New World NWLS50DEW User manual

Instruction manual
50cm Double Oven Freestanding Cooker
NWLS 0DEW
NWLS 0DEB

You’ll soon be enjoying your new Freestanding Cooker
It all begins here, with your instructions. Don’t worry, there’s
nothing too technical coming up. Just simple, step-by-step
guidance to get you up and running quickly. Sound good? Then
let’s get started.
Help and Guidance
We’re here to help you get the most from your Freestanding Cooker. Should you require any guidance, a
simple solution can often be found online at:
www.newworldassist.co.uk
If you still require further assistance, call one of our experts on 0333 305 2263

3
Contents
22
23
24
24
Product support
Troubleshooting
Help and assistance
Declaration of conformance to product
standards
Disposal
Guarantee 25
4
7
Safety information
Safety information
Getting to know your
Freestanding Cooker
Overview
Accessories 8
Installing your Freestanding
Cooker
9
11
Installation requirements
1
2
3
4
5
6
12
19
20
20
13
16
17
Electrical connection
Using your Freestanding
Cooker
Control panel
Oven functions
General oven and cooking tips Practical
Cooking Advice
Using the Solid plate zones of your
cooker
Care and Maintenance
Cleaning
Replacing oven lamps
How to remove the oven doors
Technical specification 21
18

Safety information
Important - Please read these instructions fully before installing
or operating
4
INSTALLATION WARNINGS
IMPORTANT: Prior to Installation ensure that
the local supply conditions (electricity voltage
and frequency) are compatible with the
requirements of your freestanding cooker.
IMPORTANT: Carefully unpack and examine the
appliance for any damage. If you think there is a
defect, do not use the appliance and contact
NEWWORLD Product Support on 0333 305
2263. Packaging materials should be collected
together and disposed of immediately as they
maybe harmful to children.
IMPORTANT: Keep the electrical cable (not
supplied) of your freestanding cooker away
from the hot areas of your appliance, do not let
the cable touch the appliance. Keep the cable
away from sharp edges and heated surfaces.
IMPORTANT: Ensure that the electric supply
cable is not trapped or damaged during
installation.
IMPORTANT: In the event that the cable
connecting your freestanding cooker becomes
damaged, it must be replaced by a suitably
qualified person. This cable must not be
replaced by an unauthorised person.
IMPORTANT: Protect your freestanding cooker
against atmospheric effects. Do not expose
your cooker to effects such as sun, rain, snow
etc.
IMPORTANT: The materials surrounding the
appliance (cabinets) must be able to withstand
a minimum temperature of 100°C.
IMPORTANT: When using your oven for the first
time your cooker may give off an unusual
odour from the heating elements and insulation
materials. To eliminate this odour run the oven
at 250 degrees for 40-60 minutes with the oven
empty.
WARNING: Before obtaining access to
terminals, all supply circuits must be
disconnected.
DURING USAGE
IMPORTANT: This appliance can be used by children
aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been
given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements.
WARNING: NEVER try to extinguish a cooking fire with
water. Instead switch off the appliance and cover
flame e.g with a lid or a fire blanket.
CAUTION: Do not allow children in the kitchen when
cooking or after, as the parts may still be hot. Many
parts of the cooker will become hot and present a
considerable hazard to children.
CAUTION: When the cooker is hot never touch the
oven glass by hand or with tools.
CAUTION: Before starting to use your appliance,
ensure curtains, paper or flammable items are kept
away from your appliance. Do not keep flammable
materials inside of or around your cooker.
CAUTION: Take care when closing the oven door that
there is nothing obstructing it from closing as this
may break the glass door.
IMPORTANT: When using the grill the oven door must
be kept closed.

