New image Massage & recovery gun User manual

ASSEMBLY AND USER GUIDE

BRING IT HOME

To help you get started visit:

newimagefitness.co.uk

We’re passionate about helping you be fit, strong and active!

Whatever your fitness goal, New Image has a range of unique

and easy-to-use fitness solutions to help you be your best.

We know getting started is sometimes the hardest part so we

design all our products to be simple, fun to use and effective.

We hope you enjoy your new Massage & Recovery Gun and

would love to hear your experiences. Check out our social

channels and take a look at YouTube for videos, tips and

workouts.

• Watch exclusive workout videos

• Ask questions to our thriving community

• Check out our nutritional tips and tricks

To find out more about the New Image range of fitness

equipment, tools and accessories to help you achieve your

goals, visit newimagefitness.co.uk

Join the conversation...

to New Image

WELCOME

2

3

Keep hold of your Massage & Recovery Gun User Guide. It provides product information,

workout ideas and important product maintenance tips.

Please read this assembly and user guide before first using your Massage & Recovery Gun.

Congratulations on purchasing your

new Massage & Recovery Gun!

#1

#2 #4

#5 #6 #7 #8 #9 #10

#3

Part name Qty

1 Massage Gun 1

2 Carry Case 1

3 Charging Cable 1

4 USB plug adapter 1

5 Ball massage head 1

6 Bridged massage head 1

7 Spinal massage head 1

8 Bullet massage head 1

9 Hammer massage head 1

10 Spade massage head 1

4

QUICK START GUIDE:

1

2

Open the carry case and

remove the main unit and

USB-C charging cable. Insert

the plug into power point and

male part of charging cable into

female part of the unit. Switch

on power point and leave until

fully charged.

Once charged, remove cable and

store charger away in the carry case.

Choose desired attachement head

and insert in to the unit. Push firmly

until the head feels secure.

3Turn power switch on at the base of the handle to the ‘ON’ position. Blue lights on the

upper rear will illuminate to show charge capacity (Right).

5

4

5

Once ready to operate the unit, click the power button located on the upper rear.

Each click will increase speed (5 levels) and will be indicated by blue lights (Left).

Apply the head to the specified muscle group and use to massage muscles. Avoid

contact with Head, bones, organs & wounds.

Gently apply pressure to the chosen muscle moving the device continuously in a

controlled manner to target all desired areas of muscle. It is advised to do this for no

longer than 10 minutes in each muscular zone.

(Please see how to use chart for further instruction).

6

USING THE UNIT:

1

2

3

BALL HEAD

Predominantly used for large muscle

groups, such as glutes, hamstrings,

and quadriceps.

SPINAL HEAD

Ideal for trigger points and relieving

for lower & mid back pain either

side of the spine. (Gluteus Medius &

Thoracolumbar fascia). This should

never be used directly on the bones of

the spine.

HAMMER HEAD

Suited to smaller compact muscles

like the shoulder blade (trapezius)

or IT band on the outer, upper leg

(Iliotibial).

7

4

5

6

SPADE HEAD

The narrow shape helps to reach

larger, deeper set muscles such as

upper thigh & groin area as well as

hard to reach flat muscles areas such

as the ‘Lats’ or latissimus dorsi (mid

back area).

BRIDGED HEAD

Works best for targeting naturally

curved body parts such as calves

(Gastrocnemius), upper shoulder &

neck muscles. (Trapezius & Deltoids).

BULLET HEAD

Best used for pinpointing precise

muscles and deeper tissue. Areas such

as palms of hands, soles of feet and

knee joints.

8

SAFETY INFORMATION:

• Please read this user guide before first using your New Image Massage and Recovery gun.

It is important to keep these instructions for future reference.

• This appliance can be used by children aged from 8 years and above and persons with reduced

physical or sensory or mental capabilities or lack of knowledge if they have been given supervision

or instruction concerning use of the appliance in a safe way and understand the hazards involved.

• Children shall not play with the appliance.

• Cleaning and user maintenance shall not be made by children without supervision.

• For the purposes of recharging the battery, only use the detachable supply unit provided

with this appliance. Charge time approximately 3 hours, run time in lowest speed position

approximately 2.5 hours.

• Battery is non- removable. Keep the appliance away from water.

• Do not use without first attaching suitable massage head.

• Only use accessory items recommended by the manufacturer.

• CAUTION the instructions must be followed carefully in the assembly, use and maintenance

of the equipment.

• Keep hair, fingers and loose clothing away from moving parts to avoid serious injury.

• Always consult your GP before undertaking any exercise programme.

• This product is not suitable for therapeutic purposes.

• This product is intended for home use only.

MAINTENANCE AND STORAGE

• Wipe clean only with a clean, damp cloth. DO NOT use detergents.

• This equipment should not be stored outside, in a garage or outbuilding. Keep the equipment in a

dry place with as little temperature variation as possible. Always store in the carry case provided.

• If storing for a long time, please fully charge the battery.

CUSTOMER SUPPORT / IMPORTER ADDRESS:

Should you require any support regarding this product please call our customer services on 0844

8000631 / 0344 800 0631. High Street TV, PO Box 7903, Corby NN17 9HY.

Visit newimagefitness.com for ‘how-to’ guide and workout advice.

To dispose of product and packaging please recycle where facilities

exist. Check with your Local Authority or retailer for recycling

advice in your country.

Made in China

Please read all instructions carefully and retain for future reference

Model Number: PRO8

9

EXERCISE NOTES

..............................................................................................................................................

10

EXERCISE NOTES

..............................................................................................................................................

11

Distributed by:

High Street TV, PO Box 7903,

CORBY, NN17 9HY

Version 1 03/21 CR2899

newimagefitness.co.uk
