningsubstancesand
spreadburningoil,forexample,overawidearea.Water
generatesshortcircuitsintheelectricalsystem,possibly
producingnewhazards.
TULI12WEX2016AA15
Stayawayfromopenamesduringrellingofhydraulic
oilorfuel.
Fueloroilsplashescancauseslippingandthereforeacci-
dents;cleanimmediatelyandaccuratelytheareaseven-
tuallysmeared.
Alwaystightenthesafetyplugsoffueltankandhydraulic
oiltankrmly.
Neverusefueltocleanthemachinepartseventually
smearedwithoilordust.
Useanon-inammableproductforcleaningparts.
Alwaysperformfueloroilrellinginwellairedandventi-
latedareas.
TULI12WEX2018AA16
Duringrefuellingholdthepistolrmlyandkeepitalways
incontactwiththellerneckuntiltheendoftherefuelling,
toavoidsparklesduetostaticelectricity.
Donotoverllthetankbutleaveaspaceforfuelexpan-
sion.
Neverrefuelwhentheengineisrunning.
Takeallthenecessarysafetymeasureswhenwelding,
grindingorwhenworkingnearanakedame.
TULI12WEX2019AA17
47494131A11/03/2013
10

INTRODUCTION
Cleaning
Cleantheexteriorofallcomponentsbeforecarryingout
anyformofrepair.Dirtanddustcanreducetheefcient
workinglifeofacomponentandleadtocostlyreplace-
ment.
Solventsshouldbecheckedthattheyaresuitableforthe
cleaningofcomponentsandalsothattheydonotriskthe
personalsafetyoftheuser.
Dirtfromoilorgreaseandscatteredtoolsorfaultypieces
aredangerousforpersons,becausetheycangenerate
slippingorfalls.
Forthemachinecleaning,useajetofwarmwateror
steamunderpressureandcommercialdetergents.Never
usefuel,petroleumorsolvents,becausetherstones
leaveanoilylayerthatfavoursthestickingofdust,while
solvents(evenifweak)damagethepaintandfavourthe
formationofrust.
Neverusewaterjetsorsteamonsensors,connectorsor
otherelectriccomponents.
Preventthatthewaterjetpenetratesinsidethecab.
TULI12WEX2021AA18
47494131A11/03/2013
11

INTRODUCTION
Wastedisposal
Improperlydisposingofwastecanthreatentheenviron-
ment.
EachcountryhasitsownRegulationsonthissubject.It
isthereforeadvisabletopreparesuitablecontainersto
collectandstoremomentarilyallsolidanduidmaterials
thatmustnotbescatteredintheenvironmenttoavoid
pollution.
Atpresetintervalstheseproductswillbedeliveredtodis-
posalstationslegallyrecognizedandpresentinthisCoun-
try.
Hereunderarelistedsomeproductsofthemachinere-
quiringdisposal:
•Lubricatingoil
•Brakesystemoil
•Coolantmixture,condensationrestsandpurean-
tifreeze
•Fuel
•Filterelements,oilandfuellters
•Filterelements,airlters
•Battery
Alsopollutingrags,paper,sawdustandglovesmustbe
disposedincompliancewiththesameprocedures.
Donotusefoodorbeveragecontainersthatmaymislead
someoneintodrinkingfromthem.Donotpourwasteonto
theground,downadrain,orintoanywatersource.Air
conditioningrefrigerantsescapingintotheaircandamage
theEarth’satmosphere.Governmentregulationsmayre-
quireacertiedairconditioningservicecentretorecover
andrecycleusedairconditioningrefrigerants.Obtainin-
formationontheproperwaytorecycleordisposeofwaste
fromyourlocalenvironmentalorrecyclingcentre,orfrom
yourDealer.
TULI12WEX2022AA19
47494131A11/03/2013
12

INTRODUCTION
Torque
Bolttypes
NOTICE:Usetoolsappropriatefortheworktobedone.
Makeshifttoolsandprocedurescancreatesafetyhaz-
ards.Forlooseningandtighteningnutsandbolts,use
thecorrecttools.Avoidbodilyinjurycausedbyslipping
wrenches.
TULI12ECX0475AA1
Tightennutsorboltstotorquespecications.Thereare
twokindsofbolts;hexagonTbolts(1)andsocketbolts
(2).Thetwotypesofboltsaremadefromdifferentmate-
rials.Thecorrecttypeofboltmustbeusedwhenassem-
blingthemachineand/orcomponents.
RAPH12CEX1320AA2
Speciedtighteningtorquechart
Boltdia.WrenchsizeHexagonwrenchsizeTbolt,socketbolt
M813mm6mm29.5N·m(22lbft)
M1017mm8mm64N·m(47lbft)
M1219mm10mm108N·m(80lbft)
M1422mm12mm175N·m(129lbft)
M1624mm14mm265N·m(195lbft)
M1827mm14mm390N·m(288lbft)
M2030mm17mm540N·m(398lbft)
M2232mm17mm740N·m(546lbft)
M2436mm19mm930N·m(686lbft)
M2741mm19mm1370N·m(1010lbft)
M3046mm22mm1910N·m(1409lbft)
M3350mm24mm2550N·m(1881lbft)
M3655mm27mm3140N·m(2316lbft)
1.Applylubricant(i.e.whitezincBdissolvedintospindleoil)tonutsandboltstostabilizetheirfrictioncoefcients.
2.Torquetoleranceis±10%.
3.Besuretouseboltsofcorrectlength.Boltsthataretoolongcannotbetightened,asthebolttipcomesintocontact
withthebottomofthebolthole.Boltsthataretooshortcannotdevelopsufcienttighteningforce.
4.Thetorquesgiveninthechartareforgeneraluseonly.
Donotusethesetorquesifadifferenttorqueisgivenforaspecicapplication.
5.Makesurethatthenutandboltthreadsarecleanbeforeinstalling.Removedirtorcorrosion,ifany.
47494131A11/03/2013
13

INTRODUCTION
Bolttighteningorder
Whentighteningtwoormorebolts,tightenthemalternately,asshown,toensureeventightening.
SMIL13CEX0149EA3
AEquallytightenupperandloweralternately
BTightendiagonally
CTightenfromcenteranddiagonally
47494131A11/03/2013
14

INTRODUCTION
Servicerecommendationsforsplitange
1.Besuretocleanandinspectsealingsurfaces.
Scratches/roughnesscauseleaksandsealwear.
Unevennesscausessealextrusion.Ifdefectscannot
bepolishedout,replacethecomponent.
2.BesuretouseonlyspeciedO-rings.InspectO-rings
foranydamage.TakecarenottoleO-ringsurfaces.
WheninstallinganO-ringintoagroove,usegreaseto
holditinplace.
3.Looselyassemblesplitangehalves.Makesurethat
thesplitiscentrallylocatedandperpendiculartothe
port.Hand-tightentheboltstoholdthepartsinplace.
TakecarenottopinchtheO-ring.
4.Tightenboltsalternatelyanddiagonally,asshown,to
ensureeventightening.
5.Donotuseairwrenches.Usinganairwrenchoften
causestighteningofoneboltfullybeforetightenthe
others,resultingindamagetoO-ringsoruneventight-
eningofbolts.
A-WRONG
TULI12ECX0802AA4
SMIL13CEX0150AA5
TULI12ECX0804AA6
47494131A11/03/2013
15