IIMPORTANT: Make sure the oven control knobs
are all in the off position when not in use.
IMPORTANT: If you do not intend to use your built-
in oven for a long period of time then turn off the
electric supply to the oven.
GENERAL SAFETY WARNINGS
IMPORTANT: This appliance has been designed for
non-professional, domestic use only. Do not use
this oven for commercial use or any other
application e.g room heating.
WARNING: Danger of fire: do not store flammable
items on or near the cooking surfaces or inside the
oven.
IMPORTANT: Do not try to lift or move this
appliance by pulling on the door handle.
WARNING: Ensure that the appliance is switched
off before replacing the lamp to avoid the
possibility of electric shock.
IMPORTANT: Your appliance is produced in
accordance with all applicable local and
international standards and regulations.
IMPORTANT: Maintenance and repair work must
only be performed by authorised service
technicians. Installation and repair work that is
carried out by unauthorised technicians is
dangerous and could invalidate your guarantee.
IIMPORTANT: When the door of the oven is open, do
not hang or lean anything on it. You may unbalance
your appliance or damage the door or door hinges.
IMPORTANT: Do not hang towels, dishcloths or
clothes from the built-in oven or its handles.
CLEANING AND MAINTENANCE
IMPORTANT: Always turn the appliance off before
operations such as cleaning or maintenance. You
can do this by switching the freestanding cooker off
using the cooker isolation switch
IMPORTANT: Do not remove the control knobs to
clean the control panel.
WARNING: Do not use harsh abrasive cleaners or
sharp metal scrapers to clean the oven door glass
since they can scratch the surface, which may result
in shattering of the glass.
TO MAINTAIN THE EFFICIENCY AND SAFETY
OF YOUR APPLIANCE, WE RECOMMEND YOU
ALWAYS USE OUR AUTHORISED SERVICE AGENTS
AND ORIGINAL SPARE PARTS.
FOR ASSISTANCE CALL NEW WORLD PRODUCT
SUPPORT 0333 305 2263.
5
Safety information
Important - Please read these instructions fully before installing
or operating.

Getting to know your Freestanding Cooker
You’ll be up and running in no time
Ready? Let’s begin...
Please read these instructions carefully. They contain
important information which will help you get the best
from your freestanding cooker and ensure safe and
correct installation and operation.
If you require any further assistance, our technical
experts are happy to help. For full details, refer to
the product support section at the end of these
instructions.
6

Getting to know your
You’ll be up and running in no time
7
1.
Hob plate
2.
Electric furnace
3. Control panel
4. Shelf positions
5. Wire shelf
6. Oven door
7. Shelf positions
8. Door seal
9. Baking tray
10. Hinge
11. Main oven door
12. Anti slip feet
13. Small hot plate
14. Big hot plate
13
13
14
14
5
12
2
1
3
4
6
9
11
10
8
7

Getting to know your
You’ll be up and running in no time
Accessories
1.
2.
3.
4.
1 x Baking tray
1 x Grill insert
1 x Grill pan handle
2 x Chrome shelves 3
1
2
4
8

Figure 1.
9
Installing your Freestanding Cooker
Bringing it all together
Installation requirements
THIS COOKER MUST BE INSTALLED BY A
QUALIFIED INSTALLER IN ACCORDANCE WITH
LOCAL REGULATIONS
IMPORTANT: CONTACT AN AUTHORISEDIM
SERVICE AGENT FOR INSTALLATION OF YOUR
OVEN!
Positioning
1. Make sure that there are no combustible or
flammable materials, such as curtains, in the
vicinity of the installation.
2.Furniture and cabinets surrounding the
cooker must be of material resistant to
temperatures greater than 100°C.
3.Surrounding furniture, cabinets and
extractor fans should be positioned in
accordance with the diagram shown in
the figure
4.There must be at least 2cm of free space
between the back wall and the rear of the
appliance to allow for ventilation and air
circulation.
5.If fitted, the extractor fan must be at least
65cm above the hotplates. If no fan is fitted
the minimum distance between the
hotplates and any cabinet or other structure
must be 75cm.
First Use
IMPORTANT: When using your oven for the first time your
cooker may give off an unusual odour from the heating
elements and insulation materials. This is normal for new
cookers. To eliminate this odour run the oven at 250
degrees for 40-60 mins with the oven empty.
Unpacking
Carefully unpack and examine the appliance for any
damage. If you think there is a defect, do not use the
appliance and contact Product Support on 0333 305 2263.

Installing your
Levellingfeet
Safety chain
5
10

11
Installing your Freestanding Cooker
Bringing it all together
Electrical connection
IMPORTANT: Electrical connections must be carried out by a suitably qualified person and in accordance with
all relevant local building and installation regulations.
Fitting on a Power Supply Cable
Connecting appropriate power supply terminal board/ connector block:
Using a screwdriver, prize open tabs of the Terminal board cover.
Remove the wire clamp screw.
Fasten the wires beneath the corresponding screw heads, using brass ‘bridge’ for single phase supply.
Fasten cable clamp and close the cover of the terminal board.
The ac power supply should be 220-240 V, 50/60 Hz. For electric cookers, the minimum 45A fuse, or at
least 45A a distribution circuit breaker.
Connecting the supply cable to the mains
Install an approved circuit breaker with a minimum contact opening of 3 mm, between the appliance and the
mains fuse box .The circuit breaker should be sized according to the load and should comply with current
regulations (the earth wire should not be interrupted by the circuit breaker).
The supply cable should be positioned so that it does not reach a temperature of more than 50℃ with respect
to the room temperature, anywhere along its length. Before switching fuse ON in meter-box check:
Earth continuity. The electrical safety of this appliance can only be guaranteed if the cooker is correctly
installed and earthed, in compliance with regulations on electrical installations.
The electrical capacity of the system and sockets will support the maximum power of the appliance, as
indicated on the data plate
Warning: Connect the power cord in accordance with the instructions listed in the table below
Wire cross-sectional area(mm2)
Connection mode
LNE
1N~ Min4 Min4 Min4

12
Using your
Getting the most from your appliance
Control panel
A Indicator lamp for top oven
•The indicator lamp will illuminate when oven is heating up until it reaches the selected temperature.
C Hotplate Control Knob - can be rotated in either direction
•Adjusts temperature of hotplate.
D Top Oven Temperature/Function Control Knob
• Sets temperature/mode for oven.
E Lower Oven Temperature/Function Control Knob
F Programmable Timer
• Sets temperature/mode for oven.
• Sets cooking duration .
B Indicator lamp for lower oven
•The indicator lamp will illuminate when oven is heating up until it reaches the selected temperature.
A B
DC E
F

Using your Freestanding Cooker
Getting the most from your appliance
Oven functions
13
Grill -The top central heating elements comes on .The extremely high and direct temperature of the grill makes it
possible to brown the surface of meats and roasts while locking the juices in to keep them tender. The grill is also
highly recommended for dishes that require a high temperature on the surface: beef steaks, veal, rib steak, fillets,
hamburgers etc.
Top & Bottom Element - Hot air comes from the upper and lower element in the oven. This is called
Conventional cooking and is ideal for joints of meat.
Bottom Element - Bottom element cooking is used for foods that typically need cooking with heat from
underneath - Cakes and Bread are examples of where this function would be useful.
Oven light -The oven light will operate on all oven functions.
Using your appliance for the first time
The first time you use your appliance, we recommend that you set the temperature setting to the
highest mark. Set the function switch control knob to a cooking mode and leave the oven on for about
40-60 minutes with nothing in it and the oven door shut. Then, open the oven door and allow the oven to cool.
Any odour that may be detected during this initial use is due to the evaporation of substances used
to protect the oven during storage.
Grill
Top & Bottom Element
Bottom Element
Oven light

Using your Freestanding Cooker
Getting the most from your appliance
14
This model has a digital display, 24hr clock with 3
control buttons. When the power is connected, the
screen displays ‘AUTO’.
Adjusting the digital clock
For first use of cooker, the time must be set by
using the digital timer. The time must be set every
time the cooker has been reset by the mains. To
set the correct time, press the button to remove
'AUTO' first, then + or - button to advance forward
or backward until the correct time is displayed.
Manual operation setting
If ‘AUTO’ is flashing, automatic or semi-automatic
program has been set. Press button, ‘AUTO’ will
clear from the display and the oven can be
operated manually.
Automatic setting
Automatic setting of the oven allows you to select
the end time, cooking time, temperature and
cooking mode. The oven will switch on, cook
according to the selected cooking mode and
temperature and then switch off automatically;
1.Press the function button repeatedly until
As an example: If cooking time takes 45 minutes and you
want it to finish at 14:00
1. Press the function button repeatedly until
the bar above flashes and set the cooking time
45 minutes.
2. Press the function button repeatedly until
the bar above flashes and set the finish time to
14:00.
After the above setting , the current time is
displayed and the bars above and will flash,
indicating that automatic cooking feature of the
oven is set. When the clock displays 13:15, the oven
will start cooking automatically.
While cooking the bar will flash.
the bar above flashes , then press + or – button
to set the time frame for baking.
2.Press the function button repeatedly until
the bar above flashes , then press + or – button
to set the time to switch off.
3.Set cooking temperature and cooking mode by
turning the thermostat and function knob.
After these have been set, the bars above and
will flash, indicating that automatic cooking feature
of the oven is set.
Programmable Timer
The oven starts immediately, and ‘AUTO’ will
flash. When the finish time is reached, the oven
automatically stops cooking. The alarm will ring
button and theand ‘AUTO’ will flash, press the
ringing will stop.
When the button is pressed during semi-
automatic cooking, the set cooking time is
displayed. If the button is pressed and the time
is set back to ‘O’, the semi-automatic setting will
be cancelled. When button is pressed again,
the oven will revert to the manual mode.

Using your Freestanding Cooker
Getting the most from your appliance
15
Timer
The digital countdown timer can be set up to
23 hours and 59 minutes maximum.
To set the timer, press the button and then + or
- button until the desired time is displayed. Once
the button is released, the current time and U
is displayed. When the button is pressed the
remaining time is displayed. When the set time is
reached, disappears and the alarm will ring. To
stop the alarm, press the button.
Note: After pressing the button, timer settings
should be done within 5 seconds.
In case of a power failure, all settings including
the time display will be lost. When the power is
returned, three ‘O’ and ‘AUTO’ will be displayed.
The oven light
Set cooking mode selection knob to symbol
to switch on the oven light/s. The oven light/s stay
on when the oven is operating.

16
General oven and cooking tips
General Oven Tips
The wire shelves should always be pushed firmly to the back of the oven.
Baking trays with food cooking on them should be placed level with the front edge of the
oven’s wire shelves. Other containers should be placed centrally. Keep all trays and
containers away from the back of the oven, as over-browning of the food may occur.
For even browning, the maximum recommended size of a baking tray is 340 mm (13½”) by
340 mm (13½”).
When the oven is on, do not leave the door open for longer than necessary, otherwise the
knobs may get very hot.
• Always leave 1cm gap between dishes on the same shelf. This allows the heat to
circulate freely around them.
• To reduce fat splashing when you add vegetables to hot fat around a roast, dry them
thoroughly or brush lightly with cooking oil.
• Where dishes may boil and spill over during cooking, place them on a baking tray.
Using your Freestanding Cooker
Getting the most from your appliance

17
Using your Freestanding Cooker
Getting the most from your appliance
Practical Cooking Advice
The oven offers a wide range of alternatives which allow you to cook any type of food in the best possible way. With
time you will learn to make the best use of this versatile cooking appliance and the following directions are only a
guideline which may be varied according to your own personal experience.
Preheating
You should always preheat your oven before placing food in it to cook.
Once the food has been placed in the oven, the most appropriate cooking mode can then be selected.
Using the Grill
Use the grill mode , placing the food under the center of the grill (situated on the 3rd or 4th rack from the
bottom) due to the central part of the top heating element being active.
Please use the grill pan set provided ensuring that there is no unwanted spillages formed inside your oven. When
using this mode, we recommend you set the thermostat to the highest setting. However, this does not mean you
cannot use lower temperatures, simply by adjusting the thermostat knob to the desired temperature.
When using this mode ,we advise you to set the thermostat to 200℃, as it is the most efficient way to use the
grill.
Baking Cakes
When baking cakes, always place them in a preheated oven .Make sure you wait until the oven has been preheated
thoroughly. To prevent cake from dropping/sinking – do not open the oven door during baking.
Pastry is too dry
Increase the temperature by 10℃and reduce the cooking time .
Pastry dropped
Use less liquid or lower the temperature by 10℃.
Pastry is too dark on top
Place it on a lower rack, lower the temperature, and increase the cooking time.
Cooked well on the inside but sticky on the outside
Use less liquid, lower the temperature, and increase the cooking time.
The Pastry sticks to the pan
Grease the pan well and sprinkle it with a dusting of flour or use greaseproof paper.
Use a lower temperature setting. It is not necessary to remove the food from all the racks at the same time.
Cooking Fish and Meat
When cooking white meat ,fowl and fish, use temperature setting from 180℃to 200℃.
For red meat that should be well done on the outside while tender and juicy in the inside, it is a good idea to start
with a high temperature setting (200℃-220℃) for a short time, then turn the oven down afterwards.
In general, the larger the roast, the lower the temperature setting. Place the meat on the center of the grid and place
the dripping pan beneath it to catch the fat.
Make sure that the grid is inserted so that it is in the center of the oven. If you would like to increase the amount of
heat from below, use the low rack heights. For savory roasts (especially duck and wild game), dress the meat with lard
or bacon on the top.
www.newworldassist.co.uk If you still require further assistance, call one of our experts on 0333 305 2263

18
Using your Freestanding Cooker
Getting the most from your appliance
Using the hotplates of your cooker
Do not use pots and pans which are unsteady, as these could become un-sturdy.
Do not use mats, heat diffusers or wok stands. These will cause a temperature build-up which can damage the
hob.
Do not let cooking pots over spill, this could leave a mark and residue hob.
Choosing Cooking Pots
Look at this diagram below which shows you which pans to use on the hotplates and which pans should not be
used
Always use pots and pans with flat bottoms. Uneven or thin bottoms will waste energy and cook slowly.
Always use pots and pans which are slightly larger than the hotplate. Small pans waste energy.
Always put dry pots and pans on the hotplates.
Solid Hotplates
The strong solid-cast hotplates give wide contact for cooking.
The hotplates are sealed all around which means that spilt liquids do not go under the hotplates.
Before first use
The top surface of the hotplates are sealed with a heat resistant
coating. Before using for the first time the hotplates should be heated
for a short period without a pan to harden the protective coating.
Turn the heat setting to high for approx 3 minutes to fully harden the
coating. When the hotplates have cooled apply a thin coating of cooking
oil to the hotplate to seal and protect the surface.
11
2
2

Care and maintenance
Looking after your appliance
Cleaning
WARNING! Isolate the power supply to the appliance and make sure that the cooker is cool.
Before cleaning your cooker or performing maintenance, make sure that the cooking mode selection knob and the
cooking temperature selection knob is set to ‘OFF’. To extend the life of your cooker, it must be cleaned frequently.
The inside of the cooker should preferable be cleaned immediately after use, when it is still warm (but not hot, with
warm water and soap. The soap should be rinsed away and the interior dried thoroughly. Avoid using abrasive
detergents, scourers, acidic cleaners such as lime scale remover, etc, as these could damage the enamel, and can
result in development of rust and corrosion. If stains are particularly tough to remove, use cleaners specifically
recommended to clean cookers and follow the instructions provided with the cleaner.
Never use steam cleaner for cleaning inside the cooker.
Do not clean using caustic creams, abrasive cleaning powders, thick wire wool or hard tools. Enameled parts of the
cooker can be damaged if excess cleaning liquids are not immediately removed.
After cleaning the interior parts of the cooker with a soapy cloth, rinse it and then dry thoroughly with a soft cloth.
Clean the glass surfaces with special glass cleaning agents.
Never use flammable agents like acid, thinner or petrol when cleaning your appliance.
Do not clean your cooker with a steam cleaner.
Do not wash any part of your cooker in a dishwasher.
Enameled Parts:
In order to keep enameled parts as new, it is necessary to clean them frequently with mild warm soapy water and
then dry with a cloth. Do not wash them while hot and never use abrasive powders or abrasive cleaning materials.
Do not leave anything spilled onto enameled parts for long periods of time.
Stainless Steel:
Stainless steel parts must be cleaned frequently with mildly warm soapy water and a soft sponge and then dried
with a soft cloth. Do not use abrasive powders or abrasive cleaning materials. Do not leave anything spilled onto
stainless steel parts for long periods of time.
19

Looking after your appliance
Disconnect the oven from the power supply at the fuse-box by means of the switch used to connect the
appliance to the electrical mains, or unplug the appliance.
Remove the glass cover of the lamp-holder by rotating anti-clockwise.
Remove the lamp and replace with a lamp resistant to high temperatures
(300℃) with the following characteristics:
temperatures (300℃)with the following characteristics:
Voltage: 220-240V
Wattage: 25W
Type: E 14
Replace the glass cover. Reconnect the appliance to the mains power supply.
Cleaning the oven door / How to remove the oven doors
For a more thorough clean, you can remove and disassemble the oven door. Proceed as follows:
Oven door removal and assemble procedure:
-Open the lever A completely on the left and right hinges (fig.2).
- Open the door to the full extent (fig.1)
Fig.1 Fig.2 Fig.3 Fig.4
20
-Hold the door as shown in (fig.3).
- Gently close the door (fig.3) until left and right hinge levers A are hooked to part B of the door (fig.4).
- Withdraw the hinge hooks from their location following arrow C ( fig.4).
- Rest the door on a soft surface.
- To replace the door, repeat the above steps in reverse.
